MediterraneanTan MediterraneanTan Ultra User manual

INSTRUCTION MANUAL
T
ANNING SYSTEM
(Not Suitable for Continuous Use)
DO NOT USE EQUIPMENT BEFORE READING THIS MANUAL
This manual contains important warnings and instructions.
Please read these instructions carefully and keep for your reference.
©2012 Solaire Pty Ltd
Unit 5, 32 Essington Street, Grovedale, 3216 email: [email protected]
Ph: 1300 650 079 www.solaire.com.au
DO NOT USE EQUIPMENT BEFORE READING THIS MANUAL
This manual contains important warnings and instructions.
Please read these instructions carefully and keep for your reference.
Please ll out the warranty card at the back to obtain warranty.
Please refer to video on website for additional assembly, use,
maintenance and cleaning instructions.
© 2015 Mediterranean Tan™
Unit 4, 32 Essington Street, Grovedale, 3216, Australia.
email: [email protected]
Ph: 1300 826 929
International: [phone]
www.mtwb.com.au
12 Month Warranty
INSTRUCTION MANUAL
TANNING SYSTEM
(Not Suitable for Continuous Use)
DO NOT USE EQUIPMENT BEFORE READING THIS MANUAL
This manual contains important warnings and instructions.
Please read these instructions carefully and keep for your reference.
©2012 Solaire Pty Ltd
Unit 5, 32 Essington Street, Grovedale, 3216 email: [email protected]
Ph: 1300 650 079 www.solaire.com.au
(Suitable for up to 20 sprays per day)
The Mediterranean Tan™ Ultra sound level is: 62db
ULTRA

Table of Contents
1. General Safety Information: ....................................................................................................................4
2. Set up and operate your Mediterranean Tan™ Ultra Spray Tan System: ..........................................5
3. Prepare the Micro-intel Spray Gun .........................................................................................................6
4. Adjusting the Micro-intel Spray Gun ......................................................................................................8
5. Spraying ....................................................................................................................................................9
6. Maintenance .............................................................................................................................................10
7. Troubleshooting .......................................................................................................................................12
The Mediterranean Tan™ Ultra is easy to use anywhere, whether it be
at home, in a client’s home or as a small start up business.
The Mediterranean Tan™ Ultra is easy to use
and highly cost effective since the solution goes on the client not in the air.
We predict that you’ll discover the Mediterranean Tan™ Ultra to be the simplest
most wonderfully designed home or start up spray tan unit you’ve ever used.
Superbly designed and engineered with the feedback from you, the spray tanner.
Mediterranean Tan™ Ultra Instruction Manual
Congratulations on purchasing the Mediterranean Tan™ Ultra tanning system. This product has been specially designed
to provide the best application of professional spray tanning solutions.
Take a minute to read and understand how to operate your new Mediterranean Tan™ Ultra tanning system and you will be
able to provide the perfect tan with every application.
Please watch the instructional video at http://www.mtwb.com.au/Main.asp?_=Videos
Your Mediterranean Tan™ Ultra is packaged with the following:
1. Mediterranean Tan™ Ultra unit.
2. 2.5m Flexible Plastic Hose
3. Micro-intel Spray Gun
4. Electrical lead
5. Instruction Manual (see website)
6. Warranty Card
3
ULTRA

4
1. General Safety Information
Read all instructions and safety precautions before operating the unit.
THIS INDICATES A CONDITION THAT WILL CAUSE SERIOUS INJURY OR LOSS OF LIFE IF THE WARNING IS
IGNORED.
THIS INDICATES A CONDITION THAT COULD CAUSE SERIOUS INJURY OR LOSS OF LIFE IF THE WARNING IS
IGNORED.
THIS INDICATES A CONDITION THAT MAY CAUSE MINOR INJURY AND/OR EQUIPMENT/PROPERTY DAMAGE.
GROUNDING INSTRUCTIONS
This product must be properly grounded. In the event of an electrical short circuit, grounding reduces the risk of electrical
shock by providing an alternate path for the electrical current.
This product is equipped with a cord that has a ground wire and an appropriate ground plug. Plug the unit into an outlet
that is properly installed and grounded in accordance with local codes and ordinances.
IMPROPER INSTALLATION OF THE GROUND PLUG CAN RESULT IN THE RISK OF
ELECTRICAL SHOCK. IF REPAIR OR REPLACEMENT OF THE PLUG OR CORD IS
NECESSARY, DO NOT CONNECT THE GROUND WIRE TO EITHER FLAT BLADE
TERMINAL. THE WIRE WITH GREEN INSULATION (WITH OR WITHOUT A YELLOW
STRIPE) IS THE GROUNDING WIRE.
1. For any question regarding proper installation of the ground plug, consult a qualied
(licensed or certied) electrician.
2. Do not modify the plug provided. If the plug does not t the outlet, have the proper
outlet installed by a qualied electrician.
3. This product is for use on a nominal 240-volt circuit and has a grounding plug that
looks like the plug in Figure 2. Make sure that the product is connected to an outlet
having the same conguration as the plug. No adapters should be used with this
product.
4. If an extension cord is required, use only a three wire extension cord that has the
same conguration as the unit cord, including the ground terminal. Make
sure that the extension cord is plugged into a properly grounded receptacle.
5. When using an extension cord, be sure it is in good condition and meets specications.
6. Ensure the Mediterranean Tan™ Ultra is tagged and tested every 12 months after initial purchase to comply with Aus-
tralian Electrical Safety standards.
3
1 General Safety Information:
Read all instructions and safety precautions before operating the unit.
THIS INDICATES A CONDITION THAT WILL CAUSE SERIOUS INJURY OR LOSS OF LIFE IF THE WARNING IS
IGNORED.
THIS INDICATES A CONDITION THAT COULD CAUSE SERIOUS INJURY OR LOSS OF LIFE IF THE WARNING IS
IGNORED.
THIS INDICATES A CONDITION THAT MAY CAUSE MINOR INJURY AND/OR
EQUIPMENT/PROPERTY DAMAGE.
• Risk of fire or explosion! Solvent and paint fumes can explode or ignite, causing severe
injury and property damage.
• Paints and solvents containing HALOGENATED HYDROCARBONS can react explosively
with aluminum. Always check the product’s label before using these materials in the unit.
• Hazardous vapors: Paint, solvents, insecticides and other materials may be harmful if
inhaled, causing severe nausea, fainting or poisoning.
• Make sure the room is well ventilated. Avoid all ignition sources, such as static electricity
sparks, open flames, hot objects, sparks from connecting and disconnecting power cords,
and working light switches.
• Follow the material and solvent manufacturers’ safety precautions and warnings. Do not
use liquids with flash points less than 100 degrees Fahrenheit (38 degrees Celsius).
• Static electricity can be produced by HVLP spraying. Make sure any electrically conductive
object being sprayed is grounded to prevent static sparking. The sprayer is grounded to
prevent static sparking. The spray grounded through the electrical cord. If an extension
cord is necessary, the cord must be a grounded with three wires made for the appropriate
voltage used.
• Use a respirator or mask whenever there is a chance that vapors may be inhaled. Read
all instructions with the mask to ensure that the mask will provide the necessary
protection against the inhalation of harmful vapors.
• Do not carry the turbine while spraying.
• Keep the turbine at the maximum distance from the spraying area.
4
1 General Safety Information cont’d.:
• Tipping the Spray Gun causes the Spray Gun to clog. Dried spray material also clogs the pressure delivery tube
and fittings. The Spray Gun does not function when clogging occurs.
• When not in use, be sure to disconnect the hose and place the Spray Gun into the holder in the turbine to avoid
tipping.
GROUNDING INSTRUCTIONS
This product must be properly grounded. In the event of an electrical short circuit, grounding reduces the risk of electrical
shock by providing an alternate path for the electrical current.
This product is equipped with a cord that has a ground wire and an appropriate ground plug. Plug the unit into an outlet
that is properly installed and grounded in accordance with local codes and ordinances.
IMPROPER INSTALLATION OF THE GROUND PLUG CAN RESULT IN THE RISK OF
ELECTRICAL SHOCK. IF REPAIR OR REPLACEMENT OF THE PLUG OR CORD IS
NECESSARY, DO NOT CONNECT THE GROUND WIRE TO EITHER FLAT BLADE TERMINAL.
THE WIRE WITH GREEN INSULATION (WITH OR WITHOUT A YELLOW STRIPE) IS THE
GROUNDING WIRE.
1. For any question regarding proper installation of the ground plug, consult a qualified
(licensed or certified) electrician.
2. Do not modify the plug provided. If the plug does not fit the outlet, have the proper
outlet installed by a qualified electrician.
3. This product is for use on a nominal 240-volt circuit and has a grounding plug that
looks like the plug in Figure 2. Make sure that the product is connected to an outlet
having the same configuration as the plug. No adapters should be used with this
product.
4. If an extension cord is required, use only a three wire extension cord that has the
same configuration as the unit cord, including the (round) ground terminal. Make
sure that the extension cord is plugged into a properly grounded receptacle.
5. When using an extension cord, be sure it is in good condition and heavy enough to
meet the specifications in the chart below. If an extension cord is needed the
following wire sizes must be used.
6. (See Chart 1) Figure 2
25’ cord……………………..…….10, 12, or 14 Gauge
50’ cord……………………….………..10 or 12 Gauge
100’ cord………………………………………10 Gauge
Chart 1 Extension Cord Requirements
4
