Merak MMk-616 User manual

USER GUIDE
MMk-616
Special telephone
for lifts

MERak MMk-616
Special telephone for lifts
Rev. M1.1 ©Merak. All rights reserved
User Guide 2 de 3
PLEASE READ THIS MANUAL CAREFULLY
We do recommend spending few minutes to read this manual. In it there are its description
and installation advices.
FEATURES
This is an intercommunication telephone special for lifts, provided with all 16 DTMF tone keys
to able programming any automatic emergency call telephone which accepts these tones.
16 DTMF tones: the well-known number keys from ‘0’ to ‘9’, the ‘*’, and the ‘#’ as on all
normal telephone devices,
Plus the keys ‘A’, ‘B’, ‘C’, and ‘D’ as new special features.
On the back side of telephone base, there is a ring volume selection switch.
This unit can be used as over table telephone or wall installed
CONTENTS
When opening the box verify all following contents:
Hand set
Hand set wound cable with connectors
Telephone base with key pad
Telephone line cable with connectors
Wall surface connecting RJ-11
User guide (this guide)
CONNECTION
The telephone line connection must be done to the two central cables, usually the red and green
ones of the wall surface connecting RJ-11 base1.
Plug it in the supplied cable to the wall connecting base and to the telephone unit base.
OPERATION
Both for communication and for programming simply lift the handset and proceed to talk or
dialing corresponding keys to the desired DTMF tones.
WALL INSTALLATION
Fit two screws (not supplied) vertically aligned in the wall, with a separation of 10 cm (4’). Leave
the screws not fully tight with 5 mm (0,2’) of height.
Check orientation position of the plastic piece placed just above the ‘B’ key, in order to ensure it
is in the right orientation to hold the hand set. This little plastic piece can be easily slide out of its
place, turn it up-side –down and slide it in again.

MERak MMk-616
Special telephone for lifts
Rev. M1.1 ©Merak. All rights reserved
User Guide 3 de 3
ON DESK INSTALLATION
The little plastic piece placed just above the ‘B’ key is placed for wall installation by default. But
the hand set holding effect from it may disturb for on desk use. Therefore, we advise you to change its
orientation as described above.
DECLARATION OF CONFORMITY
MERak declares that our analogical telephone special for elevators MMk-616 model, fulfills the
established essential requirements in DIRECTIVE 1999/5/CE (9 of March of 1999).
The following engineering specifications of electromagnetic compatibility and electrical security
matters have been evaluated:
EN60950: 2000
EN55022: 1998
EN55024: 1998
Also it fulfills the exigencies determined in document ‘Interfaces ITE-CA-001-V05 of ‘Telefónica’,
as European standard.
Although this telephone device is designed for intercommunication between the lift machine
room and the car cabin, for consultation and programming of data and parameters of emergency
telephones for elevators, this telephone can also be used like normal telephone for communication
and verification of the telephone line
WARRANTY AND TECHNICAL SERVICE
MERak warranty covers this product for one year against any manufacturing default.
Any breakdown or defaults caused by inadequate use or treatment are not covered by the
warranty. Any damage due to electrical discharge, lightings or storms, are excluded also of our
warranty.
If you have any problem with this telephone unit, please contact our technical service +34 93
363 14 28.
You can also contact with us to [e-mail], or visiting our web page:
www.merakeurope.com.
