Glyph GT060BR-1000 User manual

800.335.0345
glyphtech.com
FireWire 800 Hardware RAID solution.
Glyph's GT 060BR is designed for use with demanding audio and video
applications. A high-bandwidth solution, featuring two industry leading
disk mechanisms and hardware RAID 0 technology, the GT 060BR is
perfect for audio and video editing, or mass storage with blazing fast
speed. As with all GT Series products, it has a rugged construction with
durable stainless steel, and uses an internal power supply and a quiet fan.
Using 7,200 RPM drives, and available in RAID capacities up to 1.5TB,
the GT 060BR comes standard with a three-year warranty that includes
overnight advance replacement in the first year.
Technical Specifications
• Capacity: 320GB, 500GB, 800GB, 1000GB (1TB), 1500GB (1.5TB)
• Interface: Two IEEE 1394b (FireWire 800) connectors
• Bridging: Oxford 912 chip
• Rotational speed: 7,200 RPM
• Average seek time (read): 8 msec
• Max external transfer rate: 800 Mb/sec (100 MB/sec)
• Sustained transfer rate: 80 MB/sec
• Buffer size (cache): 16MB
• Dimensions: H 3.5" x W 8.6" x D 9.5"
• Weight (lbs/kg): 7.10 lbs / 3.22 kg
• Internal Power supply: Universal 100-240v, 50-60 Hz
• Operating Temperature (C/F): 41 - 122/5 - 50
• Warranty: 3 years, with 1st year 24-hour advance replacement
• Compatibility: Mac OS 10.2.5 or later, Windows 2000/XP
• Includes: FireWire-800 9pin to 9pin cable, power cable, feet, downloadable
manual
Features:
•Huge storage capacity up to 1.5TB.
• Sustain data rates of 80 MB/sec with
Mac OS X 10.4 Tiger.
• Hardware RAID 0 with no
configuration software needed.
• Fast 7,200 RPM, ATA/100 Hitachi
drives with an 8MB cache.
• Enclosure has a stainless steel faceplate,
internal quiet fan, and internal power
supply.
• Perfect for Final Cut Pro, Avid Xpress,
Adobe Premiere.
• Ideal for video, content creation, sound
libraries and data backup applications.
• Comes complete with Glyph's 24-hour
advance replacement warranty along
with outstanding technical support at
no additional charge.

GT 060BR - Firewire RAID Array
The GT 060BR is a high-speed RAID array for video professionals. All Glyph
RAID arrays are tested and optimized to work with the latest in NLE
workstations to achieve optimal performance and ensure maximum
functionality and compatibility. Glyph's legendary service and tech support is
backed by an Overnight Advance Replacement warranty on all GT 060BR
RAID arrays.
Supported Non-Linear Editors
Final Cut Pro
Avid Xpress
Adobe Premiere
Supported Hardware and Software
Mac or PC with a FireWire port
Mac OS 10.2.5 or later, Windows 2000/XP
Speed Benchmark Tests (read)
810038-1.04 GT 060BR DATA.pdf
© Glyph Technologies, a division of Ithaca Technologies, LLC
July 11, 2005
FireWire 800 Facts
• FireWire 800 supports speeds up to
800 Mb/sec, twice as fast as FireWire
400.
• If your computer does not have
built-in FireWire 800, you'll need a
PCI card to achieve a true FireWire
800 connection.
• Most 800 ports are Bi-Lingual, which
means they speak both FireWire 400
and FireWire 800.
• If you connect a 400 device to an
800 device, you will be running at
400 speed maximum.
• FireWire is forward-compatible and
back-compatible, but the bus always
runs at the speed of the slowest link.
• Beta cables are used to connect 800
devices to 800 devices.
• Bi-Lingual cables are available to
connect 400 devices to 800 devices.
• Bi-Lingual cables have a 9-pin Bi-
Lingual connector at one end a 4-
pin or 6-pin FireWire 400 connector
at the other end
Compatible with both Mac and PC,
Glyph's FireWire 800 PCI Card allows
super-fast connectivity to your FireWire
devices. With three external FireWire 800
(IEEE 1394b) bilingual ports, you can
connect not only FireWire 800 devices,
but also your
existing FireWire
400 devices.
• Bilingual cables
are also available
from Glyph.
•Card runs at 200,
400 and 800
Mbits/sec.
• Compatible with Mac G4 systems
running OS 10.2.5 or later.
• Compatible with Windows 2000/XP.
• Easy installation, no drivers necessary.
FireWire 800 Optional Accessories
The GT060BR consistantly reaches a read datarate of around 80MB/sec,
plenty of speed and overhead to capture and edit video. A G5 with OS X 10.4
and AJA’s disk test was used for the test setup.
