McDantim Trumix Triple User manual
WARNING:
This product can expose you to chemicals including lead and lead compounds, which are known
to the State of California to cause cancer and birth defects or reproduc ve harm. For more
informa on, go to www.P65Warnings.ca.gov
McDantim, Inc. Limited Five Year Warranty
Warranty not valid outside the Con nental USA
If the mechanics of this product are found to be defec ve in materials or workmanship within
fi ve years from the date of purchase, McDantim, Inc. will repair or replace, at its op on, the
defec ve product or component part. If for any reason the original purchaser is unsa sfi ed with the
performance of this product, McDantim, Inc. will, at the purchaser’s op on, replace the product or
refund the original sale price upon return of this product to McDantim, Inc. Please retain receipt
for proof of purchase. Proof of purchase is required for any warranty service or claim. Your receipt is
your warranty card.
LIMITED WARRANTY
McDantim, Inc. warrants each product to be free from defects in material and workmanship under
normal use and service for fi ve years from date of sale. The obliga on of McDantim, Inc. under this
warranty is limited to the replacement of defec ve parts. No ce of defec ve parts must be submi ed
to McDantim, Inc. within fi ve year and 15 days of date of sale. This warranty does not cover
shipping, handling, or freight charges.
DISCLAIMER OF WARRANTY
WARRANTY IS INVALID IF PURCHASER FAILS TO PROPERLY OPERATE AND/OR MAINTAIN THE
PRODUCT. THIS WARRANTY IS NOT TRANSFERABLE TO THIRD PARTIES. THIS WARRANTY IS EXPRESSLY
IN LIEU OF ALL OTHER WARRANTIES AND REPRESENTATIONS, EXPRESSED OR IMPLIED EXCEPT AS
STATED ABOVE. THERE IS NO WARRANTY FOR FITNESS FOR A PARTICULAR PURPOSE OR WARRANTY
OF MERCHANTABILITY.
EXCEPT AS OTHERWISE AGREED HEREIN McDantim, Inc. SHALL NOT BE LIABLE FOR SPECIAL OR
CONSEQUENTIAL DAMAGES, SUCH AS, BUT NOT LIMITED TO DAMAGE TO OR LOSS OF OTHER
PROPERTY OR EQUIPMENT, LOSS OF PROFIT OR REVENUE, LOSS OF USE OF THE PRODUCT , COST
OR REPLACEMENT OF THE PRODUCT, OR CLAIMS BY CUSTOMERS FOR LOSS DUE TO SERVICE
INTERRUPTIONS. THE REMEDIES OF THE PURCHASER SET FORTH HEREIN ARE EXCLUSIVE, AND THE
LIABILITY OF McDantim, Inc. WITH RESPECT TO ANY CONTRACT SHALL NOT, EXCEPT AS EXPRESSLY
PROVIDED HEREIN, EXCEED THE PRICE OF THE EQUIPMENT OR PART ON WHICH SUCH LIABILITY IS
BASED.
This warranty applies only to the original registered purchaser. TAMPERING, ACCIDENT, ABUSE,
NEGLECT, UNAUTHORIZED REPAIRS OR OTHER CAUSES UNRELATED TO DEFECTIVE MATERIALS OR
WORKMANSHIP WILL VOID THIS WARRANTY. McDantim, Inc. neither assumes nor authorizes
any representa ve or other person to assume for us any liability in connec on with the sales or any
shipment of our products.
PLEASE KEEP INSTRUCTIONS WITH YOUR PURCHASE RECEIPT FOR YOUR RECORDS!
Thank You for purchasing the McDantim, Inc. Trumix®Gas Blender Panel. Our goal is to give
you the most dependable, accurate and straight forward blender possible for food packaging,
welding or other related uses and products. We want you to be thoroughly happy with your new
system and would like to hear from you if for any reason you are, in any way, displeased.
The McDantim, Inc. Trumix®Gas Blender Panel is simple to install and use. It is extremely
accurate, reliable and requires li le maintenance. Properly installed, and supplied with clean, dry
gas, your Trumix®Gas Blender Panel will provide a perfect supply of mixed gas for many years.
Please take the me to read and understand the instruc ons, the system and the cau ons.
While the system is simple there are inherent dangers in working with pressurized gases. Pressure
vessels and storage tanks, which contain both liquids and pressurized gases, can explode or
rupture and cause serious injury or death if over-pressurized or used incorrectly. Be 100% sure
you understand the implica ons of what you are doing whenever you set up, turn on or modify
this or any system. Check with your equipment supplier (in the case of storage tanks especially)
to be sure you are not exceeding any safety limits. If you have any doubt concerning the safety
of your system, get advice from or have the work done by a qualifi ed specialist.
Cau on
With the Trumix®Gas Blender Panel you are dealing with pressurized gases. Serious
injury or death can result from improper installa on, use or service. All work on these
systems should be carried out by qualifi ed personnel only! Before a emp ng any work
on this system be sure to read and understand these and any other instruc ons that relate
to the equipment involved in these systems! The dangers include, but are not limited to,
EXPLOSION if the maximum safe pressures for any of the individual components of the
system are exceeded or ASPHYXIATION if gases are released or leaked into a confi ned
area. If you have any ques ons regarding the safety of these systems do not proceed
with the installa on or opera on un l you are 100% certain as to their safety!
Installa on Instruc ons for the
Trumix®Gas Blender Panel
Triple
Installa on Instruc ons
Step 1: Determine the best loca on for the blender! Please consider the following:
A) Select a loca on that minimizes the chance of accidental damage to the blender.
B) Select a loca on as near as is prac cal to both the supply sources and the supplied equipment.
C) Select a loca on allowing convenient access to the shut off valve for servicing.
D) Mount panel in a weather-proof area only.
Step 2: Mount panel to wall!
Step 3: Hook up gas supply and outlet!
A) Use only the gases shown on the panel label(s).
B) Make sure you are supplying the panel with clean, dry gases that are between the minimum and
maximum pressures as indicated on the panel label.
C) Turn shut-off valve(s) on panel to the off posi on.
D) Make sure the tubing from the gas sources is compa ble with the fi ngs on the panel.
DO NOT ATTEMPT TO REMOVE INLET OR OUTLET FITTINGS.
E) Install appropriate tubing adaptors in the inlet fi ngs. Be sure to use thread sealant and back-up
wrenches. Connect gases supply lines to inlet fi ngs.
F) Confi rm that your system and related equipment is safe and ready for pressurized mixed gas.
G) Connect mixed gas supply tube to mixed gas outlet fi ng.
H) Turn on the supply gases and check supply system and fi ngs for leaks.
I) Open mixed gas supply shut off valve and check system for leaks.
Opera on Guidelines and Helpful Hints
NOTES:
1) Supply the panel with clean gases.
2) Be sure no liquid can get into the blender as this will render it useless and void the warranty.
3) Some fi ngs on the panel do not have standard US threads, and should not be removed with out
checking with McDantim, Inc.!
4) NEVER EXCEED THE RECOMMENDED PRESSURES FOR ANY PART OF YOUR SYSTEM!
Trouble-shoo ng: No Outlet Gas
1) Close shut-off valve. Check pressure on pressure gauge. If pressure is low or zero, check:
a) Both supply gases. (One or both could be empty, turned off or out of adjustment.)
b) For blockage of either supply line or for a closed valve within the supply system. (The blender shuts
off if either supply gas is unavailable.)
If pressure is good:
d) Open shut-off valve completely.
2) If you con nue to have no gas, close shut-off valve, remove tubing from outlet, open shut-off valve and
check for gas fl ow.
3) If you s ll have no supply gas, call McDantim, Inc. or your gas supplier or service person. There are
no user-serviceable parts within the panel. Anything done to the internal parts will aff ect the blend
and void the warranty.
If you encounter other ques ons or problems call:
McDantim, Inc. (888) 735-5607 or (406) 442-5153
Warning
With this or any compressed gas system
there are certain dangers. If you do not
have the experience to understand these
dangers use a professional installer.
Trumix®Gas Blender Panel
Installaon Instrucons
Use primary regulators on your
gas source suitable for your
panel specicaons.
Example: If your inlet pressure
label states “Min. inlet pressure
55 psi” then you must provide at
least 55 psi to the Blender Panel.
1. Use thread sealant.
2. Do not remove ngs.
3. Use back-up wrenches.
N2CO2
Mixed Gas Out
Use reinforced tubing suitable for 150 psi.
Installa on Instruc ons
Step 1: Determine the best loca on for the blender! Please consider the following:
A) Select a loca on that minimizes the chance of accidental damage to the blender.
B) Select a loca on as near as is prac cal to both the supply sources and the supplied equipment.
C) Select a loca on allowing convenient access to the shut off valve for servicing.
D) Mount panel in a weather-proof area only.
Step 2: Mount panel to wall!
Step 3: Hook up gas supply and outlet!
A) Use only the gases shown on the panel label(s).
B) Make sure you are supplying the panel with clean, dry gases that are between the minimum and
maximum pressures as indicated on the panel label.
C) Turn shut-off valve(s) on panel to the off posi on.
D) Make sure the tubing from the gas sources is compa ble with the fi ngs on the panel.
DO NOT ATTEMPT TO REMOVE INLET OR OUTLET FITTINGS.
E) Install appropriate tubing adaptors in the inlet fi ngs. Be sure to use thread sealant and back-up
wrenches. Connect gases supply lines to inlet fi ngs.
F) Confi rm that your system and related equipment is safe and ready for pressurized mixed gas.
G) Connect mixed gas supply tube to mixed gas outlet fi ng.
H) Turn on the supply gases and check supply system and fi ngs for leaks.
I) Open mixed gas supply shut off valve and check system for leaks.
Opera on Guidelines and Helpful Hints
NOTES:
1) Supply the panel with clean gases.
2) Be sure no liquid can get into the blender as this will render it useless and void the warranty.
3) Some fi ngs on the panel do not have standard US threads, and should not be removed with out
checking with McDantim, Inc.!
4) NEVER EXCEED THE RECOMMENDED PRESSURES FOR ANY PART OF YOUR SYSTEM!
Trouble-shoo ng: No Outlet Gas
1) Close shut-off valve. Check pressure on pressure gauge. If pressure is low or zero, check:
a) Both supply gases. (One or both could be empty, turned off or out of adjustment.)
b) For blockage of either supply line or for a closed valve within the supply system. (The blender shuts
off if either supply gas is unavailable.)
If pressure is good:
d) Open shut-off valve completely.
2) If you con nue to have no gas, close shut-off valve, remove tubing from outlet, open shut-off valve and
check for gas fl ow.
3) If you s ll have no supply gas, call McDantim, Inc. or your gas supplier or service person. There are
no user-serviceable parts within the panel. Anything done to the internal parts will aff ect the blend
and void the warranty.
If you encounter other ques ons or problems call:
McDantim, Inc. (888) 735-5607 or (406) 442-5153
Warning
With this or any compressed gas system
there are certain dangers. If you do not
have the experience to understand these
dangers use a professional installer.
Trumix®Gas Blender Panel
Installaon Instrucons
Use primary regulators on your
gas source suitable for your
panel specicaons.
Example: If your inlet pressure
label states “Min. inlet pressure
55 psi” then you must provide at
least 55 psi to the Blender Panel.
1. Use thread sealant.
2. Do not remove ngs.
3. Use back-up wrenches.
N2CO2
Mixed Gas Out
Use reinforced tubing suitable for 150 psi.
WARNING:
This product can expose you to chemicals including lead and lead compounds, which are known
to the State of California to cause cancer and birth defects or reproduc ve harm. For more
informa on, go to www.P65Warnings.ca.gov
McDantim, Inc. Limited Five Year Warranty
Warranty not valid outside the Con nental USA
If the mechanics of this product are found to be defec ve in materials or workmanship within
fi ve years from the date of purchase, McDantim, Inc. will repair or replace, at its op on, the
defec ve product or component part. If for any reason the original purchaser is unsa sfi ed with the
performance of this product, McDantim, Inc. will, at the purchaser’s op on, replace the product or
refund the original sale price upon return of this product to McDantim, Inc. Please retain receipt
for proof of purchase. Proof of purchase is required for any warranty service or claim. Your receipt is
your warranty card.
LIMITED WARRANTY
McDantim, Inc. warrants each product to be free from defects in material and workmanship under
normal use and service for fi ve years from date of sale. The obliga on of McDantim, Inc. under this
warranty is limited to the replacement of defec ve parts. No ce of defec ve parts must be submi ed
to McDantim, Inc. within fi ve year and 15 days of date of sale. This warranty does not cover
shipping, handling, or freight charges.
DISCLAIMER OF WARRANTY
WARRANTY IS INVALID IF PURCHASER FAILS TO PROPERLY OPERATE AND/OR MAINTAIN THE
PRODUCT. THIS WARRANTY IS NOT TRANSFERABLE TO THIRD PARTIES. THIS WARRANTY IS EXPRESSLY
IN LIEU OF ALL OTHER WARRANTIES AND REPRESENTATIONS, EXPRESSED OR IMPLIED EXCEPT AS
STATED ABOVE. THERE IS NO WARRANTY FOR FITNESS FOR A PARTICULAR PURPOSE OR WARRANTY
OF MERCHANTABILITY.
EXCEPT AS OTHERWISE AGREED HEREIN McDantim, Inc. SHALL NOT BE LIABLE FOR SPECIAL OR
CONSEQUENTIAL DAMAGES, SUCH AS, BUT NOT LIMITED TO DAMAGE TO OR LOSS OF OTHER
PROPERTY OR EQUIPMENT, LOSS OF PROFIT OR REVENUE, LOSS OF USE OF THE PRODUCT , COST
OR REPLACEMENT OF THE PRODUCT, OR CLAIMS BY CUSTOMERS FOR LOSS DUE TO SERVICE
INTERRUPTIONS. THE REMEDIES OF THE PURCHASER SET FORTH HEREIN ARE EXCLUSIVE, AND THE
LIABILITY OF McDantim, Inc. WITH RESPECT TO ANY CONTRACT SHALL NOT, EXCEPT AS EXPRESSLY
PROVIDED HEREIN, EXCEED THE PRICE OF THE EQUIPMENT OR PART ON WHICH SUCH LIABILITY IS
BASED.
This warranty applies only to the original registered purchaser. TAMPERING, ACCIDENT, ABUSE,
NEGLECT, UNAUTHORIZED REPAIRS OR OTHER CAUSES UNRELATED TO DEFECTIVE MATERIALS OR
WORKMANSHIP WILL VOID THIS WARRANTY. McDantim, Inc. neither assumes nor authorizes
any representa ve or other person to assume for us any liability in connec on with the sales or any
shipment of our products.
PLEASE KEEP INSTRUCTIONS WITH YOUR PURCHASE RECEIPT FOR YOUR RECORDS!
Thank You for purchasing the McDantim, Inc. Trumix®Gas Blender Panel. Our goal is to give
you the most dependable, accurate and straight forward blender possible for food packaging,
welding or other related uses and products. We want you to be thoroughly happy with your new
system and would like to hear from you if for any reason you are, in any way, displeased.
The McDantim, Inc. Trumix®Gas Blender Panel is simple to install and use. It is extremely
accurate, reliable and requires li le maintenance. Properly installed, and supplied with clean, dry
gas, your Trumix®Gas Blender Panel will provide a perfect supply of mixed gas for many years.
Please take the me to read and understand the instruc ons, the system and the cau ons.
While the system is simple there are inherent dangers in working with pressurized gases. Pressure
vessels and storage tanks, which contain both liquids and pressurized gases, can explode or
rupture and cause serious injury or death if over-pressurized or used incorrectly. Be 100% sure
you understand the implica ons of what you are doing whenever you set up, turn on or modify
this or any system. Check with your equipment supplier (in the case of storage tanks especially)
to be sure you are not exceeding any safety limits. If you have any doubt concerning the safety
of your system, get advice from or have the work done by a qualifi ed specialist.
Cau on
With the Trumix®Gas Blender Panel you are dealing with pressurized gases. Serious
injury or death can result from improper installa on, use or service. All work on these
systems should be carried out by qualifi ed personnel only! Before a emp ng any work
on this system be sure to read and understand these and any other instruc ons that relate
to the equipment involved in these systems! The dangers include, but are not limited to,
EXPLOSION if the maximum safe pressures for any of the individual components of the
system are exceeded or ASPHYXIATION if gases are released or leaked into a confi ned
area. If you have any ques ons regarding the safety of these systems do not proceed
with the installa on or opera on un l you are 100% certain as to their safety!
Installa on Instruc ons for the
Trumix®Gas Blender Panel
Triple
Other McDantim Blender manuals
