McIntosh MCD1100 User manual

MCD1100
cd player
www.mcintoshlabs.com
n More than a simple CD player, the MCD1100
will play CD/SACD/MP3/WMA disks at the
highest possible fidelity which yields
maximum musical enjoyment. Five additional
digital inputs and outputs are available
allowing the use of many consumer
and professional digital devices.
n A MAC or PC may be connected
through the dedicated USB input
for superior playback of stored
music using any of the popular music
management programs.
n High performance, variable volume,
balanced outputs will run any power
amplifier directly or may be used
with the built in headphone
amplifier for private listening.
n Die Cast aluminum transport and
drawer assembly delivers quiet
operation, precise handling of disks
and long operational life.
n Classic 3D glass faceplate design and
polished stainless steel chassis are beautiful
to see while adding long term value.
Highest possible fidelity yields
maximum musical enjoyment.

www.mcintoshlabs.com
Disc Formats
SACD, CD, MP3, WMA
Number of Channels
2
Analog Audio Outputs
20Hz to 20kHz
Total Harmonic Distortion
2VRMS (Fixed Unbalanced)
4VRMS (Fixed Balanced)
6VRMS (Variable Unbalanced)
12VRMS (Variable Balanced)
Frequency Response
SACD 4Hz-40KHz -2dB+/-0.5dB
CD 4Hz-20kHz +/-0.5dB
S/N Ratio
110dB
Dynamic Range
100dB
Total Harmonic Distortion
SACD 0.0015%
CD 0.0015%
Digital Audio Outputs (CD Audio only)
Format: SPDIF
Optical: TOS Link, -15~-21dBm
Coaxial: RCA Jack, 0.5V p-p @ 75ohms
XLR: XLR Connector, 5V p-p @ 110 ohms
BNC: BNC Connector, 0.5V p-p @ 75ohms
Sampling Frequencies: 44.1KHz (PCM)
Digital Audio Inputs (CD Audio only)
Format: SPDIF
Optical: TOS Link, -15~-21dBm
Coaxial: RCA Jack, 0.5V p-p @ 75 ohms
XLR: XLR Connector, 5V p-p @ 110 ohms
BNC: BNC Connector, 0.5V p-p @ 75 ohms
USB: USB Type B Connector
Sampling Frequencies: Up to 192KHz,
24Bit for Optical and USB inputs
Overall Dimensions
Width 17-1/2” (44.5cm)
Depth 19” (48.3cm) including handles
Height 9-7/16” (24cm) including feet
Weight
28.2 pounds (12.79kg) net, 44.6 pounds
(20.23kg) in shipping carton
R-Core Power Transformer
The special construction of the R-Core power
transformer minimizes noise and hum radiation.
Variable Balanced and
Unbalanced Audio Outputs
Balanced for long cable runs in a noisy
environment and unbalanced for short runs.
Balanced offers optimum noise rejection.
The maximum output level is 6Vrms which
allows direct drive of power amplifiers
without need for preamplifier.
Phase-Locked Loop
Internal Clock Generation
Clocks are generated by Phase-Locked
Loop generator for a stable and low
jitter operation.
For the Consumer’s Protection:
In order to ensure the highest level of
customer satisfaction, “new” McIntosh
products may only be purchased
over-the-counter or delivered and
installed by an Authorized McIntosh
Dealer. McIntosh products that are
purchased over the Internet, by phone
or mail order are presumed to be “used”
and do not qualify for any McIntosh
Warranty. McIntosh does not warrant,
in any way, products that are purchased
from anyone who is not an Authorized
Dealer or products that have had their
serial number altered or defaced.
Companion Products
The McIntosh C1000 Preamplifier, MC601 Power Amplifier and the XR200 Loudspeaker are logical
companions for the MCD1100 CD Player. Your Authorized Dealer can provide additional
information on other McIntosh product combinations.
To experience the legendary performance of McIntosh, please call on us at 1.800.538.6576.
Part # 35012700
