Mercia Garden Products 01OSBA0307PB-V1 Instruction manual

P 1
01OSBA0307PB-V1 (01OSBA1007DDSW-V1 & 01OSBA1307DDSW-V1)
3x7 OSB Apex Exstension pack
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
**Protim Aquatan T5 (621)**
Your building has been treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct
application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied)
including a Phillips screwdriver, Stanley knife, wood saw, step ladder and drill with 2mm
bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions.
For the duration of heavy or extended periods of rain, swelling of the wood panels may
occur. Warping of the wood may also occur during excessive dry spells due to an interior
moisture loss. Unfortunately, these processes cannot be avoided but can be helped. It is
suggested that the outdoor building is sprayed with water during extended periods of
warm sunshine and sheltered as much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to protect
the product during transit and for upto 3 months against mould. To validate your
guarantee and ensure longevity of the product, it is ESSENTIAL the building is treated
with a wood preserver within the rst three months of assembly and thereafter in
accordance with the manufactures recommendations. Care must be taken to ensure
the product is placed on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to
diagrams for the base dimensions, The base should be slightly smaller than the external
measurement of the building, i.e. The cladding should overlap the base, creating a run
o for water. It is also recommended that the oor be at least 25mm above the
surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in
the case of childrens products independently tested to EN71 level, we cannot accept
responsibility for your safety whilst erecting or using this product.
Refer to the instructions pages for you specic product code
For ease of assembly, you
will need a tape measure to
check dimensions of
components.

6
7
8
9
5
10
Ridge bar 1050mm
F2770-1050mm
Eaves frame 1044mm
FS2828-1044mm
P 2
01OSBA0307PB-V1 (01OSBA1007DDSW-V1 & 01OSBA1307DDSW-V1)
10x7
Overall Dimensions:
Width = 2230mm
Depth = 3198mm
Height = 2118mm
Base Dimensions:
Width = 2066mm
Depth = 3120mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
13x7
Overall Dimensions:
Width = 2230mm
Depth = 4248mm
Height = 2118mm
Base Dimensions:
Width = 2066mm
Depth = 4170mm
Plane Side Panel
AI-01SHPPS1050X1567-V1
OSB Floor
AI-01OSBF2066X1050-V1
Roof OSB
PI-03-0338
1 2 3
4
Truss beam 1101mm
F2744-1141mm (ANGLED)
Truss centre support 360mm
F2744-400mm (ANGLED)
Truss support 140mm
F2744-160mm (ANGLED)
Cover trim 1575mm
S1230-546mm
U-Channel
PI-07-0013
QTY - 10x7- 1
13x7- 2
QTY - 10x7- 2
13x7- 4
QTY - 10x7- 2
13x7- 4
QTY - 10x7- 1
13x7- 2
QTY - 10x7- 2
13x7- 4
QTY - 10x7- 1
13x7- 2
Nail Bag
Felt Tacks x 50
30mm Screw x 52
40mm Screw x 52
50mm Screw x 56
Remove transportation blocks from the bottom of each
panel before beginning assembly. Each Panel should
have two blocks.
Pre Assembly
***** Please read the instructions for the OSB 7x7 Apex rst before continuing *****
60mm Screw x 16
QTY - 10x7- 2
13x7- 4
QTY - 10x7- 4
13x7- 8
QTY - 10x7- 2
13x7- 4
QTY - 10x7- 4
13x7- 8

P 3
Please retain product label and instructions for future reference
Pre drill
hole
40mm
screw
Step 1
Place oor on rm and level base, ensure
base has suitable drainage free from areas
where water can collect. (See front page on
base requirements).
Attach the oors using 40mm screws.
10x7- 10x40mm Screws
13x7- 20x40mm Screws
10x7
13x7
Pre drill
hole
50mm
screw
Step 2
Place the 7x7 plain side at on the ground
and x the the short plain panel with
3x50mm screws.
*Fix a second short plain panel for the
13x7 in the same way.
**Do not secure the building to the oor
until the roof is tted. Fix the panels onto
the oor using 50mm screws in alignment
with the oor joists.
10x7- 3x50mm Screws
13x7- 6x50mm Screws
10x7
13x7

P 4
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
Please retain product label and instructions for future reference
Pre drill
hole
50mm
screw
Step 3
Place the 7x7 window side at on the
ground and x the the short plain panel
with 3x50mm screws.
*Fix a second short plain panel for the
13x7 in the same way.
**Do not secure the building to the oor
until the roof is tted. Fix the panels onto
the oor using 50mm screws in alignment
with the oor joists.
10x7- 3x50mm Screws
13x7- 6x50mm Screws
10x7
13x7
Step 4
Attach the gable ends as shown in the 7x7
instructions and follow the steps to t the
window.
**Do not secure the building to the oor
until the roof is tted. Fix the panels onto
the oor using 50mm screws in alignment
with the oor joists.
10x7
13x7

P 5
Please retain product label and instructions for future reference
50mm
screw
Pre drill
hole
Pre drill
hole
Pre drill
hole
Pre drill
hole
50mm
screw
30mm
screw
60mm
screw
Step 5
To make the building rigid, support truss’
need to be built in position.
A. Create the Ridge bar using the
U-channel. This will combine the
longer ridge bar of the 7x7 and the
shorter bar of extension kit.
x the U-channel using 30mm
screws.
*13x7 will need extending at both
ends of the orignal ridge bar.
10x7 - 10x30mm screws.
13x7 - 20x30mm screws.
B. Attach the ‘L’bracket, provided in
the 7x7 xing kit, to either end of
the extended ridge bar with
4x30mm per bracket.
8x30mm screws
C. Place a truss beam into position so
that the ridge end is in line with the
ridge bar and the lower end in line
with the buildings’framing as
shown.
Mark the position of the lower end
with a pencil.
At the marked position x the truss
support block with 2x50mm screws.
Fix the Truss beam to the Ridge bar
and the Truss support Block with
2x50mm screws.
Repeat with opposite side and
secure both Truss beams with the
Truss centre support from
underneath with 2x60mm
screws.
*The 13x7 is extended at both ends.
repeat the steps shown at the point
where the ridge bar is extended.
10x7 - 8x50mm screws.
4x60mm screws.
13x7 - 16x50mm screws.
8x60mm screws.
B.
A.
C.
Ridge bar
Truss beam
Truss beam
**Do not secure the building to the oor until the roof is tted. Fix
the panels onto the oor using 50mm screws in alignment with the
oor joists.
Step 6
To strengthen the building a second set of
Trusses need to be xed into postion.
10x7
The second Truss is tted at the centre point
of the window. Secure the Truss in the same
manner as shown previously.
8x50mm screws.
4x60mm screws.
13x7
Two Trusses need to be tted either side of
the window as shown. Secure the Trusses in
the same manner as shown previously.
16x50mm screws.
8x60mm screws.
**Do not secure the building to the oor
until the roof is tted. Fix the panels onto
the oor using 50mm screws in alignment
with the oor joists.
10x7
13x7
60mm
screw

P 6
Please retain product label and instructions for future reference
Please retain product label and instructions for future reference
Pre drill
hole
30mm
screw
Step 7
Fix the Eaves framing to the Roof OSB ush to
the short edge with 3x30mm screws.
For the larger roof section follow the
instructions given in 01OSBA0707DDSW-V1
10x7- 6x30mm screws
13x7- 12x30mm screws
Pre drill
hole
40mm
screw
Step 8
10x7
To secure the Roof to the building, start at
the front, making sure the front edge of the
Large Roof sheet is ush to the door gable.
Fix the Large Roof sheet as shown in
01OSBA0707DDSW-V1.
Further secure the Large Roof by xing
through the roof into the Truss with
4x40mm screws.
Once the large roof sheet is xed into
postion, x the small roof sheet as shown
with 12x40mm screws.
10x7- 16x40mm Screws
13x7
To secure the Roof to the building, start at
the front, making sure the front edge of the
Small Roof sheet is ush to the door gable.
Fix the Small Roof sheet as shown with
12x40mm screws.
Fix the Large Roof sheet as shown in
01OSBA0707DDSW-V1.
Further secure the Large Roof by xing
through the roof into the Trusses with
8x40mm screws.
Once the large roof sheet is xed into
postion, x the small roof sheet as shown
with 12x40mm screws.
13x7- 28x40mm Screws

P 7
Please retain product label and instructions for future reference
Step 9
Once the Roof is xed into position, x the
building to the oor with evenly spaced
50mm screws.
In addition to the 16x50mm given in the
01OSBA0707DDSW-V1;
10x7- 6x50mm Screws
13x7- 12x50mm Screws
Step 10
Fix the Cover Trims to the building to the
front and back as described in
01OSBA0707DDSW-V1.
10x7
Fix the two Cover Trims to the the seam of
the building as shown with 3x30mm screws
per trim.
10x7- 6x30mm Screws
13x7
Fix the four Cover Trims to the the seam of
the building as shown with 3x30mm screws
per trim.
13x7- 12x30mm Screws
Pre drill
hole
50mm
screw
Pre drill
hole
30mm
screw

P8
Please retain product label and instructions for future reference
Step 11
Cut the felt into 3 even lengths. Lay onto
roof as shown ensuring there is overhang
around the sides then nail the felt tacks
every 100mm.
In addition to the 104x Felt Tacks given in
the 01OSBA0707DDSW-V1;
10x7- 25x Felt Tacks
13x7- 50x Felt Tacks
Felt
tacks
Step 12
Complete the building by following the
01OSBA0707DDSW-V1 instructions for
attaching the fascias.
This manual suits for next models
2
Other Mercia Garden Products Storage manuals
Popular Storage manuals by other brands

G-Technology
G-Technology G-SPEED eS installation guide

Toshiba
Toshiba Canvio AeroCast user manual

Western Digital
Western Digital WDBACH0020HAL - My Book Studio LX Specifications

Dell
Dell PowerVault MD3200 Series Deployment guide

Nurve Networks
Nurve Networks HYDRA SD MAX user manual

Quest Leisure Products
Quest Leisure Products C0102 instructions

Seagate
Seagate MOMENTUS ST91603010AS product manual

Western Digital
Western Digital My Passport WDBBEP0010BBK user manual

IOGear
IOGear GHE225U user manual

Buffalo
Buffalo HDW-PDU3 MiniStation Air Specifications

Allen-Bradley
Allen-Bradley 1770-M10 Assembly and installation manual

Buffalo
Buffalo HDW-PDU3 MiniStation Air Quick setup guide
