Mercia Garden Products 0628POPA0603FGDD3TW-V1 Instruction manual

P 1
0628POPA0603FGDD3TW-V1
28MM LOG CABIN, PENT WITH OUTDOOR PATIO AREA, 6M X 3M, FULLY GLAZED DOUBLE DOOR, THREE TALL WINDOWS.
2mm Drill bit
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All buildings should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied)
including a Phillips screwdriver, Stanley knife, wood saw, step ladder and drill with 2mm
bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions.
For the duration of heavy or extended periods of rain, swelling of the wood panels may
occur. Warping of the wood may also occur during excessive dry spells due to an interior
moisture loss. Unfortunately, these processes cannot be avoided but can be helped. It is
suggested that the outdoor building is sprayed with water during extended periods of
warm sunshine and sheltered as much as possible during rain or snow.
BUILDING A BASE
When thinking about where the building and base are going to be constructed:
Ensure that there will be access (60cm) to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to
diagrams for the base dimensions. The base should be slightly smaller than the external
measurement of the building, i.e. the cladding should overlap the base, creating a run
o for water. It is also recommended that the oor be at least 25mm above the
surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of safety and in
the case of childrens products independently tested to EN71 level, we cannot accept
responsibility for your safety whilst erecting or using this product.
Refer to the instructions pages for your specic product code
For ease of assembly use a
rubber mallet to t the log
boards. Do NOT use a heavy
hammer.
Ensure to measure and check before cutting
boards.
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
It is advisable to use a hand
saw when cutting roof and
oor boards.
To ensure log boards are even, use a spirit
level to check each layer has been installed
correctly.
Measure
under the
head
Measure
overall
length
Screws & Nails Bolts To identify the
xings required
for each step use a
measuring tape.

P 2
0628POPA0603FGDD3TW-V1
Overall Dimensions:
Width = 6024mm
Depth = 3326mm
Height = 2491mm
Base Dimensions:
Width = 5896mm
Depth = 2804mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Tall Window Contents
6
2
1
3
4
Window QTY 3
AI-06LOGDGW684X1905-V3
5
Double Door Contents
8
7
9
10
Mortice Lock
QTY 1
PI-07-0017
Key Plate
QTY 1
PI-07-0017
Handles (Pair)
QTY 1
PI-07-0188
Adjustable Hinge QTY 6 PI-07-0209
Tower Bolt
QTY 2
PI-07-0114
Master Door QTY 1
(Morticed for lock)
AI-06LOGDGFGMD750X1900-V3
11
12
13
15
15a 15c
16 17 18 19
Secondary DoorQTY 1
AI-06LOGDGFGSD750X1900-V3
Door Frame Left Upright - 71x70x2065mm QTY 1
AI-0628LOGDUFL-V3
Door Frame Right Upright - 71x70x2065mm QTY 1
AI-0628LOGDUFR-V3
Door Frame Top - 84x125x1632mm QTY 1
AI-0628LOGDDTF-V3
Door Frame Bottom - 71x70x1508mm QTY 1
AI-0628LOGDDBF-V3
Door Strip - 16x60x1880mm QTY 1
S1660-1880mm
14
Rain Guard QTY 1
RG2844-1520 (28x44x1520mm)
15b
Window Frame Left Upright - 71x70x2065mm QTY 3
AI-0628LOGDUFL-V3
Window Frame Right Upright - 71x70x2065mm QTY 3
AI-0628LOGDUFR-V3
Window Frame Top - 84x125x805mm QTY 3
AI-0628LOGWTF-V3
Window Frame Bottom - 71x70x685mm QTY 3
AI-0628LOGWBF-V3
Rain Guard QTY 3
RG2844-710 (28x44x710mm)
Door on the Front
Door on the Side

P 3
Please retain product label and instructions for future reference
30
31
32
40
41
29
Main Gable QTY 2
AI-0628POPA0603FGDD3TW-G-V1
Starter Board - 66x28x2996mm QTY 2
LB28RT66-A-2996
Log Board - 120x28x229mm QTY 36
LB28-B-229
Bearer - 44x44x2804mm QTY 2
F4444-2804-PT
Bearer - 44x44x2716mm QTY 11
F4444-2716-PT
Log Board - 120x28x2996mm QTY 62
LB28-A-2996
Finisher Board - 50x28x2872mm QTY 1
LB28RG50-B-2872
Starter Board - 66x28x2996mm QTY 1
LB28RT66-B-2996
20
22
23
26
27
28
Log Board - 120x28x2996mm QTY 1
LB28-AD-2996 ( 1 X Double Door cut out, 1X Window cut out)
24
Log Board - 120x28x2996mm QTY 1
LB28-AD-2996 (2X Window cut outs)
25
Log Board - 120x28x229mm QTY 18
LB28-C-229
Log Board - 120x28x500mm QTY 56
LB28-B-500
Log Board - 120x28x500mm QTY 18
LB28-C-500
Finisher Board - 50x28x2996mm QTY 1
LB28RG50-A-2996
Log Board - 120x28x2872mm QTY 1
LB28-B-2872
Log Board - 120x28x2996mm QTY 20
LB28-B-2996
Starter Board - 66x28x500mm QTY 1
LB28RT66-B-500
Finisher Board - 50x28x2996mm QTY 1
LB28RG50-B-2996
Log Board - 120x28x3092mm QTY 1
LB28-B-3092
Finisher Board - 50x28x3092mm QTY 1
LB28RG50-B-3092
33
37
38
36
34
35
Bearer - 44x44x2996mm QTY 1
F4444-2996-PT
Bearer - 44x44x500mm QTY 1
F4444-500-PT
43
42
Roof Purlin - 45x120x5992mm QTY 2
F45120-A-5992
39
Main Gable Point QTY 2
AI-0628POPA0603FGDD3TW-G-V1
20a
21
21a
Middle Gable QTY 1
AI-0628POPA0603FGDD3TW-MG-V1
Middle Gable Point QTY 1
AI-0628POPA0603FGDD3TW-MG-V1

P 4
Please retain product label and instructions for future reference
Fascia - 16x120x3100mm QTY 4
S16120-3100
Fascia - 16x20x16x3600mm QTY 2
S16120-3600
Roof Board - 121x16x3300mm QTY 55
MB16-3300
Floor Board - 121x16x2744mm QTY 26
MB16-2744
47
Eaves Frame - 27x44x2995mm QTY 4
F2744-2995
48
49
46
51
52
Storm Brace - 44x27x2000mm QTY 13
F2744-2000
53
Closure Trim - 16x28x2400mm (approx length) QTY 15
S1628-2400
54
Felt
Roof Spacers QTY 5
PI-07-0208 (20x100x2mm)
55
Bearer - 44x44x96mm QTY 1
F4444-96-PT
Bearer - 44x44x400mm QTY 2
F4444-G-440-PT (400mm nished length)
44
45
Double Storm Brace - 16x120x2110mm QTY 2
S16120-2110
50
Felt Tacks x 305
70mm Screw x 105
Nail Bag
40mm Screw x 488
30mm Screw x 180
70mm Bolt Set x 26
There may be extra screws present in the nail bag
80mm Screw x 32
90mm Bolt Set x 4
60mm Screw x 34
Pre-assembly
*Please note:
Each board interlocks at either end in a staggered pattern.
Before securing ensure that the boards are tted properly
in their respective tongues and grooves.

For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
P 5
Please retain product label and instructions for future reference
Step 1
Parts Needed - No. 41 QTY 2
No. 42 QTY 2
Lay the bearers (No. 41 & 42) onto
a rm and level surface (free from
areas where standing water can
collect) as shown in the
illustration.
Fix the bearers together at each
corner using 2 screws per corner
using 8x70mm screws in total,
ensuring the bearers are ush.
Once fully assembled, ensure the
bearers are square by measuring
from corner to corner as
illustrated, making sure the
measurements are equal.
If the bearers are not aligned
equally, unscrew, adjust and
re-align accordingly.
8x70mm Screws
Pre drill
hole
70mm
screw
IMPORTANT: Pre-drill before xing screws.
41
41
42
42
Step 2
Parts Needed - No. 42 QTY 8
Following the same method,
arrange the remaining bearers
(No. 42) inside the assembled
frame.
*Ensure there is an equal amount
of space between each frame.
Secure each of the bearers in place
using 2x70mm screws for each
side of the bearer, ensuring the
bearers remain level.
32x70mm Screws
Pre drill
hole
70mm
screw
42
41
42
42
42
42
42
42
42
42
42

P 6
Please retain product label and instructions for future reference
Step 3
Parts Needed - No. 40 QTY 1
No. 42 QTY 1
No. 45 QTY 2
*Please note:
You can position your Patio Area on either side of the log cabin, depending on which side you
attach the bearers.
**For illustration purposes, the instructions will show the Patio area on the right of the log cabin.**
Arrange the bearers (No. 40, 42 & 45) onto the previously constructed bearers, as shown in the
illustration.
Secure each of the bearers in place using 70mm screws. For bearers (No. 40 & 45) direct the screws
through at an angle to x through to the next bearer, as shown in the illustration, ensuring the
bearers remain level.
Using the same method as in Step 1, ensure the bearers are square by measuring from corner to
corner as illustrated, making sure the measurements are equal.
If the bearers are not aligned equally, unscrew, adjust and re-align accordingly.
12x70mm Screws
Pre drill
hole
70mm
screw
42
40
45
45
Pre drill
hole
70mm
screw
Step 4
Parts Needed - No. 43 QTY 1
No. 44 QTY 1
Arrange the remaining bearers (No. 43 & 44) onto
the previously constructed bearers, ensuring
(No.43) is positioned 360mm from bearer (No. 42),
as shown in the illustration.
Secure each of the bearers in place using 70mm
screws, ensuring to screw through (No.44) at an
angle, as shown in the illustration.
4x70mm Screws
43
44
360mm
42

P7
Please retain product label and instructions for future reference
22 25
Pre drill
hole
70mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 5
Parts Needed - No. 22 QTY 2
No. 23 QTY 1
No. 24 QTY 1
No. 25 QTY 3
Place the starter boards (No. 22, 23 & 24) on to the assembled bearers
and place the rst three log boards (No. 25) in the notches as shown.
Ensure the boards sit square on the base using the same method used
in Step 1. Measure corner to corner, making sure the measurements are
equal.
Once the boards are square, lift up the log boards (No. 25) and x the
starter boards in place by screwing through the notch into the bearer
below, using 1x70mm screw per notch.
Secure board No.23 in place by screwing at an angle through the side of
the starter board into the bearer below, as shown in the illustration.
7x70mm Screws
22
25
23
25
24
*Ensure boards sit ush

P 8
Please retain product label and instructions for future reference
Step 6
Parts Needed - No. 25 QTY 18
No. 26 QTY 6
No. 27 QTY 6
No. 29 QTY 12
*Please note:
You can construct your cabin to have the Doors on the front or the Doors on the side, dependant on your needs.
(See contents page image for reference) Please ensure to construct your Log Cabin by following either the ‘Doors
on the front’ or ‘Doors on the side’ instructions, dependant on which side you choose.
Following the method shown in the illustration, lay the rst 6 boards (No. 24, 25, 26, 27, 28 & 29) o of the starter
boards to create your rst level.
*Ensure that the boards are level and ush with each other as you lay each one.
Ensure the boards (No.26) are level, ush and in line with the boards next to them.
Secure every other board (No. 26) in place by screwing through the side of the board at an angle into the end of the
board next to it (No. 25), using 1x60mm screw per board.
3x60mm Screws
25
25
27
25
Doors on the Side
Doors on the Front
26
29
29
25 25
25
26
29
IMPORTANT: Pre-drill before xing screws.
Rubber Mallet
may be required
to t parts.
Pre drill
hole
60mm
screw
27
29

P 9
Please retain product label and instructions for future reference
Step 7
Parts Needed - No. 9 QTY 1
No. 10 QTY 1
No. 11 QTY 1
No. 12 QTY 1
Arrange the left, right, top & bottom door
frames (No’s. 9, 10, 11 & 12) onto a level
surface.
Secure the top and bottom frames to the
uprights using 2x80mm screw per corner,
ensuring the screws do NOT protrude through
the front of the door framing.
8x80mm Screws
Pre drill
hole
80mm
screw
11
12
9
10
IMPORTANT : Pre-drill before xing screws.
The internal lip of the door
frame should be postioned on
the inside of the building.
12 10
15a
7
8
15
15b
a
b
IMPORTANT : Pre-drill before xing screws.
Secondary Door Master Door
Pre drill
hole
30mm
screw
Step 8
Parts Needed - No. 7 QTY 1
No. 8 QTY 1
No. 15 QTY 6
The Adjustable Door Hinge (No.17) comes
in three parts.
Fasten No. 17a into 17b as shown in the
illustration.
Place the master and secondary doors
(No.7 & 8) into the assembled double door
frame and x 3 x Adjustable door hinges
(No.15c) to each door using 3x30mm screws
per hinge.
Fix 3 x Adjustable Door Hinges (No. 15a&b)
onto the door frame using 4x30mm screws per
hinge.
*Ensure the hinges are tted to the external
of the door frame so the doors open outwards
from the log cabin.
Locate the doors into the hinges Place the
doors on the hinges ensuring there is equal
spacing on each side between the door and
door frame, and the doors open & close freely
without restriction.
It is important to t the doors within the frames
at this stage soi that you can establish the posi-
tion of the hinges. The hinges come in three
parts. Remove th doors from the frme after
tting.
*Ensure to screw into the framing and not
into the channel.
42x30mm Screws
a
b

P 10
Please retain product label and instructions for future reference
Step 9
To adjust and align your doors:
1. Lift up the doors to separate the two
parts of th hinge.
2. Turn the rotating barrel (No.15a) in /
out to move the postion of the doors
either in or away from each other.
3. You can then place the door(s) back
on to the hinge and check whether they
require more / less adjustments, if
further adjustments are required repeat
number 2.
15a
IMPORTANT : Pre-drill before xing screws.
2
3
5
4
Step 10
Parts Needed - No. 2 QTY 3
No. 3 QTY 3
No. 4 QTY 3
No. 5 QTY 3
Arrange the left, right, top & bottom window
frames (No. 2, 3, 4,& 5) onto a rm and level
surface. Secure the top and bottom frames to
the uprights using 2x80mm screw per corner,
ensuring the screws do NOT protrude
through the front of the window framing.
Use this method to assemble three window
frames.
24x80mm Screws
Pre drill
hole
80mm
screw
53
The internal lip of the window
frame should be positioned on
the inside of the building.
1
Pre drill
hole
40mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 11
Parts Needed - No. 1 QTY 3
Rest the window (No. 1) into the assembled
window frame as shown in the illustration, and
secure into position by screwing through the
framing into the window, using 4x40mm screws
per side.
*Place the frame & window at onto a level
surface to help x into place.
Use this method to assemble three windows.
48x40mm Screws
.

P 11
Please retain product label and instructions for future reference
Step 12 - Doors on the Front
Parts Needed - No. 30 QTY 18
Once you have laid 6 boards (o of the starter) locate one of the assembled
window frames onto the inside corner of the log cabin as shown in the illustration.
Ensure the window frame is resting on top of the log board and the log boards
(No.29) are locted ush into one side of the window frame.
**If you have not yet assembled your window frames please refer to steps 10 & 11.
Once the window frame is in position, place the log boards (No.30) ush into
the other side of the window frame, securing it in place.
*Ensure that the boards are level and ush with each other as you lay each one.
Rubber Mallet
may be required
to t parts.
Doors on the Side
Doors on the Front
29
27
a
b
Step 12 - Doors on the Side
Parts Needed - No. 28 QTY 18
Once you have laid 6 boards (o of the starter) locate one of the assembled
window frames onto the inside corner of the log cabin as shown in the illustration.
Ensure the window frame is resting on top of the log board and the log boards
(No.27 ) are locted ush into one side of the window frame.
**If you have not yet assembled your window frames please refer to steps 10 & 11.
Once the window frame is in position, place the log boards (No.28) ush into
the other side of the window frame, securing it in place.
*Ensure that the boards are level and ush with each other as you lay each one.
Rubber Mallet
may be required
to t parts.
a
b
30 28
a
b
a
b

P 12
Please retain product label and instructions for future reference
Step 13 - Doors on the Front
Parts Needed - No. 28 QTY 18
Once you have positioned the rst window and boards, locate another one of
the assembled window frames onto the log cabin as shown in the illustration.
Ensure the window frame is resting on top of the log board and the log boards
(No.30) are locted ush into one side of the window frame.
Locate the assembled door frame onto the the log cabin as shown in the
illustration, ensuring it is resting on top of the starter board and the log boards
(No.27) are located ush into one side of the frame.
**If you have not yet assembled your window or door frames please refer to steps 7-11.
Once the door frame is in position, place the log boards (No.28) ush into
the other side of the door frame, securing it in place.
*Ensure that the boards are level and ush with each other as you lay each one.
Rubber Mallet
may be required
to t parts.
a
b
Doors on the Side
Doors on the Front
30
27
28
a
b
a
b
Step 13 - Doors on the Side
Parts Needed - No. 30 QTY 18
Once you have positioned the rst window and boards, add the assembled
door frame onto the log cabin as shown in the illustration.
Ensure the door frame is resting on top of the log board and the log boards
(No.28) are locted ush into one side of the door frame.
Locate one of the assembled window frames onto the the log cabin as shown in
the illustration, ensuring it is resting on top of the starter board and the log boards
(No.29) are located ush into one side of the frame.
**If you have not yet assembled your window or door frames please refer to steps 7-11.
Once the frames are in position, place the log boards (No.30) ush into the
other side of the window frame, securing it in place.
*Ensure that the boards are level and ush with each other as you lay each one.
Rubber Mallet
may be required
to t parts.
a
b
28
29
30

P 13
Please retain product label and instructions for future reference
Step 14
Parts Needed - No. 27 QTY 18
No. 29 QTY 18
Locate the last assembled window frame onto the log cabin as shown in the
illustration.
Ensure the window frame is resting on top of the starter board and the log boards
(No.30 or 28) are locted ush into one side of the window frame.
**If you have not yet assembled your window or door frames please refer to steps 10 & 11.
Once the frame is in position, lay the log boards (No.27 &29) ush into the sides
of the windows/door frames, interlocking each board to build up the front corner,
securing the windows/door in place.
*Ensure that the boards are level and ush with each other as you lay each one.
Rubber Mallet
may be required
to t parts.
a
b
29
Doors on the Side
Doors on the Front
28
27
a
b
a
b
30
27
29

P 14
Please retain product label and instructions for future reference
Step 15
Parts Needed - No. 25 QTY 18
No. 26 QTY 6
No. 27 QTY 6
No. 29 QTY 12
Following the method shown in the illustration, lay the next 6 boards (No. 25, 26, 27 & 29 )
onto the log cabin to create your second level.
*Ensure that the boards are level and ush with each other as you lay each one.
Ensure the boards (No.26) are level, ush and in line with the boards next to them.
Secure every other board (No. 26) in place by screwing through the side of the board at an
angle into the end of the board next to it (No. 25), using 1x60mm screw per board.
3x60mm Screws
Doors on the Side
Doors on the Front
25 25
27
25
26
29
29
Rubber Mallet
may be required
to t parts.
Pre drill
hole
60mm
screw
IMPORTANT : Pre-drill before xing screws.
25 25
29
25
27
29
26
Step 16
Parts Needed - No. 25 QTY 18
No. 26 QTY 6
No. 27 QTY 6
No. 29 QTY 12
Following the method shown in the illustration, lay the next 6 boards (No. 25, 26, 27 & 29 )
onto the log cabin.
*Ensure that the boards are level and ush with each other as you lay each one.
Ensure the boards (No.26) are level, ush and in line with the boards next to them.
Secure every other board (No. 26) in place by screwing through the side of the board at an
angle into the end of the board next to it (No. 25), using 1x60mm screw per board.
3x60mm Screws
Doors on the Side
Doors on the Front
IMPORTANT : Pre-drill before xing screws.
Rubber Mallet
may be required
to t parts.
Pre drill
hole
60mm
screw
25
25
27
25
26
29
29
25
25
29
25
27
29
26

P 15
Please retain product label and instructions for future reference
Step 17
Parts Needed - No. 25 QTY 3
No. 26 QTY 1
No. 29 QTY 1
No. 31 QTY 1
No. 32 QTY 1
Following the method shown in the illustration, lay the next layer of boards
(No. 25, 26, 29, 31 & 32) onto the log cabin
*Ensure that the boards are level and ush with each other as you lay each
one.
Doors on the Side
Doors on the Front
25
25
31
25
26
29
32
25
25
32
25
26
29
31
Rubber Mallet
may be required
to t parts.
Step 18
Parts Needed - No. 20 QTY 2
No. 21 QTY 1
No. 25 QTY 2
Following the method shown in the illustration, place the Log boards (No. 25 , 26 & 29) , the
Main Gable (No. 20), and the Middle Gable (No. 21) onto the log cabin.
*Ensure that the boards are level and ush with each other as you lay each one.
Fix each board to the one below by screwing through the notch using 1x70mm screw per
corner, as shown in the illustration
Secure board (No.26) in place by screwing through the side of the board at an angle into the
end of the board next to it (No. 25), using 1x60mm screw.
6x70mm Screws
1x60mm Screw
70mm
screw
Pre drill
hole
Doors on the Side
Doors on the Front
20 25
25
20
26
29
21
20 25
25
20
29
21
IMPORTANT : Pre-drill before xing screws.
Rubber Mallet
may be required
to t parts.
60mm
screw
No. 26 QTY 1
No. 29 QTY 1
26

P 16
Please retain product label and instructions for future reference
70mm
screw
Step 19
Parts Needed - No. 20a QTY 1
No. 21a QTY 1
No. 33 QTY 1
Following the method shown in the illustration, place one of the Main Gable Points (No. 20a), the Middle
Gable Point (No. 21a) and the Log board (No. 33) onto the Cabin area of the Log Cabin, as shown in the illus-
tration.
*Ensure that the boards are level and ush with each other as you lay each one.
Fix to x the Gable Point (No. 20a) to the Main Gable (No. 20) below by screwing through the notch/board
using 1x70mm screw, as shown in the illustration
Secure board (No.33) in place, by screwing through the notch of the Middle Gable Point (No.21a) into the end
of board (No.33) using 1x70mm screw, as shown in the illustration.
**Ensure to stagger the screws so as not to collide with the previous screw.
2x70mm Screws
Pre drill
hole
Doors on the Front
33
33
32
20
21a
Rubber Mallet
may be required
to t parts.
20a
Doors on the Side
21a
20a
Step 20
Parts Needed - No. 20a QTY 1
No. 34 QTY 1
Following the method shown in the illustration, place the Main Gable Point (No. 20a) and the Log board (No. 34)
onto the Patio area of the Log Cabin, as shown in the illustration.
*Ensure that the boards are level and ush with each other as you lay each one.
Fix to x the Gable Point (No. 20a) to the Main Gable (No. 20) below by screwing through the notch/board using
1x70mm screw, as shown in the illustration
Secure board (No.34) in place by screwing at an angle through the side of the board (No.34) into the Middle Gable
Points notch (No.21a) using 1x70mm screw, as shown in the illustration.
**Ensure to stagger the screws so as not to collide with the previous screw.
2x70mm Screws
70mm
screw
Pre drill
hole
Doors on the Side
Doors on the Front
34
33
20
IMPORTANT : Pre-drill before xing screws. IMPORTANT : Pre-drill before xing screws.
Rubber Mallet
may be required
to t parts.
21a
20a
34
21a
20a

P 17
Please retain product label and instructions for future reference
Step 21
Parts Needed - No. 35 QTY 1
No. 36 QTY 1
No. 37 QTY 1
No. 38 QTY 1
Following the method shown in the illustration, place the nisher boards (No. 35, 36,37 & 38) on
to the Log Cabin.
*Ensure that the boards are level and ush with each other as you lay each one.
Fix each board to the one below by screwing through the notch/board using 1x70mm screw per
corner, as shown in the illustration
Secure boards (No.35 & 36) in place by screwing through the board at an angle into the adjacent
gable/board using 70mm screws, as shown in the illustration
**Ensure to stagger the screws so as not to collide with the previous screw.
8x70mm Screws
70mm
screw
Pre drill
hole
Doors on the Side
Doors on the Front
38
37
36
35
38
37
36
35
Rubber Mallet
may be required
to t parts.
70mm
screw
Pre drill
hole
IMPORTANT : Pre-drill before xing screws.
Step 22
Parts needed - No. 50 QTY 2
Place the double storm braces (No.50) on either side of the patio area, (internally and externally) ensuring to
locate it centrally over where the middle log boards sit ush, as shown in the illustration.
*Ensure the storm braces are secured at the highest point possible on each side.
The storm braces will need to be altered during the buildings life as the moisture content within the log boards
changes. The boards will expand during periods of high moisture (Winter) and shrink during periods of low mois-
ture (Summer.)
**Storm braces will help your building expand and contract properly.
***It is important that each bolt is tightened using a washer so as not to damage the log boards.
Secure the double storm braces into position from the inside of the cabin using 4x90mm bolts (2 at the top, 2 at
the bottom), making sure the washer & nut are tightened from the outside of the logcabin. Ensure the bolts go
through both the internal and external double storm brace.
4x90mm Bolts
50
50
IMPORTANT : Pre-drill before xing screws.

P 18
Please retain product label and instructions for future reference
39
Pre drill
hole
70mm
screw
Step 23
Parts needed - No. 39 QTY 2
Align the Roof Purlins (No. 39) into the cut out notches on each
gable top, ensuring they interlock.
To accuratley locate the notches into the purlins, ensure there is a
2748mm distance between the Main and Middle gable inside the
cabin, and 2968mm in the patio area.
Secure the roof purlins by screwing through the purlin into the
gable (ensure to pre-drill to avoid the boards splitting) using
2x70mm screws per notch.
*Please note: The gable shown is for illustrative purposes and may
dier in width from your choice in product. Nevertheless, despite any
dierences the process of xing the purlins is the same.
12x70mm Screws
IMPORTANT : Pre-drill before xing screws.
39
39
b
Rubber Mallet
may be required
to t parts.
39
a
2748mm
2968mm
40mm
screw
Pre drill
hole
*Cut to t
Step 24
Parts needed - No. 46 QTY 55
Place the rst roof board (No. 46) onto the log cabin, making sure the boards are ush to the end of the
roof purlin. Ensure there is an even amount of overhang between the log boards and roof board at the front and
back of the cabin. Once in position x to the purlins, front and back of the log cabin using 4x40mm screws.
Ensure the roof boards are not laid too close together, use the spacers (No.55) provided to create a 2mm gap.
Adjusting the spacing between the boards allows the wood to swell in damp weather.
Continue to place the roof boards onto the roof, ensuring each roof board is interlocked and level. Once in
position x the roof boards to the purlin, front and back of the log cabin using 4x40mm srews per roof board.
You have been issued with 55 roof boards, but in reality you may only need to use 54.
The last board will overhang. Using a straight edge and a pencil, mark out a line as a guide.
Cut along the pencil mark and remove the excess. Place the cut down board’s back onto the roof and secure into
place using 4x40mm screws per board.
*Please Note: This image is for illustrative purposes and may dier from your choice in product.
Nevertheless the process of cutting and tting the last roof board(s) is the same.
220x40mm Screws
a
b
a
IMPORTANT : Pre-drill before xing screws.
46
b

P 19
Please retain product label and instructions for future reference
Step 25
Parts Needed - No. 51 QTY 4
Ensuring the roof boards are ush at the
overhanging side, x the eaves frames
(No. 51) to the underside of the roof
boards using 9x30mm screws per frame,
as shown in the illustration
*Please Note: This image is for illustrative
purposes and may dier from your choice
in product. Nevertheless the process of
xing the eaves frames is the same.
36x30mm Screws
30mm
screw
Pre drill
hole 51
IMPORTANT : Pre-drill before xing screws. Step 26
Lift each door onto the already existing
hooks on the door frame, ensuring the hook
and bands connect.
*Some adjustment may be required to
align properly.

P 20
Please retain product label and instructions for future reference
IMPORTANT : Pre-drill before xing screws.
Pre drill
hole
Step 27
Parts Needed - No. 16 QTY 1
No. 17 QTY 1
No. 18 QTY 1
Fit the Mortice lock (No. 17) into the
recess in the master door (No. 7) and secure
using the screws provided. Attach the Key
plate (No. 18) to the secondary door (No. 8)
with 4x30mm screws.
Fit the door handles (No. 16) and
connect with the metalbar to the mortice
lock using 8x30mm screws. Ensure the lock
mechanism closes correctly. If not, remove
the lock and turn the catch around using
the small grub screw.
*Please note: This image is for illustrative
purposes and may dier from your choice in
product (regarding ironmongery).
Nevertheless the process of xing the frames is
the same. Once components have been tted,
try closing doors to ensure the doors can be
closed and the lock works.
If your doors do need adjusting please look at
step 9.
12x30mm Screws
a
b
30mm
screw
The Mortice Lock is Reversible
a
b
18 17
8 7
16
Step 28
Parts Needed - No. 13 QTY 1
No. 19 QTY 2
Attach the Door Strip (No. 13) to the
back of the secondary door using
4x40mm screws as shown.
Once xed, place the Tower Bolts
(No. 19) roughly into position at the
top/bottom of the door strip. With a
pencil mark the around the bolt.
After marking the bolt onto the
frame, drill a hole for the barrel bolt to
locate into.
Following the hole being drilled,
place the tower bolts into position and
secure using 4x40mm screws per bolt.
12x40mm Screws
a
b
c
c
Pre drill
hole
40mm
screw
19
IMPORTANT : Pre-drill before xing screws.
13
b
a
