Mercedes-Benz SLR McLaren
Maintenance Booklet

PLEASE NOTE
WE STRONGLY RECOMMEND THAT YOU
HAVE YOUR VEHICLE SERVICED BY
YOUR AUTHORIZED MERCEDES-BENZ
CENTER WHO IS FULLY EQUIPPED
TO PROVIDE THIS SERVICE AND THAT
GENUINE MERCEDES-BENZ PARTS BE
USED.
SERVICE, REPLACEMENT, OR REPAIR OF
THE EMISSION CONTROL DEVICES AND
SYSTEMS CAN BE PERFORMED BY ANY
AUTOMOTIVE REPAIR ESTABLISHMENT
OR INDIVIDUAL USING CERTIFIED
PARTS.
THE USE OF DEFECTIVE OR NON-
EQUIVALENT PARTS MAY RESULT IN
YOUR EMISSION PERFORMANCE
WARRANTY CLAIM BEING DENIED.

1
Maintenance Booklet
Vehicle data
왘
Model
왘
Vehicle Identification Number (VIN)
왘
Date of initial registration
왘
Paint color and code
왘
License Plate No.
왘
License Plate No.
왘
License Plate No.
왘
License Plate No.

Maintenance Booklet
2
H
Natural resources form the basis of our
existence on this planet. The objectives
of our policy are for these resources to be
used sparingly and in a manner which
takes the requirements of both nature
and humanity into account.
Our declared policy is integrated environ-
mental protection. This policy starts at
the root causes and encompasses in its
management decisions all the conse-
quences for the environment which could
arise from production processes or the
products themselves.
You too can help to protect the environ-
ment by operating your Mercedes-Benz
SLR in an environmentally responsible
manner.
Operating conditions and your individual
driving style to a large extent influence
fuel consumption and the rate of engine,
brake, and tire wear. To reduce fuel con-
sumption and the rate of wear, please
consider the following:
• Avoid short trips.
• Make sure that the tire pressures are
always correct.
• Avoid frequent, abrupt acceleration.
• Do not carry any unnecessary weight.
• Remove ski holders and roof racks
once you no longer need them.
• Do not warm up the engine with the
car stationary.
• Shift gears such that each gear is
used only up to 2/3 of its maximum
engine speed.
• Keep an eye on the vehicle's fuel con-
sumption.
A regularly serviced vehicle will also help
protect the environment. You should ad-
here to the maintenance intervals dis-
played by the Maintenance System
service indicator, along with other main-
tenance work described in this booklet.
We recommend that you have services
performed by an authorized Mercedes-
Benz Center using Genuine Mercedes-
Benz parts.
Protecting the environment

3
Maintenance Booklet
Introduction
Mercedes-Benz Maintenance System.4
Regular checks . . . . . . . . . . . . . . . . .8
Notes on the warranty . . . . . . . . . . . .9
Parts / Operating materials . . . . . .10
Service records . . . . . . . . . . . . . . . . 10
Emission system maintenance
General . . . . . . . . . . . . . . . . . . . . . . . 11
Emission System Caution -
Gasoline Engines . . . . . . . . . . . . . . . 12
Confirmations
First visit. . . . . . . . . . . . . . . . . . . . . .15
Tire inspection or rotation . . . . . . . .17
Maintenance services. . . . . . . . . . . . 19
Maintenance overview
Mercedes-Benz SLR model . . . . . . . 50
First visit . . . . . . . . . . . . . . . . . . . . . 52
Tire rotation . . . . . . . . . . . . . . . . . . . 53
Service . . . . . . . . . . . . . . . . . . . . . . . 54
Additional work . . . . . . . . . . . . . . . 58
Spark plug replacement intervals . . 60
Recommended additional
maintenance checks at
150,000 miles . . . . . . . . . . . . . . . . . . 61
Emissions systems
maintenance jobs . . . . . . . . . . . . . . 63
Contents

Maintenance Booklet
4
We want you to enjoy your Mercedes-
Benz SLR automobile. Vehicle safety and
operational reliability are two very
important factors and to maintain them,
regular maintenance services are
necessary.
We continuously strive to improve our
product, and ask for your understanding
that we reserve the right to make
changes in the required periodic
maintenance work which is required for
our vehicles.
Your Mercedes-Benz SLR comes
equipped with the Mercedes-Benz SLR
Maintenance System. The Maintenance
System tracks distance driven and the
time elapsed since your last service. The
next necessary maintenance service is
indicated in the maintenance service
indicator in the instrument cluster.
Additional work that is not calculated by
the Maintenance System is required at
maintenance intervals. Please refer to
“Additional Work to be Performed” on
page 58 for more details.
Following each service, your authorized
Mercedes-Benz Center will reset the
Maintenance System service indicator by
confirming the service items performed.
!
If the Maintenance System service
counter was inadvertently reset, have
a Mercedes-Benz Center correct it.
Please only reset if the proper
maintenance service has been
performed. Resetting the system
without performing the proper service
will result in engine and/or other
vehicle damage not covered by the
Mercedes-Benz Limited Warranty.
Introduction

5
Maintenance Booklet
A detailed listing of service procedures
performed are contained in this booklet,
starting on page 49.
Additional work
Additional work means any work that is
not calculated by the Maintenance Sys-
tem. This work is listed in the section
“Additional Work to be Performed”, see
page 58. This type of work has to be car-
ried out according to the individual vehi-
cle type, due to the specific technical
parameters, wear processes or special
equipment on each different vehicle.
Special service requirements
Brake fluid should be replaced every two
years, preferably in the spring, see page
59. We recommend that you only use
brake fluid approved by Mercedes-Benz.
A reminder for the next scheduled brake
fluid replacement is affixed in the engine
compartment.
Coolant should be checked for the prop-
er concentration before the start of the
winter season (or once a year in hot re-
gions). Have the coolant (water/anticor-
rosion/antifreeze mixture) replaced
every 4 years, see page 59.
Replacement of coolant (water/anticor-
rosion/antifreeze mixture) may be re-
quired more frequently if coolant is not
maintained according to instructions
and/or other than approved anticorro-
sion/antifreeze products for your vehicle
are being used. For instructions on cool-
ant, see “Coolants” in your vehicle Oper-
ator’s Manual. For a listing of approved
anticorrosion/antifreeze products for
your vehicle, refer to the Factory Ap-
proved Service Products pamphlet in
your vehicle literature portfolio, or con-
tact an authorized Mercedes-Benz
Center.
Introduction

Maintenance Booklet
6
Introduction
Interior filters (e.g. dust filter, recircu-
lating air filter, activated charcoal filter or
combination filter) are replaced accord-
ing to the maintenance intervals listed.
Under severe dust conditions, or with the
Climate Control frequently operating in
the air recirculation mode, the respective
filter should be replaced correspondingly
sooner.
Tire inspection -Your vehicle’s tires are
a critical component to overall vehicle
performance and vehicle stability. The
useful life of tires will vary and is
proportional to tire type, speed rating,
ambient conditions, tire loading, tire
inflation pressure, road surfaces, and
individual driving style, among other
factors. Therefore, Mercedes-Benz
recommends regular checks for wear and
proper inflation.
The first tire inspection, which includes
checking for proper inflation pressure
and tread condition, is at no charge pro-
vided it is performed at an authorized
Mercedes-Benz Center prior to 6,500
miles on the vehicle odometer.
For your convenience, this Maintenance
Booklet contains a tire inspection confir-
mation page on which you can record the
date and mileage when tire inspections
were performed.
Tire rotation - Tire rotations can only be
performed on vehicles with the same tire
dimensions on all four wheels (e.g. winter
tires). In cases where your vehicle is
configured with staggered tire sizes
(different tire sizes, front vs. rear), tire
rotations are not possible.
If your vehicle’s tire configuration allows
for rotation, tire rotation should be
performed by observing a front-to-rear
pattern that will maintain the intended
rotational (spinning) direction of the tire
(on unidirectional tires, an arrow on the
sidewall indicates the intended rotation
or spinning direction of the tire) and in
accordance with the tire manufacturer’s
recommended intervals, or sooner at first
signs of irregular (uneven) tread wear.

7
Maintenance Booklet
Tire manufacturer’s rotation
recommendations will necessitate a tire
rotation at least once in between
maintenance services and at every
maintenance service based on
Mercedes-Benz SLR maintenance
intervals.
The first tire rotation is at no charge pro-
vided it is performed at an authorized
Mercedes-Benz Center prior to 6,500
miles on the vehicle odometer.
For your convenience, this Maintenance
Booklet contains a tire rotation confirma-
tion page on which you can record the
date and mileage when tire rotations
were performed.
Spark Plugs should be replaced accord-
ing to schedule on page 60. Severe oper-
ating conditions (frequent starting and
stopping, excessive idling, sustained fast
highway driving) may call for spark plugs
to be replaced correspondingly sooner.
Engine oils and oil filters are specifical-
ly tested for their suitability in our en-
gines and durability for our service
intervals. Therefore, only use approved
engine oils and oil filters required for ve-
hicles with Maintenance System. For a
listing of approved engine oils and oil fil-
ters, refer to the Factory Approved Serv-
ice products pamphlet, or contact an
authorized Mercedes-Benz Center.
Using engine oils and oil filters of specifi-
cation other than those expressly re-
quired for the Maintenance System or
changing of oil and oil filter at change in-
tervals longer than those called for by the
Maintenance System will result in engine
damage not covered by the Mercedes-
Benz Limited Warranty.
Introduction

Maintenance Booklet
8
Introduction
Regular checks
In addition to the services, we recom-
mend that you check the following items
regularly (for example: weekly, when re-
fueling, or before any long journey):
• Engine oil level - Check the engine oil
level using the multifunction steering
wheel/multifunction display oil level
check. Further information about en-
gine oil level measurement can be
found in the vehicle Operator’s Manu-
al.
• Coolant level - Please refer to the Op-
erator’s Manual for the correct proce-
dure to check the coolant level.
• Brake fluid level -If brake fluid has to
be added, see an authorized Mer-
cedes-Benz Center to determine the
cause, e.g. leaks or worn brake pads.
• Windshield washing system - If the
washer fluid level drops below 1/3, the
windshield washer fluid level warning
lamp will illuminate. Add washer fluid
mixed with Mercedes-Benz windshield
washer solvent/concentrate, test
function and check wiper blades.
• Check lights
• Tire condition and pressures –
Check at least every other week.
Please refer to section “Tires and
wheels” in the Operator’s Manual for
guidelines and correct procedures to
check tire condition and pressures.
Please refer to the Factory Approved
Service Products booklet or see your
Mercedes-Benz Center for more informa-
tion on selecting the proper fluids, lubri-
cants, and oils for your vehicle.

9
Maintenance Booklet
Introduction
Notes on the warranty
An extensive and well-equipped network
of Mercedes-Benz Centers is at your dis-
posal for service work. Your authorized
Mercedes-Benz SLR can ensure that your
vehicle is professionally and thoroughly
serviced and repaired.
Please see the Service and Warranty In-
formation booklet for detailed informa-
tion on warranty terms and coverage.
Please follow the instructions given in
this Maintenance Booklet, even if you
entrust the vehicle to a third party for
use or care. Only in this way will you
be able to ensure that your warranty
rights are not affected.
Service, replacement, or repair of the
emission control devices and systems
can be performed by any automotive
repair establishment or individual us-
ing certified parts.
We strongly recommend that you
have your vehicle serviced by your au-
thorized Mercedes-Benz Center which
is fully equipped to provide this serv-
ice.
Please note that engines have to be serv-
iced in accordance with special instruc-
tions and using special measuring
equipment to comply with legal require-
ments concerning exhaust emissions.
Modifications to or tampering with emis-
sions components is not permissible.
Your authorized Mercedes-Benz Center is
familiar with the relevant regulations.

Maintenance Booklet
10
Introduction
Parts / Operating materials
We recommend only the use of Genuine
Mercedes-Benz parts for service and re-
pairs, since they meet our specifications.
It is also important to only use fuels, lubri-
cants and anticorrosion/antifreeze cool-
ant meeting factory specifications.
Please refer to the Factory Approved
Service Products booklet or see your
Mercedes-Benz Center for more informa-
tion on this subject.
Service records
Your authorized Mercedes-Benz Center
will certify in the Maintenance Booklet
the maintenance services on your vehicle
which it has performed.
Other than the maintenance services de-
scribed, the Maintenance Booklet does
not record or reflect any repair work that
may have been performed to your vehi-
cle. Please keep those receipts with your
vehicle records.
For information concerning warranty, see
your Service and Warranty Information
booklet.
Your authorized Mercedes-Benz Center
will gladly furnish additional information
on the maintenance of your vehicle.
We extend our best wishes for many
miles of safe, pleasurable driving.
Mercedes-Benz USA, LLC
A DaimlerChrysler Company

11
Maintenance Booklet
Emission System Maintenance
General
The U.S. Environmental Protection Agen-
cy and, in California, the Air Resources
Board have certified that the emission
control systems of your vehicle comply
with the applicable exhaust emission
standards for model year 2005 vehicles.
This vehicle also complies with the appli-
cable Canadian Motor Vehicle Emission
Standards.
To be certain that the emission control
systems function as designed, regular
maintenance is necessary for compo-
nents of the vehicle which affect exhaust
and evaporation emissions composition.
The vehicle owner is responsible for the
regular maintenance of the emission con-
trol system, as well as the use of premi-
um unleaded gasoline with an anti-knock
index of at least 91 (displayed on the
pump) in all gasoline engine models un-
less otherwise specified.
Failure to properly maintain the emission
system may result in repairs not being
covered by the emission system warran-
ties.
Explanations of each maintenance job
are given in numerical order on page 63.

Maintenance Booklet
12
Emission System Maintenance
Emission Control System Caution -
Gasoline Engines
Your Mercedes-Benz SLR vehicle is
equipped with both a three-way catalyst
and a closed loop oxygen sensor system
to comply with current exhaust emission
regulations. Keep your vehicle in proper
operating condition by following our rec-
ommended maintenance instructions as
outlined.
The following has to be adhered to:
a) In all gasoline engine models, use
only premium unleaded gasoline
with an anti-knock index of at least
91 (as displayed on the pump) un-
less otherwise specified. Damage to
the engine could occur if premium un-
leaded fuel is not used. Refer to the
Operator’s Manual for special precau-
tions.
b) Leaded gasoline should not be used
under any circumstances. Damage
to the emission control components
will result.
c) The specified engine maintenance
jobs have to be performed com-
pletely and at the required inter-
vals. Correct ignition timing and
properly functioning spark plugs for in-
stance are important for the service
life of the catalysts. Failure to properly
perform the specified maintenance
jobs may adversely affect the emis-
sion control system on the vehicle and
reduce its service life.

13
Maintenance Booklet
Emission System Maintenance
d) The operation of the emission con-
trol system must not be altered in
any way. Alterations are not permissi-
ble by law. In addition, alterations may
result in damage to the catalysts, in-
creased fuel consumption, and im-
paired engine running conditions.
e) Irregular engine running conditions
should be corrected immediately by
an authorized Mercedes-Benz Cent-
er. Such irregular running conditions
can influence the proper function of the
emission control system.
If the “CHECK ENGINE” indicator lamp in
the instrument cluster illuminates when
the engine is running, it indicates a possi-
ble malfunction of the engine manage-
ment system or emission control system.
We recommend that you have the mal-
function checked as soon as possible.

Maintenance Booklet
14
Notes

15
Maintenance Booklet
Confirmations
First visit: 1,000 miles - 3,000 miles
Date: _______________________
Odometer: ___________________
Performed Yes/No
Diagnostic test
{
Q+A on vehicle {
Rubber stamp
Signature
First visit:
1,000 miles -
3,000 miles
Appointment Month/year
First visit
provided at
no charge*
*This first visit for a basic vehicle diag-
nostic test at an authorized Mercedes-
Benz Center is provided at no charge.
Please refer to the Service and Warranty
Information Booklet for full details.

17
Maintenance Booklet
Confirmations
Tire inspection or rotation
If applicable to your vehicle’s tire configuration (see page 6), tire rotation should be performed in
accordance with the tire manufacturer’s recommended intervals, or sooner at first signs of irregular
(uneven) tread wear. Tire manufacturer’s rotation recommendations will necessitate a tire rotation at
least once in between maintenance and at every maintenance service based on Mercedes-Benz
maintenance intervals.
Reminder:
Tire
inspection or
rotation
First tire
inspection or
rotation
provided at
no charge*
*This first tire inspection or rotation (if
applicable) at an authorized Mercedes-
Benz Center at any time up to 6,500
miles (vehicle odometer) is provided at
no charge. Please refer to the Service
and Warranty Information Booklet for full
details.
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Date: ____________ Odometer: ___________________
Tire rotation should be performed in accordance with the tire manufacturer’s recommendations in the
Tire Warranty Pamphlet included in your vehicle literature portfolio. However, tires should be rotated at
the first sign of irregular (uneven) tread wear, even if it occurs before the recommended rotation inter-
vals, and should be checked regularly for wear and proper inflation. Please note that the useful life of
tires will vary and is proportional to tire type, speed rating, ambient conditions, tire loading, tire inflation
pressure, road surfaces, and individual driving style, among other factors.
The first tire inspection or rotation (if applicable) occurring at an authorized Mercedes-Benz Center at
any time up to 6,500 miles (vehicle odometer) is provided at no charge.

Maintenance Booklet
18
Confirmations
Tire inspection or rotation
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________
Date: ____________ Odometer: _______________

19
Maintenance Booklet
Confirmations
Maintenance: 10,000 miles
Service and applicable Additional Work
For scope of work, refer to maintenance overview and description of maintenance services starting on page 49.
Date: ____________________________________
Odometer: ________________________________
Oil Brand / viscosity: _______________________
Repair order no. (if applicable) _________________
Maintenance service completed:
Rubber stamp
Signature
First
Maintenance
due
10,000 miles
or
Month/year
