Megamaster 570 Elite Quick reference guide

ASSEMBLY& OPERATING INSTRUCTIONS
Important: Read these instructions for use carefully so as to familiarize yourself with the
appliance before using your charcoal kettle grill. Keep these instructions for future reference
.
WARNI NG
To reduce the ris k of fire burn haz ard or other injury, read the manual carefully and
completely before using your charcoal kettle.
dfWARNI NG
FOR OUTDOOR USE ONLY.
www.megamaster.co.za
Manuf ac t ured in China· Dis t ributed by Mega Group · PO Box 15, Woodlands, 0027, Sout h Afric a· Tel: [phone]

Installation Final Check List
Operating Instructions
Care and Maintenance
Trouble Shooting
Warranty Information
16
17-20
20
21
22
Safety Instructions
Package Content List
Explode View
Part List
Hardware Contents
Assembly Instructions
2-3
4-5
6
7
8
9-15
2
Please read the following instructions carefully before attempting to assemble,operate or
install the product.Failure to follow these instructions may result in serious bodily injury
and/or property damage. If you have questions regarding the product please call customer
service at ([phone].
WARNI NG
This outdoor cooking appliance is not intended to be installed in or on boats and other
recreational vehicles.
Safety Instructions
Tabl e of Contents

3
1. The charcoal kettle must never be used indoors or for heating purposes.
2. Do not repair or replace any part of the charcoal kettle unless specifically recommended in
this manual. All other service should be referred to a qualified technician. This charcoal
kettle is not intended to be installed in or on recreational vehicles or boats.
3. Children should not be left alone or unattended in an area where the charcoal kettle is
being used. Do not allow them to sit, stand or play in or around the charcoal kettle at any
time.
4. Do not touch the charcoal kettle while the charcoal kettle is in operation, or until the
charcoal kettle has cooled down after use.
5. Do not use gasoline, alcohol, or other highly volatile fluids to ignite charcoal. If using
charcoal starter fluid(not recommended),remove any fluid that may have drained through
the bowl vents before lighting the charcoal.
6. Do not add charcoal starter fluid or charcoal infused with charcoal lighter fluid to already
hot or warm charcoal. Cap starter fluid after use and place a safe distance away from the
grill.
7. Use heat-resistant braai mitts or gloves while cooking, adjusting air vents(dampers), adding
charcoal and handling thermometer or lid.
8. Extinguish charcoal when finished cooking. To extinguish, close bowl vent and lid damper
and place lid on bowl. Do not use water to control flare-ups or to extinguish charcoal.
9. Never dump hot charcoal where it might be stepped on or be a fire hazard. Never dump
ashes or charcoal before they are fully extinguished.
10. Do not use this charcoal kettle unless all parts are in place. This charcoal kettle must be
properly assembled according to the assembly instructions. Improper assembly may be
dangerous.
11. Do not leave the charcoal kettle unattended while cooking.
12. Do not operate the charcoal kettle under unprotected combustible constructions. Use only
in well ventilated areas. Do not use in buildings, garages, sheds, breezeways or other such
enclosed areas.
13. Keep the area surrounding the charcoal kettle free from combustible materials including,
fluids, trash and vapors such as gasoline or charcoal lighter fluid. Do not obstruct the flow
of combustion and ventilation air.
Safety Instructions

Package Content List
1
4
Bowl ---1pc 2Leg cap, top ---3pcs
3Top leg ---3pcs 4
56
78
910
Bottom leg C---1pc
Bottom leg B ---1pc Bottom leg A ---1pc
Cart bottom grate
---1pcs
Wheel ---2pcs
Wheel cap ---2pcs Lid handle assembly ---1pc

Package Content List
5
11 12
13 14
15 16
17 18
19 20
Bowl vent assembly ---1pc Ash catcher ---1pc
Charcoal grate ---1pc Cooking grate ---1pc
Temperature gauge ---1pc Lid assembly ---1pc
Lid hook ---1pc Lid handle decorative sheet
---1pc
Bowl handle assembly---1pc Heat shield piece---1pc

Parts Diagram
14
15
16
17
18
26
23
25
27
28
29
24
12
19
21
22
11
10
9
5
3
2
1
8
6
7
13
20
4
6

7
No. Part(Descreption) Warranty
coverage(year) QTY
1Lid handle assembly 11
2Mica plate 12
3Lid handle decorative sheet 11
4Heat shield piece 11
5Lid damper 11
6Temperature gauge 11
7Lid 11
8Lid hook 11
9Hinged cooking grate 12
10 Cooking grate 11
11 Charcoal grate 11
12 Bowl handle assembly 11
13 Cooking grate support bracket 13
14 Bowl 11
15 Bowl pad 13
16 Leg cap, top 13
17 Top leg as sembly 13
18 Bottom leg C 11
19 Bowl vent assembly 11
20 Handle of bowl vent 11
21 Ash catcher hook 12
22 Ash catcher 11
23 Bottom legA 11
24 Leg cap, bottom 11
25 Cart bottom grate 11
26 Bottom leg B 11
27 Wheel 12
28 Wheel axle 12
29 Wheel cap 1 2
Part List

Ax9 Bx1 Cx5 Dx2
Hardware package list
Tools Needed
Ex9 Fx5
Truss Head Screw
M6x 15mm Nut M6
Flat Washer
M5
Axle Nut
M6
Flat Washer
M6
Truss head screw
M5x 16mm
8
Teflon Was her
M6
Gx4
Heat Insulating
Spacer
Hx2
Ix2
Wheel Axle
10MM

1
A
2
x3
Assembly Instructions
9
A
x6
1
3
2
E
x6
E
x3
564
!
6

x2
3
10
8
7
D
4
9
x2
I

11
6
10
C
x2
F
x2
G
x4
5
GGF

12
8
12
7
B
x1
C
x1
F
x1
11

13
10 14
913

14
x2
12
C
x2
H
19
F
x2
17
18
20
11
15
16
H
F

13
15
14

16
Your charcoal kettle is ready to use!
1. The cooking grate and charcoal grate are flat.
2. Ash catcher can not drop to floor.
3. Vents can be turned.
4. Leg spread and stand securely.
Charcoal kettle special features
A. Built-in thermometer
A durable, built-in lid thermometer allows you to easily monitor your charcoal kettle’s
temperature.
B. Lid hook
Inside the charcoal kettle lid is an angled lid hook. Simply slide the lid to the side and
hang the lid on the firebox.
C. Hinged cooking grate
The hinged grate has an area on both sides that lift up to allow you to easily add
charcoal.
D. High capacity ash catcher
The easy high capacity ash catcher makes users to remove and clean ash quickly.
Installation Final Check List

17
How to use your charcoal kettle
Before light
Choose a proper location to grill
lOnly use this charcoal kettle in a well-ventilated area. Do not use in a garage, building,
breezeway, or any other enclosed area.
lKeep the charcoal kettle on a secure, level surface at all times.
lDo not use charcoal kettle within five feet of any combustible material. Combustible
materials include, but are not limited to, wood or treated wood decks, patios, and
porches.
Preparing the charcoal kettle for lighting
1. Remove the lid and position it on the side of your charcoal kettle using either the lid
hook located on the inside of the lid.
2. Remove the cooking (top) grate from your charcoal kettle.
3. Remove the charcoal (bottom) grate and clear ashes or chunks of old charcoal from the
bottom of the bowl. Charcoal requires oxygen to burn, so be sure that nothing clogs the
vents.
4. Release the ash catcher, then dispose of the ashes.
5. Open bowl vent by moving the handle to the open position.
6. Replace charcoal (bottom) grate.
Lighting Charcoal
1. Light the charcoal using newspaper or other paper.
2. Light the charcoal using lighter cubes.
Warning: Please read the following instructions carefully before attempting to
assemble, operate or install the product. The charcoal kettle becomes extremely
hot and can cause burning. Failure to comply with these instructions may result in
serious bodily injury.
Note: Remove all packaging,including straps,before using the charcoal kettle.
Operating Instructions

Tips and tricks for grilling success
Wear Gloves
Always wear a barbecue mitt or mitts when using your charcoal grill. Vents, dampers,
handles, and the bowl will all get hot during the grilling process, so be sure to keep your
hands and forearms protected.
Keep the air flowing
A charcoal fire needs air. The lid should be closed as much as possible, but keep the lid
damper and bowl vent open. Remove the ashes on the bottom of the grill regularly to prevent
them from blocking the vents.
Put a lid on it
For four important reasons the lid should be closed as much as possible.
1.Keeps the grate hot enough to sear the food.
2.Speeds up the cooking time and prevents the food from drying out.
3.Traps the smokiness that develops when fat and juices vaporize in the charcoal kettle.
4.Prevents flare-ups by limiting oxygen.
Tame the flam e
Flare-ups happen, which is good because they sear the surface of what you are grilling,
however too many flare-ups can burn your food. Keep the lid on as much as possible. This
limits the amount of oxygen inside the grill, which will help extinguish any
flare-ups. If the flames are getting out of control, move the food over indirect heat temporarily
until they die down.
Watch the time and temperature
If you are grilling in a colder climate or in a higher altitude, the cooking times will be longer. If
the wind is blowing hard it will raise a charcoal kettle’s temperature, so always keep
close to your charcoal kettle and remember to keep the lid on as much as possible so that
the heat does not escape.
18

Grilling Methods
Grilling with direct heat
Use the direct method for small, tender pieces of
food that takes less than 20minutes to cook, such
as:
lHamburgers
lSteaks
lChops
lKabobs
lBoneless chicken pieces
lFish fillets
lShellfish
lSliced vegetables
With direct heat, the fire is right below the food. It
sears the surfaces of the food, developing flavors,
texture and delicious caramelization while it also
cooks the food all the way to the center.
Arrange the charcoal for direct heat
1.Put on barbecue mitts or gloves.
2.After the charcoal is fully fit, spread them evenly
across the charcoal grate with long tongs.
3.Replace the cooking grate.
4.Place the lid on the grill.
5.Open the lid damper.
6.Preheat the grid for approximately 10 to15
minutes.
7.Once the cooking grate is preheated, using a
stainless steel bristle grill brush, clean the cooking
grate.
8.Open the lid and place your food on the grate.
9.Place the lid on the grill.
Grillling with indirect heat
Use the indirect method for larger cuts of
meat that require 20minutes or more of
grilling time, or for foods so delicate that
direct exposure to the heat would dry them
out or scorch them, such as:
lRoasts
lBone-in poultry pieces
lWhole fish
lDelicate fish fillets
lWhole chickens
lTurkeys
lRibs
With indirect heat, the heat is on both sides
of the charcoal kettle or off to one side of
the grill. The food sits over the unlit part on
the cooking grate.
Arrange the charcoal for indirect heat
1.Put on barbecue mitts or gloves.
2.After the charcoal is fully fit, with long
tongs, arrange the charcoal so that they will
be set on either side of the food. Position
the charcoal on the side of the bowls
opposite the handles. A drip pan may be
placed between the charcoal to collect
drippings.
3.Replace the cooking grate.
19

20
Cleaning
Follow a few basic maintenance instructions to keep your grill looking and grilling better for
years to come!
lFor proper air flow and better grilling, remove accumulated ashes and old charcoal from
the bottom of the kettle and the ash catcher before use. Make sure that all of the
charcoal is fully extinguished and the grill is cool before doing so.
lYou may notice "paint-like” flakes on the inside of the lid. During use, grease and smoke
vapors slowly oxidize into carton and deposit on the inside of your lid. Brush the
carbonized grease from the inside of the lid with a stainless steel bristle grill brush. To
minimize further build-up, the inside of the lid can be wiped with a paper towel after
cooking while the grill is still warm(not hot).
lIf your grill is subject to a particularly harsh environment, you will want to clean the
outside more often. Acid rain, chemicals and salt water can cause surface rusting to
appear. Megamaster recommends wiping down the outside of your grill with warm soapy
water. Follow up with a rinse and thorough drying.
lDo not use sharp objects or abrasive cleaners to clean the surfaces of your grill.
Arrange the charcoal for indirect heat
4. Place the lid on the grill. The charcoal kettle has a thermometer, always position the lid so
that the thermometer is not above the charcoal where it will be exposed to direct heat.
5. Open the lid damper.
6. Preheat the grate for approximately 10 to15 minutes.
7. Once the cooking grate is preheated, using a stainless steel bristle grill brush, clean the
cooking grate.
8. Open the lid and place your food on the grate.
9. Place the lid on the grill.
Note: When removing the charcoal kettle lid during cooking, lift to the side, rather than
straight up. Lifting straight up may create suction, drawing ashes up onto your food.
Care and Maintenance
