MEGAPOWER MVP232 User manual

User’s Manual
MODEL MVP232
HIGH RESOLUTION
PORTABLE DIGITAL PRESENTER
VISUAL PRESENTER

TABLE OF CONTENTS
Chapter 1 –Introduction ------------------------------------------------------ 1-5
1.1 About Your Digital Presenter -----------------------------------------------
3
1.2 Safety Information ------------------------------------------------------------ 3-4
1.3 System Contents -------------------------------------------------------------- 4-5
Chapter 2 –Installation ------------------------------------------------------ 6-7
2.1 Setting Up ----------------------------------------------------------------------- 6
2.2 Connector Panel ---------------------------------------------------------------- 7
2.3 Connecting to TV or Monitor or Multimedia Projector ----------------- 7
Chapter 3 – Using the Digital Presenter ---------------------------------- 8-9
3.1 Control Buttons --------------------------------------------------------------- 8-9
Chapter 4 –Care and Maintenance --------------------------------------- 10
4.1 Cleaning the Digital Presenter Housing -------------------------------------
10
4.2 Cleaning the CCD Camera Lens --------------------------------------------- 10
4.3 Transporting the Digital Presenter ------------------------------------------- 10
Chapter 5 –Troubleshooting Guide --------------------------------------- 11
Appendix 1 –Product Specifications for MVP-232 ----------------------
1

Note:
1. The appliance inlet of the power supply is the disconnector from mains and must be
anytime easily accessible.
2. The maximum noise level of the product is LPA£70dB (A) DIN 45635-19-01-KL2.
1. Der Gerätestecker des Netzteiles bildet die Trennvorrichtung zum
Versorgungsstromkreis und muß jederzeit leicht zugänglich sein.
2. Max. Geräuschpegel: LPA£70dB (A) DIN 45635-19-01-KL2.
FCC Information
This equipment has been tested and found to comply with the limits for a class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense
Instruction to Use
This equipment generates and uses the radio-frequency energy and, if not installed and
used in accordance with the instruction manual, may cause interference to radio and
television reception. It has been tested and found to comply with the limits for a class A
computing device in accordance with the specifications in Subpart J of Part 15 of FCC
Rules, which are designed to provide reasonable protection against such interference
when operated in a commercial environment. If this equipment does cause interference
to radio or television reception, the user may try to correct the interference by one or
more of the following measures:
1. Reorient the receiving antenna for the radio or television.
2. Relocate the equipment with respect to the receiver.
3. Plug the equipment into a different outlet so the equipment and receiver are on
different branch circuits.
4. Fasten cables using mounting screws to ensure adequate electromagnetic interference
controls.
Acknowledgments
The followings are registered trademark or trademarks of their respective corporations:
IBM, Microsoft.
2

Chapter 1
Introduction
1.1 About Your Portable Digital Presenter
The Portable Digital Presenter is a convenient, versatile, state-of-the-art presentation system. It
is an effective and valuable tool for presenting printed material or 3-D objects on a TV or
through a multimedia projector onto a large screen. The enlarged display allows large groups
to
simultaneously view the object clearly and lively, and is particularly well suited for business
meetings, conferences and group instruction.
The following lists some of the specific features of the Portable Digital Presenter:-
- Perfect match with LCD/DLP projectors.
- VGA output with up to XGA resolution.
- High sensitivity and low illumination. The minimum illumination is 0.5 Lux.
- Close up focus down to 1 cm.
- Positive/Negative function gives very good color reproduction for negatives.
- Save images to PC via the USB port
- 13x Digital Zoom and Mechanical zoom (goose neck).
- IR remote control allows more convenient operation.
- Comparison of Live and Saved images.
- Light weight and small size. Easy to carry around, deluxe carrying bag included.
1.2 Safety Information
Please read these instructions before using your Portable Digital Presenter. Failure to comply
with these instructions could result in electric shock, fire, personal injury or damage to your
Portable Digital Presenter.
Power Source
Check the power specification plate on the back of the Digital Presenter. Ensure that your line
voltage matches with the rating of the Digital Presenter. The Digital Presenter accepts
AC power 90-264V, 43-67 Hz power sources.
Technical Service
Unplug this Digital Presenter from the wall outlet and refer servicing to authorized technical
staff under the following conditions:
1. When the power adaptor or plug is damaged or frayed.
3

2. If liquid has been spilled into the Digital Presenter.
3. If the Digital Presenter has been exposed to rain or water.
4.
If the Digital Presenter does not operate normally by following the operating instructions.
Adjust only those controls, which are covered by the operating instructions. Improper
adjustment of other controls may result in damage and will often require extensive work
by the authorized technical staff to restore the Digital Presenter to normal operation.
5.
If the Digital Presenter has been dropped or the cabinet has been damaged.
6. If the Digital Presenter exhibits a distinct change in performance
1.3 System Contents
items should be included in your package:
1. Digital Presenter
2. AC/DC Power Adapter
3. VGA Cable
4. USB Cable
5. VGA In Adaptor Cable
6. Remote Control
7. User’s Manual
8. Carrying Bag
Check to make sure all parts are included in the shipping box. If any are missing, contact
your dealer immediately.
4
Handle your Digital Presenter carefully as you remove it from the shipping box. The following
Digital
Presenter
VGA Cable
AC/DC power
Adaptorl

5
USB Cable
Remote
Control
VGA In
Adaptor Cable
User's Manual
Carrying Bag
MVP232
User’s
Manual

Chapter 2
2.1 Setting Up
1. Place the Portable Digital Presenter on a flat surface. Raise or Adjust the Goose Neck and
turn the CCD camera so that the camera lens is pointing to the object to be displayed.
2. Plug DC jack of the AC Power Adapter into the port labeled DC 12V on the rear panel of
the Digital Presenter.
3. Plug the power adapter into a convenient AC outlet.
4. Follow the instructions in section 2.3 to connect other cables.
5. Place the object in front of the digital presenter. Push the "SOURCE" button on the top of the
base to select the Presenter VGA output or input. Rotate the Focusing Knob to get a sharp
image. Adjust the height of the Goose Neck to vary the size of the displayed object.
6. To select Video Output, press the "SIGNAL" button on the remote control.
6
Camera
Head
Base
Goose
Neck
Control
Panel
LED Lamp

2.2 Connector Panel
This illustration shows the connector panel on your Digital Presenter. Refer to this figure when
connecting the Digital Presenter.
2.3 Connecting to TV or Monitor or Multimedia Projector
7

Chapter 3
Using the Digital Presenter
3.1 Control Buttons
Digital Presenter.
Control Panel
POWER Power ON or Off the Presenter
TELE Zooms in and enlarges size of object
WIDE Zooms out and reduces size of object
ROTATE Rotates & Mirror the image
LAMP Power On the LED lamp
8
The following describes the control button on the Remote Control and Control Panel of the

Remote Control
FREEZE Freezes the current image
SIGNAL Toggles between RGB & internal AV output
DIVISION
Compare current & stored image
NEGATIVE Press this function for negative film
CAPTURE
Stores images
PLAYBACK Recalls stored images
NEXT Shown next stored images
TEXT Toggles between Text & Image mode
B/W Selects Black/White or Color
Other Keys No function in this model
OSD Control
OSD menu: PICTURE, RGB, RESOLUTION & SYSTEM
Continuously press the "AF" button for over 3 seconds to enter OSD Menu
then press "WIDE" or "TELE" & "FAR" or "NEAR" button to select or adjust the menu
9

Chapter 4
Care and Maintenance
The information in this chapter describes how to care for and prevent accidental damage to
your Digital Presenter You should treat your Visual Presenter with the same care you would
give to any other valuable equipment
4.1 Cleaning the Digital Presenter Housing
DO NOT try to service the Digital Presenter. Except for the lamps, the interior of the Digital
Presenter contains no user-serviceable parts. Refer all Digital Presenters servicing to your
dealer. Failure to do so can result in serious personnel injury or damage to the Digital Presenter.
DO NOT clean the housing with organic solvents, such as those containing acetone. Wipe the
exterior of the housing with a soft, damp cloth. Protect the Digital Presenter from rain, snow or
extreme temperature
4.2 Cleaning the CCD Camera Lens
To clean the camera lens:
1. Apply a non-abrasive glass cleaner to a soft, dry cleaning cloth. Be careful not to use
excessive amount of liquid glass cleaner. Also, do not use abrasive cleaners, solvents, or
other harsh chemicals that might scratch the lens.
2. Lightly wipe the cleaning cloth over the lens from center to the edge in circular motion.
4.3 Transporting the Digital Presenter
The Digital Presenter is a highly sophisticated piece of electronic equipment that is sensitive to
impact, excessive heat, cold and humidity. When transporting the Digital Presenter, use a
protective carrying bag or use the original packing carton to minimize shock and impact.
Store and transport the Digital Presenter at temperature between 0 and 140 degrees Fahrenheit
(-17 to 60 degrees Centigrade). Avoid storage in automobiles during seasonal temperature
extremes. Automobile interior temperatures can exceed 160 degree Fahrenheit (70 degrees
Centigrade) in summer. If the Digital Presenter has been exposed to extremely hot, cold or
humid conditions, allow it to stand at room temperature for 30 minutes before use.
10

Chapter 5
Troubleshooting Guide
If you are having a problem operating the Visual Presenter, first make sure you have set
it up according to the instructions in Chapter 3. You should also check the adjustments
and the INPUT connections. Verify that all power is switched on. Before calling for
service, check the troubleshooting suggestions in this chapter.
Problem Solutions
No image on the TV or Monitor
Check cable connections. Check INPUT source
selection is correct.
Remote Control does not function
Check that there are no obstacles between the
remote control and the video presenter.
Check the battery in the remote control.
11

Appendix 1
Product Specifications for MVP-232
Projection Lens f=6.0 mm, F=1.6
Zoom 13X Digital Zoom
Total Effective Pixels 1024 x 768 ; 1280 x1024
Resolution 800 TV Lines (VGA)
Focusing Manual
Imager 1/3” 2 million pixel sensor
TV System PAL or NTSC
Image Store 20 Images
Signal to Noise Ratio >50 dB
Negative / Positive Selectable
Color / B&W Selectable
White Balance Automatic
Image Freeze Yes
Image Comparison Yes, Live and Saved
RGB Mode XGA, SXGA
Brightness Adjustable
Input Ports RGB x 1, DC In
Output Ports RGB x 1, C-VIDEO x 1, USB x 1
Head Rotation 360 Deg.
Size
130(L)x140(W)x45(H)mm(Base)
(5.1"x5.5"x1.8")
Weight 1 kg / 2.2 lb.
Power DC 12V 1.5 A, 15W Power Consumption
Included Accessories
User's Manual, VGA Cable, Remote
Control,AC/DC Power Adaptor, VGA In
Adaptor Cable, Carrying Bag
12
