15" STRING TRIMMER 2/14/2007
MODEL NO. MCT2303A N/A
SERVICE SPARE PARTS LIST

SPECIFY MODEL NO. WHEN ORDERING PARTS DATE
REVISED DATE
15" STRING TRIMMER 2/14/2007
MODEL NO. MCT2303A N/A
No. STK CODE Parts No. Description QNo. STK CODE Parts No. Description Q
1 6003-230301 READ HOUSING 1 17-7 6008-230301 SPOOL CARRIER 1
2 6038-230301 HOUSING (R) 1 17-8 6194-202001 CUTTING LINE 1
3 6169-230301 FAN 1 18 6228-230310 BAG BEHIND ASS'Y 1
4 6099-230301 MOTOR 1 18-1 9081-332101 CONNECTOR 1
5 6022-230301 SWITCH 1 18-2 6SDAB-05-08 SCREW 1
6 6228-230304 CONNECTING HEAD ASS'Y 1 18-3 9056-332101 KNOB 1
7 6038-230302 HOUSING (L) 1 18-4 6228-230312 BAG BEHIND 1
8 6SDABB4.5-18 SCREW 9 18-5 6SXDB-06-16 SCREW 1
9 6010-230301 WIRE 1 18-6 9111-332102 BACK SHAFT FLEX 1
10 6010-230302 WIRE 1 18-7 9042-332101 CONNECTOR 1
11 9228-330336 HANDLE ASS'Y 1 18-8 6SDAB-05-12 SCREW 1
11-1 9068-330305 HANDLE 1 18-9 9189-332101 GEAR SPRING 1
11-2 9SKKBY10/24-1 SCREW 2 19 6228-230311 BAG FRONT ASS'Y 1
11-3 9068-330306 HANDLE 1 19-1 6035-230301 LOCK NUT 1
11-4 9NAC-10/24 NUT 2 19-2 6SXDB-06-30 SCREW 1
12 6028-230302 TRIGGER 1 19-3 6RZ04-08S RIVET 1
13 6NAB-06 NUT 1 19-4 6RZ04-06 RIVET 1
14 6056-230302 KNOB 1 19-5 6005-230301 KEEPER 1
15 6SXDB-06-60 SCREW 1 19-6 9228-A10102 BAG FRONT 1
16 6262-230303 GUARD 1 19-7 9111-A10101 SHAFT FLEX ASS'Y 1
17 6228-230303 CUTTING LINE ASS'Y 1 19-8 6131-230302 STEEL RING 1
17-1 6064-230301 CUP 1 19-9 9148-230301 BEARING 1
17-2 6079-230302 SPRING 1 19-10 6157-230301 FELT 1
17-3 6079-230301 SPRING 1 19-11 9087-A10101 SOCKET 1
17-4 6056-230301 PUSH BUTTON 1 19-12 6014-633501 WASHER 1
17-5 6158-230301 REX HEAD COVER 1 19-13 6124-230303 CONNECTING HEAD 1
17-6 6SDABB04-16 SCREW 4
