REVISED DATE PAGE
N/A 1/2
DATE
10/29/2004
SPECIFY MODEL NO. WHEN ORDERING PARTS
30cc Gas String Trimmer
MODEL NO. MT3025 / 41AD302G977
SERVICE SPARE PARTS LIST

No. STK CODE JFT Parts No. Description QNo. STK CODE JFT Parts No. Description QNo. STK CODE JFT Parts No. Description Q
1 MC-9295-310501 SPARK PLUG 1 34 MC-9228-334507 FILTER ASS'Y 1 63 MC-9228-332626 BAG BEHIND 1
2 MC-9SGEB-05-10 SCREW 2 35 MC-9287-334501 CARBURETOR 1 64 MC-9228-330336 HANDLE ASS'Y 1
3 MC-9211-334502 PLATE (SPARK SIDE) 1 36 MC-9014-334505 CARBURETOR GASKET 1 64-1 MC-9068-330306 HOUSING, HANDLE-UPPER 1
4 MC-9012-330301 GROMMET 1 37 MC-9SKKB-05-19 SCREW 4 64-2 MC-9SKKBY10/24-1 SCREW 2
5 MC-9SRCB-05-22 SCREW 4 38 MC-9211-334503 PLATE 1 64-3 MC-9068-330305 HOUSING, HANDLE-UNDER 1
6 MC-9SXMBJ05-50 SCREW 2 39 MC-9012-334501 GROMMET 1 64-4 MC-9NAC-10/24 NUT 2
7 MC-9228-334503 MUFFLE ASS'Y 1 40 MC-9072-334501 INSULATOR 1 65 MC-9027-332101 REDUTION 1
8 MC-9014-GP0102 MUFFLE GASKET 2 41 MC-9014-334506 INSULATOR GASKET 1 66 MC-9228-A10105 SRTINGHEAD ASS'Y 1
9 MC-9211-334501 MUFFLE PLATE 1 42 MC-9157-332101 SEAL 1 67 MC-9228-331011 KNOB ASS'Y 1
10 MC-9017-334501 COVER (FLYWHEEL SIDE) 1 43 MC-9228-334501 CRANKCASE ASS'Y 1 68 MC-9228-A10110 COVER ASS'Y 1
11 MC-9SGEB-04-10 SCREW 4 43-1 MC-9151-334502F CRANKCASE (STARTER SIDE) 1 68-1 MC-9125-331001 PARTS BAG 1
12 MC-9017-334502 GASKET 1 43-2 MC-9PA-03-08 PIN 3 68-2 MC-9017-A10101 COVER 1
13 MC-9014-334507 GASKET 2 43-3 MC-9151-334501F CRANKCASE (FLYWHEEL SIDE) 1 68-3 MC-9SKKBY10/24-0.62 SCREW 2
14 MC-9292-334501F CYLINDER 1 43-4 MC-9SGEB-05-20 SCREW 3 68-4 MC-9250-330301 KIT, KNIFE 1
15 MC-9014-334501 GASKET 1 44 MC-9DB-620101 BEARING 2 68-5 MC-6NGB-10/24 NUT 2
16 MC-9189-334501 PISTON RING 2 45 MC-9014-334502 GASKET 1 69 MC-9228-334510 HANDLE ASS'Y 1
17 MC-9131-334501 CIRCLLP 2 46 MC-9157-334501 SEAL 1 69-1 MC-6SDABB04-12 SCREW 4
18 MC-9115-334501 PISTON PIN 1 47 MC-9CB-32 C RING 1 69-2 MC-9068-332103 HOUSING, HANDLE 1
19 MC-9290-334501 PISTON 1 48 MC-9169-334501 FLYWHEEL 1 69-3 MC-9010-332103 WIRE ASS'Y, SWITCH 1
20 MC-9067-334501 AXLS COVER 2 49 MC-9228-334506 FUEL TANK ASS'Y 1 69-4 MC-9010-334501 THROTTLE CABLE 1
21 MC-9NR-KV9129.8 NEEDLE BEARING 1 50 MC-9SKKBY05-18 SCREW 3 69-5 MC-9059-332101 HOSE 1
22 MC-6221-830301 KEY 1 51 MC-9NHC-08 NUT 1 69-6 MC-9028-332101 TRIGGER 1
23 MC-9228-334502 CRANK/ROD ASS'Y 1 52 MC-9WFB-06-15 WASHER 2 69-7 MC-9024-332102 SPRING 1
24 MC-9288-334501-CH IGNITION COIL 1 53 MC-9176-GP0101 CLUTCH (WITH SPRING) 1 69-8 MC-9176-332101 LIBERATE SHAFT 1
25 MC-9SRCB-05-20 SCREW 2 54 MC-9WWB-08 WAVE PLATE 2 69-9 MC-9024-332103 SPRING 1
26 MC-9010-332102 COIL WIRE 1 55 MC-9214-GP0101 SCREW 2 69-10 MC-9176-332102 LIBERATE CHUNK 1
27 MC-9SGKB-05-12.5 SCREW 4 56 MC-9228-334508 TRANSMISSION SUPPORT ASS'Y 1 69-11 MC-6SLABB3.5-10 SCREW 2
28 MC-9228-334504 STARTER HOUSING ASS'Y 1 57 MC-9NDB-05 NUT 2 69-12 MC-9022-330502 SWITCH 1
29 MC-9228-MD0107 PAWLS ASS'Y 1 58 MC-9SDABM05-25 SCREW 2 69-13 MC-9068-332104 HOUSING, HANDLE 1
30 MC-9134-334501 KNOB 1 59 MC-9012-334502 GROMMET 1 70 MC-9228-332619 TRIMMER WHEEL 1
31 MC-9017-334505 FILTER COVER 1 60 MC-9SKKB-05-16 SCREW 4 71 MC-9SGKBY10/24-0.625SCREW 1
32 MC-9183-334501 FILTER 1 61 MC-6SDAB-05-08 SCREW 2
33 MC-9SGEB-05-52 SCREW 2 62 MC-9WFB-5.64-12 WASHER 2
圖面上無此料件但BOM內有 6WFB-06 黑平華司
9263-334502 阻風板
Stocking Codes are: 9NR-KT12179.8 滾針培林
A - Dealer stocked B - Distributor stocked C - Factory stocked
DATE REVISED DATE PAGE
SPECIFY MODEL NO. WHEN ORDERING PARTS
10/29/2004 N/A 2/2
MODEL NO.
30cc Gas String Trimmer
MT3025 / 41AD302G977
SERVICE SPARE PARTS LIST
