MCS MCS-***B Series Installation and operating instructions

Any questions regarding this release, contact: [email protected]
Micro Control Systems, Inc. 5580 Enterprise Parkway Fort Myers, Florida 33905
[phone] FAX: [phone] www.mcscontrols.com
Information contained in this document has been prepared by Micro Control Systems, Inc. and is copyright © protected 2017.
Copying or distributing this document is prohibited unless expressly approved by MCS.
APPLICATION NOTE
APP #106
Date Author Description
01-27-15 DEW Created initial version
01-28-15 DEW Revisions to copy, photo replaced p 4 Wiring Diagram updated
01-29-15 DEW Wiring Diagram updated ver 1-29-15
02-10-15 DEW Updated to 3 pages
10-26-17 DEW Add new installation diagram/wiring for new Transducers
Revision History APP #106
MCS-PRESSURE TRANSDUCER
Installation for older model
MCS-150 - MCS-200 - MCS-250
MCS-500 - MCS-667
Installation for the
following Transducers (see diagram)
MCS-150AB - MCS-200B - MCS-200BW
MCS-500B - MCS-667B

MCS-Pressure Transducer (old style with washer)
1. PACKAGING
• Transducer with Washer
2. TRANSDUCER AND PARTS
• Transducer, black protector and washer
removed from bag
3. TRANSDUCER PARTS
• Transducer parts before installation
Black Cap
Removed Copper
Washer
4. PRIOR TO INSTALLING ON FITTING
• Showing typical angle valve on Hanbell Screw
Compresser where Transducer will
be placed.
5. PLACEMENT OF WASHER
• Showing correct placement of washer,
make sure placement of washer is with
bevel out.
6. TRANSDUCER MOUNTED TO ANGLE VALVE
• Finished placement of MCS-TRANSDUCER

MCS-Pressure Transducer Version B
7. WIRING AND PARTS DIAGRAM (old style with washer)
8. WIRING AND PARTS DIAGRAM (New style - part # ending with ‘B’)
