ATMOSPHERE APSTM Series
Haze Generator
MAX APSTM Series
Fog Generator
USER GUIDE
No: 120815, Revision A/a

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 2 / 11
Intentionally left blank

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 3 / 11
INTRODUCTION
Congratulations! You are now in possession of a MDG MAX Fog Generator series and/or
a MDG ATMOSPHERE Haze Generator series.
We hope it will bring you long hours of satisfaction. This product is available in many
versions to satisfy the needs of our professional users.
Please read the following instructions carefully and completely before filling your
generator with fog fluid and turning it on.
CAUTION
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
CAUTION
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 4 / 11
BASIC DESCRIPTION
The MDG MAXTM and ATMOSPHERETM Series as well as their H.O. / TOURINGTM Versions
were designed with safety and reliability in mind. They are capable of generating pure
white fog or haze for as long as you want (100% duty cycle). Those generators are also
equipped, as a standard feature, with the Automatic Purging SystemTM (APSTM). This
system purges the heating module(s) after the first heating cycle and after every emission
of fog preventing residual build up and clogging.
The MDG MAXTM and MAXTM H.O. / TOURINGTM Series are variable output Fog Generators
capable of generating large volumes of very dense fog in a short period of time. They are
one of the quietest units on the market.
The MDG ATMOSPHERETM and ATMOSPHERETM H.O. / TOURING Series are non-stop haze
generators capable of creating the finest and almost invisible mist. They highly
emphasize laser and light beams. They also feature variable output.
At the heart of the MDG Generators is an electronic assembly that keeps the heating
module(s) at a very stable temperature which integrates three types of fail-safe systems.
Those three types of electronic fail-safe systems are designed to protect against over and
under-heating conditions and, against component failure.
The temperature is maintained within a narrow margin (the HEAT yellow LED turn on &
off from time to time to indicate the control of temperature) otherwise, an error
condition will result and the Fog Generator will shut down. When one of the safety
systems is activated, the HEAT yellow LED will start blinking indicating the fail mode.
Shut down the main power switch, wait 3 to 4 minutes and retry the generator. If the
fail mode still appears, unplug your generator and return it to an authorized service
center for verification.
The FOG ON signal (green LED) can be applied to produce fog / haze for as long as the
ready level is reached and all other control parameters are within specifications. When
the “FOG ON” signal is removed, the APSTM cycle is automatically initiated to clear the
heating module(s). Never remove the power to a generator while it is producing fog –
See the shut down procedures.
The 100% Duty cycle is continuous with specified line voltage, and will degrade with line
voltage loss. If that is the case, it can be compensated by reducing maximum operating
pressure.

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 5 / 11
SHUT DOWN PROCEDURE
A Generator must never be shut down while making Fog. To power off a Generator the
following sequence must be observed:
Always turn off the fog emission,
Wait a minimum of 1 minute for the purge cycle to complete, if possible avoid
purging at very low pressure which reduces the efficiency of the Automatic Purging
SystemTM. The recommended minimum purging pressure is 10 psi.
Power of the Fog Generator (by switching off the “MAIN POWER SWITCH” or by
removing the MAIN POWER.
The CO2or N2gases are used as a propellant when generating Fog / Haze. They are also
used for purging the heating module(s) when the APSTM cycle is initiated. Output
pressure can be adjusted by mean of the CO2or N2gas regulator. The ideal range for
MAXTM Series is 10 to 40 psi. and the H.O. / TOURINGTM Version is 10 to 60 psi., for the
ATMOSPHERETM Series it is 5 to 20 psi. and the H.O. / TOURINGTM Version is 5 to 30 psi.
FILLING OF THE FLUID RESERVOIR
WARNING
Use only MDG Neutral Fog Fluid. Not doing so, will void the warranty and
may damage the generator.
CAUTION
DISCONNECT UNIT BEFORE ADDING FOG FLUID.
To fill the fluid reservoir, unscrew the brass closure and pour the MDG Neutral Fog Fluid
until it reaches the inside bottom of the opening. Avoid overfilling, screw back the
closure and make sure it is tightened.

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 6 / 11
OPERATING INSTRUCTIONS
The MDG Fog Generators are quite easy to operate and require no preventive
maintenance. They are supplied with a removable remote control. A DMX Interface can
be bought as an option.
When the MAIN POWER (115 or 230Vac) and the MAIN POWER SWITCH is applied, the
generator is placed in stand-by mode. When in stand-by mode, most of the electronic
controls are off (except for the three types of fail-safe systems), waiting for the ON switch
on the remote control to be activated.
When the ON switch is pressed, the red LED indicating that the unit is working will light
up, as well as the yellow LED call HEAT, indicating the start of the heating cycle which will
last approximately 10 minutes. When the temperature reaches a pre-adjusted level called
the READY level (indicated by a green LED), the HEAT yellow LED will turn off. The
Automatic Purging SystemTM (APSTM) will be automatically initiated.
After the first purging cycle is completed (approx. time 30 to 60 sec.) the generator is
ready to produce fog. The amount of the fog / haze emission can be controlled by
adjusting the working pressure of the CO2gas regulator.
When an overheating condition is detected, or if the internal temperature reaches 60°C
(140°F), a safety circuit is triggered. This circuit removes the power to the heating
elements, preventing hazardous conditions.
When an under-heating condition occurs, the generator will stop producing fog until the
temperature of the heating module is back within parameters.

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 7 / 11
SETTING UP
WARNING:
When not in use ALWAYS switch off the power switch located on the back panel, or
unplug the generator.
Never install above people.
These Fog Generators must be installed in an upright position on a stable and level
surface.
Do not operate at less than 2 meters (6.5 ft.) from people.
Use in a well ventilated area.
Maximum Operating Pressure: ATMOSPHERE APS 138 kPa / 1.38 bar / 20 psi,
ATMOSPHERE APS H.O. / TOURING 207 kPa / 2.07 bar / 30 psi, MAX 3000 APS & MAX
5000 APS 276 kPa / 2.76 bar / 40 psi, and MAX 5000 APS H.O. / TOURING 414 kPa /
4.14 bar / 60 psi,
GAS REQUIREMENTS
WARNING
In the European Community the gas cylinder and regulator must be
compliant with the Pressure Vessel Directive.
In North America the gas cylinder must be manufactured, inspected and
tested in accordance with U.S. Department of Transportation (DOT) 3AL
and Transport Canada (TC) 3ALM requirements.
WARNING
The CO2 gas regulator and the N2 regulator do not use the same thread to
mate with the cylinder. Make sure to use a CO2gas regulator with the CO2
gas cylinder and to use a N2gas regulator with the N2cylinder.
WARNING
Only use industrial grade Carbon Dioxide gas (CO2) or
industrial grade Nitrogen gas (N2).
CAUTION
To prevent gas leak and drop of pressure, ALWAYS use a neoprene washer
when connecting the regulator to the cylinder

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 8 / 11
TECHNICAL SPECIFICATIONS
AtmosphereAPS
AtmosphereAPS H.O.
Max 3000APS
Max 5000APS
Max 5000APS
H.O.
Electrical
Voltage - VAC
115
230
115
230
115
230
115
230
230
Frequency - Hz
50-60
50-60
50-60
50-60
50-60
50-60
50-60
50-60
50-60
NB of phase
1
1
1
1
1
1
1
1
1
Watts
715
715
1415
1415
715
715
1415
1415
2815
Amp.
6,2
3,2
12,3
6,2
6,2
3,2
12,3
6,2
12,3
FLUID
Type –M.S.D.S. available on request
MDG
Neutral
MDG
Neutral
MDG
Neutral
MDG
Neutral
MDG
Neutral
MDG
Neutral
MDG
Neutral
MDG
Neutral
MDG Neutral
Reservoir size –litre (US gal.)
2,5 (0.66)
2,5 (0.66)
6,5 (1.72)
6,5 (1.72)
2,5 (0.66)
2,5 (0.66)
2,5 (0.66)
2,5 (0.66)
6,5 (1.72)
Consumption in litre (US oz) per hour
@ 138 kPa / 1,38 bar / 20 psi
0,055
(1.85)
0,055
(1.85)
-
-
-
@ 207 kPa / 2.07 bar / 30 psi
0,11 (3.7)
0,11 (3.7)
@ 276 kPa / 2,76 bar / 40 psi
-
-
-
-
1 (34)
1 (34)
2,6 (88)
2,6 (88)
@ 414 kPa / 4.14 bar / 60 psi
-
-
-
-
-
-
-
-
4,5 (120)
GAS
Type (industrial grade quality)
CO2or N2
CO2or N2
CO2or N2
CO2or N2
CO2or N2
CO2or N2
CO2or N2
CO2or N2
N2 Only
Consumption in Kg (Lb) per hour
@ 138 kPa / 1,38 bar / 20 psi
0,18 (.4)
0,18 (.4)
-
-
-
-
-
-
-
@ 207 kPa / 2.07 bar / 30 psi
-
-
0,36 (0.8)
0,36 (0.8)
-
-
-
-
-
@ 276 kPa / 2,76 bar / 40 psi
-
-
-
-
0,97 (2.13)
0,97 (2.13)
2,25 (5)
2,25 (5)
-
@ 414 kPa / 4.14 bar / 60 psi
-
-
-
-
-
-
-
-
5 (11)
OUTPUT
Fog volume in m3(ft3) per min.
@ 276 kPa / 2,76 bar / 40 psi
-
-
-
-
85 (3 000)
85 (3 000)
218 (7680)
218 (7680)
445 (15750)
Total running time in hour
@ 138 kPa / 1,38 bar / 20 psi
45
45
60
60
-
-
-
-
-
color
Pure white
Pure white
Pure white
Pure white
Pure white
Pure white
Pure white
Pure white
Pure white
Particule size in microns
0,5 –0,7
0,5 –0,7
0,5 –0,7
0,5 –0,7
0,5 –0,7
0,5 –0,7
0,5 –0,7
0,5 –0,7
0,5 –0,7

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 9 / 11
WARRANTY
When installed and operated as recommended, MDG Fog Generators Ltd.,
guarantees that this product will remain free of defects in parts and labor for a period
of five (5) years from the moment it is delivered. This warranty does not apply if the
product has been modified without our written authorization, or repaired without a
written authorization from MDG or one of is authorized service center, or if it is used
under conditions for which it has not been designed, or if a none MDG Fog Fluid has
been used. MDG Fog Generators Ltd is not responsible for any damages resulting
from a faulty installation or from abusive use of the product.
If any device is found unsatisfactory under the terms of this warranty, MDG Fog
Generators Ltd will repair or replace it free of all charges except transportation costs.
This warranty applies only to the product itself and MDG Fog Generators Ltd
declines responsibility for any losses, costs, or damages resulting from its use.
MDG Fog Generators Ltd shall not be liable for consequential damage in case of
any failure to meet the conditions of any warranty or shipping schedule, nor will
claims for labor, loss of profits, repairs, or other expenses incidental to replacement be
allowed.
The repair or replacement of the product, by MDG Fog Generators Ltd shall
constitute fulfillment of all obligations to the purchaser.
No other guarantees or warranties, expressed or implied, are made by MDG Fog
Generators Ltd in connection with its products. This warranty is nontransferable and
applies to the original purchaser only.
To obtain satisfaction under the terms of this warranty, contact your local sales
office, and we will be pleased to help you.

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 10 / 11
DECLARATION OF CONFORMITY

Atmosphere APS & Max APS Series
User Guide120815, Rev: A/a 11 / 11
NOTE
