Medion Notebook Computer User manual

NOTES ON THIS MANUAL
Keep these instructions with your computer at all times. The
proper set up, use and care can help extend the life of your com-
puter. In the event that you transfer ownership of this computer,
please provide these instructions to the new owner.
This manual is divided into sections to help you find the informa-
tion you require. Along with the Table of Contents, an Index
has been provided to help you locate information.
In addition, many application programs include extensive help
functions. As a general rule, you can access help functions by
pressing F1 on the keyboard. These help functions are available to
you when you use the Microsoft Windows®operating system or
the various application programs.
We strongly recommend that you read the Online Manual for your
Notebook, which can be found in the Start Menu.
Information about your PC
This interactive manual is designed to provide additional informa-
tion about your Notebook as well as useful links accessible via the
World Wide Web.
Windowsxp invites you to a tour (notes on the task bar) to familiar-
ize yourself with the operating system. We listed further useful
sources of information starting on page 57.
AUDIENCE
These instructions are intended for both the novice and advanced
user. Regardless of the possible professional utilization, this Note-
book is designed for day-to-day household use. The functions
and applications for use with this Notebook have been designed
with the entire family in mind.

ii
DOCUMENT YOUR NOTEBOOK
It is important to document the details of your Notebook purchase
in the event you need warranty service. The serial number can be
found on the back of the Notebook:
Serial Number ......................................
Date of Purchase ......................................
Place of Purchase ......................................
QUALITY
Medion has selected the components in this computer for their
high level of functionality, ease of use, safety and reliability.
Through balanced hardware and software design we are able to pro-
vide you with an innovative personal computer useful for applications
relating to both work and leisure.
We are pleased to welcome you as our newest customer. Thank
you for choosing Medion.
SERVICE
Medion is pleased to provide individualized customer service
throughout the life of your Notebook. Please feel free to contact a
customer service representative with any questions relating to
this Notebook.
Copyright©2005 Medion®. All rights reserved. Microsoft®, MS-DOS®, and Windows are regis-
tered trademarks of Microsoft Corporation in the U.S. and other countries. Pentium® is a regis-
tered trademark of Intel Corporation. The names of actual companies and products mentioned
herein may be the trademarks of their respective owners.
This product incorporates copyright protection technology that is protected by method claims
of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection technology must be authorised by
Macrovision Corporation, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is pro-
hibited.
Information in this document is subject to change without notice.
