Operating Instructions
MEIKO - Tray washing machine
Modell BTA 160 / BTA 240
MIKE 3 - CE
TRANSLATION OF THE "ORIGINAL OPERATING INSTRUCTIONS"
The original operating instructions can be downloaded from: https://partnernet.meiko.de

Operating Instructions Tray washing machine Modell BTA 160 / 240
Datei:BA_BTA_9668415_EN_2009-10.docx 9668415
2/48
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
Contents
Page
1Introduction and general information 4
1.1 Storage 5
1.2 Name and address of manufacturer 5
1.3 Description of the type of equipment 5
2Explanation of the safety symbols used 5
3Use of the appliance for the purpose intended 6
4CE-Declaration of Conformity 6
4.1 CE-Declaration of Conformity 7
4.2 Declaration of Incorporation 8
5General safety instructions 10
5.1 Operator's duty of care 10
5.2 Basic safety measures 11
6Assembly instructions (for a partially completed machine) 13
7Delivery, shipping, installation and assembly 14
7.1 Delivery 14
7.2 Transport and installation 14
7.3 Installation and assembly 18
7.4 Floor load from the dish-washing machine 18
7.5 Instructions for the disposal of the packaging material 18
7.6 Connection to the electricity supply. 19
7.7 Temperature sensors / Temperature limit switches 20
7.8 Fresh water connection 21
7.9Waste water connection 22
7.10 Hot steam, hot water from the pumps 23
7.11 Exhaust air connection of the appliance 24
7.12 Installation and connection of dosing units 24
8Machine settings for initial commissioning by the service engineer 25
8.1 Commissioning 25
8.2 Chemical product settings 25
8.3 Works to be carried out before initial commissioning 26
8.4 Setting the temperature of the wash tank, clean water rinsing, drying 26
8.5 Program selection/ Conveyor speed 28
9Preparation – Operation 28
10 Operation 29
10.1 Washing interruption 30
11 Shutting the appliance down 31
12 Short operating instructions 32
13 Cleaning 33
13.1 Safety instructions for cleaning 33
13.2 Cleaning after operation 33
13.3 Cleaning instructions – daily 34
13.4 Care of stainless steel surfaces 35
13.5 Cleaning after operation 35
14 Tips for self-help in the case of faults 37
15 Staff training 38
16 Disposal of the installation 38
17 Noise level 38
18 Non-ionizing radiation 38
19 Maintenance 39
19.1 Basic safety measures during normal operation 39

Operating Instructions Tray washing machine Modell BTA 160 / 240
Datei:BA_BTA_9668415_EN_2009-10.docx 9668415
3/48
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
20 Maintenance recommendation 40

Operating Instructions Tray washing machine Modell BTA 160 / 240
Datei:BA_BTA_9668415_EN_2009-10.docx 9668415
4/48
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
1 Introduction and general information
Dear Customer,
We are delighted about the confidence you have shown in our products.
It is very important to us that you should obtain significant use from MEIKO products and
that they should make your work easier.
If you follow the instructions in this document carefully, your dishwashing machine will
always give you total satisfaction and will have a long service life.
The dishwashing machine has been assembled by us at the factory and has undergone a
thorough inspection. This provides us with the certainty and you with the guarantee that
you will receive a fully developed product.
We would therefore ask you to read these operating instructions carefully before
using the installation. Any further associated operating instructions for
accessories and integrated third-party products must be strictly observed!
These operating instructions inform users of this installation about the installation, its
operating methods, Its use, the safety instructions and the maintenance.
This information will help you to get to know the installation fully and to use it properly. It
will also enable you to avoid repairs and the related loss of operational time.
In the event of any damage caused by non-observance of these operating instructions,
any guarantee claims are invalid. We accept no liability for any additional damage caused
as a result.
MEIKO is constantly working on the further development of all its models.
We would therefore ask you to understand that because of this, we must reserve the right
to make modifications at any time to any items covered by the contract in terms of their
shape, fittings and technical characteristics.
No claims may therefore be based on the details, the images or the descriptions
contained in these operating instructions.
Should you require any further information, or in case any particular problems not dealt
with in great detail in the operating instructions should arise, you may contact the relevant
MEIKO branch to obtain the information you require.
We should also like to inform you that the contents of these instructions do not form part
of or amend any earlier or existing agreement, statement, or legal position.
All MEIKO’s obligations arise from the relevant purchase contract which also contains the
entire and only valid guarantee provisions.
The operating instructions must exist in the local language for each EU country. If this is
not the case, the dish-washing machine must not be commissioned.
The original operating instructions in Germany, and all operating instructions in all
languages for EU countries can be downloaded from the following address:
https://partnernet.meiko.de
The complete technical documentation is issued to you free of charge.
Additional copies will be charged at cost.
These contractual guarantee rules shall be neither extended nor restricted as a result of
any explanations given in the instructions.
MEIKO very much hopes that you will enjoy our product and use it successfully.

Operating Instructions Tray washing machine Modell BTA 160 / 240
Datei:BA_BTA_9668415_EN_2009-10.docx 9668415
5/48
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
1.1 Storage
Always store the operating instructions close to the installation!
The operating instructions must always be kept within easy reach!
When contacting us, always have the Operating Instructions open in front of you so that
our staff can refer to them.
1.2 Name and address of manufacturer
Please address any queries, technical problems etc. directly to:
MEIKO Maschinenbau GmbH & Co. KG
Englerstraße 3
D - 77652 OFFENBURG
Phone + 49 (0)781 / 203-0
http://www.meiko.de
[e-mail]
or:
Name and address of the MEIKO branch, manufacturer’s agent or dealer.
(Insert company stamp or address)
1.3 Description of the type of equipment
Please provide the following information on any query and/or when ordering spare parts:
Type:
SN:
These information can be found on the plate in the electrical switch cabinet
2 Explanation of the safety symbols used
The following safety symbols will appear throughout these operating instructions. The
purpose of these symbols is to draw the reader’s attention to the text of the adjacent
safety information.

Operating Instructions Tray washing machine Modell BTA 160 / 240
Datei:BA_BTA_9668415_EN_2009-10.docx 9668415
6/48
We reserve the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstraße 3, D-77652 Offenburg, Tel.: [phone], Fax: [phone]
IMPORTANT!
This symbol warns that there is danger to human life and health.
DANGER!
This symbol warns that there is danger to the installation, to material
or to the environment.
This symbol denotes information that helps you to understand the
installation’s operation.
Warning of dangerous electrical current!
Warning of possible hand injuries!
3 Use of the appliance for the purpose intended
The tray washing machine must be used only in accordance with regulations.
The tray washing machine BTA 160 / BTA 240 is exclusively designed for the washing
and drying of trays in a
horizontal position.
Only one tray size can be used.
Other objects must not be passed through the machine.
This
dish-washing machine is intended solely for use in a commercial environment.
4 CE-Declaration of Conformity
A Declaration of Incorporation is provided with the machine if it is not supplied in fully
operational state, that is, as a partially completed machine pursuant to the Machine
Directive.
An EC Declaration of Conformity is provided with the machine if it is supplied in fully
operational state as a complete machine.
DANGER!
