Mega Motion Travel Pal User manual

Mega Motion Inc.
P.O. Box 275
Taylor, PA 18517-0275
1-800-MEGA-508
Owner’s Manual
*INFMANU3199*
Mega Motion, Inc.
P.O. Box 275
Taylor, PA 18517-0275
www.mega-motion.com

Mega Motion Service Center:________________________________________________________
Address: ________________________________________________________________________
Phone Number:__________________________
Purchase Date: __________________________ Serial Number:____________________________
SAFETY GUIDELINES
Copyright © 2009
Mega Motion Inc.
INFMANU3199/Rev B/August 2009
The symbols below are used throughout this owner's manual and on the scooter to identify warnings and
important information. It is very important for you to read them and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow
designated procedures can cause either personal injury, component damage or
malfunction. On the product, this icon is represented as a black symbol on a yellow
triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause personal injury and/or equipment damage. On the product,
this icon is represented as a white symbol on a blue dot.
PROHIBITED! These actions are prohibited. These actions should not be performed at
any time or in any circumstances. Performing a prohibited action can cause personal
injury and/or equipment damage. On the product, this icon is represented as a black
symbol with a red circle and a red slash.
Please fill out the following information for quick reference:
NOTE: This owner’s manual is compiled from the latest specifications and product information avail-
able at the time of publication. We reserve the right to make changes as they become necessary. Any
changes to our products may cause slight variations between the illustrations and explanations in this
manual and the product you have purchased.
DO NOT RETURN THIS PRODUCT TO THE
STORE. CALL 1-800-MEGA-508 FIRST.
STOP

3
Travel Pal www.mega-motion.com
CONTENTS
I. INTRODUCTION .......................................................................................................................4
II. SAFETY ........................................................................................................................................5
III. YOUR TRAVEL SCOOTER ...................................................................................................17
IV. BATTERIES AND CHARGING ..........................................................................................21
V. OPERATION .............................................................................................................................26
VI. DISASSEMBLY AND ASSEMBLY ...................................................................................28
VII. BASIC TROUBLESHOOTING ...........................................................................................29
VIII. CARE AND MAINTENANCE .............................................................................................31
IX. WARRANTY ..............................................................................................................................34
APPENDIX I - SPECIFICATIONS ..............................................................................................36

4www.mega-motion.com Travel Pal
I. INTRODUCTION
SAFETY
Welcome to Mega Motion Inc . The product you have purchased combines state of the art components with
safety, comfort, and styling in mind. We are confident the design features will provide you with the con-
veniences you expect during your daily activities. Understanding how to safely operate and care for this
product should bring you years of trouble free operations and service.
Read and follow all instructions, warnings and notes in this manual and all other accompanying literature
before attempting to operate this product for the first time. In addition, your safety depends upon you, as
well as your provider, caregiver, or healthcare professional in using good judgement.
If there is any information in this manual which you do not understand, or if you require additional assis-
tance for setup or operation, please contact 1-800-MEGA-508. Failure to follow the instructions, warn-
ings, and notes in this manual and those located on your Mega Motion product can result in personal
injury or product damage and will void Mega Motion’s product warranty.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter, or modify this product
or remove or render inoperable or unsafe any guards, shields, or other safety features of this product; fail,
refuse, or neglect to install any retrofit kits from time to time provided by Mega Motion to enhance or
preserve the safe use of this product.
SHIPPING AND DELIVERY
Before using your scooter, make sure your delivery is complete as some components may be individually
packaged. If you do not receive a complete delivery, please contact Mega Motion immediately. Where
damage has occurred during transport, either to the packaging or content, please contact the delivery com-
pany responsible.
INFORMATION EXCHANGE
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear
about the safety and reliability of your new Travel Scooter, and about the service you received from Mega
Motion. Please notify us of any change of address, so we can keep you apprised of important information
about safety, new products, and new options that can increase your ability to use and enjoy your Travel
Scooter. Please feel free to contact us at the address below:
Mega Motion Inc.
P.O. Box 275
Taylor, PA 18517-0275
1-800-MEGA-508
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact
us and we will be glad to send you a new one immediately.

5
Travel Pal www.mega-motion.com
PRODUCT SAFETY SYMBOLS
The symbols below are used on the Travel Scooter to identify warnings, mandatory actions, and prohibited
actions. It is very important for you to read and understand them completely.
Corrosive chemicals contained in battery.
Maximum weight capacity.
Place unit on level ground and stand to one side when changing from drive mode
to freewheel mode or freewheel mode to drive mode.
Locked and in drive mode.
Unlocked and in freewheel mode.
II. SAFETY
Read and follow the information in the owner’s manual.
Pinch/Crush points created during assembly.
EMI-RFI- This product has been tested and passed at an immunity level of 20 V/m.
Use only AGM or Gel-Cell batteries.

6www.mega-motion.com Travel Pal
II. SAFETY
Do not remove anti-tip wheels.
Do not connect an extension cord to the AC/DC converter or the battery charger.
Keep tools and other metal objects away from battery terminals. Contact with
tools can cause electrical shock.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.
Maintain and store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while
operating.
Wear safety goggles.
Contains Lead.

7
Travel Pal www.mega-motion.com
II. SAFETY
Explosive conditions exist!
Do not place the Travel Scooter in freewheel mode on a decline or incline.
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and
new batteries. Always replace both batteries at the same time.
Battery charger for indoor use only.
Disposal and recycling — Contact your local recycling center for information on
proper disposal and recycling of your Mega Motion product and its packaging.
Do not allow unsupervised children to play near the Travel Scooter while the
batteries are charging.
Keep your hands away from the tires when driving. Be aware that loose fitting
clothing can become caught in drive tires.

8www.mega-motion.com Travel Pal
II. SAFETY
GENERAL
Your Travel Scooter is a state-of-the-art life-enhancement device designed to increase mobility. Mega
Motion provides an extensive variety of products to best fit the individual needs of the Travel Scooter user.
Please be aware that the final selection and purchasing decision regarding the type of Travel Scooter to be
used is the responsibility of the Travel Scooter user who is capable of making such a decision.
The contents of this manual are based on the expectation that a mobility device expert has properly fitted
the Travel Scooter to the user and has assisted Mega Motion in the instruction process for the use of the
product.
There are certain situations, including some medical conditions, where the Travel Scooter user will need
to practice operating the Travel Scooter in the presence of a trained attendant. A trained attendant can be
defined as a family member or care professional specially trained in assisting a Travel Scooter user in
various daily living activities.
As you begin using your Travel Scooter during daily activities, you will probably encounter situations in
which you will need some practice. Simply take your time and you will soon be in full and confident
control as you maneuver through doorways, on and off elevators, up and down ramps, and over moderate
terrain.
Below are some precautions, tips, and other safety considerations that will help the user become accus-
tomed to operating the Travel Scooter safely.
MODIFICATIONS
Mega Motion has designed and engineered your Travel Scooter to provide maximum mobility and utility.
However, under no circumstances should you modify, add, remove, or disable any feature, part, or func-
tion of your Travel Scooter.
WARNING! Do not modify your Travel Scooter in any way not authorized by Mega Motion.
Do not use accessories if they have not been tested or approved for Mega Motion
products.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move your Travel Scooter by any of its removable
parts, including the armrests, seat, or shroud.
PRE-RIDE SAFETY CHECK
Get to know the feel of your Travel Scooter and its capabilities. Mega Motion recommends that you per-
form a safety check before each use to make sure your Travel Scooter operates smoothly and safely.
MANDATORY! Do not operate your new Travel Scooter for the first time without
completely reading and understanding this owner’s manual.

9
Travel Pal www.mega-motion.com
II. SAFETY
Perform the following inspections prior to using your Travel Scooter:
Maintain but do not exceed the psi/bar/kPa air pressure rating indicated on each tire if equipped with
pneumatic tires.
Check all electrical connections. Make sure they are tight and not corroded.
Check all controller connections to the electronics tray. Make sure they are secured properly.
Check the brakes (freewheel lever in drive mode).
Check battery charge.
If you discover a problem, contact 1-800-MEGA-508 for assistance.
WEIGHT LIMITATIONS
Your Travel Scooter is rated for a maximum weight capacity. Refer to the specifications table for
information. Keep in mind that the maximum weight capacity includes the combined weight of the user
and any accessories mounted to the Travel Scooter.
MANDATORY! Stay within the specified weight capacity for your Travel Scooter. Exceeding
the weight capacity voids your warranty. Mega Motion will not be held responsible for
injuries and/or property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your Travel Scooter. Carrying passengers on your
Travel Scooter may affect the center of gravity, resulting in a tip or a fall.
TIRE INFLATION
If your Travel Scooter is equipped with pneumatic tires, you should check or have the air pressure checked
regularly. Proper inflation pressures will prolong the life of your tires and help ensure the smooth operation
of your power chair.
WARNING! It is important that the psi/bar/kPa air pressure rating indicated on the tire be
maintained in pneumatic tires at all times. Do not underinflate or overinflate your tires.
Low pressure may result in loss of control, and overinflated tires may burst. Failure to
maintain the psi/bar/kPa air pressure rating indicated on the pneumatic tires at all times
may result in tire and/or wheel failure.
WARNING! Inflate your Travel Scooter drive tires from a regulated air source with an
available pressure gauge. Inflating your tires from an unregulated air source could
overinflate them, resulting in a burst tire.
NOTE: If the tires on your Travel Scooter list the psi rating only, use the following conversion formulas
to find the bar or kPa rating: bar = psi x 0.06895; kPa = psi x 6.89476.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe
access. Some ramps may have turning switchbacks (180-degree turns) that require you to have good cor-
nering skills on your Travel Scooter.
Proceed with extreme caution as you approach the downgrade of a ramp or other incline.
Take wide swings with your Travel Scooter around any tight corners. If you do that, the Travel
Scooter’s rear wheels will follow a wide arc, not cut the corner short, and not bump into or get hung
up on any railing corners.
When driving down a ramp, keep the Travel Scooter’s speed adjustment set to the slowest speed setting
to ensure a safely controlled descent.
Avoid sudden stops and starts.

10 www.mega-motion.com Travel Pal
II. SAFETY
Figure 1. Maximum Recommended Incline Angles
260 lbs.
(117.9 kg)
6° (10.5%)
200 lbs.
(90.72 kg)
7° (12.3%)
150 lbs.
(68 kg)
8° (14.1%)
When climbing an incline, try to keep your Travel Scooter moving. If you must stop, start up again slowly,
and then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial
to the slowest setting and driving in the forward direction only. If your Travel Scooter starts to move down
the incline faster than you anticipated or desired, allow it to come to a complete stop by releasing the
throttle control lever. Then push the throttle control lever forward slightly to ensure a safely controlled
descent.
WARNING! When on any sort of an incline or decline, never place the Travel
Scooter in freewheel mode, especially while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the
face of the incline. Drive your Travel Scooter straight up the incline. This greatly
reduces the possibility of a tip or a fall. Always exercise extreme caution when
negotiating an incline.
WARNING! Do not drive your Travel Scooter across the side of an incline or
diagonally up or down an incline; do not stop, if possible, while driving up or
down an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e.,
areas covered with snow, ice, cut grass, or wet leaves).
WARNING! Even though your Travel Scooter is capable of climbing slopes
greater than those illustrated in figure 1, do not, under any circumstances,
exceed the incline guidelines or any other specifications presented in this
manual. Doing so could cause instability in your Travel Scooter.
Handicap public access ramps are not subject to government regulation in all countries, and therefore do
not necessarily share the same standard degree of slope. Other inclines may be natural or, if man-made,
not designed specifically for Travel Scooters. Figure 1 illustrates your Travel Scooter’s stability and its
ability to climb grades under various weight loads and under controlled testing conditions.
These tests were conducted with the Travel Scooter’s seat in the highest position and adjusted rearward on
the seat base to its farthest rearward position. Use this information as a guideline. Your Travel Scooter’s
ability to travel up inclines is affected by your weight, your Travel Scooter’s speed, your angle of approach
to the incline, and your Travel Scooter setup.
WARNING! Never carry an oxygen tank weighing more than 15 lbs. (6.8 kg). Never fill the
front or rear basket with contents exceeding 15 lbs. (6.8 kg).
WARNING! Any attempt to climb or descend a slope steeper than what is shown in figure
1 may put your Travel Scooter in an unstable position and cause it to tip.

11
Travel Pal www.mega-motion.com
II. SAFETY
Figure 2. Normal Driving Position
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility
of tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning),
uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction
(such as passing from a grassy area to a paved area – especially at high speed while turning), and abrupt
directional changes. High cornering speeds are not recommended. If you feel that you may tip over in a
corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your Travel
Scooter from tipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable center of
gravity. When using your Travel Scooter at higher speeds, do not corner sharply. This
greatly reduces the possibility of a tip or fall.
BRAKING INFORMATION
Your Travel Scooter is equipped with these powerful brake systems:
Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the
center/stop position.
Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or
when power is removed from the system for any reason.
When you approach an incline, it is best to lean forward. See figures 2 and 2A. This shifts the center of
gravity of you and your Travel Scooter toward the front of the Travel Scooter for improved stability.
NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the
powered Travel Scooter may roll back approximately 1 foot (30.48 cm) before the brake engages. If the
throttle control lever is released while moving in reverse, the powered Travel Scooter may roll back
approximately 3 feet (1 meter) before the brake engages.
Figure 2A. Increased Stability Driving Position

12 www.mega-motion.com Travel Pal
II. SAFETY
Figure 3. Correct Curb Approach Figure 4. Incorrect Curb Approach
OUTDOOR DRIVING SURFACES
Your Travel Scooter is designed to provide optimum stability under normal driving conditions—dry, level
surfaces composed of concrete, blacktop, or asphalt. However, Mega Motion recognizes that there will be
times when you will encounter other surface types. For this reason, your Travel Scooter is designed to
perform admirably on packed soil, grass, and gravel. Feel free to use your Travel Scooter safely on lawns
and in park areas.
Avoid driving on uneven terrain and/or soft surfaces.
Avoid tall grass that can become tangled in the running gear or wrapped around the axle.
Avoid loosely packed gravel and sand.
Do not use your Travel Scooter in fresh or salt water.
Do not use your Travel Scooter at the edge of a stream, lake, or ocean.
If you feel unsure about a driving surface, avoid that surface.
PUBLIC STREETS AND ROADWAYS
WARNING! You should not operate your Travel Scooter on public streets and roadways.
Be aware that it may be difficult for traffic to see you when you are seated on your Travel
Scooter. Obey all local pedestrian traffic rules. Wait until your path is clear of traffic, and
then proceed with extreme caution.
STATIONARY OBSTACLES (STEPS, CURBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges, and/or drop-offs (curbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your Travel Scooter climb or descend an obstacle that
is inordinately high.
WARNING! Do not attempt to have your Travel Scooter proceed backward down any step,
curb, or other obstacle. This may cause the Travel Scooter to tip.
WARNING! Be sure your Travel Scooter is traveling perpendicular to any curb you may be
required to ascend or descend. See figures 3 and 4.
WARNING! Even though your Travel Scooter may be capable of handling greater obstacles,
Mega Motion recommends that you do not attempt to negotiate a curb that has a height
greater than 2 in. (5 cm). Doing so could cause instability in your Travel Scooter.

13
Travel Pal www.mega-motion.com
II. SAFETY
INCLEMENT WEATHER PRECAUTIONS
Exposure of your Travel Scooter to inclement weather conditions should be avoided whenever possible.
If suddenly caught up in rain, snow, severe cold or heat while operating your Travel Scooter proceed to
shelter at the earliest opportunity. Thoroughly dry your Travel Scooter before storing, charging, or oper-
ating your Travel Scooter.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery
surfaces can cause damage to the Travel Scooter and electrical system. Maintain and
store your Travel Scooter in a dry and clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of
upholstered and non-upholstered items on the Travel Scooter, possibly resulting in skin
irritation. Exercise caution when using your Travel Scooter in extremely hot or cold
conditions or when exposing your Travel Scooter to direct sunlight for prolonged periods
of time.
FREEWHEEL MODE
Your Travel Scooter is equipped with a manual freewheel lever that, when pushed forward, allows the
Travel Scooter to be pushed. For more information about how to place your Travel Scooter into and out
of freewheel mode, see III. “Your Travel Scooter.”
WARNING! When your Travel Scooter is in freewheel mode, the braking system is
disengaged.
Disengage the drive motors only on a level surface.
Ensure the key is removed from the key switch.
Stand beside the Travel Scooter to engage or disengage freewheel mode. Never sit
on a Travel Scooter to do this.
After you have finished pushing your Travel Scooter, always return it to the drive
mode to lock the brakes.
An added feature built into the Travel Scooter is “push-too-fast” protection which safeguards the Travel
Scooter against gaining excessive speed while in freewheel mode.
“Push-too-fast” operates differently depending on which of two conditions exists:
If the key is turned to the “off” position while in freewheel mode, the Travel Scooter’s controller
activates regenerative braking when the Travel Scooter is pushed faster than a maximum threshold
which has been preprogrammed. In this case, the controller is acting as a speed governor.
If the key is in the “on” position while in freewheel mode, you will encounter considerable resistance
at any speed because the brakes are fully engaged. This prevents the Travel Scooter from gaining
unwanted momentum should the manual freewheel lever inadvertently be released while driving the
Travel Scooter.
STAIRS AND ESCALATORS
Travel Scooters are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Do not use your Travel Scooter to negotiate steps or escalators.
DOORS
Determine if the door opens toward or away from you.
Use your hand to turn the knob or push the handle or push-bar.
Drive your Travel Scooter gently and slowly forward to push the door open. Or drive your Travel
Scooter gently and slowly backwards to pull the door open.

14 www.mega-motion.com Travel Pal
II. SAFETY
ELEVATORS
Modern elevators have a door edge safety mechanism that, when pushed, reopens the door(s).
If you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge
or allow the rubber door edge to contact the Travel Scooter and the door will reopen.
Use care that pocketbooks, packages, or Travel Scooter accessories do not become caught in elevator
doors.
NOTE: If your Travel Scooter’s turning radius is greater than 60 in. (152.4 cm), it may be difficult to
maneuver in elevators and building entrances. Use caution when attempting to turn or maneuver your
Travel Scooter in small spaces, and avoid areas that might pose a problem.
LIFT/ELEVATION PRODUCTS
If you will be transporting your Travel Scooter during travel, you may find it necessary to use a vehicle-
mounted lift system or elevation product to aid in transportation. Mega Motion recommends that you
closely review the warnings, instructions, specifications, and safety information set forth by the manufac-
turer of the lift/elevation product before using that product.
WARNING! Not all lift systems/elevation products are rated for use with an occupied mobility
device. Mega Motion recommends that you do not remain seated in your Travel Scooter
when it is being used in connection with any type of lift system/elevation product unless:
That product is rated for occupied use by the manufacturer.
You are able to occupy your mobility device in strict conformity with the warnings,
instructions, specifications, and safety guidelines set forth by the manufacturer.
WARNING! Always turn off the power to the unit when you are being transferred via an
elevation product. Failure to do so may result in accidental throttle control lever contact,
resulting in unintended movement and personal injury or product damage.
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information.
MANDATORY! Battery posts, terminals, and related accessories contain lead
and lead compounds. Wear goggles and gloves while handling batteries and
wash hands after handling.
WARNING! Travel Scooter batteries are heavy. See specifications table. If you
are unable to lift that much weight, be sure to get help. Use proper lifting
techniques and avoid lifting beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen
battery.
WARNING! Connect the battery harnesses in the proper manner. RED (+) cables
must be connected to positive (+) battery terminals/posts. BLACK (-) cables must
be connected to negative (-) battery terminals/posts. Protective caps should be
installed over all battery terminals. REPLACE cables immediately if damaged.
BATTERY DISPOSAL AND RECYCLING
If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag and contact your
local waste disposal agency or recycling center for instructions on disposal and battery recycling, which
is our recommended course of action.

15
Travel Pal www.mega-motion.com
MOTOR VEHICLE TRANSPORT
Mega Motion recommends that you do not remain seated in your Travel Scooter while traveling in a motor
vehicle. The Travel Scooter should be stowed in the trunk of a car or in the back of a truck or van with the
batteries removed and properly secured. In addition, all removable Travel Scooter parts, including the
armrests, seat, and shroud should be removed and/or properly secured during motor vehicle transport.
WARNING! Although your Travel Scooter may be equipped with a positioning belt, this
belt is not designed to provide restraint during motor vehicle transport. Anyone travelling
in a motor vehicle should be properly secured in the motor vehicle seat with safety belts
fastened securely.
WARNING! Do not sit on your Travel Scooter while it is in a moving vehicle.
WARNING! Always be sure your Travel Scooter and its batteries are properly secured
when it is being transported. Batteries should be secured in an upright position, and
protective caps should be installed on the battery terminals. Batteries should not be
transported with any flammable or combustible items.
PREVENTING UNINTENDED MOVEMENT
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact.
GETTING ONTO AND OFF OF YOUR TRAVEL SCOOTER
Getting onto and off of your Travel Scooter requires a good sense of balance. Please observe the following
safety tips when getting onto and off of your Travel Scooter:
Remove the key from the key switch.
Ensure that your Travel Scooter is not in freewheel mode. See III. “Your Travel Scooter.”
Make certain that the seat is secured into place.
WARNING! Position yourself as far back as possible in the Travel Scooter seat to prevent
the Travel Scooter from tipping.
WARNING! Avoid putting all of your weight on the Travel Scooter armrests and do not use
the armrests for weight bearing purposes, such as transfers. Such use may cause the
Travel Scooter to tip, resulting in a fall from the Travel Scooter and personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
Travel Scooter to tip.
REACHING AND BENDING
Avoid reaching or bending while driving your Travel Scooter. Bending forward creates the risk of acci-
dental throttle control lever contact. Bending to the side while seated creates the risk of tipping. It is
important to maintain a stable center of gravity and keep the Travel Scooter from tipping. Mega Motion
recommends that the Travel Scooter user determine his/her personal limitations and practice bending and
reaching in the presence of a qualified attendant.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the
Travel Scooter deck or from either side of the Travel Scooter. Movements such as these
may change your center of gravity and the weight distribution of the Travel Scooter and
cause your Travel Scooter to tip.
PROHIBITED! Keep your hands away from the tires when driving. Be aware that loose
fitting clothing can become caught in drive tires.
II. SAFETY

16 www.mega-motion.com Travel Pal
PRESCRIPTION DRUGS/PHYSICAL LIMITATIONS
The Travel Scooter user must exercise care and common sense when operating his/her Travel Scooter.
This includes awareness of safety issues when taking prescribed or over-the-counter drugs or when the
user has specific physical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter
medication or if you have certain physical limitations. Some medications and limitations
may impair your ability to operate your Travel Scooter in a safe manner.
ALCOHOL/SMOKING
The Travel Scooter user must exercise care and common sense when operating his/her Travel Scooter.
This includes awareness of safety issues while under the influence of alcohol or while smoking.
WARNING! Do not operate your Travel Scooter while you are under the influence of
alcohol, as this may impair your ability to operate the Travel Scooter in a safe manner.
WARNING! Mega Motion strongly recommends that you do not smoke cigarettes while
seated in your Travel Scooter, although the Travel Scooter seat has passed the
necessary testing requirements for cigarette smoke. You must adhere to the following
safety guidelines if you decide to smoke cigarettes while seated in your Travel Scooter:
 Do not leave lit cigarettes unattended.
 Keep ashtrays a safe distance from the seat cushions.
 Always make sure cigarettes are completely extinguished before disposal.
ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency
waves can have an adverse affect on the performance of electrically-powered mobility
vehicles.
Electromagnetic and Radio Frequency Interference can come from sources such as cellular phones, mobile
two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters,
wireless computer links, microwave signals, paging transmitters, and medium-range mobile transceivers
used by emergency vehicles. In some cases, these waves can cause unintended movement or damage to
the control system. Every electrically-powered mobility vehicle has an immunity (or resistance) to EMI.
The higher the immunity level, the greater the protection against EMI. This product has been tested and
has passed at an immunity level of 20 V/M.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio
transmitters may cause unintended movement of your electrically-powered mobility
vehicle due to EMI. Exercise caution when using any of these items while operating your
mobility vehicle and avoid coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered
mobility vehicle can increase the susceptibility of the vehicle to EMI. Do not modify your
Travel Scooter in any way not authorized by Mega Motion.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance
of other electrical devices located nearby, such as alarm systems.
NOTE: If unintended motion or brake release occurs, turn your Travel Scooter off as soon as it is safe
to do so. Call Mega Motion at 1-800-MEGA-508 to report the incident.
II. SAFETY

17
Travel Pal www.mega-motion.com
TILLER CONSOLE COMPONENTS
The tiller console houses all controls needed to drive your Travel Scooter, including the key switch, throt-
tle control lever, horn button, speed adjustment dial, and the battery condition meter. See figure 5.
WARNING! Do not expose the tiller console to moisture. In the event that the tiller
console does become exposed to moisture, do not attempt to operate your Travel
Scooter until the tiller console has dried thoroughly.
III. YOUR TRAVEL SCOOTER
Key Switch
Insert the key into the key switch and turn it clockwise to power up (turn on) your Travel Scooter.
Turn the key counterclockwise to power down (turn off) your Travel Scooter.
Although the key can be left in the key switch when the Travel Scooter is powered down, we recommend
removing it to prevent unauthorized use of your Travel Scooter.
WARNING! If the key is moved to the “off” position while your Travel Scooter is in motion,
the electronic brakes will engage and your Travel Scooter will come to an abrupt stop!
Throttle Control Lever
This lever allows you to control the forward speed and the reverse speed of your Travel Scooter up to the
maximum speed you preset with the speed adjustment dial.
Place your right hand on the right handgrip and your left hand on the left handgrip.
Use your right thumb to push the right side of the lever to disengage your Travel Scooter’s brakes and
move forward.
Release the lever and allow your Travel Scooter to come to a complete stop before pushing the other
side of the lever to move in reverse.
When the throttle is completely released, it automatically returns to the center “stop” position and
engages your Travel Scooter’s brakes.
Horn Button
The Travel Scooter must be “on” for the horn to be operational. This button activates a warning horn. Do
not hesitate to use the warning horn when doing so may prevent accident or injury.
Battery Condition Meter
When the key is fully inserted into the key switch, this meter indicates approximate battery strength. For
further information on the battery condition meter, see IV. “Batteries and Charging.”
BATTERY CONDITION METER
HORN BUTTON
KEY
(INSERTED INTO KEY
SWITCH)
SPEED ADJUSTMENT
DIAL
THROTTLE CONTROL LEVER
(REVERSE)
Figure 5. Tiller Console
THROTTLE CONTROL
LEVER (FORWARD)

18 www.mega-motion.com Travel Pal
Figure 6. Tiller Adjustment
III. YOUR TRAVEL SCOOTER
Tiller Handle
The tiller handle is located below the tiller adjustment knob
(see figure 6) and should be used when lifting the front end of
the Travel Scooter during storage or transport. Make sure the
tiller lock knob is in the locked position before using the tiller
handle to lift the Travel Scooter.
Tiller Lock Knob
The tiller lock knob allows the tiller to be locked in the straight
ahead position. Locking the tiller is helpful when transporting
the Travel Scooter because it will stabilize the front wheel,
keeping the Travel Scooter from moving from side to side.
WARNING! Before getting onto your Travel
Scooter, always check that the tiller lock
knob is in the unlocked position. See figure 7.
Attempting to ride your Travel Scooter with
the tiller lock knob in the locked position can
result in personal injury.
From the unlocked position (see figure 7), lock the front wheel
by pushing the tiller lock knob in and turning it clockwise 90°.
See figure 8.
Speed Adjustment Dial
This dial allows you to preselect and limit your Travel
Scooter’s top speed.
The image of the tortoise represents the slowest speed setting.
The image of the hare represents the fastest speed setting.
LOWER TILLER COMPONENTS
Tiller Adjustment Knob
Your Travel Scooter is equipped with an adjustable pivoting
tiller that you can position to maximize your ergonomic comfort.
WARNING! Remove the key from the key
switch before adjusting the tiller or the seat.
Never attempt to adjust the tiller or the seat
while the Travel Scooter is in motion.
To use the tiller adjustment knob:
1. While supporting the tiller, turn the tiller adjustment knob
counterclockwise to loosen the tiller. See figure 6.
2. Move the tiller to a comfortable position.
3. Turn the tiller adjustment knob clockwise to secure the
tiller in position.
NOTE: In order to lower the tiller to its lowest point, you
must first remove the seat.
LOCKED
POSITION
Figure 8. Tiller Lock Knob (Locked)
Figure 7. Tiller Lock Knob (Unlocked)
UNLOCKED
POSITION
TILLER
ADJUSTMENT
KNOB
TILLER
HANDLE

19
Travel Pal www.mega-motion.com
SEAT ADJUSTMENTS
To adjust the height of the seat:
1. Remove the seat by lifting it straight up and off of the
Travel Scooter.
2. Use the attached ring to pull and remove the detent
pin from the lower seat post. See figure 9.
3. Raise or lower the upper seat post to the desired seat
height.
4. While holding the upper seat post at that height,
align the adjustment holes of the upper and lower
seat posts.
5. Fully insert the detent pin.
6. Reinstall the seat.
To adjust the width of the armrests:
1. Loosen the armrest adjustment knobs located at the
rear of the seat.
2. Slide the armrests in or out to the desired width.
3. Tighten the armrest adjustment knobs as required.
NOTE: The armrests can also pivot upwards to aid in
getting onto and off of the Travel Scooter.
REAR SECTION COMPONENTS
The manual freewheel lever, anti-tip wheels, motor/
transaxle assembly, and charging system components
are located on the rear section of your Travel Scooter.
See figure 10.
WARNING! Before placing your Travel
Scooter into or taking it out of freewheel
mode, remove the key from the key
switch. Never sit on a Travel Scooter
when it is in freewheel mode. Never put
a Travel Scooter in freewheel mode on
any incline.
Motor/Transaxle Assembly
The motor/transaxle assembly is an electromechanical
unit that converts electrical energy from your Travel
Scooter’s batteries into the controlled mechanical
energy that drives the Travel Scooter’s wheels.
III. YOUR TRAVEL SCOOTER
Figure 9. Seat Height Adjustment
ANTI-TIP WHEELS
MANUAL FREEWHEEL LEVER
MOTOR/TRANSAXLE
ASSEMBLY
Figure 10. Rear Section
UPPER SEAT POST
LOWER SEAT POST
DETENT PIN

20 www.mega-motion.com Travel Pal
Manual Freewheel Lever
Whenever you need or want to push your Travel Scooter for short distances, you can put it in freewheel
mode.
1. Push forward on the manual freewheel lever to disable the drive system and the brake system. You may
now push your Travel Scooter.
2. Push the manual freewheel lever backward to reengage the drive and the brake systems; this takes your
Travel Scooter out of freewheel mode.
WARNING! When your Travel Scooter is in freewheel mode, the braking system is
disengaged.
 Disengage the drive motors only on a level surface.
Ensure the key is removed from the key switch.
Stand to the side of the Travel Scooter to engage or disengage freewheel mode.
Never sit on a Travel Scooter to do this.
After you have finished pushing your Travel Scooter, always return it to the drive
mode to lock the brakes.
Anti-Tip Wheels
The anti-tip wheels are an integral and important safety feature of your Travel Scooter. They are bolted to
the frame at the rear of the scooter.
PROHIBITED! Do not remove the anti-tip wheels or modify your Travel Scooter in any way
that is not authorized by Mega Motion.
III. YOUR TRAVEL SCOOTER
Charger Power Cord Receptacle
The Travel Scooter’s 3-pin off-board charger cord
plugs into this receptacle. See figure 11.
Main Circuit Breaker (Reset Button)
When the voltage in your Travel Scooter’s batteries
becomes low or the Travel Scooter is heavily
strained because of excessive loads or steep inclines,
the main circuit breaker may trip to protect the
motor and electronics from damage. See figure 11.
The main circuit breaker reset button pops out
when the breaker trips.
When the breaker trips, the entire electrical sys-
tem of your Travel Scooter shuts down.
Allow a minute or two for your Travel Scooter’s
electronics to “rest.”
MAIN CIRCUIT BREAKER
(RESET BUTTON)
CHARGER POWER CORD
RECEPTACLE
Push in the reset button to reset the main circuit breaker.
If the main circuit breaker trips frequently, you may need to charge your batteries more often. You may
also need to have the batteries load tested.
If the main circuit breaker trips repeatedly, contact Mega Motion at 1-800-MEGA-508.
Figure 11. Charging System Components
