Medion Notebook Computer User manual

NOTES ON THIS MANUAL
Keep these instructions with your computer at all times. The
proper set up, use and care can help extend the life of your com-
puter. In the event that you transfer ownership of this computer,
please provide these instructions to the new owner.
This manual is divided into sections to help you find the informa-
tion you require. Along with the Table of Contents, an Index
has been provided to help you locate information.
In addition, many application programs include extensive help
functions. As a general rule, you can access help functions by
pressing F1 on the keyboard. These help functions are available to
you when you use the Microsoft Windows®operating system or
the various application programs.
We strongly recommend that you read the Online Manual for your
Notebook, which can be found in the Start Menu.
ÂImportant: Additional information about your
notebook can be found in the online help in the
Start Menu of your notebook. Click on:
Information about your notebook
This interactive manual is designed to provide additional informa-
tion about your Notebook as well as useful links accessible via the
World Wide Web.
Windowsxp invites you to a tour (notes on the task bar) to famil-
iarize yourself with the operating system. We listed further useful
sources of information starting on page 64.

ii
AUDIENCE
These instructions are intended for both the novice and advanced
user. Regardless of the possible professional utilization, this Note-
book is designed for day-to-day household use. The functions and
applications for use with this Notebook have been designed with
the entire family in mind.
DOCUMENT YOUR NOTEBOOK
It is important to document the details of your Notebook purchase
in the event you need warranty service. The serial number can be
found on the back of the Notebook:
Serial Number ......................................
Date of Purchase ......................................
Place of Purchase ......................................
QUALITY
We have selected the components in this computer for their high
level of functionality, ease of use, safety and reliability.
Through balanced hardware and software design we are able to
provide you with an innovative personal computer useful for ap-
plications relating to both work and leisure.
We are pleased to welcome you as our newest customer.
