MEN G304 User manual

User Manual

G304
Unmanaged 4-Port Rugged Industrial Ethernet Switch
with PoE+
3U CompactPCI Serial
2017-02-0120G304-00 E1

20G304-00 E1 2017-02-01 Page 2
Contents
Contents
Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About this Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Legal Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 External Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
1.4 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
1.5 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1.6 Product Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1 Connecting and Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3 Functional Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
3.2 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
3.2.1 Front Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
3.2.2 Rear Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2.3 Signal Mnemonics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2.4 Ethernet Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.2.5 Ethernet Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.2.6 Power over Ethernet (PoE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.3 CompactPCI Serial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Figures
Figure 1. Front interfaces (standard RJ45 model (left) and optional M12 model (right))9
Figure 2. Board layout – top view (without heat sink). . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Figure 3. Block diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Figure 4. Product labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Tables
Table 1. Connector types – Ethernet (RJ45). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Table 2. Pin assignment – Ethernet (RJ45). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Table 3. Connector types – Ethernet M12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Table 4. Pin assignment – Ethernet (8-pin M12). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Table 5. Signal mnemonics – Ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Table 6. Ethernet status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Table 7. Default switch configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Table 8. Power over Ethernet classes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

20G304-00 E1 2017-02-01 Page 3
About this Document
About this Document
This user manual is intended only for system developers and integrators, it is not
intended for end users.
It describes the design, functions and connection of the product. The manual does not
include detailed information on individual components (data sheets etc.).
History
G304 product page with up-to-date information and downloads:
www.men.de/products/g304/
Issue Comments Date
E1 First issue 2017-02-01

20G304-00 E1 2017-02-01 Page 4
About this Document
Conventions
Indicates important information or warnings concerning situations which
could result in personal injury, or damage or destruction of the
component.
Indicates important information or warnings concerning proper
functionality of the product described in this document.
The globe icon indicates a hyperlink that links directly to the Internet.
When no globe icon is present, the hyperlink links to specific information
within this document.
Italics Folder, file and function names are printed in italics.
Mono A monospaced font type is used for hexadecimal numbers, listings, C
function descriptions or wherever appropriate. Hexadecimal numbers are
preceded by "0x".
Comment Comments embedded into coding examples are shown in green text.
IRQ#
/IRQ
Signal names followed by a hashtag "#" or preceded by a forward slash "/"
indicate that this signal is either active low or that it becomes active at a
falling edge.
In/Out Signal directions in signal mnemonics tables generally refer to the
corresponding board or component, "in" meaning "to the board or
component", "out" meaning "from the board or component".

20G304-00 E1 2017-02-01 Page 5
Product Safety
Product Safety
Electrostatic Discharge (ESD)
Computer boards and components contain electrostatic sensitive devices.
Electrostatic discharge (ESD) can damage components. To protect the PCB
and other components against damage from static electricity, you should
follow some precautions whenever you work on your computer.
Power down and unplug your computer system when working on the
inside.
Hold components by the edges and try not to touch the IC chips, leads,
or circuitry.
Use a grounded wrist strap before handling computer components.
Place components on a grounded antistatic pad or on the bag that came
with the component whenever the components are separated from the
system.
Only store the product in its original ESD-protected packaging. Retain
the original packaging in case you need to return the product to MEN for
repair.

20G304-00 E1 2017-02-01 Page 6
Legal Information
Legal Information
Changes
MEN Mikro Elektronik GmbH ("MEN") reserves the right to make changes without further
notice to any products herein.
Warranty, Guarantee, Liability
MEN makes no warranty, representation or guarantee of any kind regarding the
suitability of its products for any particular purpose, nor does MEN assume any liability
arising out of the application or use of any product or circuit, and specifically disclaims
any and all liability, including, without limitation, consequential or incidental damages.
TO THE EXTENT APPLICABLE, SPECIFICALLY EXCLUDED ARE ANY IMPLIED WARRANTIES
ARISING BY OPERATION OF LAW, CUSTOM OR USAGE, INCLUDING WITHOUT LIMITATION,
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE OR USE. In no event shall MEN be liable for more than the contract price for
the products in question. If buyer does not notify MEN in writing within the foregoing
warranty period, MEN shall have no liability or obligation to buyer hereunder.
The publication is provided on the terms and understanding that:
1. MEN is not responsible for the results of any actions taken on the basis of
information in the publication, nor for any error in or omission from the publication; and
2. MEN is not engaged in rendering technical or other advice or services.
MEN expressly disclaims all and any liability and responsibility to any person, whether a
reader of the publication or not, in respect of anything, and of the consequences of
anything, done or omitted to be done by any such person in reliance, whether wholly or
partially, on the whole or any part of the contents of the publication.
Conditions for Use, Field of Application
The correct function of MEN products in mission-critical and life-critical applications is
limited to the environmental specification given for each product in the technical user
manual. The correct function of MEN products under extended environmental
conditions is limited to the individual requirement specification and subsequent
validation documents for each product for the applicable use case and has to be agreed
upon in writing by MEN and the customer. Should the customer purchase or use MEN
products for any unintended or unauthorized application, the customer shall indemnify
and hold MEN and its officers, employees, subsidiaries, affiliates, and distributors
harmless against all claims, costs, damages, and expenses, and reasonable attorney fees
arising out of, directly or indirectly, any claim or personal injury or death associated with
such unintended or unauthorized use, even if such claim alleges that MEN was negligent
regarding the design or manufacture of the part. In no case is MEN liable for the correct
function of the technical installation where MEN products are a part of.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified for the specific task in accordance with the relevant documentation,
in particular its warning notices and safety instructions. Qualified personnel are those
who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.

20G304-00 E1 2017-02-01 Page 7
Legal Information
Conformity
MEN products are no ready-made products for end users. They are tested according to
the standards given in the Technical Data and thus enable you to achieve certification of
the product according to the standards applicable in your field of application.
RoHS
Since July 1, 2006 all MEN standard products comply with RoHS legislation.
Since January 2005 the SMD and manual soldering processes at MEN have already been
completely lead-free. Between June 2004 and June 30, 2006 MEN’s selected component
suppliers have changed delivery to RoHS-compliant parts. During this period any change
and status was traceable through the MEN ERP system and the boards gradually became
RoHS-compliant.
WEEE Application
Nevertheless, MEN is registered as a manufacturer in Germany. The registration number
can be provided on request.
Copyright © 2017 MEN Holding. All rights reserved.
The WEEE directive does not apply to fixed industrial plants and tools. The
compliance is the responsibility of the company which puts the product
on the market, as defined in the directive; components and sub-
assemblies are not subject to product compliance.
In other words: Since MEN does not deliver ready-made products to end
users, the WEEE directive is not applicable for MEN. Users are
nevertheless recommended to properly recycle all electronic boards
which have passed their life cycle.
Germany
MEN Mikro Elektronik GmbH
Neuwieder Straße 3-7
90411 Nuremberg
Phone [phone]
France
MEN Mikro Elektronik SAS
18, rue René Cassin
ZA de la Châtelaine
74240 Gaillard
Phone [phone]
USA
MEN Micro Inc.
860 Penllyn Blue Bell Pike
Blue Bell, PA 19422
Phone [phone]
China
MEN Mikro Elektronik
(Shanghai) Co., Ltd.
Room 808-809, Jiaxing
Mansion, No. 877 Dongfang
Road
200122 Shanghai
Phone [phone]
[email protected]
www.men.de
[email protected]
www.men-france.fr
[e-mail]
www.menmicro.com
[e-mail]
www.men-china.cn

Product Overview
20G304-00 E1 2017-02-01 Page 8
1 Product Overview
1.1 Product Description
Unmanaged Industrial Ethernet Switch
The G304 is an unmanaged 3U Ethernet switch implemented as a CompactPCI Serial
board. It occupies one peripheral slot, using a 4 HP front panel with 4 Gigabit Ethernet
ports on RJ45 connectors, and one direct Ethernet connection to the CPU card using PCI
Express on P1. Options include M12 front connectors, and a P6 connector to extend the
number of Ethernet channels available on the board to six.
Reliable Communication System Component
The G304 supports full-duplex and half-duplex operation with auto-negotiation, high-
speed nonblocking store-and-forward switching. Its built-in test mechanisms make the
G304 an even more reliable component in the communication system.
In addition, the switch can act as Power over Ethernet Plus (PoE+) Power Sourcing
Equipment (PSE), supplying other devices on all ports with up to 30 W (class 0, 1, 2, 3, 4)
per port for power according to IEEE 802.3 Section 2 - Type 1 and 2 (formerly known as
IEEE 802.3at). The maximum power available for one G304 is limited to 61.6 W, according
to CPCI-S.0 specification.
Compliant to Railway Standards
The board is specifically designed for rugged mobile communication systems. It is
therefore, for example, fully compliant with the EN 50155 railway standard, screened for
a -40°C to +85°C operation temperature and ready for coating.

Product Overview
20G304-00 E1 2017-02-01 Page 9
1.2 External Interfaces
Figure 1. Front interfaces (standard RJ45 model (left) and optional M12 model (right))
G304
Serial
®
CompactPCI
12
LALA
43
LALA
X1
X2
X3
X4
G304
Serial
®
CompactPCI
12
LALA
43
LALA
X1
X2
X3
X4

Product Overview
20G304-00 E1 2017-02-01 Page 10
1.3 Board Layout
Figure 2. Board layout – top view (without heat sink)
1.4 Block Diagram
Figure 3. Block diagram
Ethernet
connectors
CompactPCI Serial connector P1
ŽŵƉĂĐƚW/^ĞƌŝĂůĐŽŶŶĞĐƚŽƌWϲ;ŽƉƟŽŶĂůͿ
Port 2
Port 1
Port3
Port4
Isolation
PHY
PCIex1
GbEthernet
GbEthernet
GbEthernet
GbEthernet
FFront RearROptions
PoE+
PoE+
PoE+
PoE+
F
SwitchDevice
10/100/
1000BASE‐TEthernet
Controller
GbEthernet
F
F
F
GbEthernet
PoE+
PCIex1
PoE
Controller
P1
R
P6
R

Product Overview
20G304-00 E1 2017-02-01 Page 11
1.5 Technical Data
Switch Key Features
High-speed non-blocking, store-and-forward switching
Port configuration: copper, 10/100 and 1000 Mbit/s
Auto-negotiation / Auto MDI/MDIX crossover on all ports
8K MAC address lookup table with automatic learning and aging
Port-based VLANs
Power Over Ethernet
PSE (Power Sourcing Equipment)
Supported standard: IEEE 802.3 Section 2, Type 1 and 2
Supply classes: 0, 1, 2, 3, 4
Number of powered devices: up to four (up to 61.6 W total)
Front Interfaces
Ethernet
-Four RJ45 connectors, 10/100/1000BASE-T, or
-Four 8-pin M12 connectors, X-coded, 10/100/1000BASE-T
-Eight link and activity LEDs (two per channel)
Rear Interfaces
Ethernet
-One Gigabit Ethernet 1000BASE-T port on CompactPCI P1, uplink
-One Gigabit Ethernet 10/100/1000BASE-T port on CompactPCI P6 (optional)
Backplane Standard
Compliance with CompactPCI Serial PICMG CPCI-S.0 Specification
Peripheral slot
Host connection:
-One PCI Express x1 link, PCIe 1.x
-Used as Ethernet switch uplink
Electrical Specifications
Supply voltage
-+12 V (-3%/+5%)
Power consumption
-7 W approx. (without PoE)
-85 W max. (with PoE)
Isolation voltage
-IEE802.3 (2012), Section 1; 9.7 Electrical Isolation - Environment A for 500 V (with
M12 connectors), or
-IEE802.3 (2012), Section 1; 9.7 Electrical Isolation - Environment B for 1500 V
(with RJ45 connectors)

Product Overview
20G304-00 E1 2017-02-01 Page 12
Mechanical Specifications
Dimensions
-3U, 4 HP
Weight
-348 g (with M12 connectors)
Environmental Specifications
Temperature range (operation)
--40°C to +85°C (screened)
-Airflow: 1.0 m/s
Temperature range (storage): -40°C to +85°C
Cooling concept
-Air-cooled, or
-Conduction-cooled in MEN CCA frame
Relative humidity (operation): max. 95% non-condensing
Relative humidity (storage): max. 95% non-condensing
Altitude: -300 m to +3000 m
Climatic tests according to EN 68068
Shock: EN 61373
Vibration: EN 61373
Conformal coating; optional
Reliability
MTBF: 1 040 974 h @ 40°C according to IEC/TR 62380 (RDF 2000)
Safety
Flammability
-UL 94V-0
EMC
EN 55022 (radio disturbance)
IEC 61000-4-2 (ESD)
IEC 61000-4-4 (burst)

Product Overview
20G304-00 E1 2017-02-01 Page 13
1.6 Product Identification
MEN user documentation may describe several different models and/or design revisions
of the G304. You can find information on the article number, the design revision and the
serial number on two labels affixed to the board.
Article number: Indicates the product family and model. This is also MEN’s order-
ing number. To be complete it must have 9 characters.
Revision number: Indicates the design revision of the product.
Serial number: Unique identification assigned during production.
If you need support, you should communicate these numbers to MEN.
Figure 4. Product labels
00.00.00
0*-00
Revisionnumber Serialnumber
Completearticlenumber

Getting Started
20G304-00 E1 2017-02-01 Page 14
2 Getting Started
2.1 Connecting and Starting
You can use the following check list when installing the board in a system for the first
time and with minimum configuration.
»Power down the system.
»Insert the G304 into a peripheral slot of your CompactPCI Serial system, making
sure that the backplane connectors are properly aligned.
Note: The peripheral slots of every system are marked by a circle with a plus sign behind
it on the backplane and/or at the front panel:
»Power up the system.

Functional Description
20G304-00 E1 2017-02-01 Page 15
3 Functional Description
3.1 Power Supply
The G304 is supplied via the backplane.
3.2 Ethernet
The G304 uses the 10/100/1000BASE-T switch component Marvell 88E6171.
3.2.1 Front Connection
3.2.1.1 RJ45
Table 1. Connector types – Ethernet (RJ45)
Table 2. Pin assignment – Ethernet (RJ45)
Connector Type
On G304 Modular 8/8-pin receptacle according to FCC68
Mating Modular 8/8-pin plug according to FCC68
1000BASE-T 10/100BASE-T
1BI_DA+ TX+
2BI_DA- TX-
3BI_DB+ RX+
4BI_DC+ -
5BI_DC- -
6BI_DB- RX-
7 BI_DD+ -
8 BI_DD- -
1
8

Functional Description
20G304-00 E1 2017-02-01 Page 16
3.2.1.2 M12
Table 3. Connector types – Ethernet M12
Table 4. Pin assignment – Ethernet (8-pin M12)
3.2.2 Rear Connection
3.2.3 Signal Mnemonics
Table 5. Signal mnemonics – Ethernet
Connector Type
On G304 8-pin M12 receptacle X-coded, e.g., Phoenix Contact SACC-CI-M12FSX-
8CON-L90
Mating 8-pin M12 plug X-coded
1000BASE-T 10/100BASE-T
1BI_DA+ TX+
2BI_DA- TX-
3BI_DB+ RX+
4BI_DB- RX-
5 BI_DD+
6 BI_DD-
7BI_DC-
8BI_DC+
Refer to the CompactPCI Serial standard PICMG CPCI-S.0 for the exact position of the
Ethernet ports on the rear I/O connectors.
Signal Direction Function
BI_Dx+/- in/out Differential pairs of data lines for 1000BASE-T
RX+/- in Differential pair of receive data lines for 10/100BASE-T
TX+/- out Differential pair of transmit data lines for 10/100BASE-T
2
4
1
3
5
6
7
8

Functional Description
20G304-00 E1 2017-02-01 Page 17
3.2.4 Ethernet Status LEDs
Table 6. Ethernet status LEDs
3.2.5 Ethernet Switch
3.2.5.1 Default Configuration
The configuration is stored in an EEPROM and is loaded into the controller at startup.
By using a customer-specific configuration EEPROM, the G304 can act similarly to a
managed switch with fixed settings.
The default configuration of the G304 is shown in the following table.
Table 7. Default switch configuration
See Chapter 1.2 External Interfaces on page 9 for the position of the LEDs.
Appearance Label Color Function
L Green Indicates the link status
On: Link up
Off: No link
Blinking: n/a
A Yellow Indicates Ethernet activity
On: n/a
Off: No activity
Blinking: Transmit/Receive activity
Please contact MEN if you need a switch with a non-standard
configuration.
Setting Default
Duplex mode Full Duplex
Port speed Auto-Negotiate
VLAN configuration disabled
Quality of Service disabled
Port Mirroring disabled
Port Monitoring disabled
Port trunking disabled
Power over Ethernet functionality PSE functionality enabled
12
LALA
43
LALA

Functional Description
20G304-00 E1 2017-02-01 Page 18
3.2.6 Power over Ethernet (PoE)
Table 8. Power over Ethernet classes
3.3 CompactPCI Serial
Class Guaranteed Power
at PD Input
Guaranteed Power
at PSE Output
0 0.44 W to 12.96 W 15.4 W
1 0.44 W to 3.84 W 4.0 W
2 3.84 W to 6.49 W 7.0 W
3 6.49 W to 12.95 W 15.4 W
4 12.95 W to 25.5 W 30.0 W
A combination of different classes is also possible. See Chapter 1.5
Technical Data on page 11 for maximum output power.
Refer to the CompactPCI Serial standard PICMG CPCI-S.0 for detailed
information regarding the rear I/O connectors.
CompactPCI Serial Specification PICMG CPCI-S.0 Revision 2.0:
2015; PCI Industrial Computers Manufacturers Group (PICMG)
www.picmg.org
Introduction to CompactPCI Serial on Wikipedia:
en.wikipedia.org/wiki/CompactPCI_Serial
