VENT-FREE NATURAL GAS HEATER

OWNER’S OPERATION AND INSTALLATION MANUAL

MBN10TLA

™

This appliance may be installed in an aftermarket*, permanently located, manufactured

(mobile) home, where not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the rating plate. This

appliance is not convertible for use with other gases.

*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

Carbon Monoxide Poisoning:Early signs

ofcarbonmonoxidepoisoningresemblethe

flu, with headaches, dizziness, and/or nau-

sea. If you have these signs, the heater may

not be working properly. Get fresh air at

once! Have heater serviced. Some people

are more affected by carbon monoxide than

others. These include pregnant women,

peoplewithheartorlungdiseaseoranemia,

those under the influence of alcohol, and

those at high altitudes.

Natural Gas: Natural gas is odorless. An

odor-making agent is added to natural gas.

Theodorhelpsyoudetectanaturalgasleak.

However, the odor added to natural gas can

fade.Naturalgasmaybepresenteventhough

no odor exists.

Make certain you read and understand all

Warnings. Keep this manual for reference.

It is your guide to safe and proper operation

of this heater.

WARNING ICON G001

WARNINGS

IMPORTANT: Read this owner’s

manual carefully and completely

before trying to assemble, oper-

ate, or service this heater. Im-

proper use of this heater can

causeseriousinjuryordeathfrom

burns, fire, explosion, and car-

bon monoxide poisoning.

DANGER: Carbon monoxide

poisoning may lead to death!

SAFETY

INFORMATION

WARNING:Anychangetothis

heater or its controls can be

dangerous.

1. This appliance is only for use with the

typeof gasindicated onthe ratingplate.

Thisappliance isnot convertiblefor use

with other gases.

2. If you smell gas

• shut off gas supply

• do not try to light any appliance

• do not touch any electrical switch; do

not use any phone in your building

• immediately call your gas supplier

from a neighbor’s phone. Follow the

gas supplier’s instructions

• ifyou cannotreach your gas supplier,

call the fire department

3. Heater shall not be installed in a bath-

room.

4. This heaterneeds fresh,outside airven-

tilation to run properly.This heater has

an oxygen depletion sensing (ODS)

safety shutoff system. The ODS shuts

down the heater if not enough fresh air

is available. See Air for Combustion

and Ventilation, pages 4 through 6.

5. Keep all air openings in front and bot-

tom of heater clear and free of debris.

This will insure enough air for proper

combustion.

6. If heater shuts off, do not relight until

you provide fresh, outside air. If heater

keeps shutting off, have it serviced.

7. Do not run heater

• where flammable liquids or vapors

are used or stored

• under dusty conditions

8. Do not use heater if any part has been

under water. Immediately call a quali-

fied service technician to inspect the

room heater and to replace any part of

the control system and any gas control

which has been under water.

9. Turn off heater and let cool before ser-

vicing. Only a qualified service person

should service and repair heater.

10. Operating heater above elevations of

4,500 feet could cause pilot outage.

11. Before usingfurniture polish, wax, car-

pet cleaner, or similar products, turn

heater off. If heated, the vapors from

theseproducts may createa white pow-

der residue within burner box or on

adjacent walls or furniture.

Do not place clothing or other

flammable material on or near

the appliance. Never place any

objects on the heater.

Surface of heater becomes very

hot when running heater. Keep

children and adults away from

hot surface to avoid burns or

clothing ignition. Heater will re-

main hot for a time after shut-

down. Allow surface to cool be-

fore touching.

Carefully supervise young chil-

dren when they are in the same

room with heater.

Make sure grill guard is in place

before running heater.

Keeptheapplianceareaclearand

free from combustible materials,

gasoline and other flammable

vapors and liquids.

Due to high temperatures, the

appliance should be located out

oftrafficandawayfromfurniture

and draperies.

WARNING: Do not use any

accessory not approved for use

with this heater.

105728

OWNER’S MANUAL

PRODUCT

IDENTIFICATION

LOCAL CODES

Install and use heater with care. Follow all

localcodes. In theabsence oflocal codes,use

the latest edition of The National Fuel Gas

Code ANS Z223.1 also known as NFPA 54*.

*Available from:

American National Standards Institute, Inc.

1430 Broadway

New York, NY 10018

National Fire Protection Association, Inc.

Batterymarch Park

Quincy, MA 02269

Figure 1 - Vent-Free Natural Gas Heater

Heater

Cabinet

Grill

Guard

Glass

Panel

Front

Panel

Control Knob

Ignitor Button

1. Remove heater from carton.

2. Remove all protective packaging ap-

plied to heater for shipment.

3. Check heater for any shipping damage.

If heater is damaged, promptly inform

dealer where you bought heater.

UNPACKING

PRODUCT

FEATURES

SAFETY DEVICE

This heater has a pilot with an Oxygen

Depletion Sensing (ODS) safety shutoff

system. The ODS/pilot is a required feature

for vent-free room heaters. The ODS/pilot

shuts off the heater if there is not enough

fresh air.

PIEZO IGNITION SYSTEM

This heater has a piezo ignitor. This system

requires no matches, batteries, or other

sources to light heater.

THERMOSTATIC HEAT

CONTROL

This heater has a thermostat sensing bulb

and thermostat control. This results in the

greatestheater comfort.This can also result

in lower gas bills.

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

AIR FOR

COMBUSTION AND

VENTILATION

Today’s homes are built more energy effi-

cient than ever. New materials, increased

insulation,andnewconstructionmethodshelp

reduce heat loss in homes. Home owners

weather strip and caulk around windows and

doorstokeepthecoldairoutandthewarmair

in.Duringheatingmonths,homeownerswant

their homes as airtight as possible.

While it is good to make your home energy

efficient,yourhomeneedstobreathe.Fresh

air must enter your home. All fuel-burning

appliances need fresh air for proper com-

bustion and ventilation.

Exhaustfans,fireplaces,clothesdryers,and

fuel burning appliances draw air from the

house to operate. You must provide ad-

equate fresh air for these appliances. This

will insure proper venting of vented fuel-

burning appliances.

PROVIDING ADEQUATE

VENTILATION

The following are excerpts from National

Fuel Gas Code. NFPA 54/ANS Z223.1, Sec-

tion5.3,AirforCombustionandVentilation.

Allspacesinhomesfallintooneofthethree

following ventilation classifications:

1. Unusually Tight Construction

2. Unconfined Space

3. Confined Space

The information on pages 4 through 6 will

help you classify your space and provide

adequate ventilation.

Unusually Tight Construction

The air that leaks around doors and win-

dows may provide enough fresh air for

combustion and ventilation. However, in

buildings of unusually tight construction,

you must provide additional fresh air.

Unusually tight construction is de-

fined as construction where:

a. walls and ceilings exposed to the

outside atmosphere have a con-

tinuous water vapor retarder with

a rating of one perm (6 x 10-11 kg

per pa-sec-m2) or less with open-

ings gasketed or sealed

and

b. weather stripping has been

added on openable windows and

doors

and

c. caulking or sealants are applied

to areas such as joints around

window and door frames, be-

tween sole plates and floors,be-

tween wall-ceiling joints, be-

tween wall panels, at penetra-

tionsforplumbing,electrical,and

gas lines, and at other openings.

If your home meets all of the three

criteria above, you must provide ad-

ditional fresh air. See

Ventilation Air

From Outdoors

, page 6

If your home does not meet all of the

three criteria above, proceed to

Deter-

mining Fresh-Air flow for Heater Lo-

cation

on page 5.

Confined and Unconfined

Spaces

The National Fuel Gas Code ANS Z223.1

defines a confined space as a space whose

volumeislessthan50cubicfeetper1000Btu

per hour (4.8 cubic meters per kw) of the

aggregate input rating of all appliances in-

stalledin that spaceandan unconfinedspace

as a space whose volume is not less than 50

cubic feet per 1000 Btu per hour (4.8 cubic

meters per kw) of the aggregate input rating

ofallappliancesinstalledinthatspace.Rooms

communicating directly with the space in

which the appliances are installed*, through

openings not furnished with doors, are con-

sidered a part of the unconfined space.

This heater shall not be installed in a con-

fined space or unusually tight construction

unlessprovisions areprovided foradequate

combustion and ventilation air.

*Adjoining rooms are communicating only

iftherearedoorlesspassagewaysorventila-

tion grills between them.

WARNING: This heater shall

notbeinstalledinaconfinedspace

or unusually tight construction

unless provisions are provided

foradequatecombustionandven-

tilation air. Read the following in-

structions to insure proper fresh

air for this and other fuel-burning

appliances in your home.

105728

OWNER’S MANUAL

AIR FOR

COMBUSTION AND

VENTILATION

Continued

DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION

Determining if You Have a Confined or Unconfined Space

Use this worksheet to determine if you have a confined or unconfined space.

Space:Includestheroominwhichyouwillinstallheaterplusanyadjoiningroomswithdoorlesspassagewaysorventilationgrillsbetween

the rooms.

1. Determine the volume of the space (length x width x height).

Length x Width x Height = _________________cu. ft. (volume of space)

Example:

Space size 18 ft. (length) x 16 ft. (width) x 8 ft. (ceiling height) = 2304 cu. ft. (volume of space)

If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of

the space.

2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.

_____________ (volume of space) ÷50 cu. ft. = (Maximum Btu/Hr the space can support)

Example:

2304 cu. ft. (volume of space) ÷50 cu. ft. = 46.1 or 46,100 (maximum Btu/Hr the space can support)

3. Add the Btu/Hr of all fuel burning appliances in the space.

Vent-free heater ______________Btu/Hr

Gas water heater* ______________Btu/Hr

Gas furnace ______________Btu/Hr

Vented gas heater ______________Btu/Hr

Gas fireplace logs ______________Btu/Hr

Other gas appliances* +______________Btu/Hr

Total =______________Btu/Hr

* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.

4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.

_____________ Btu/Hr (maximum the space can support)

_____________ Btu/Hr (actual amount of Btu/Hr used)

Example:

46,100 Btu/Hr (maximum the space can support)

50,000 Btu/Hr (actual amount of Btu/Hr used)

Thespace intheaboveexampleisaconfinedspacebecausetheactualBtu/HrusedismorethanthemaximumBtu/Hrthespacecansupport.

You must provide additional fresh air. Your options are as follows:

A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoining

room or add ventilation grills between rooms. See Ventilation Air From Inside Building, page 6.

B. Vent room directly to the outdoors. See Ventilation Air From Outdoors, page 6.

C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined.

If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no

additional fresh air ventilation.

Continued

Example:

Gas water heater 40,000 Btu/Hr

Vent-free heater +10,000 Btu/Hr

Total =50,000 Btu/Hr

WARNING:Iftheareainwhichtheheatermaybeoperatedissmallerthanthatdefinedasanunconfinedspace

or if building is of unusually tight construction, provide adequate combustion and ventilation air by one of the

methods described in the

National Fuel Gas Code, ANS Z223.1, Section 5.3

or applicable local codes.

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

Figure 3 - Ventilation Air from Outdoors

Outlet

Air Ventilated

Attic

Outlet

Air

Inlet

Air

Inlet Air Ventilated

Crawl Space

Crawl

Space

To Attic

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation

grills or ducts. You must provide two per-

manent openings: one within 12" of the

ceiling and one within 12" of the floor.

Connecttheseitemsdirectlytotheoutdoors

orspacesopentotheoutdoors.Thesespaces

include attics and crawl spaces. Follow the

National Fuel Gas Code NFPA 54/ANS

Z223.1,Section5.3,AirforCombustionand

Ventilation for required size of ventilation

grills or ducts.

IMPORTANT:

Do not provideopenings for

inlet or outlet air into attic if attic has a

thermostat-controlledpowervent.Heatedair

enteringtheatticwillactivatethepowervent.

Figure 2 - Ventilation Air from Inside Building

Remove

Door into

Adjoining

Room,

Option 3

Ventilation Grills

Into Adjoining Room,

Option 2

12"

Ventilation

Grills

into Adjoining

Room,

Option 1

AIR FOR

COMBUSTION AND

VENTILATION

Continued

VENTILATION AIR

Ventilation Air From Inside

Building

Thisfreshairwouldcomefromanadjoining

unconfined space. When ventilating to an

adjoining unconfined space, you must pro-

vide two permanent openings: one within

12" of the ceiling and one within 12" of the

floor on the wall connecting the two spaces

(seeoptions1and2,Figure2).Youcanalso

remove door into adjoining room (see op-

tion 3, Figure 2). Follow the National Fuel

Gas Code NFPA 54/ANS Z223.1, Section

5.3, Air for Combustion and Ventilation for

required size of ventilation grills or ducts.

WARNING: Rework work-

sheet, adding the space of the

adjoining unconfined space. The

combined spaces must have

enough fresh air to supply all

appliances in both spaces.

105728

OWNER’S MANUAL

INSTALLATION

Continued

CHECK GAS TYPE

Use only natural gas. If your gas supply is

notnatural, donotinstall heater.Calldealer

where you bought heater for proper type

heater.

INSTALLATION ITEMS

Beforeinstallingheater,makesureyouhave

the items listed below:

• piping (check local codes)

• sealant (resistant to propane/LP gas)

• equipment shutoff valve *

• ground joint union

• test gauge connection *

• sediment trap

• tee joint

• pipe wrench

* A CSA/AGA design-certified equipment

shutoff valve with 1/8" NPT tap is an ac-

ceptable alternative to test gauge connec-

tion. Purchase the optional CSA/AGA de-

sign-certifiedequipmentshutoffvalvefrom

your dealer. See Accessory, page 16.

WARNING: A qualified ser-

vice person must install heater.

Follow all local codes.

LOCATING HEATER

Thisheaterisdesignedtobemountedonawall.

WARNING:Maintainthemini-

mumclearancesshowninFigure

4.Ifyoucan,providegreaterclear-

ancesfromfloor,ceiling,andjoin-

ing wall.

CAUTION: If you install the

heater in a home garage

• heater pilot and burner must

be at least 18 inches above

floor

• locateheaterwheremovingve-

hicle will not hit it

IMPORTANT:

Vent-freeheatersaddmois-

ture to the air. Although this is beneficial,

installing heater in rooms without enough

ventilation air may cause mildew to form

from too much moisture. See Air for Com-

bustion and Ventilation, pages 4 through 6.

CAUTION: This heater cre-

ates warm air currents. These

currents move heat to wall sur-

faces next to heater. Installing

heater next to vinyl or cloth wall

coverings or operating heater

where impurities (such as to-

bacco smoke, aromatic candles,

cleaning fluids, oil or kerosene

lamps, etc.) in the air exist, may

discolor walls.

WARNING: Never install the

heater

• in a bathroom

• in a recreational vehicle

• where curtains, furniture,

clothing, or other flammable

objectsarelessthan36inches

from the front, top, or sides of

the heater

• as a fireplace insert

• in high traffic areas

• in windy or drafty areas

Forconvenienceandefficiency,installheater

• where there is easy access for operation,

inspection, and service

• in coldest part of room

Figure4-MountingClearancesAsViewed

From Front of Heater

THERMOSTAT SENSING

BULB

The thermostat sensing bulb is located in-

side the heater. Do not move this bulb dur-

ing installation or operation of the heater.

INSTALLING HEATER TO

WALL

Marking Screw Locations

1. Determine where you will locate

heater.

WARNING:Maintainminimum

clearances shown in Figure 5. If

you can, provide greater clear-

ancesfromfloorandjoiningwall.

2. Mark two mounting screw loca-

tions on wall (see Figure 5).

Mounting

Screw

Locations

8 7/8"

Minimum To

Maintain 6"

Clearance

From Wall

7 3/4"

20 1/4"

Minimum To

Maintain 3"

Clearance

From Floor

FLOOR

JOINING WALL

36"

FLOOR

CEILING

Minimum

Minimum To Top Surface

Of Carpeting, Tile Or Other

Combustible Material

Minimum

From

Sides Of

Heater

Right

Side

Left

Side

Minimum to Top

Surface of

Carpeting, Tile or

Other Combustible

Material

NOTICE: This heater is intended

foruseassupplementalheat.Use

this heater along with your pri-

mary heating system. Do not in-

stall this heater as your primary

heatsource.If you haveacentral

heating system, you may run

system’scirculatingblowerwhile

usingheater.Thiswillhelpcircu-

late the heat throughout the

house. In the event of a power

outage, you can use this heater

as your primary heat source.

Figure 5 - Mounting Screw Locations

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

Placing Heater On Mounting

Screws

1. Locate two keyhole slots on back panel

of heater (see Figure 9).

2. Place large openings of slots over

screwheads. Slide heater down until

screws are in small portion of slots.

Figure 11 - Installing Bottom Mounting

Screw

Figure 9 - Location Of Keyhole Slots On

Back Panel Of Heater

Removing Front Panel Of Heater

1. Remove two screws near bottom cor-

ners of front panel.

Liftstraightupongrillguard untilitstops.

Grill guard will slide up about 1/4".

3. Pull bottomof frontpanel forward,then

down.

Keyhole Slots

Installing Bottom Mounting

Screw

1. Locate bottom mounting hole. This

hole is near bottom on back panel of

heater (see Figure 11).

2. Mark screw location on wall.

3. Remove heater from wall.

4. If installing bottom mounting screw

into hollow or solid wall, install wall

anchor. Follow steps 1 through 5 un-

der Attaching To Wall Anchor Method.

If installing bottom mounting screw

into wall stud, drill hole at marked lo-

cation using 9/64" drill bit.

5. Replace heater on wall.

6. Insert bottom anchor screw through

backpanel intobottom anchorordrilled

hole (see Figure 11).

7. Tighten screw until heater is firmly se-

cured to wall. Do not over tighten.

Note:

Do not replace front panel at this

time. Replace front panel after making

gas connections and checking for leaks

(see pages 9 and 10).

Figure 10 - Removing Front Panel Of

Heater

Figure 6 - Folding Anchor

Figure 7 - Popping Open Anchor Wings

For Thin Walls

Thin Walls

(1/4" to 1/2" thick)

Thin or Thick

Wall

(thick wall

shown)

Solid

Wall

1/16" Space

Figure 8 - Tightening Anchors

Attaching to Wall Anchor Method

Follow instructions below to attach mount-

ing screws to hollow walls (wall areas be-

tween studs) or solid walls (concrete or

masonry).

1. Drill holes at marked locations using

5/16"drill bit. Forsolid walls (concrete

or masonry), drill at least 1 1/4" deep.

2. Fold wall anchor (see Figure 6).

3. Insert wall anchor (wings first) into

hole. Tap anchor flush to wall.

4. For thin walls (1/2" or less), insert red

key into wall anchor. Push red key to

“pop”open anchor wings(seeFigure 7).

IMPORTANT:

Do not hammer key!

Forthick walls(over 1/2"thick) orsolid

walls, do not pop open wings.

5. Tighten two screws until 1/16" space

(thickness of penny) is between

screwheads and wall (see Figure 8).

INSTALLATION

Continued

Installing Two Mounting Screws

Note:

Wall anchors and mounting screws

areinhardwarepackage.Thehardwarepack-

age is provided with heater.

Attaching to Wall Stud Method

For attaching mounting screw to wall stud

Drillhole at markedlocation using9/64"

drill bit.

2. Insert mounting screw into wall stud.

3. Tighten screw until 1/16" space (thick-

ness of penny) is between screwhead

and wall.

105728

OWNER’S MANUAL

CONNECTING TO GAS

SUPPLY

WARNING:Aqualified service

personmustconnectheatertogas

supply. Follow all local codes.

IMPORTANT:

Checkgas line pressurebe-

fore connecting heater to gas line. Gas line

pressure must be no greater than 14 inches

of water. If gas line pressure is higher,

heater regulator damage could occur.

Installationmustincludeaequipmentshutoff

valve, ground joint union, and plugged

1/8" NPT tap. Locate NPT tap within reach

for test gauge hook up. NPT tap must be

upstream from heater (see Figure 12).

IMPORTANT:

Installanequipmentshutoff

valve in an accessible location. The equip-

ment shutoff valve is for turning on or

shutting off the gas to the appliance.

Apply pipe joint sealant lightly to male

threads. This will prevent excess sealant

fromgoing intopipe. Excesssealant inpipe

could result in clogged heater valves.

Install sediment trap (trap) in supply line as

shown in Figure 12. Locate sediment trap

whereitiswithinreachforcleaning.Locate

sediment trap where trapped matter is not

likelytofreeze. Asedimenttraptraps mois-

ture and contaminants. This keeps them

fromgoing intoheater controls. If sediment

trap is not installed or is installed wrong,

heater may not run properly.

IMPORTANT:

Holdpressureregulatorwith

wrench when connecting it to gas piping

and/or fittings.

CAUTION: Use only new,

black iron or steel pipe. Inter-

nally-tinned copper tubing may

be used in certain areas. Check

your local codes. Use pipe 3/8"

diameter or greater to allow

proper gas volume to heater. If

pipe is too small, undue loss of

pressure will occur.

WARNING: Never connect

heater to private (non-utility) gas

wells. This gas is commonly

known as wellhead gas.

Continued

CAUTION:Usepipejointseal-

ant that is resistant to liquid pe-

troleum (LP) gas.

* ACSA/AGAdesign-certifiedequipmentshutoffvalvewith1/8"NPTtapisanacceptable

alternative to test gauge connection. Purchase the optional CSA/AGA design-certified

equipment shutoff valve from your dealer. See Accessory, page 16.

Tee Joint

Reducer

Bushing to

1/8" NPT

Plug Tap

Test

Gauge

Connection *

Pressure

Regulator

Tee

Joint

Pipe

Nipple

Cap

Sediment

Trap

Heater

Cabinet

3/8" NPT

Pipe Nipple

Ground Joint Union

Equipment

Shutoff

Valve *

From

Gas Meter

(5" W.C. to

10.5" W.C.

Pressure)

Figure 12 - Gas Connection

3" Minimum

INSTALLATION

Continued

WARNING:Thisappliancere-

quires a 3/8" NPT (National Pipe

Thread) inlet connection to the

pressure regulator.

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

OPERATING

HEATER

A. Thisappliancehasapilotwhichmust

belightedbyhand.Whenlightingthe

pilot,followthese instructionsexactly.

B. BEFORE LIGHTING smell all

aroundtheappliance areaforgas.Be

suretosmell next tothe floorbecause

some gas is heavier than air and will

settle on the floor.

WHAT TO DO IF YOU SMELL

GAS

• Do not try to light any appliance.

•

Donot touchanyelectricswitch;do

not use any phone in your building.

• Immediatelycall yourgas supplier

from a neighbor’s phone. Follow

the gas supplier’s instructions.

• If you cannot reach your gas sup-

plier, call the fire department.

C. Useonlyyourhandtopushinorturn

thegas controlknob.Neverusetools.

If the knob will not push in or turn

by hand, don’t try to repair it, call a

qualified service technician or gas

supplier. Force or attempted repair

may result in a fire or explosion.

D. Do not use this appliance if any part

has been under water. Immediately

call a qualified service technician to

inspect the appliance and to replace

any part of the control system and

any gas control which has been un-

der water.

WARNING: If you do not fol-

low these instructions exactly, a

fireorexplosionmayresultcaus-

ing property damage, personal

injury or loss of life.

FOR YOUR SAFETY

READ BEFORE

LIGHTING

Pressure Testing Heater Gas

Connection

1. Open equipmentshutoffvalve (seeFig-

ure 13).

2. Open main gas valve located on or near

gas meter.

3. Make sure control knob of heater is in

the OFF position.

4. Check all joints from equipment shutoff

valve to control valve (see Figure 14).

Applymixtureof liquidsoapandwater to

gas joints. Bubbles forming show a leak.

5. Correct all leaks at once.

6. Light heater (see Operating Heater,

pages 10 and 11). Check the rest of the

internal joints for leaks.

7. Turn off heater (see To Turn Off Gas

To Appliance, page 11).

8. Replace front panel.

POSI

Figure 13 - Equipment Shutoff Valve

Equipment

Shutoff

Valve

Open

Closed

Figure 14 - Checking Gas Joints

CHECKING GAS

CONNECTIONS

WARNING: Test all gas pip-

ing and connections for leaks

after installing or servicing. Cor-

rect all leaks at once.

WARNING:Neveruseanopen

flame to check for a leak. Apply a

mixture of liquid soap and water

toalljoints.Bubblesformingshow

a leak. Correct all leaks at once.

Pressure Testing Gas Supply

Piping System

Test Pressures In Excess Of 1/2 PSIG

(3.5 kPa)

1. Disconnect appliance with its appliance

maingasvalve(controlvalve)andequip-

ment shutoff valve from gas supply pip-

ingsystem.Pressuresinexcessof1/2psig

will damage heater regulator.

2. Cap off open end of gas pipe where

equipmentshutoffvalvewas connected.

3. Pressurizesupply piping systemby either

usingcompressedairoropeningmaingas

valve located on or near gas meter.

4. Check all joints of gas supply piping

system. Apply mixture of liquid soap

and water to gas joints. Bubbles form-

ing show a leak.

5. Correct all leaks at once.

6. Reconnect heater and equipment

shutoff valve to gas supply. Check re-

connected fittings for leaks.

Test Pressures Equal To or Less Than

1/2 PSIG (3.5 kPa)

1. Close equipmentshutoffvalve(see Fig-

ure 13).

2. Pressurizesupply piping systemby either

usingcompressedairoropeningmaingas

valve located on or near gas meter.

3. Check all joints from gas meter to

equipment shutoff valve (see Figure

14). Apply mixture of liquid soap and

water to gas joints. Bubbles forming

show a leak.

4. Correct all leaks at once.

INSTALLATION

Continued

Control Valve

Location

Gas Meter

Equipment

Shutoff

Valve

105728

OWNER’S MANUAL

Figure 15 - Control Knob In The OFF

Position

LIGHTING

INSTRUCTIONS

1. STOP! Read the safety informa-

tion, page 10.

2. Makesureequipment shutoffvalve

is fully open.

3. Turn control knob clock-

wise

Clockwise

to the OFF position.

4. Wait five (5) minutes to clear out

anygas.Then smellfor gas, includ-

ing near the floor. If you smell gas,

STOP! Follow “B” in the safety in-

formation on page 10. If you don’t

smell gas, go to the next step.

5. Turn control knob counterclock-

wise

C-clockwise

to the PILOT posi-

tion. Press in control knob for five

(5) seconds (see Figure 15).

Note:

You may be running this

heaterfor the first time afterhook-

ing up to gas supply. If so, the con-

trol knob may need to be pressed

in for 30 seconds. This will allow

air to bleed from the gas system.

6. With control knob pressedin, push

down and release ignitor button.

This will light pilot.The pilot is at-

tached to the front of burner. The

pilot can be seen through the glass

panel. If needed, keep pressing ig-

nitor button until pilot lights.

Note:

If pilot does not stay lit, re-

fer to Troubleshooting, pages 13

through15.Alsocontact aqualified

service person or gas supplier for

repairs. Until repairs are made,

light pilot with match. To light pi-

lot with match, see Manual Light-

ing Procedure, column 3.

7. Keepcontrolknob pressedin for30

secondsafterlightingpilot.After30

seconds, release control knob.

• If control knob does not pop up

when released, contact a quali-

fied service person or gas sup-

plier for repairs.

OPERATING

HEATER

Continued

IGNITOR

PILOT

OFF

Control

Knob

Ignitor

Button

Note:

If pilot goes out, repeat steps

3 through 7.This heater has a safety

interlocksystem.Waitone (1)minute

before lighting pilot again.

8. Turn control knob counterclockwise

C-clockwise

to desiredheatinglevel.The

mainburnershould light.Set control

knob to any heat level between HI

and LO.

CAUTION: Do not try to ad-

just heating levels by using the

equipment shutoff valve.

Figure 16 - Pilot

Pilot Burner

Ignitor Electrode

Thermocouple

TO TURN OFF GAS

TO APPLIANCE

1. Remove front panel (see Figure 10,

page 8).

2. Followsteps1through5underLight-

ing Instructions, column 1.

3. With control knob pressed in, strike

match. Hold match to pilot until pi-

lot lights.

4. Keep control knob pressed in for 30

seconds after lighting pilot.After 30

seconds,releasecontrolknob.Follow

step 8 under Lighting Instructions.

5. Replace front panel.

Shutting Off Heater

1. Turncontrolknobclockwise

Clockwise

to the OFF position.

2. Turn off all electric power to the ap-

pliance if service is to be performed.

Shutting Off Burner Only (pilot

stays lit)

Turn control knob clockwise

Clockwise

the PILOT position.

THERMOSTAT

CONTROL

OPERATION

The thermostatic control used on these

models differs from standard thermo-

stats. Standard thermostats simply turn

on and off the burner. The thermostat

used on this heater senses the room tem-

perature. The thermostat adjusts the

amount of gas flow to the burner. This

increases or decreases the burner flame

height.Attimestheroommayexceedthe

set temperature. If so, the burner will

shut off. The burner will cycle back on

whenroom temperaturedropsbelowthe

settemperature.Thecontrolknobcanbe

set to any heat level between HI and LO.

Note:

The thermostat sensing bulb mea-

sures the temperature of air near the

heatercabinet.Thismaynotalwaysagree

with room temperature (depending on

housing construction, installation loca-

tion, room size, open air temperatures,

etc.). Frequent use of your heater will let

you determine your own comfort levels.

MANUAL LIGHTING

PROCEDURE

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

GRH/OV 008BAD PILOT/LP

CLEANING AND

MAINTENANCE

CABINET

Air Passageways

• Use a vacuum cleaner or pressurized air

to clean.

Exterior

• Use a soft cloth dampened with a mild

soap and water mixture. Wipe the cabi-

net to remove dust.

WARNING: Turn off heater

and let cool before cleaning.

CAUTION: You must keep

control areas, burner, and circu-

lating air passageways of heater

clean. Inspect these areas of

heater before each use. Have

heaterinspectedyearlybyaquali-

fied service person. Heater may

needmorefrequentcleaningdue

to excessive lint from carpeting,

bedding material, pet hair, etc.

BURNER FLAME PATTERN

Figure 19 shows a correct burner flame

pattern.Figure20showsanincorrectburner

flame pattern. The incorrect burner flame

patternshowsyellowtippingoftheflame.It

also shows the flame higher than 1/2 the

glass panel height.

WARNING: If yellow tipping

occurs, your heater could pro-

duce increased levels of carbon

monoxide.Ifburner flamepattern

shows yellow tipping, follow in-

structions at bottom of this page.

NOTICE: Do not mistake orange

flames with yellow tipping. Dust

or other fine particles enter the

heater and burn causing brief

patches of orange flame.

Figure 19 - Correct Burner Flame Pattern

Figure20-IncorrectBurnerFlamePattern

1/2 GLASS HEIGHT

INSPECTING

BURNER

Check pilot flame pattern and burner flame

pattern often.

PILOT FLAME PATTERN

Figure 17 shows a correct pilot flame pat-

tern. Figure 18 shows an incorrect pilot

flame pattern. The incorrect pilot flame is

not touching the thermocouple. This will

cause the thermocouple to cool. When the

thermocouple cools, the heater will shut

down.

If pilot flame pattern is incorrect, as shown

in Figure 18

• turn heater off (see To Turn Off Gas to

Appliance, page 11)

•

see Troubleshooting, pages 13 through 15

Figure 17 - Correct Pilot Flame Pattern

Figure 18 - Incorrect Pilot Flame Pattern

Ifburnerflamepatternisincorrect,asshown

in Figure 20

• turn heater off (see To Turn Off Gas to

Appliance, page 11)

•

seeTroubleshooting,pages 13 through 15

GRH/OV 009GOOD PILOT

Thermocouple Pilot Burner

1/2 GLASS HEIGHT

Yellow

Tipping

CLEANING BURNER

PILOT AIR INLET HOLE

We recommend that you clean the unit ev-

ery 2,500 hours of operation or every three

months.

Figure 21 - Pilot Inlet Air Hole

Pilot Assembly

Pilot Air Inlet

Hole

Wealsorecommendthatyoukeeptheburner

tube and pilot assembly clean and free of

dustanddirt.Tocleanthesepartswerecom-

mend using compressed air no greater than

30 PSI. Your local computer store, hard-

ware store, or home center may carry com-

pressed air in a can. You can use a vacuum

cleaner in the blow position. If using com-

pressed air in a can, please follow the direc-

tions on the can. If you don't follow direc-

tionsonthecan, youcoulddamagethepilot

assembly.

1. Shut off the unit, including the pilot.

Allow the unit to cool for at least thirty

minutes.

2. Inspect burner, pilot for dust and dirt.

3. Blow air through the ports/slots and

holes in the burner.

Clean the pilot assembly also. A yellow tip

on the pilot flame indicates dust and dirt in

the pilot assembly. There is a small pilot air

inlet hole about two inches from where the

pilot flame comes out of the pilot assembly

(see Figure 21). With the unit off, lightly

blowair throughthe airinlet hole.You may

blowthroughadrinkingstrawifcompressed

air is not available.

105728

OWNER’S MANUAL

TROUBLESHOOTING

Note:

Alltroubleshootingitemsarelistedin

order of operation.

WARNING: Turn off heater

and let cool before servicing.

Only a qualified service person

shouldserviceandrepairheater.

OBSERVED PROBLEM

When ignitor button is pressed, there is no

spark at ODS/pilot

When ignitor button is pressed, there is

spark at ODS/pilot but no ignition

ODS/pilot lights but flame goes out when

control knob is released

CAUTION: Never use a wire,

needle, or similar object to clean

ODS/pilot.ThiscandamageODS/

pilot unit.

POSSIBLE CAUSE

1. Ignitor cable pinched or wet

2. Ignitor electrode not connected to igni-

tor cable

3. Piezo ignitor nut is loose

4. Broken ignitor cable

5. Ignitor electrode broken

6. Bad piezo ignitor

7. Ignitor electrode positioned wrong

1. Gas supply turned off or equipment

shutoff valve closed

2. Control knob not in PILOT position

3. Control knob not pressed in while in

PILOT position

4. Air in gas lines when installed

5. ODS/pilot is clogged

6. Gas regulator setting is not correct

1. Control knob not fully pressed in

2. Control knobnot pressedin longenough

Safetyinterlocksystem hasbeentriggered

4. Equipment shutoff valve not fully open

5. Thermocouple connection loose at con-

trol valve

6. Pilot flame not touching thermocouple,

which allows thermocouple to cool,

causing pilot flame to go out. This prob-

lem could be caused by one or both of

the following:

A) Low gas pressure

B) Dirty or partially clogged ODS/pilot

7. Thermocouple damaged

8. Control valve damaged

REMEDY

1. Free ignitor cable if pinched by any

metal or tubing. Keep ignitor cable dry

2. Reconnect ignitor cable

3. Tighten nut holding piezo ignitor to

heater cabinet. Nut is located inside

heater cabinet at top

4. Replace ignitor cable

5. Replace ignitor

6. Replace piezo ignitor

7. Replace ignitor

1. Turn on gas supply or open equipment

shutoff valve

2. Turn control knob to PILOT position

3. Press in control knob while in PILOT

position

4. Continue holding down control knob.

Repeat igniting operation until air is re-

moved

5. Clean ODS/pilot (see Cleaning and

Maintenance, page 12) or replace ODS/

pilot assembly

6. Replace gas regulator

1. Press in control knob fully

2. After ODS/pilot lights, keep control

knob pressed in 30 seconds

3. Wait one minutefor safetyinterlock sys-

tem to reset. Repeat ignition operation.

4. Fully open equipment shutoff valve

Hand tighten until snug, then tighten 1/4

turn more

6. A) Contact local natural gas company

B) Clean ODS/pilot (see Cleaning and

Maintenance, page 12) or replace ODS/

pilot assembly

7. Replace thermocouple

8. Replace control valve

Continued

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

TROUBLESHOOTING

Continued

OBSERVED PROBLEM

Burner does not light after ODS/pilot is lit

Delayed ignition of burner

Burner backfiring during combustion

Yellow flame during burner combustion

Slightsmokeorodorduringinitialoperation

Heater produces a whistling noise when

burner is lit

Whitepowderresidueformingwithinburner

box or on adjacent walls or furniture

REMEDY

1. Clean burner orifice (see Cleaning and

Maintenance,page 12)or replaceburner

orifice

2. Replace burner orifice

3. Contact local natural gas company

1. Contact local natural gas company

2. Clean burner orifice (see Cleaning and

Maintenance,page 12) orreplace burner

orifice

1. Clean burner orifice (see Cleaning and

Maintenance,page 12) orreplace burner

orifice

2. Contact local natural gas company

3. Replace burner

4. Replace gas regulator

1. Check burner for dirt and debris. If

found, clean burner (see Cleaning and

Maintenance, page 12)

2. Contact local natural gas company

3. Replace gas regulator

1. Problem will stop after a few hours of

operation

1. Turn control knob to LO position and

let warm up for a minute

2. Operateburner until airis removed from

line. Have gas checked by local natural

gas company

3. Observe minimum installation clear-

ances (see Figure 4, page 7)

Clean burner (see Cleaning and Mainte-

nance, page 12) or replace burner orifice

Turn heater off when using furniture

polish, wax, carpet cleaners, or similar

products

POSSIBLE CAUSE

1. Burner orifice is clogged

2. Burner orifice diameter is too small

3. Inlet gas pressure is too low

1. Manifold pressure is too low

2. Burner orifice is clogged

1. Burner orifice is clogged or damaged

2. Inlet gas pressure is too low

3. Burner damaged

4. Gas regulator defective

1. Not enough air

2. Inlet gas pressure is too low

3. Gas regulator defective

1. Residues from manufacturing processes

1. Turning control knob to HI position

when burner is cold

2. Air in gas line

3. Air passageways on heater blocked

4. Dirty or partially clogged burner orifice

1. When heated,vapors from furniture pol-

ish, wax, carpet cleaners, etc. turn into

white powder residue

105728

OWNER’S MANUAL

WARNING: If you smell gas

• Shut off gas supply.

• Do not try to light any appliance.

• Donottouchanyelectricalswitch;donot useany phonein yourbuilding.

• Immediately call your gas supplier from a neighbor’s phone. Follow the

gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

IMPORTANT

: Operating heater where impurities in air exist may create odors. Cleaning

supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc.,

create fumes. These fumes may mix with combustion air and create odors.

POSSIBLE CAUSE

1. Metal expanding while heating or con-

tracting while cooling

1. Heater burning vapors from paint, hair

spray, glues, etc. See

IMPORTANT

statement above.

2. Gas leak. SeeWarning statement at

top of page

1. Not enough fresh air is available

2. Low line pressure

3. ODS/pilot is partially clogged

1. Gas leak. SeeWarning statement at

top of page

2. Control valve defective

1. Foreign matter between control valve

and burner

2. Gas leak. SeeWarning statement at

top of page

1. Not enough combustion/ventilation air

OBSERVED PROBLEM

Heater produces a clicking/ticking noise

just after burner is lit or shut off

Heater produces unwanted odors

Heater shuts off in use (ODS operates)

Gasodorevenwhencontrolknob isinOFF

position

Gas odor during combustion

Moisture/condensationnoticedonwindows

REMEDY

1. This is common with most heaters. If

noise is excessive, contact qualified ser-

vice person

1. Ventilate room. Stop using odor-causing

products while heater is running

2. Locate and correct all leaks (see Check-

ing Gas Connections, page 10)

Open window and/or door for ventilation

2. Contact local natural gas company

3. Clean ODS/pilot (see Cleaning and

Maintenance, page 12)

1. Locate and correct all leaks (see Check-

ing Gas Connections, page 10)

2. Replace control valve

1. Take apart gas tubing and remove for-

eign matter

2. Locate and correct all leaks (see Check-

ing Gas Connections, page 10)

1. Refer to Air for Combustion and Venti-

lation requirements (page 4)

TROUBLESHOOTING

Continued

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

ILLUSTRATED

PARTS

BREAKDOWN

MBN10TLA

21 22

23 19

12-1

12-2

ODS/PILOT

105728

OWNER’S MANUAL

PARTS LIST

MBN10TLA

This list contains replaceable parts used in your heater. When ordering parts, follow the

instructions listed under Replacement Parts on page 18 of this manual.

KEY PART

NO. NUMBER DESCRIPTION QTY.

1 098304-01 Screw, #10 x 3/8" 2

2 099467-08 Front Panel Assembly 1

3 099318-04 Grill Guard 1

4 101108-01 Grill Guard Clip 2

5 102017-02 Bottom Glass Retainer 1

6 098260-11 Glass Panel 1

7 098532-06AA Top Glass Retainer 1

8 M11084-38 Screw, #8 x 3/8" 8

9 098352-03BR Deflector Unit 1

10 098271-03 Ignitor Cable 1

11 098249-01 Nut, M5 2

12 100701-03 ODS/Pilot Assembly 1

12-1 098514-01 Thermocouple 1

12-2 098594-01 Ignitor Electrode 1

13 104263-01 Burner 1

14 099387-11 Pilot Tubing 1

15 104259-05 Injector, 1 Piece 1

16 NJF 8C Hex Nut 1

17 099415-14 Pressure Regulator 1

18 104261-01 Burner Tubing 1

19 104264-01 Regulator Tubing 1

20 098522-11 Thermostat Gas Valve 1

21 102571-04 Cabinet Assembly 1

22 097159-04 Piezo Ignitor 1

23 099553-01 Pilot Shield 1

24 098303-02 Screw, #6 x 5/16" 2

PARTS AVAILABLE - NOT SHOWN

102471-01 Control Position Label 1

100642-02 Assembly, Hardware 1

105728

VENT-FREE NATURAL GAS HEATER

MBN10TLA

™

Note:

Use only original replacement parts.

Thiswillprotectyourwarrantycoveragefor

parts replaced under warranty.

PARTS UNDER WARRANTY

Contactauthorizeddealerfromwhomyoupur-

chasedthisproduct.Iftheyareunabletosupply

original replacement part(s), call Cans Unlim-

ited, Incorporated’s Technical Service Depart-

ment at 1-800-922-7407 for information.

When contacting your dealer or Cans Un-

limited, Incorporated, have ready:

• your name

• your address

• model and serial numbers of your heater

• how heater was malfunctioning

• typeofgasused(propane/LPornaturalgas)

• purchase date

Usually,wewillaskyoutoreturnthedefec-

tive part to the factory.

PARTS NOT UNDER

WARRANTY

Contact authorized dealers of this product.

If they cannot supply original replacement

part(s), either contact Cans Unlimited,

Incorporated’s Parts Department at 1-800-

922-7407 for referral information.

WhencallingCansUnlimited,Incorporated,

have ready:

• model number of your heater

• the replacement part number

REPLACEMENT

PARTS

EQUIPMENT SHUTOFF

VALVE - GA5010

Equipmentshutoffvalvewith1/8"NPTtap.

ACCESSORY

Purchasetheseheateraccessoriesfromyour

local dealer. If they cannot supply this ac-

cessories, either contact Cans Unlimited,

Incorporated’s Parts Department at 1-800-

922-7407 for referral information. You can

also write to the address listed on the back

page of this manual.

TECHNICAL

SERVICE

You may have further questions about in-

stallation, operation, or troubleshooting.

If so, contact Cans Unlimited,

Incorporated’s Technical Service Depart-

ment at 1-800-922-7407.

SPECIFICATIONS

When Gas Pressure Is Too Low

• pilot will not stay lit

• burner will have delayed ignition

• heater will not produce specified heat

When Gas Quality Is Bad

• pilot will not stay lit

• burner will produce flames and soot

• heater will backfire when lit

Youmayfeelyourgaspressureistoolowor

gas quality is bad. If so, contact your local

natural gas supplier.

SERVICE HINTS

Btu (Variable) 5,000/10,000

Type Gas Natural Only

Ignition Piezo

Pressure Regulator Setting 3" W.C.

Inlet Gas Pressure (inches of water)

Maximum 10.5"

Minimum 5"

Dimensions, Inches (H x W x D)

Heater (Including knobs and grill) 21 1/2x 13 1/2x 7

Carton 25 1/4x 16 3/4x 7 1/2

Weight (pounds)

Shipping 19

105728

OWNER’S MANUAL

NOTES

_______________________________________________________________________________________________

KEEP THIS WARRANTY

Model

Serial No.

Date Purchased

Always specify model and serial numbers when communicating with the factory.

We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written

warranty. We make no other warranty, expressed or implied.

WARRANTY INFORMATION

LIMITED WARRANTY

MEDALLION VENT-FREE HEATERS

CansUnlimited, Incorporated warrants this product tobefreefrom defects in materials and components fortwo(2)years from the

date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all

applicable instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.

Thiswarrantyisextendedonlytotheoriginalretailpurchaser.Thiswarrantycoversonlythecostofpart(s)requiredtorestorethisheater

toproperoperatingconditionandanallowanceforlaborwhenprovidedbyaCansUnlimited,IncorporatedAuthorizedServiceCenter.

Warrantypart(s)MUSTbeobtainedthroughauthorizeddealersofthisproductand/orCansUnlimited,Incorporatedwhowillprovide

originalfactoryreplacementparts.Failuretouseoriginalfactoryreplacementpartsvoidsthiswarranty.TheheaterMUSTbeinstalled

by a qualified installer in accordance with all local codes and instructions furnished with the unit.

This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts that fail or become

damaged as a result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. Travel, diagnostic

cost,labor,transportationandanyandallsuchothercostsrelatedtorepairingadefectiveheaterwillbetheresponsibility oftheowner.

TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE OF THE

PRODUCT; THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED WARRANTIES AND

LIMITSTHEDURATIONOF ANYAND ALLIMPLIEDWARRANTIES,INCLUDINGWARRANTIESOFMERCHANTA-

BILITYANDFITNESSFORAPARTICULARPURPOSETOTWO(2)YEARSONALLCOMPONENTS FROMTHEDATE

OF FIRST PURCHASE: AND CANS UNLIMITED, INCORPORATED’S LIABILITY IS HEREBY LIMITED TO THE

PURCHASEPRICEOF THEPRODUCTAND CANS UNLIMITED,INCORPORATEDSHALL NOTBELIABLEFOR ANY

OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Somestatesdonotallowalimitationonhowlonganimpliedwarrantylastsoranexclusionorlimitationofincidentalorconsequential

damages, so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.

For information about this warranty write:

105728-01

Rev. B

03/00

105728 01

NOT A UPC

Distributed by: C.U.I.

Cans Unlimited, Incorporated

1700 Poplar Drive

Greer, SC 29651

GAS PRODUCTS

™

Table of contents

Other Medallion Gas Heater manuals

Medallion

Medallion MR16P Quick start guide

Medallion

Medallion MR10PT Quick start guide

Medallion

Medallion MBN10LA Quick start guide

Medallion

Medallion MBP20LB Quick start guide

Medallion

Medallion MBP20TLB Quick start guide

Medallion

Medallion MBN20LB Quick start guide

Medallion

Medallion MBN20TLB Quick start guide

Medallion

Medallion MBP10LA Quick start guide

Popular Gas Heater manuals by other brands

Sealey

Sealey CH4200.V3 manual

Beretta

Beretta CIAO e 24 - 28 C.S.I. Installation and user manual

Superior Fireplaces

Superior Fireplaces LMF30GT Assembly, installation and operation instructions

BENSON

BENSON RS Use and maintenance instructions

USSC

USSC Ambiance B9945L Installation and operation instructions

pleasant hearth

pleasant hearth VFL3-SO18DT manual

White Mountain Hearth

White Mountain Hearth LS-18RS-1 Installation instructions and owner's manual

Dru

Dru ART 2 Instructions for installation and operation

White Mountain Hearth

White Mountain Hearth LS-18H-1 Installation instructions and owner's manual

Hearth and Home Technologies

Hearth and Home Technologies HEAT-OUT-GAS installation instructions

HearthStone

HearthStone Killington owner's manual

Dyna-Glo

Dyna-Glo Delux RMC-KFA400TDGD User's manual and operating instructions

Viessmann

Viessmann VITOCROSSAL 200 CI2 Series installation instructions

Roberts Gorden

Roberts Gorden CORAYVAC CRVB12PN instructions

Dyna-Glo

Dyna-Glo RMC- 55R7 owner's manual

Dyna-Glo

Dyna-Glo BF10DTL-2 manual

MrHeater

MrHeater MHVFR20TB NG owner's manual

Dura Heat

Dura Heat GFA40 user manual

Medallion MBN10TLA Quick start guide

Popular Gas Heater manuals by other brands
