McCulloch 6238-989801 Guide

N/A
No. TK COD
E
Parts No. Description QNo. STK CODE Parts No. Description Q
1 A MC-6SDANB02-05 SCREW 2 18 A MC-6228-989901 SHAFT ASS'Y 1
2 B MC-6158-989901 PRESSURE PLATE 1 19 A MC-6022-989903 SWITCH 4
3 B MC-6141-989901 SOCKET, MAIN BODY 1 20 A MC-6056-989901 BUTTON, FRONT 1
4 A MC-6024-989902 SPRING 1 21 A MC-6024-989904 SPRING 1
5 A MC-6056-989902 BUTTON, AFTER 1 22 B MC-6035-JR0102 SPRING CAP 1
6 A MC-6115-989901 PIN 2 23 A MC-6188-989901 BUTTON 1
7 B MC-6114-989901 LEVER 1 24 A MC-6024-989903 SPRING 1
8 B MC-6038-989902 HOUSING (L) 1 25 B MC-6010-989901 WIRE 1
9 A MC-6SDABB04-16 SCREW 11 26 B MC-6010-989802 WIRE 1
10 A MC-6228-989801 MOTOR ASS'Y 1 27 B MC-6010-989803 WIRE 1
11 B MC-6043-989901 MOTOR PLATE 1 28 B MC-6010-989804 WIRE 1
12 A MC-6SQAC-04-10 SCREW 2 29 B MC-6010-989805 WIRE 1
13 A MC-6022-989904 SWITCH 1 30 B MC-6010-989806 WIRE 1
14 B MC-6023-989901 HANGER 1 31 B MC-6010-989807 WIRE 1
15 B MC-6041-989901 TERMINAL HOLDER 132 B MC-6010-989908 WIRE 1
16 B MC-6038-989901 HOUSING (R) 1 33 MC-6228-18BE01 1.7Ah BATTERY ASS'Y 2
17 A MC-9SLABB03-12 SCREW 1
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
DATE REVISED
DATE
4/7/2003
MODEL NO.
SPECIFY MODEL NO. WHEN ORDERING PARTS
Motor Ass'y
6238-989801
SERVICE SPARE PARTS LIST
25
A
钡??
D
28

BC
26 27
EF
29 30

GH
32
31
1
2
3
4
5
6
8
9
11
12
14
15
16
17
18
19
20
21
M
M
(6099-9699A1)
钡?瞶?
上開關
割草機馬達
下開關 中開關
前把手開關
後把手開關
主機馬達
13
22
23
24
10
7
中
後把手開關
前把手開關
33
18-5
18-4
18-3
18-1
18-2
10-1 10-2

N/A
No. Parts No. STK
CODE Description NO. REQ % No. Parts No. STK CODE Description NO. REQ %
1 MC-6SDABB04-14 A SCREW 14 MC-9012-330501 A RUBBER
2 MC-6250-202501 A KNIFE 15 MC-6154-980101 B CONNECT (L)
3 MC-6262-980101 A GUARD 16 MC-6041-980101 B TERMINAL ASS'Y
4 MC-6228-202004A A SPOOL ASS'Y 17 MC-6079-981001 A SPRING LAMINATION
5 MC-6024-202604 A SPRING 18 MC-6197-981001 A PIN
6 MC-6228-980201 A MOTOR ASS'Y 19 MC-6SVAB-05-10 A SCREW
7 MC-6063-980101 A GUIDE 20 MC-6056-981001 A BUTTON
8 MC-6038-980101 B HOUSING (L) 21 MC-6154-980102 B CONNECT (R)
9 MC-6010-980101 B WIRE 22 MC-6SDABB04-18 A SCREW
10 MC-6087-980101 B TUBE 23 MC-6SHDB-06-52 A SCREW
11 MC-9196-202601 B HANDLE 24 MC-6161-980101 A BRACKET
12 MC-6056-230302 A KNOB 25 MC-6038-980102 B HOUSING (R)
13 MC-6NAB-06 A NUT
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
SPECIFY MODEL NO. WHEN ORDERING PARTS DATE REVISED
DATE
Trimmer Ass'y 4/7/2003
MODEL NO. 6238-980201
SERVICE SPARE PARTS LIST
8
6321
754
9

N/A
No. Parts No. STK
CODE Description NO. REQ % No. Parts No. STK CODE Description NO. REQ %
1 MC-6129-980501 B TUBE 9 MC-6154-980501 B CONNECT (L)
2 MC-6097-980501 - LABEL 10 MC-6097-980502 - LABEL
3 MC-6MB-626-01 B BEARING 11 MC-6056-981001 A BUTTON
4 MC-6236-980501 A NUT 12 MC-6079-981001 A SPRING LAMINATION
5 MC-6014-220002 A WASHER 13 MC-6197-981001 A PIN
6 MC-6169-980501 B FAN 14 MC-6SVAB-05-10 A SCREW
7 MC-6014-220001 A WASHER 15 MC-6154-980502 B CONNECT (R)
8 MC-6228-980501 A PIVOT ASS'Y 16 MC-6SDABB03-18 A SCREW
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
SPECIFY MODEL NO. WHEN ORDERING PARTS DATE REVISED
DATE
Blower Ass'y 4/7/2003
MODEL NO. 6238-980501
SERVICE SPARE PARTS LIST
1
2
3
4
6
7
5
9
8
15
16
10
11
12
13
14

N/A
No. STK
CODE Parts No. Description QNo. STK CODE Parts No. Description Q
1 - MC-6228-18CP01 CHARGER ASS'Y 1 1-10 B MC-6256-CP1201 LIGHT-PIPE 1
1-1 - MC-6187-CP1202 GUIDE PAPER 1 1-11 A MC-6158-CP1201 PRESSURE PLATE 1
1-2 A MC-6023-CP1201 HANGER 2 1-12 A MC-6141-CP1201 PLUG 1
1-3 A MC-6SVAZA05-50 SCREW 6 1-13 A MC-6SDANB02-05 SCREW 2
1-4 A MC-6SDABB04-16 SCREW 12 1-14 A MC-6205-CP1201 CHARGER 1
1-5 A MC-6156-822001 ROLL PIN 6 1-15 A MC-6SDABB04-10 SCREW 2
1-6 B MC-6085-CP1201 BASE 1 1-16 - MC-6097-18CPXX LABEL 1
1-7 B MC-6164-18CP01 P.C.BOARD 1 1-17 B MC-6123-CP1201 HOUSING 1
1-8 A MC-6SDABB03-10 SCREW 1 2 MC-6205-SA1806 ADAPTOR 1
1-9 A MC-6SDABB03-10 SCREW 4
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
SPECIFY MODEL NO. WHEN ORDERING PARTS DATE REVISED
DATE
Charger Ass'y 4/26/2004
MODEL NO.
SERVICE SPARE PARTS LIST
1-21-31-41-7
1-8
1-9
1-10
1-11
1-12
1-13
1-14
1-15
1-16
1-17
1-6
1-1
1-5
2

N/A
No. Parts No. STK
CODE Description NO. REQ % No. Parts No. STK CODE Description NO. REQ %
1 MC-6SDAB-03-10 A SCREW 11 MC-6WFB-05 A WASHER
2 MC-6014-981003 A WASHER 12 MC-6077-981001 B COVER
3 MC-6MB-607-01 B BEARING 13 MC-6NAB-05 A NUT
4 MC-6228-981003 A TRANSMISSION ASS'Y 14 MC-6217-981001 B HOUSING (L)
5 MC-6017-981001 A BLADE COVER 15 MC-6056-981001 A BUTTON
6 MC-6250-981001 A BLADE 16 MC-6079-981001 A SPRING
7 MC-6PC04-20 B PIN 17 MC-6197-981001 A PIN
8 MC-6228-981002 A RECIPROCAL ASS'Y 18 MC-6SVAB-05-10 A SCREW
9 MC-6228-981001 A GEAR SHAFT ASS'Y 19 MC-6217-981002 B HOUSING (R)
10 MC-6SDAB-05-12 A SCREW 20 MC-6SDABB03-15 A SCREW
Stocking Codes are:
A - Dealer stocked B - Distributor stocked C - Factory stocked
SPECIFY MODEL NO. WHEN ORDERING PARTS DATE REVISED
DATE
Hedge Trimmer Ass'y 4/7/2003
MODEL NO. 6238-981001
SERVICE SPARE PARTS LIST
1
2
4
3
6
5
7
8
9
10
12
13
14
15
16
17 18
19
20
11
