Melissa & Doug Multi-Activity Play Table User manual

Multi-Activity
Play Table
ASSEMBL V INSTRUCTIONS
Have a
question
or need help?
Give
us a call!
1-800-284-3948
Item# 2371
We care about your comments. Please call us!
~sa.-tDo~
1-soo-2s4.3q4s
www.MelissoAndDoug.com
Melissa & Doug products meet or exceed U.S. testing
standards and pass our high quality requirements.
© Melissa & Doug, LLC , P.O. Box 590 , Westport, CT 06881
MADE IN CHINA
.& WARNING:
CHOKING HAZARD • Small Parts.
Not for children under 3 years .
Ages3+
.& CAUTION:
ADULT ASSEMBLY REQUIRED .

Melissa & Doug
Customer Service: 1-800-284-3948
THANK YOU!
Thank you for choosing the Melissa & Doug Multi-Activity Play Table! It's a terrific way to help nurture a
child's creativity
and imagination, and to inspire hands-on independent play for years to come.
NOW IT'S TIME TO PUT IT TOGETHER!
Don't worry, assembling your new table is simple, and we're here to help. It may go a little faster with a
partner to lend a hand, but we've made it so one person can assemble the table. l-lere are a few tips before
you begin:
•Read
through all the instructions first.
•
Clear a flat, covered space (carpeted is best) to lay out all the materials so everything is close at hand.
•You
will need a Phillips head and flat head screwdriver (not included) to assemble the table. We've
included everything else you need. All parts are labeled with a sticker (A-V).
•
The instructions include lots of helpful pictures-we show you, step-by-step, how to align pieces and parts
for speedy and accurate assembly. Note that the hardware needed for each step is shown in the upper
right corner of the page, each piece being added in a given step is highlighted in gray, and the "assembled
view" (what it looks like in the completed product when the step is completed) is included in the lower
right
corner of every page.
•
In the instructions, the name of a part is followed by a letter in parentheses. This letter corresponds to
the sticker on the part, as well as the picture of the part shown on pages 2-3.
•l-lelpful hints
are highlighted with a large exclamation point.
IMPORTANT: Helpful hints
are found here.
•
If you have any questions, we're here for you! Give our customer service team a call at 1-800-284-3948!
WARNINGS!
Retain these instructions for future reference.
Warning-Prevent Tip Overs!
•Do
not allow children to pull, climb, sit, or stand on any part of the table.
• Never place computers, televisions, or other heavy objects on top of the table.
• The table must be placed on a hard, flat, and level surface.
• !=or more information on how to prevent furniture tip overs in your home, visit Anchorlt.gov.
•
The table must be assembled as instructed.
MAINTENANCE:
Ensure the table continues to function properly and safely by regularly checking the hardware and
tightening when necessary.

PARTS - Be Smart-Sort Your Parts
Before you begin assembly, make sure you have all the parts listed
below. Use the hex wrench (part
V) to attach the bolts, a Phillips
head screwdriver (not included)
to attach the screws, and a flat
head screwdriver (not included)
to align the barrel nuts.
0 rear drawer panel
G) side drawer panels (2)
C9 bottom drawer panel G) front drawer panel
G side panels (2) G front/rear supports (2)
0 front panel 4D rear panel
0 drawer stabilizer 0 table cross supports 0 wood dowel
C, drawer support
0 corner braces (4) 0 rubber bumpers (4)
Ci) surface panels (2)
2

I-IARDWARE
G long
bolt (8)
E) barrel
nut (8)
G) short
bolt (4)
8 bolt
cap (4)
0 short
screw (2)
(!) long
screw (24)
G hex wrench
l-lelpful I-lints and Tips
•Note: Some packages of hardware may have extra pieces.
•You
will need a Phillips head and flat head screwdriver (not included)
to assemble the table.
I-low to Correctly Install Barrel Nuts
IMPORT ANT: Press a barrel nut
into the hole in the part, making
sure the "-" pattern is facing up.
IMPORTANT: Using a flat head
screwdriver, turn the nut until the"-"
slot is straight and the threaded hole
is facing outward to accept the screw.
Melissa & Doug Customer Service: 1- 800 -284- 3948
3

STEP 1 - Every Journey Begins with
the l=irst Step
• First, attach the 2
side drawer panels
(part B) to the rear
drawer panel (part A)
using 4 long bolts
(part P) and 4 barrel
nuts (part Q). Make
sure the grooves on
the bottom of all the
panels face the
inside.
•
Second, slide the
bottom drawer panel
(part C) into the
grooves on the
drawer assembly.
•Third, using 4 long
bolts (part P) and 4
barrel nuts (part Q),
attach the front
drawer panel (part D)
to the drawer
assembly.
IMPORTANT:
Make sure the
grooves on the
inside are aligned.
IMPORTANT: The
drawer panel (part C)
is
slightly longer than it is
wide. It must be oriented
correctly
to slide into the
drawer assembly.
Assembled View
4

STl;:P 2 - We're l-lere to Support You
• First, using 2 short bolts (part R) and 2 bolt caps
(part
S), attach a front/rear support (part F) to
the rear panel (Part 1-1).
•Second, using 2 short bolts (part R) and 2 bolt
caps (part
S), attach remaining front/rear
support (part F) to the front panel (part G).
0
·,_ -,_ -,_ '- --,_ -
0
IMPORTANT:
Make sure the
holes on both
front/rear
supports are
facing
out .
Assembled View
Melissa & Doug Customer Service: 1-800-284-3948
5

STEP 3 -
Be
Wise Stabilize
Using
2
short
screws
(part
T),
attach
the
drawer
stabilizer
(part
I)
to
the
front
panel
(part
G).
Assembled View
6

STEP 4 - That's Right
Using 2 long screws (part U), attach
the right side panel (part E:) to the
front panel (part G).
I-IELPFUL I-IINT : This step
may be easier
to assemble
with
the table upside down.
IMPORTANT:
Make sure the
Melissa & Doug
logo
is facing out.
Assembled View
Melissa & Doug Customer Service: 1-800-284-3948
7

STEP s -Put Up a Good ~ront
Using 2 long screw (part U),
attach
the rear panel (part 1-0
to the table assembly.
1-U;:LPFUL I-IINT: This step
may be easier to assemble
with the table upside down.
Assembled View
8

STEP 6 - What's
Left
Using 4 long
screws
(part
U)
,
attach
the
left
side
panel
(part
E)
to
the
table
assembly.
Assembled
View
Melissa
&
Doug
Customer
Service: 1-800-284-3948
9

STEP 7 - Don't Be Cross
Using 4 long screws
(part U), attach the
table cross supports
(part J) to the front and
rear supports on the
inside of the table.
IMPORTANT: Make
sure
the notches in
the cross supports
are facing up.
Assembled View
STEP 8 - There's More-There's a Drawer
Slide the drawer into the opening in the
front of the table.
Assembled View
10

STE:P 9 - This Dowel Will Do Well
Slide the wooden dowel
(part K) through the hole in
the back of the drawer and
into the notch in the front
support.
Assembled View
STE:P 10 - E:xtra Support
Using 2 long screws (part U), attach the
drawer support (part L) to the
table cross supports. Make
sure the notch in the
drawer support is facing
the drawer. Slide
the wooden dowel
(part K) into the
notch in the drawer
support.
IMPORTANT: You may
need to rotate the
front of the drawer
slightly downward for
the dowel to fit.
Assembled View
Melissa & Doug Customer Service: 1-800-284-3948
11

STE:P 11 - Brace Yourself
Using 8 long screws {part U),
attach the 4 corner braces
{part M) to the notches in both
the table cross supports and
the front/rear supports.
(!) (!)
I l
! !
i i
,f= m ... -------::1,b
Assembled View
12

STEP 12 - Top it Off
• l=irst, slide the 4
rubber bumpers
(part N) onto the a
long
side of the
surface panels
(part 0). Each
panel
will have
two bumbers
• Second, place the
surface panels
(part Q) onto the
table.
Assembled View
Melissa & Doug Customer Service: 1-800-284-3948
13

YOU DID IT!
Now the real fun begins-it's time to get playing! This space-defining play area is ideal for lots of different
activities. I-I ere are some of the suggested uses and special features of the Multi-Activity Play Table:
• MANY
USES: The play possibilities are endless with this versatile table! Set up and play with train sets, blocks,
race cars, puzzles, games, dollhouses, and more! It's
the perfect spot for drawing, painting, or other arts and
crafts projects. Spread
out picture books, arrange dolls or stuffed animals, or clear a spot for a tea party!
•
LARGE PLAY AREA: With approximately 11 square feet (3.35 square meters) of play space, there's ample
room for
independent play or for lots of kids to play together. There's even enough space for multiple
activities
at once!
•
JUST Tl-IE RIGI-IT I-IEIGI-IT: At 17.5 inches tall, the activity table works for small and tall alike-toddlers will use
it as
they learn to stand and walk, and older kids will gather around it on knees, pillows, or kid-sized chairs for
years
to come!
•
STORAGE DRAWER: Use the jumbo-sized pull out drawer for convenient storage of train tracks, puzzle and
game pieces, craft supplies, and more. It's
perfect for keeping toys and crafts together, in reach, and off the
floor!
•LIFT-OUTPLAY
BOARDS: When it comes time to move or clean around the table, simply clear it off and lift out
the play boards! Clean-up is breeze!
ACC~SSORIZ~
Melissa & Doug offers lots of toys, games, and crafts that can be used with your Multi-Activity Play Table! To
find
the full range of items we offer, visit us at MelissaAndDoug.com!
