Merax VD - 9005 User manual

ASSEMBLY INSTRUCTIONS
STORAGE BED
VD - 9005
1
®

2
A
I
F
F
Detail View
K
C
D
F
F
E
G
I
P
L
L
Q
P
M
N
O
OO
O
X
Y
Z
W
V
UT
S
S
R
B
H
E
J
J

3
Leg - 1pc
Leg - 1pc Horizontal rail - 2pcs Door panel - 4pcs
Footboard - 1pc Headboard - 1pc Top rail - 2pcs
Side rail - 2pcs Slat - 1 set Side frame - 2pcs
Front frame - 1pc Back frame - 1pc Slide bar - 4pcs
Top panel - 2pcs Top panel - 1pc Drawer back - 6pcs
Drawer side - 12pcs Drawer bottom - 6pcs Drawer front - 1pc
Back
Long
Long
Side equal
Short
Short
Back
Back
Back
Back
Back
Drawer front - 1pc Drawer front - 1pc
Drawer front - 1pc Drawer front - 1pc
Drawer front - 1pc
Leg - 1pc Leg - 1pc
Long
Long
Short
Short
Short
Short
Long
Side equal
Long

4
Hex-Head bolts (16pcs)
1/4*110 #13
Horizontal-hole bolts (16pcs)
Ø10*13
Wood dowel (24pcs)
Ø10*40
Hex-Head bolts (4pcs)
1/4*70 #13
Hex-Head screws (10pcs)
1/4*50 #13
Wood dowel (42pcs)
Ø8*30
Wood dowel (8pcs)
Ø10*30
Wood screws (6pcs)
4*30
Wood screws (16pcs)
4*25
Wood screws (48pcs) Allen key (1pc)
3.5*25
Wood screws (32pcs)
3.5*15
Wheels (6pcs)

STEP 1:
5
STEP 2:
1
12PCS
2
12PCS
3
24PCS
3
3
2
1
4
5
1
12
2
6
12
- Insert the Wood dowels (3), the Horizontal-hole bolts (2) into the
Horizontal rail (E) and the Headboard (H) as shown.
- Attach the Leg (B) into the Horizontal rail (E) and the Headboard (H)
with the Hex-head bolts (1). Tighten the Hex-head bolts (1)
about 80% with the Allen key (12).
- Insert the Door panels (F) into the groove of the Horizontal rail (E)
and the Headboard (H).
- Attach the Leg (A) the pre-assembly unit. Tighten the
Hex-head bolts (1) with the Allen key (12).
- Repeat for the Footboard (G).
- Insert the Wood dowels (6), the Horizontal-hole bolts (2) into the Side rails (J).
- Attach the Side rails (J) into the Headboard and the Footboard with the Hex-head bolts (1).
- Tighten the Hex-head bolts (1) with the Allen key (12).
- Insert the Wood dowels (5) into the side of the Headboard (H) and the Footboard (G).
- Attach the Top rails (I) into the Headboard and the Footboard with the Hex-head bolts (4) as shown.
- Tighten the Hex-head bolts (4) with the Allen key (12).
E
F
FG
C
D
I
J
J
I
B
F
F
E
H
A
1
4PCS
2
4PCS
4
4PCS
5
6PCS
6
8PCS

6
STEP 3:
STEP 4:
// 8
8
5
5
13
- Insert the Wood dowels (5) into the
Horizontal rails (O) as shown.
- Attach the Slide bars (O) into the Front
frame (M) and the Back frame (N) with
the Screws (8).
-Tighten the Screws (8) with the
Screwdriver (not included).
* No pre-drilled holes on the Front frame and the
Back frame, please use the Screwdriver (not included)
to drill the holes with a little vigor.
- Attach the Slat (K) into the Side rails (J) with
the Screws (13).
- Tighten the Screws (13) with the Screwdriver
(not included).
* No pre-drilled holes on the rails, please use the
screwdriver (not included) to drill the holes with
a little vigor.
M
N
M N M N
O
O
O
O
O
O
5
16PCS
8
16PCS
13
6PCS
K

7
STEP 5:
STEP 6:
5
5
7
12
10
9
10
- Attach the Wheels (9) into the bottom of the Drawer frame with the screws (10).
- Tighten the screws (10) with the Screwdriver (not included).
* No pre-drilled holes on the bottom drawer frame, please use the
Screwdriver (not included) to drill the holes with a little vigor.
- Insert the Wood dowels (5) into the Front frame (M) and the Back frame (N) as shown.
- Attach the Side frames (L) into the Front frame (M) and the Back frame (N) with
the Hex-head screws (7).
- Tighten the Hex-head screws (7) with the Allen key (12).
L
L
5
20PCS
7
10PCS
9
6PCS
10
12PCS

8
STEP 7:
STEP 8:
11
10
/
11
- Insert the Drawers into the Drawer frame as shown.
- Attach the Top panels (P, Q) into the Drawer frame with the Screws (10).
- Tighten the Screws (10) with the Screwdriver (not included).
* No pre-drilled holes on the top drawer frame, please use the
Screwdriver (not included) to drill the holes with a little vigor.
- Attach the Drawer sides (S) into the Drawer backs (R) with the Screws (11).
- Tighten the Screws (11) with the Screwdriver (not included).
- Insert the Drawer bottoms (T) into the groove of the Drawer sides (S) and the Drawer backs (R).
- Attach the Drawer fronts (U/V/W/X/Y/Z) into the Drawer sides (S) with the Screws (11).
- Tighten the Screws (11) with the Screwdriver (not included).
* No pre-drilled holes on the Drawer back and the Drawer front, please use the
Screwdriver (not included) to drill the holes with a little vigor.
T
P
Q
U
P
U/ V/ W/ X/ Y
R
S
V
W
Z
X
Y
S
Z
11
48PCS
10
20PCS

9
COMPLETED:
Push the Drawer frame under the Storage bed.
