Meinberg ANZ14 User manual

Meinberg Radio Clocks
Lange Wand 9
31812 Bad Pyrmont, Germany
Phone: [phone]
Fax: [phone]
https://www.meinbergglobal.com
[email protected]
ANZ14: LED Display with DCF77 Radio Clock Option (ANZ14/DCF77)
The 14-digit LE-Display shows the time, date and day-of-week. The displays brightness is adjustable via the
menu. RS232 or 20mA-interface, unlimited series connection possible, with buffered hardware clock and
integrated power supply unit.
The Network option [1]ANZ14/NET: can act as a slave clock for [2]Meinberg LANTIME NTP Time Server.
Key Features
- Stand Alone Radio Clock or Display for external Clock
- Adjustable display brightness
- Good visible LED Display for Time, Date and Day-of-the-Week
- Buffered hardware clock
- optional as Slave Clock for Meinberg LANTIME NTP Time Server (ANZ14/NET)
- Integrated Power Supply (100 - 240VAC)
- Configuration with two push buttons and setup menu.
rev 2023.0216.1037 anz14Page 1/4

Description
A serial time sting is generated either once per second, once per minute, on request only or never. Baudrate, framing
and time zone can be configured separately by menu and two front panel buttons. It is also possible to use the ANZ14
as a display for a preconnected clock.
Buffered Real Time Clock
In case of supply voltage failure the onboard real time clock keeps the time powered by a backup capacitor for more
than 150 hours. This capacitor does not need any maintenance and ensures that the ANZ14 returns with the actual time
information even before the first synchronization. Alternatively, the clock can be ordered with a lithium battery which has
a live time of at least 10 years guaranteed.
DCF77 Receiver Option:
The ANZ14/DCF77 model variant is a standalone radio clock with integrated DCF77 receiver. An external ferrit antenna
is used to receive the signal from the DCF77 transmitter and supplies it to the onboard LF receiver where it is
demodulated by a straight detector with automatic gain control.
The ANZ14/DCF77 will be delivered with an indoor antenna AI01 and 5m cable or, by customers specifications, with an
outdoor antenna option AW02. Antenna cables can be prefabricated as required. The connection to the external
antenna can be done via BNC connector at the rear panel of the display.
Serial Interface
The ANZ14 provides two serial ports which can either be used as RS232 or RS422 interfaces. The COM0 interface
provides an RS422 output, COM1 provides an RS422 input. On this way, a ANZ14 with DCF receiver can synchronize
an additional ANZ14 without receiver. The transfer rate and the data format are free selectable. The serial port can sent
a time string once per second, once per minute or only on request by sending an ASCII character '?' (ASCII code 3Fh).
rev 2023.0216.1037 anz14Page 2/4

Characteristics
Features Interface !Two Interfaces (RS232 / RS422)
Receiver Type ANZ14/DCF77: Narrowband straight receiver with automatic gain control, Bandwidth:
approx. 40Hz
Display 12 numeric LED digits for time and date
2 alphanumeric LED digits for day of the week
14mm/13mm character height (time/date), variable brightness
Modulation indicated by LEDs
Setup menu for configuration
Without RF signal the clock runs on XTAL with an accuracy of ±1·10-6 (after 24 hours of
synchronous operation), indicated by LED
Reception Monitoring Multiple check of received time telegram
Plausibility control by using two complete time telegrams
Interface Two serial Interfaces - RS232 / RS422, configurable by menu,
Baudrate: 9600 baud
Framing: 8N1
RS422 Out via COM0; RS422 In via COM1
Output Strings: [3]Meinberg Standard Time String, Atis or SAT-String
Electrical connectors 9pin SubD female connector
BNC female connector (ANZ14/DCF77 only)
power cord receptacle
Power Supply 100 - 240 V AC (50 - 60Hz), 100mA or
9 - 36 V DC, 500mA or
20 - 60 V DC, 250mA
(please specify with your order)
Backup battery type When main power supply fails, hardware clock runs free on quartz basis, life time of
lithium battery min. 10 years
Form Factor Aluminium stack case (optional: black anodised)
height x width x depth (72mm x 144mm x 132mm), for cutouts of 140mm x 68mm
Ambient Temperature 0 to 50 °C (32 to 122 °F)
Humidity Max. 85% (non-condensing) at 40 °C
Contents of Shipment DCF77ANZ only: Scope of supply includes an active ferrite antenna [4]AI01 and 5m of
RG174 coaxial cable.
Optional: [5]AW02 with RG58 and patch cord (pre-assembled on demand).
Warranty Three-year warranty
Options Equipped with a network connector RJ45 in the rear panel and special software the
ANZ14 can be used as a Slave Clock for Meinberg LANTIME NTP Time Server [6]
(ANZ14/NET).
rev 2023.0216.1037 anz14Page 3/4

RoHS Status of Product This product is fully RoHS-compliant.
WEEE Status of Product This product is handled as a B2B (Business to Business) category product. To ensure
that the product is disposed of in a WEEE-compliant fashion, it can be returned to the
manufacturer. Any transportation expenses for returning this product (at end-of-life)
must be covered by the end user, while Meinberg will bear the costs for the waste
disposal itself.
Manual
The English manual is available as a PDF file: [7]Download (PDF)
