Memorex MX5510 User manual

INSTRUCTION BOOK
MINI SYSTEM DIGITAL AM/FM 5 CD CHANGER
DUAL CASSETTE RECORDER
WITH TURNTABLE AND REMOTE CONTROL
MODEL: MX5510
BEFORE OPERATING THIS PRODUCT,
PLEASE READ THESE INSTRUCTIONS COMPLETELY

CAUTION:TOPREVENTTHE RISKOFELECTRIC
SHOCK,DONOTREMOVECOVER(ORBACK).
NOUSER-SERVICEABLEPARTSINSIDE.
REFERSERVICINGTOQUALIFIEDSERVICEPERSON-
NEL.
Thissymbolindicates thatdangerous volt-
age constitutinga riskof electric shockis
present withinthis unit.
This symbol indicatesthat there areimpor-
tantoperating andmaintenanceinstructions
inthe literatureaccompanyingthis unit.
WARNING:TO PREVENT FIRORSHOCKHAZARD,DO
NOTEXPOSETHISAPPLIANCETORAINOR MOISTURE.
WARNING:UNAUTHORIZEDRECORDING OFCOPYRIGHTED
MATERIAL MAY VIOLATE APPLICABLE COPYRIGHT LAWS,
MANUFACTURER ASSUMES NO RESPONSIBILITY FORUNAU-
THORIZED DUPLICATION, USE OR OTHER ACTSWHICH
INFRINGE UPON THE RIGHTSOF COPYRIGHTOWNERS.
ExplanationofSymbols
This symbol is intended to
alert the user of the
presence of uninsulated
dangerous voltage within
the product encasement
that may be of sufficient
magnirude to constitute a
risk of electric shock to
persons.
Thissymbolis intend-
ed to alert the user of
the presence of
importantoperating
andmaintenance
(servicing)instruc-
tionsinthe literature
accompanyingthe
appliance.
WARNING
To prevent fire or shock haz-
ard,do notexpose thisappli-
anceto rainormoisture.
Ifthis happens,make sure
thepower to the electrical
outlet is turned off before.
SAFETYCERTIFICATION
Thisunit ismadeand testedto meetexactingsafety standards.
ItmeetsUL andFCCrequirementsand complieswithsafety
performancestandardsof theU.SDepartment ofHealthand
HumanServices.
CAUTION-USEOFCONTROLSORADJUSTMENTSORPER-
FORMANCEOFPROCEDURESOTHERTHANTHOSESPECIFIED
HEREINMAYRESULTINHAZARDOUSRADIATIONEXPOSURE.
THISUNITSHOULDNOTBEADJUSTEDORREPAIREDBYANY-
ONEEXCEPTPROPERLYQUALIFIEDSERVICEPERSONNEL.
FCCINFORMATION
ForCDplayer section:
Thisdevicecomplies withPart15 oftheFCC Rules.
Operationis subjectto thefollowing twoconditions:
'
'
''
'
CAUITION
DO NOT OPEN
(1)This devicemay notcause harmfulinterference, and(2) this devicemust acceptany interferencereceived, including
interferencethat maycauseundesired operation.
NOTE:
Thisequipment hasbeen tested andfound tocomply withthelimits fora ClassB digitaldevice,pursuant toPart 15of the
FOCRules.These limitsaredesigned to providereasonableprotection againstharmfulinterferencein aresidential
installation. Thisequipment generates,usesand canradiateradio frequencyenergy and,Ifnot installedandused in
accordancewith theInstalled andused inaccordance withthe Instructions,may causeharmful interferenceto radio
communications. However,thereis noguarantee thatinterference willnotoccur ina particularinstallation. If this
equipmentdoes causeharmfulinterference toradio ortelevisionreception, whichcan bedeterminedby turningthe
equipmentoff and on, the useris encouragedto try to correct theinterference byone ormore of thefollowing measures:
Relocatethereceivingantenna.
Increasetheseparation betweenthe equipmentandreceiver.
Connectthe equipmentinto outleton acircuit differentfrom thatto whichthe receiveris connected.
Consultthe dealer oran experiencedradio/TV technicianfor help.

1.ReadInstructions -All thesafety and
operatinginstructions shouldbe read
beforethe applianceis operated.
2.RetainInstructions - Thesafety and
operatinginstructionsshould be
retained for future reference.
3.HeedWarning -All warningson the
applianceandin theoperating instruc-
tions should be followed.
SafetyInstructions
Donot operatethe unitfrom anypower
scurceexcept thatindicated onthe
stereoor in the owner smanual.
Donot installthe unitnear or overa radi-
ator,orotherheat sources.
Donot mounttheunit toa wallorceiling
exceptasrecommended bythemanu-
facturer.
Donot place theunitin abuilt-inenclo-
suresuch as abookcase orcabinet, un-
lessproper ventllationisprovided.
Donotblock theventilationopenings of
theunit byplacing iton abed, soft, rug,
etc.
Donot allowobjects tofall orliquids to
spillintothe unitthroughthe openings.
Do not use the unit near water, such as
bathtub, washbowl,sink, laundry tub,
swimmingpool,etc.
Donot allowanything torest on,roll over,
or pinch the power cord, or place the
power cord where it is subject to traffic
orabuse; thismay result in a firehazard.
Do not use a cart or stand
not recommendedbythe ma-
nufacturer.
Do not try to roll cart with
small castors across
thresholds or deep pile car-
pets. Quick stops, excessive
force, and uneven surfaces
may cause the unit and cart
combination tooverturn.
Donot cleanthe unit exceptas described
inthe owners manual.
Donot attempt toservicethe unitbeyond
thatdescribed inthe owner smanual: all
otherservicing shouldbe referredto que-
lifiedservice personnel.
Donotleavethe unit onwhenunattended;
amalfunction mayresult in afire hazard.
NOTE:Foraddedprotectionduring a ligh-
tningstorm or whenever the unitwill be
leftunattended fora long periodof time,
disconnect the power source.
HaveTheUnitServiced
If
--the power cord or the plug has been
damaged.
--objectshave fallen,or liquidhas been
spilledontothe unit.
--theunit hasbeen exposedto rainor
excessivemolsture.
--theunit doesnot appearto operatenor-
mallyorexhibits amarkedchangein
performance.
--theunit hasbeen droppedor theen-
casementdamaged.
Example of Antenna Grounding as per NEC - National Electric Code
CAUTION:TOREDUCETHERISK
OFELECTRICSHOCK,DONOT
REMOVECOVER(ORBACK).
NOUSERSERVICEABLEPARTS
INSIDE;REFERSERVICINGTO
QUALIFIEDSERVICEPERSON-
NEL.
GROUNDING
CONDUCTORS
(NEC SECTION)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
GROUND
CLAMP
NEC - NATIONAL ELECTRICAL CODE
'
'
'

4
TABLE OF CONTENTS
INSTALLATION...................................................................................................................................................2~5
Accessories...........................................................................................................................................................2
Positioning Your Main Unit.....................................................................................................................................2
Rear Panel Connections........................................................................................................................................3
Connecting the Speakers.......................................................................................................................................4
Connecting Optional Equipment............................................................................................................................5
FUNCTIONAL OVERVIEW.....................................................................................................................................6~11
Front Panel..................................................................................................................................................6 - 8
LCD Display...........................................................................................................................................................9
Remote Control...........................................................................................................................................10-11
AMPLIFIER............................................................................................................................................................12
General...............................................................................................................................................................12
TIMER SETTING .........................................................................................................................................12~13
Clock Setting..........................................................................................................................................................12
Time On/Off Setting......................................................................................................................................12-13
Sleep Timer....................................................................................................................................................13
TURNTABLE/ PHONO..............................................................................................................................................14
CD CHANGER.................................................................................................................................................15~17
Loading Disc Into The CD Tray................................................................................................................................15
Disc Status..........................................................................................................................................................15
Normal CD Playback.......................................................................................................................................15
CD Random Playback......................................................................................................................................16
CD Repeat Playback..........................................................................................................................................16
Displaying Time Information..........................................................................................................................16-17
CD Program ( CD Memory )..............................................................................................................................17
TAPE PLAYER..................................................................................................................................................18~19
Loading One Tape............................................................................................................................................18
Normal Playback ( Deck A and Deck B )............................................................................................................18
Recording ( Deck A )....................................................................................................................................18-19
Sequential Playback ( Deck B to Deck A).............................................................................................................19
TUNER.............................................................................................................................................................20
Auto (automatic)/Manual Tuning...........................................................................................................................20
Preset Memory................................................................................................................................................20
GENERAL INFORMATION...............................................................................................................................21
Troubleshooting....................................................................................................................................................21
System Specifications.........................................................................................................................................22

5
ACCESSORIES POSITIONING YOUR MAIN UNIT
Thispackage contains:
- 1 Main Unit
- 2 Front Speakers
- 1 FM Antenna
- 1RemoteControl
- 1 Instruction book
Placetheunit on stable,level surface, outof direct sunlight
andawayfrom sources ofexcessive dust, dirt,heat, water,
moisture,vibration and strongmagnetic fields.
Do not connect the unit to the AC power supply until all
otherconnectionshavebeen made andtheACvoltage (in-
dicated on the type plate on the back cover) has been
checked.
Whenpositioning the unit,bear inmind thatevery receiver
produces heat which must be able to dissipate freely. For
this reason do not cover any vents and make sure that
thereis sufficientventilation aroundthe unit.
AlwaysremoveallCDsfromthechangerbeforemovingthe
system.
INSTALLATION
MAINUNIT
FM Antenna
Front Left/Right Speakers
REMOTECONTROL
++
++
_
_
MUTE
1
9
RANDOM
SKIP
TIMER
TUNING
SEARCH
VOLUME
DISC-SKIP
EQ
+10
INTRO
M-DOWN/
STOP
M-UP/
REPEAT
OPEN/
CLOSE
PLAY/
PAUSE
5
0
6
7
8
4
3
PH/AUX
TAPE
TUNER/BAND
CD
2
POWER
+
_
SLEEP
MEMO/
C.ADJ
MODE/
REMAIN

6
Plug the FM antenna to the FM terminal of the main unit.
ANTENNAORSPEAKER WIRECONNECTIONTO
TERMINALS
INSTALLATION
REARPANELCONNECTIONS
1. FM ANTENNA (FM 300 ohm)
For connecting the 300 ohm antenna supplied.
2. AUX IN (L/R)
For connecting optional video equipment.
3. FRONT SPEAKERS (4 OHM)
Connectsupplied left and right front speakers here.
4. AC POWER CORD
Pluginto astandard 120V/60Hzhousehold wall outlet.
CONNECTINGTHEFM ANTENNA
NOTE: Pushand holdspeaker terminaltab down to insert
wire. Release tab to lock wire in terminal. Make sure
the insulation is completely removed from the ends of
theantennaand speakerwiresat allconnectionpoints.
R SPEAKERS L
+
_
+
_
AUX IN
R
FM ANT L
12 3

7
INSTALLATION
CONNECTINGTHESPEAKERS
Connecting the Front Speakers
Connect the right front speaker to the front speaker ²R ²
terminal on the back of the main unit, and the left front
speaker to the front speaker ²L ²terminal.
Make sure the (+) (red) and (-) (black and red) cables are
connectedto thecorrect frontspeaker terminals [(+) to (+)
and(-) to (-)].
LL
R SPEAKERS L
+
-
+
-
RIGHT
LEFT

8
INSTALLATION
CONNECTINGOPTIONALEQUIPMENT
Connecting a Video system
Connectthe ²L²and²R²Audiooutputterminals of your
laser disc or VCR system to the ²L ²and ²R ²VIDEO
INPUTterminals ofthe mainunit.

9
FUNCTIONAL OVERVIEW
FRONTPANEL FRONTPANEL
MODE/
REMAIN
DISC SKIP
MEMO/
C-ADJ.
INTRO. PLAY/PAUSE RANDOM
5
DISC
CHANGER
FLAT
TUNER/BAND CD TAPE PHONO/AUX
SLEEP
OPEN/CLOSE
VOLUME
PHONES
RECORD/PLAY BACK
A
PLAY BACK
B
R
6
78910 11 12 13 14 15 16 17
18
19
21
22
23
20
25
4
5
1
2
3
24
27 2826

10
FUNCTIONAL OVERVIEW
12. TUNER / BAND
•Not in TUNER mode, press to set TUNER mode.
•InTUNERmode, pressto change the receiving BAND
betweenFM and AM
13. CD
•Not in CD mode, press to set CD mode.
•In CD mode, it has the same function as the DISC
SKIP key. Press to set or skip to next valid disc in
ascendingorder.
14. TAPE
Press to select the function of TAPE.
15. PHONO / AUX
Press to select the PHONO function or the AUX input
source. Both PHONO and AUX are mixing-channels.
You can mix sounds if you play the PHONO and input
another signal from the AUX at the same time.
16. OPEN / CLOSE
Press to open or close the CD door
17. DISC SKIP
•In CD memory set mode, press to set to next valid
discnumber in ascending order.
•In CD normal play or stop mode,press to skip to next
validdisc in ascendingorder.
•Not in CD mode, press to skip to next valid disc in
ascendingorder when the door is open.
18. VOLUME
Press the VOLUME button to adjust the volume level
upordown.
19. MODE / REMAIN
•In TUNER mode, press to change the following dis-
play : Band and Frequency, Time display.
•In CD normal play mode, press to change the follow-
ingdisplay : Each playing time, Each remainingtime,
Totalremainingtime,Total playingtime, Timedisplay.
•InCD randomplay mode,press to change the follow-
ingdisplay : Each playing time, Each remainingtime,
Timedisplay.
•In CD memory play mode, press to change the fol-
lowing display : Each playing time, Each remaining
time,Program number, Timedisplay.
•In CD stop mode, press to change the following dis-
play : All time display, Time display.
•In TAPE or AUX mode, press to change the following
display : AUX or TAPE, Time display.
NOTE: The above Time display includes: Clock display,
Time ON, Time OFF.
FRONTPANEL
1. REPEAT / MEMO •UP
•InCDmode, press tochangethefollowingrepeat play
mode : All disc, Rpeat all disc, Repeat one disc,
Repeatone track.
•In TUNER mode, press to display the preset memory
inascendingorder.
2. STOP / MEMO •DOWN
•In CD mode, press to stop CD playing and exit CD
memoryregistrationmode.WhenCDisstoped,press
this key to clear CD memory.
•In TUNER mode, press to display the preset memory
indescendingorder.
3. TIMER
Press to set timer on or off. When timer is on, will
illuminate.
4. ST. / NOR & MONO. / H.S.D.
•In TAPERECORDmode, press toselectnormal mode
orto increase the TAPE recording speed to twice the
normalrecordingspeed.
•In FM mode, press to select either STEREO sound or
MONOsound.
5. SLEEP
Pressto select theSLEEP timeron oroff. Keep press-
ing this key to set the sleep time from 00 to 90 min-
utes.
6. POWER
Press the POWER button to switch the main power of
the unit to ON or STANDBY.
7. FLAT
Press to select FLAT sound mode.
8. ROCK
Press to select ROCK sound mode.
9. CLASSIC
Press to select CLASSIC sound mode.
10. POP
Press to select POP sound mode.
11. SENSOR
Infrared rays sensor, to receive the information
transmittedfrom theremote control.
FRONTPANEL

11
FUNCTIONAL OVERVIEW
FRONTPANEL
20. PHONES
Plugheadphonesintothisjack.Pressthevolumebutton
to adjust the sound level.
21. MEMO / C-ADJ.
•In TUNER mode, press to store AM/FM stations in
the memory locations.
•In CD mode, press to do CD program in memory
locations.
•In clock adjust mode, press to set clock or timer
adjustment.
22. TUNING •UP / NEXT
•In TUNER mode, press less than 0.5 second to do
manualtuningin ascendingorder.
•In TUNER mode, press longer than 0.5 second to do
autotuning in ascendingorder.
•InCD mode, presslessthan0.5 second tomovetrack
inascendingorder.
•In CD mode, when CD is playing, press longer than
0.5 second to search in ascending order.
•Inclock or timeradjusting mode,press to adjustclock
timein ascending order.
23. TUNING •DOWN / PREVIOUS
•In TUNER mode, press less than 0.5 second to do
manualtuningin descendingorder.
•In TUNER mode, press longer than 0.5 second to do
autotuning in descendingorder.
•InCD mode, presslessthan0.5 second tomovetrack
indescendingorder.
•In CD mode, when CD is playing, press longer than
0.5second to search in descendingorder.
•Inclock or timer adjusting mode, press toadjust clock
timein descending order.
24. [ DECK A ] CASSETTE FUNCTION KEYS
•RECORD .............Press to activate cassette
recording.
•PLAY .....................Press to activate cassette
playing.
•REWIND............Press to activate cassette
rewinding.
•F. FWD. .............Press to activate cassette
fastforwarding.
•STOP / EJECT ..Press once to stop play, re-
windor fast forward.Press a
second time to eject the
cassette.
•PAUSE...............Press to pause playback.
FRONTPANEL
25. [DECK B ] CASSETTEFUNCTIONKEYS
•PLAY..................Press to activate cassette
playing.
•REWIND.............Press to activate cassette
rewinding.
•F. FWD. .............Press to activate cassette
fastforwarding.
•STOP / EJECT ...Press once to stop play, re-
windor fast forward.Press a
second time to eject the
cassette.
•PAUSE ...............Press to pause playback.
26. INTRO
Pressto set or release the intro scanplay mode inCD
mode.
27. PLAY / PAUSE
Press to begin playback of the CD and press again to
pauseCD playback.
28.RANDOM
Pressto toggle CD random play mode. TheRANDOM
indicatorappearson the displayand tracks onall discs
are played in random order. When the last track of the
last disc is played, the system will automatically stop,
unlessyou haveselected REPEAT mode.

12
FUNCTIONAL OVERVIEW
13. CLASSIC
Illuminates if the CLASSIC EQ mode is selected.
14. DISCNUMBER
Illuminates if the corresponding tray has disc in CD
mode.
15. FLAT
IIIuminates if the FLAT EQ mode is selected.
16. RECCDSYNC
IlluminatesiftheCD-SYNCtaperecordingfunctionhas
beenselected.
17. MHz/KHz
Illuminates while the FM or AM station has been se-
lectedin TUNER mode.
18. INTRO
Illuminatesif you selectthe INTROplay functionin CD
mode.
19. ON / OFF
will illuminate if the Timer is on by pressing the
TIMER button on the remote to select.
ON will flash if Time ON function is selected by
pressing the MODE / REMAIN button on the remote
repeatedly.
OFF will flash if Time OFF function is selected
bypressingtheMODE / REMAINbuttonon the remote
controlrepeatedly.
LCDDISPLAY
1. TOTAL
Illuminates if you select the total remain time or total
time in CD normal play mode.
2. MEMORY
Illuminates if any track or station has been stored to a
CD program or tuner memory in CD mode or TUNER
mode.
3. REMAIN
Illuminates if you select the each remain time or total
remain time in CD play mode.
4. SLEEP
Illuminates if you select the SLEEP function.
5. STEREO
Illuminates ifastereo singal isreceived in tunermode.
6. MUTE
Illuminates if you select the MUTE function.
7. RANDOM
Illuminatesifyouselect the randomplayfunction in CD
mode.
8. Illuminates during CD playback mode.
9.
Illuminates when CD playback has been paused.
10. REPEAT
Illuminates if you select the repeat play function in CD
mode.
11. POP
Illuminates if the POP EQ mode is selected.
12. ROCK
Illuminates if the ROCK EQ mode is selected.
LCDDISPLAY
24
56 7 8 9 10 11 12 13
1516171819
114
3 24 56 7 8 9 10 11 12 13
1516171819
114
3

13
FUNCTIONAL OVERVIEW
REMOTECONTROLREMOTECONTROL
4. 0 - 9 / +10
•In CD mode, press to select favorite track.
•In TUNER mode,press to select favorite preset sta-
tion.
5. MODE / REMAIN
•In TUNER mode, press to change the following dis-
play : Band and Frequency, Time display.
•In CD normal play mode, press to change the follow-
ingdisplay : Each playing time, Each remainingtime,
Totalremaining time, Totalplaying time,Timedisplay.
•InCD randomplay mode,press to change the follow-
ingdisplay : Each playing time, Each remainingtime,
Timedisplay.
•In CD memory play mode, press to change the fol-
lowing display: Each playing time, Each remaining
time,Program number,Timedisplay.
•In CD stop mode, press to change the following dis-
play : All time display, Time display.
•In TAPE or AUX mode, press to change the following
display : AUX or TAPE, Time display.
6. MUTE
Presstocancelsound. Press againtoreturn the sound
toitsprevious level.The MUTE indicatorwill illuminate
whenthe MUTE functionis on.
7. PH. / AUX
Press to select the PHONO function or the AUX input
source. Both PHONO and AUX are mixing channels.
You can mix sounds if you play the PHONO and input
another signal from the AUX at the same time.
8. TAPE
Press to select the function of TAPE.
9. EQ
PressEQbuttonrepeatedlyto selectROCK,CLASSIC,
POPorFLAT EQsettingand the adjacentindicatorwill
illuminate.
1. POWER
Press the POWER button to switch the main power of
the unit to ON or STANDBY.
2. CD
•If not in CD mode, press to set CD mode.
•In CD mode, it has the same function as the DISC
SKIP key. Press to set or skip to next valid disc in
ascendingorder.
3. TUNER/BAND
•If not in TUNER mode, press to set TUNER mode.
•InTUNERmode,press to changethereceiving BAND
betweenFM and AM.
INSTALLING BATTERIES:
1.Remove thebattery coverfrom the back of the remote.
2. Insert 2 *AA* batteries into the remote, paying careful attention to the polarity
diagram (+ / -) on the battery compartment cover.
3.Replace the battery cover.
++
++
_
_
MUTE
1
9
RANDOM
SKIP
TIMER
TUNING
SEARCH
VOLUME
DISC-SKIP
EQ
+10
INTRO
M-DOWN/
STOP
M-UP/
REPEAT
OPEN/
CLOSE
PLAY/
PAU SE
5
0
67 8
43
PH/AUX
TAPE
TUNER/BAND
CD
2
POWER
+
_
SLEEP
MEMO/
C.ADJ
1
2
3
4
5
6
7
8
9
MODE/
REMAIN

14
FUNCTIONAL OVERVIEW
REMOTECONTROL
NOTE: The above Time display includes: Clock display,
Time ON, Time OFF.
10. MEMO / C-ADJ.
•In TUNER mode, press to store AM/FM stations in
the memory locations.
•In CD mode, press to do CD program in memory
locations.
•In clock adjust mode, press to set clock or timer
adjustment.
11. OPEN / CLOSE
Press to open or close the CD door.
12.RANDOM
Pressto toggle CD random play mode. TheRANDOM
indicatorappearsonthe displayand trackson alldiscs
are played in random order. When the last track of the
last disc is played, the system will automatically stop,
unlessyou haveselected REPEAT mode.
13. INTRO
Pressto set or release the intro scanplay mode inCD
mode.
REMOTECONTROL
14.SLEEP
Pressto select theSLEEP timeron oroff. Keep press-
ing this key to set the sleep time from 00 to 90 min-
utes
15. M-UP / REPEAT
•InCDmode,pressto change thefollowingrepeatplay
mode : All disc, Repeat all disc, Repeat one disc,
Repeatone track.
•In TUNER mode, press to call the preset memory in
ascendingorder..
16. DISC SKIP
•In CD memory set mode, press to set to next valid
discnumber in ascending order.
•In CD normal play or stop mode,press to skip to next
validdisc in ascendingorder.
•Not in CD mode, press to skip to next valid disc in
ascendingorder when the door is open.
17. STOP / DOWN
•In CD mode, press to stop CD playing and exit CD
memoryregistration mode.When CDis stoped, press
this key to clear CD memory.
•In TUNER mode, press to display the preset memory
indescendingorder.
18. SKIP (-) or (+)
•In TUNER mode, press less than 0.5 second to do
manualtuning.
•In TUNER mode, press longer than 0.5 second to do
autotuning.
•InCD mode, presslessthan0.5 second tomovetrack
upordown.
•In CD mode, when CD is playing, press longer than
0.5 second to search up or down.
•Inclock or timeradjusting mode,press to adjustclock
time.
19.PLAY/PAUSE
Press to begin playback of the CD and press again to
pauseCD playback.
20. VOLUME (-) or (+)
Press (+) or (-) button to adjust the sound level up or
down.
++
++
_
_
MUTE
1
9
RANDOM
SKIP
TIMER
TUNING
SEARCH
VOLUME
DISC-SKIP
EQ
+10
INTRO
M-DOWN/
STOP
M-UP/
REPEAT
OPEN/
CLOSE
PLAY/
PAUSE
5
0
678
43
PH/AUX
TAPE
TUNER/BAND
CD
2
POWER
+
_
SLEEP
MEMO/
C.ADJ
11
12
10 13
14
15
17
18
19
20
16
MODE/
REMAIN

15
CLOCKSETTINGGENERAL
1. Press the POWER button to turn the system on.
2. Select the source by pressing the desired source se-
lectorbutton:
•Press the TUNER button to listen to a radio station.
•Press the TAPE button for audio cassette.
•Press the CD button to listen to a compact disc.
•PressthePHONO /AUX buttonto select phonograph
functionor for alaser discplayer,camcorderor VCR,
etc...
3. Pressthe VOLUME buttonon the frontpanel or on the
remotecontrol toadjust thevolume levelup ordown.
4. PresstheEQbuttonrepeatedlytoselectapresetequal-
izer mode: ROCK , CLASSIC, POP or FLAT.
NOTE: The Graphic Equalizer separates and adjusts the
bass,midrange and treble levels.These preset selec-
tions adjust the sound to simulate and enhance the
acoustical effects of ROCK, CLASSIC, POP or FLAT.
5. PresstheMUTEbuttontocancel thesound.TheMUTE
indicator will illuminate. Press again to return to origi-
nalsoundlevel.
AMPLIFIER TIMER SETTING
1. Turn the system on and press the MODE / REMAIN
button until the clock appears in the display.
2. Press the MEMO / C-ADJ button one time and hour
digitwillflash.Thenpress the TUNING•DOWN/PRE-
VIOUSorTUNING •UP/NEXT buttonuntilthe correct
hourdigitappears.
3. PresstheMEMO/C-ADJbutton again and minute digit
will flash. Then press the TUNING • DOWN / PREVI-
OUS or TUNING • UP / NEXT button until the correct
minutedigit appears.
TIME ON SETTING
1. Turn the system on and press the MODE / REMAIN
button until the Time ON appears.
Your music center can automatically turn itself on or off
when the on or off time arrives.
TIME ON / OFF SETTING

16
TIMER SETTING
3. Pressthe MEMO /C-ADJ buttonagain andminute digit
will flash. Then press the TUNING • DOWN / PREVI-
OUS or TUNING • UP / NEXT button until the correct
minutedigit appears.
TIME OFF SETTING
1. Press the MODE / REMAIN button until the Time OFF
appears.
2. Press the MEMO / C-ADJ button one time and hour
digit will flash. Then press the TUNING • DOWN /
PREVIOUS or TUNING • UP / NEXT button until the
correcthour digit appears.
NOTE: Make sure TIMER appears in the top left corner.
If TIMER dose not appear on LCD display, press
TIMER button on remote control and follow steps
above to set.To cancel TIMER ON/OFF setting,
press TIMER button on remote control again until
the TIMER disappears from LCD display.
Your system can automatically turn itself off after 10 to 90
minutes. Choose the period that you wish system to stay
on, and when the “SLEEP” time arrives, the system will
turn itself off automatically.
1. Turn the system on and press SLEEP button. The
“SLEEP” indicator will illuminate.
2. Press the SLEEP button continuously to set the sleep
time from 90 to 10.
4. Press the TIMER button until the appears, then
press the POWER button to turn the system to
STANDBYmode.
NOTE: Make sure the is displayed. The system will
automatically turn on/off itself when set time arrives.
SLEEPTIMER
3. Pressthe MEMO /C-ADJ buttonagain andminute digit
will flash. Then press the TUNING • DOWN / PREVI-
OUS or TUNING • UP / NEXT button until the correct
minutedigit appears.
2. Press the MEMO / C-ADJ button one time and hour
digit will flash. Then press the TUNING • DOWN /
PREVIOUS or TUNING • UP / NEXT button until the
correcthour digit appears.

17
TURNTABLE
PHONO PHONO
CONTROLSANDFEATURES
1. 45 rpm Adaptor
2. Turntableplatter
3. Cueinglever
4. Speed selector
5. Tone arm
6. Tone arm rest
PLAYING ARECORD:
1. Switch the system on using the POWER button.
2. Removethe stylus (needle) cover.
3. Unlock the tone arm using the tone arm lock.
4. Use the function selector to select the PHONO / AUX
position.
5. Set the speed selector to either 33 rpm or 45 rpm
according to the record to be played.Use the 45 rpm
spindle adaptor to play 45 rpm records.
6. Placea record on theturntable. Usingthe cueinglever,
raisethetone arm.Move the tonearm outwards, away
fromtheturntable platter.Theturntable platter willstart
to rotate.
7. Move the tone arm over the record and release gently.
The stylus will lower onto the record and start to play.
8. Adjust the VOLUME control to obtain desired listening
level.
9. Adjust the graphic equalizer to suit your listening
pleasure.
10. During play(if you wish so) move the tone arm inward
towardsthecenteroftheturntableplatter,thusswitching
it off. Be sure the tone arm is replaced and locked
correctlyusingthetonearmlock.Thiswillavoiddamage
to the stylus when the record deck is not in use.
11.Whentherecordhasfinishedplaying,theturntableplatter
willswitch offautomatically. Secure tonearm usingthe
tone arm lock.
NOTE: Ifyouinput asignalfrom theAUX jack whilePhono
isplaying, you mayhear both simultaneously.
33
45
3
2
4
5
6
1

18
CD CHANGER
NORMALCDPLAYBACKLOADING A DISC INTO THE CD TRAY
DISC STATUS
To check the disc status, first press the PLAY / PAUSE
button to start playback, then press the DISC SKIP button
once for each disc.
1. When the particular disc tray is being checked by the
playbacksensor,thetotaltracksnumber andtotaltime
willbe readand displayed.
2. If there is no disc in the selected tray, the disc number
indicator light will go out.
1. Press the PLAY / PAUSE button to start playback.
Press repeatly to start or pause the CD playback.
2. The playback sensor will search the disc trays.
3. If the first disc tray is empty, the disc number indicator
for that disc will disappear. Then the playback sensor
will detect the next disc and the semi-circle indicator
for the next disc will illuminate.
4. Whenthe first discis found,it willimmediately begin to
readand display thetotal tracksnumber andtotal time
of this disc. Press the PLAY / PAUSE button to begin
playback from track 1.
5. Press the TUNING • DOWN / PREVIOUS or TUNING
• UP / NEXT button briefly to select the desired track.
6. Press and hold the TUNING • UP / NEXT button to
moveforward.
7. Press and hold the TUNING • DOWN / PREVIOUS
buttontomove backward.
8. Press the STOP / MEMO • DOWN button to stop CD
playback.
9. You can interrupt CD playback by pressing PLAY /
PAUSE. Press the same key again to resume play-
back.
10. Toselect anotherdisc, simply pressthe DISC SKIP or
CDbuttonrepeatedly untilthe desired discis selected.
1. Press the POWER button to switch on the system.
2. Select the CD function by pressing the CD button on
the front panel. You can also press the CD button on
theremote control.
3. The disc indicator corresponding to the currently se-
lecteddisc willbe surroundedby an illuminating semi-
circle at all times.
4. Pressthe OPEN /CLOSE buttonto openthe CD door.
5. Insert only one disc into each of the five CD trays.
6. To insert a disc into the fifth tray, press the DISC SKIP
orCD button andthe fifthdisc positionwill rotate tothe
frontautomatically.
7. Press the OPEN / CLOSE button again to close the
CDdoor.
1
2
3
4
5
5
1
2
3
4

19
CD CHANGER
CDREPEATPLAYBACK
1. Pressthe RANDOMbutton beforeor duringplay.
2. TheRANDOMindicatorilluminates and tracksarenow
playedin a randomorder.
CDRANDOM PLAYBACK
3. Each time you press the TUNING• UP /NEXT button
the next random track will play.
4. Press the TUNING • DOWN / PREVIOUS button to
return to the beginning of the track.
5. Press the RANDOM button again if you wish to return
to normal play.
3. Press the REPEAT / MEMO • UP button three times
before or during playback to select the REPEAT ONE
mode. When this mode is selected, the same track
willbe played repeatedly.
4. Press the REPEAT / MEMO • UP button four times to
cancel the Repeat Playback function.
1. Pressthe REPEAT/MEMO•UP buttononce before or
duringplaybacktoselectthe REPEAT ALLDISCmode,
andthe²REPEATALL DISC²indicatorwill illuminate.
When this mode is selected, the tracks on all discs
willbe played repeatedly.
CDREPEATPLAYBACK
2. Press the REPEAT / MEMO • UP button twice before
or during playback to select the REPEAT ONE DISC
mode, and the ²REPEAT ONE DISC ²indicator will
illuminate. When this mode is selected, all tracks on
oneparticular disc willbe played repeatedly.
DISPLAYINGTIMEINFORMATION
1. In CD normal play mode, press MODE / REMAIN but-
ton to change the following display :
•Playing time of current track.
•Remaining time of current track.
1
2345
1
2345
1
2345
1
2345
1
2345
1
2345

20
CD CHANGER
CD PROGRAM ( CD MEMORY )
Storing a Program
1. In CD stop mode, press the MEMO / C-ADJ button to
selectthe CDprogram function.
2. The track number, program number and “MEMORY”
indicators will flash.
4. Press the MEMO / C-ADJ. button to store the track
numberyouselected intothe CD program,and the CD
program number will skip one step forward to wait for
you to select and store another track number.
NOTE: You can also select and store the track number
directly with the number keys 0-9 / +10 on the remote
control.
5. Select another track number and store the track into
the CD program by following step 3 to step 4.
6. Up to 40 CD tracks can be programmed. When 40
tracks have been stored, the ²FULL ²indicator will
illuminate.
Checking a Program
1. In CD PLAYBACKmode,press the TUNING • DOWN
/PREVIOUS orTUNING • UP/ NEXT button tocheck
theCD programwhich youstored.
2. EachtimetheTUNING•DOWN/ PREVIOUS or TUN-
ING • UP / NEXT button is pressed, the CD program
number appears together with the corresponding disc
andtrack number.
Playing a Program
1. Press the PLAY / PAUSE button to start the CD pro-
gram from the first track you stored.
2. Alsoyou can pressthe TUNING •DOWN /PREVIOUS
or TUNING • UP / NEXT button to select a particular
track to play from the CD program.
3. Programmed tracks will remain stored in the memory
(even when the system is switched off) until they are
erased.
Erasing a Program
In CD stop mode, press the STOP / MEMO • DOWN
buttontoerasetheCD program. TheMEMORYindica-
tor goes out and the program is erased.
NOTE: When the CD program has been done, you can
onlyplay thememory tracks.Unless you erase the CD
program,the CD normalplaying cannot be resumed.
•Total remaining time of current disc
•Total playing time of current disc.
3. Select the disc number by pressing the DISC SKIP
button,andpresstheTUNING•UP/NEXTorTUNING
• DOWN / PREVIOUS button until the desired track
number that you wish to program appears on the dis-
play.
1
2
3
4
5
1
2345
1
2
3
4
5
