2 Overview
2.1 Overview Devices
The description refers to the following LED Indicators (order shown in bold):
•SCN-LED55.01 LED-Indicator, 55mm
o12 RGBW LEDs, Logic and Converter functions
•SCN-GLED1W.01 Glass LED-Indicator, white
o12 RGBW LEDs, Logic and Converter functions
•SCN-GLED1S.01 Glass LED-Indicator, black
o12 RGBW LEDs, Logic and Converter functions
2.2 Usage & Areas of application LED Indicator
The LED Indicator serves as a reminder of certain states. In this case, each of the 12 LEDs can be
either normally switched on or flash in four different colors (red, green, blue, white) to show any
state. The 6 row elements can be individually labeled in both designs, the glass LED Indicator as well
as the 55mm LED Indicator.
In addition, the display features 8 logic blocks as well as an alarm and converter function. Via the
logic function, states or functions can be evaluated in detail by using AND/OR functions. In response
to its states, byte values or scene numbers can be sent.
Through the built-in alarm function interrupts can be triggered with the signal change of any LED. To
this end, 4 different alarm objects are available.
By using the converter function, temperature values, byte values and 2-bit values can be converted
to simple bit values.

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
5
5
2.3 Structure and location of the LEDs
The following figure shows the location of each LED. For orientation, the position of the
programming button is indicated:
Figure 1: Structure and location of the LEDs
2.4 Exemplary circuit diagram
Figure 2: Exemplary circuit diagram

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
6
6
2.5 Start Up
After wiring, the allocation of the physical address and the parameterization of every channel follow:
(1) Connect the interface with the bus, e.g. MDT USB interface
(2) set bus power up
(3) Press the programming button at the device(red programming LED lights)
(4) Loading of the physical address out of the ETS-Software by using the interface(red LED goes
out, as well this process was completed successful)
(5) Loading of the application, with requested parameterization
(6) If the device is enabled you can test the requested functions(also possible by using the ETS-
Software)

Technical Manual –LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
7
7
3 Communication objects
3.1 Summary and Usage
The following table shows the available objects and their use:
Nr.
Name
Object function
Data type
Direction
Info
Usage
Tip
LED-Objects:
0
LED 1
Switch
DPT 1.001
receive
Indicator reacts to
Input-telegram
Control
buttons, status
of actuators,
states of binary
inputs,…
This communication object is
used to switch the LEDs, and the
signal change of the LEDs.
1
LED 1
Priority 1
DPT 1.001
receive
Indicator reacts to
Input-telegram
Control
buttons, status
of actuators,
states of binary
inputs
This communication object is
used to switch the LED priority,
and the signal change of the LED
priority.
2
LED 1
Priority 2
DPT 1.001
receive
Indicator reacts to
Input-telegram
Control
buttons, status
of actuators,
states of binary
inputs
This communication object is
used to switch the LED priority,
and the signal change of the LED
priority.
+3
next LED

Technical Manual –LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
8
8
Central objects:
36
Day/Night
Switch
DPT 1.001
receive
Indicator reacts
to Input-telegram
Control buttons,
Visu…
Switching the Day / Night
function, certain functions can be
called or brightness can be
adjusted in consequence of
switching this object.
37
All LEDs
Block Object
DPT 1.001
receive
Indicator reacts
to Input-telegram
Control buttons,
Visu…
Calling blocks all LEDs and
switches them off
38
Absent
Switch
DPT 1.001
receive
Indicator reacts
to Input-telegram
Control buttons,
Visu…
The alarm is switched on by
activation of the Absent function
Alarm objects:
39
Alarm 1-4
Output
DPT 1.001
sending
Indicator sends
current state
Visu,
Actuators …
Object can be used to send
alarms to visualization or
actuators, which can trigger
certain commands.
+1
next Alarm
43
Alarm
Monitoring
DPT 1.001
sending
Indicator sends
current state
Visu,
Actuators …
Object sends „1-telegram“ if
signal is not sent

Technical Manual –LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
9
9
Logic objects:
44
Logic A
Input logic 1-8
DPT 1.001
receive
Indicator reacts
to Input-telegram
Control buttons,
status of
actuators, states
of binary
inputs,…
Input of the logic function
Eingang der Logikfunktion.
52
Logik A
Output Switching
DPT 1.001
sending
Indicator sends
current state
Visu,
Actuators …
Sends a Bit value if logic function
is satisfied
52
Logik A
Output Scene
DPT 18.001
sending
Indicator sends
current state
Visu,
Actuators …
Sends adjusted scene number if
logic function is satisfied
52
Logik A
Output Value
DPT 5.001
sending
Indicator sends
current state
Visu,
Actuators …
Sends adjusted value if logic
function is satisfied
+9
nächste Logik
Converter objects:
116
Converter module A
Input value A1
(Byte-->Bit)
DPT 5.001
receive
Indicator reacts
to Input-telegram
Actuator, Visu,
Control
Buttons…
Input of the converter module
116
Converter module A
Input A Compelled
guidance
(2 Bit-->Bit)
DPT 2.001
receive
Indicator reacts
to Input-telegram
Presence
detector,
Actuator, Visu…
Input of the converter module
116
Converter module A
Input value A1
(Temperature-->Bit)
DPT 9.001
receive
Indicator reacts
to Input-telegram
Temperature-
sensor/
controller
Input of the converter module

Technical Manual –LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
10
10
118
Converter module A
Gate Control input A
DPT 1.009
receive
Indicator reacts
to Input-telegram
Control Buttons,
Visu
Object is used to set whether the
input value passed, or is to be
converted. When the gate is
closed, the converter is disabled.
119
Converter module A
Output value A1
DPT 1.002
sending
Indicator sends
telegram
Visu,
Actuators …
Sends 0 or 1 depending on the
preset threshold.
Active in byte -> bits and
temperature -> bit
119
Converter module A
A1: Compelled guidance
ON
DPT 1.002
sending
Indicator sends
telegram
Visu,
Actuators …
Sends 1 if Forced ON, 0 otherwise
Active with positive guidance ->
bit
120
Converter module A
A2: Compelled guidance
OFF
DPT 1.002
sending
Indicator sends
telegram
Visu,
Actuators …
Sends 1 if forced operation,
otherwise 0
Active with positive guidance ->
bit
+5
next converter module
136
Operating
Status
DPT 1.001
sending
Indicator sends
state
Visu…
Sends a "Set" message when the
device is on the bus
Table 1: Communication Objects

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
11
11
3.2 Default settings of the communication objects
Default Settings
Nr.
Name
Object Function
Length
Priority
C
R
W
T
U
0
LED 1
Switch
1 Bit
Low
X
X
X
X
1
LED 1
Priority 1
1 Bit
Low
X
X
X
X
2
LED 1
Priority 2
1 Bit
Low
X
X
X
X
+3
next LED
36
Day/Night
Switch
1 Bit
Low
X
X
37
All LEDs
Block Object
1 Bit
Low
X
X
38
Absent
Switch
1 Bit
Low
X
X
39
Alarm 1
Output
1 Bit
Low
X
X
X
+1
next Alarm
43
Alarm
Monitoring
1 Bit
Low
X
X
X
44
Logic A
Input logic 1
1 Bit
Low
X
X
X
+1
nächste
Eingangslogik
52
Logic A
Ausgang Schalten
1 Bit
Low
X
X
X
52
Logic A
Ausgang Szene
1 Byte
Low
X
X
X
52
Logic A
Ausgang Wert
1 Bit
Low
X
X
X
+9
next Logic
116
Converter module A
Input value A1
2 Byte
Low
X
X
116
Converter module A
Input value A1
1 Byte
Low
X
X
116
Converter module A
Input value A1
2 Bit
Low
X
X
118
Converter module A
Gate control Input A
1 Bit
Low
X
X
119
Converter module A
Output value A1
1 Bit
Low
X
X
X
120
Converter module A
Output value A2
1 Bit
Low
X
X
X
+5
next Converter
136
Operating
Status
1 Bit
Low
X
X
X
Table 2: Default Settings communication objects
You can see the default values for the communication objects from the upper chart. According to
requirements the priority of the particular communication objects as well as the flags can be
adjusted by the user. The flags allocates the function of the objects in the programming thereby
stands C for communication, R for Read, W for write, T for transmit and U for update.

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
12
12
4 Reference ETS-Parameter
4.1 General settings
The following figure shows the general settings for the LED display:
Figure 3: General settings
The following table shows the available settings:
ETS-text
Dynamic range
[default value]
comment
Startup time
1s –60s
[1s]
Time between Reset and functional start
of the device
Send cyclic object operating
▪not send
▪10min –24h
Adjustment if the operating state should
be send cyclic via an object
Switch Day/Night
▪Day = 1/Night = 0
▪Day = 0/Night = 1
Adjustment of the polarity of the
day/night object
Behavior at bus power reset
▪no read LED
objects
▪read LED objects
Adjustment if the LED objects should be
read at a reset
Activate alarms
▪No
▪Yes
Activation of the alarms
Activate absence
▪absent at object
value = 0
▪absent at object
value = 1
Adjustment of the polarity of the
„absent“ telegram

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
13
13
Delete alarm
▪automatically
▪delete with
attendance
Determining how the alarm to be reset:
Automatic: alarm is reset immediately
when alarm is no longer active
Clear with attendance: The alarm is
cleared only if the absence is turned off
Monitoring for objects
▪no alarm
▪send Timeout
alarm at object
failure
Sets whether an alarm should be
triggered when cyclical monitoring for an
LED fails.
Table 3: General settings
The relevant communication objects for the general settings are shown in the following table:
Number
Name
Length
Usage
36
Day/Night
1 Bit
Switching between Day/Night
37
All LEDs –Block object
1 Bit
blocks all LEDs
38
Absent
1 Bit
switches the absent function and so the alarms are
switched on
136
Operating
1 Bit
sends a 1-telegram in the adjusted time periods if the
device is active
Table 4: General communication objects

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
14
14
4.2 LED-Settings
Every of the 12 LEDs can be adjusted and controlled individually. The parameters for LED 1 are
described. LEDs 2-12 have the same parameters.
4.2.1 LED Control
Below the settings for the LED control are shown:
Figure 4: LED Control
The following table shows the possible settings:
ETS-text
Dynamic range
[default value]
comment
LED 1
▪active
▪not active
Activation/Deactivation of the LED
LED reacts on
▪external object
▪internal logic
object
▪internal converter
object
Selection of the controlling of the LED
Table 5: LED-Control
If the parameter „LED reacts on“ is set to external object, an additional object is shown, which can be
connected individually:
Number
Name
Length
Usage
0
LED 1
1 Bit
Controlling LED 1
Table 6: LED Control via external object
Furthermore, the LED can respond to internal objects. Both the internal logic objects and the internal
converter objects are available. In order to reduce the design effort, in this case the connection is
made internally. This additional parameter is displayed, which sets the internal connection.
For the setting "LED responds to internal logic object" looks as follows:
Figure 5: LED control via internal logic object:
In this example, the LED is switched in response to the output of the first logic function. This driving
course is designed so that the output of logic module is a bit value. If the logic module is set as a byte
value or scene, the LED is turned off with the value 0, all others turn the LED on.

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
15
15
For the setting "LED responds to internal converter object" looks as follows:
Figure 6: LED control via internal converter object
In this example, the LED is switched by the converter A as a function of the first output.
4.2.2 LED Display behavior
Below the settings for the display behavior of the LEDs can be seen:
Figure 7: Display behavior LEDs

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
16
16
The following table shows the available settings:
ETS-text
Dynamic range
[default value]
comment
Color setting
▪red
▪green
▪blue
▪white
Adjustment of the LED color
Behavior of indicator
▪light on
▪blinking
▪flash
Adjustment of the light behavior:
light on:
light on = switched on permanently
blinking = flashing rhythm 1:1
flash = short on, long off
Indicator by day
▪off
▪dark
▪bright
Adjustment of the light behavior at day.
Only adjustable if the day/night object is
active(General settings)
Indicator by night
▪off
▪dark
▪bright
Adjustment of the light behavior at night.
Only adjustable if the day/night object is
active(General settings)
Table 7: Display behavior LED
The settings for the LED display behavior behavior are identical for the setting with LED object value
1, as well as for the LED priority settings.
4.2.3 LED Priority
By using the LED priority, it is possible to switch the LED of prime importance. So the value of the
normal LED control will be overwritten. Two LED priorities are available. The priority of the LED
controlling is staggered as follows (from high to low priority): LED Priority 1→LED Priority 2 →
normal LED Control.
The settings for the LED priority (settings for Led priority 2 are identical) are as follows:

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
17
17
Figure 8: Settings LED priority 1/2
The activation of the LED priority can be done via external objects, internal logic objects or internal
converter objects. The settings are the same as described in 4.2.1 LED Control.
Standardly, the priority is activated with the value 1. Via the parameter “invert object”, the priority
can be set as active at the value 0.
The display behavior of the LED at activation of the LED priority is the same like described in 4.2.2
LED Display behavior, but can be set individually for the LED priority.
If the parameter “Assignment of communication objects” is set to external object, an additional
object is shown, which can be connected individually:
Number
Name
Length
Usage
1
LED Priority 1
1 Bit
Controlling the LED Priority 1
2
LED Priority 2
1 Bit
Controlling the LED Priority 2
Table 8: Communication objects LED priority

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
18
18
4.2.4 Monitoring
Via the monitoring of the LEDs, it can be controlled if the LED indicator gets in defined time steps a
signal from the external object. If the LED indicator receives no signal, a particular behavior can be
called, e.g. flashing red.
The following picture shows the available settings for the monitoring:
Figure 9: Monitoring
The following table shows the available settings for the monitoring:
ETS-text
Dynamic range
[default value]
comment
Monitoring for Object LED
▪no monitoring
▪1min –240min
[30min]
Adjustment in which time periods, a
signal must be received on the object LED
1. “No monitoring” deactivates the
monitoring of the object.
Monitoring for Object Priority 1
▪no monitoring
▪1min –240min
Adjustment in which time periods, a
signal must be received on the object LED
priority 1. “No monitoring” deactivates
the monitoring of the object.
Table 9: Monitoring
The display behavior in case of a loss of the signal is the same like in 4.2.2 LED Display behavior
described.
It should be noted that monitoring can be enabled only when the parameter "LED reacts on” is set
to “external object", because the LED indicator cannot monitor itself.
In addition, at failures an object can be set, which indicates a loss of a signal. This must be activated
in the general settings:
Figure 10: Monitoring of objects

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
19
19
The following table shows the object, which indicates a loss of a signal:
Number
Name
Length
Usage
43
Alarm –Monitoring
1 Bit
Sends 1 if a signal is not received in the adjusted time
period
Table 10: Timeout alarm
If a LED with activated „Monitoring“ does not receive a signal in the adjusted time period, this object
sends a logical 1.
4.2.5 Behavior after Reset
After a bus voltage reset, or download, the objects for the LED have no value and therefore no
defined switching state. To produce a defined state for this case, the setting is shown below:
Figure 11: Behavior after Reset

Technical Manual
LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Phone: [phone] • Fax: [phone] • [email protected] • www.mdt.de
20
20
4.3 Alarm function
The LED Indicator contains of an extensive alarm-function, which can monitor LEDs in the absent
mode. As soon as a LED gets a certain value, this can be signaled by sending a one-command on one
of four freely adjustable alarm objects. Both the LEDs and the LED 1 priority of all LEDs can be
monitored.
The settings for the LED1 can be seen in the pictures below:
Figure 12: Alarm function - LED 1
Figure 13: Alarm function - LED priority 1
The available settings are shown in the table below:
ETS-text
Dynamic range
[default value]
comment
Alarm at absent for LED 1
▪no alarm
▪Alarm at 1
▪Alarm at 0
Setting if and when an alarm should be
triggered for LED 1
Alarm at 1 = Alarm is triggered when LED
is turned on
Alarm at 0 = Alarm is turned on when LED
is turned off
Assign alarm object
▪Alarm 1
▪Alarm 2
▪Alarm 3
▪Alarm 4
Setting which object sends an one-
command in case of this alarm
Alarm at absent for Priority 1
LED 1
▪no alarm
▪Alarm at 1
▪Alarm at 0
Setting if and when an alarm for priority 1
LED 1 should be triggered
Alarm at 1 = Alarm is triggered when LED
1 is turned on priority
Alarm at 0 = Alarm is turned on when LED
is turned off Priority 1
Assign alarm object
▪Alarm 1
▪Alarm 2
▪Alarm 3
▪Alarm 4
Setting which object sends an one-
command in case of this alarm
Table 11: Alarm function
