Megatouch XL™ Technical Service Manual Contents
Section 1 - Cabinet Information
General Information- All Cabinet Styles (Pink)
Dimensions/Shipping weights
General Information - Countertop (Blue)
Parts illustrations
Parts list
General Information - 19” Upright (Gold)
Parts illustrations
Parts list
General Information - 19” Cabaret (White)
Parts illustrations
Parts list
Section 2 - Troubleshooting Information
Touchscreens (Pink)
Troubleshooting
Advanced touchscreen calibration
Removal and Installation of Touchscreen
Glass
Microtouch touchscreen information
Access/Removal of Major Assemblies (Blue)
CD-ROM player
Monitor
Circuit Boards
Troubleshooting Guide (Gold)
Troubleshooter™ Instructions (White)
CMOS Setup (Green)
Mars 2000 Bill Acceptor (Yellow)
DIP switch settings
Coin-in menu instructions
Section 3 - Power Supply
GlobTek ST-230WF (Pink)
Parts list
Schematics
Sparkle Power International (Blue)
Schematics
Section 4 - Circuit Boards
DeAmertek CPU (Pink)
NO INFO AVAILABLE
Telco CPU (Blue)
Schematics
CRT-500 I/O Board (Gold)
Parts list
Schematics
Communications Board (White)
Parts list
Schematic
Section 5 - Monitors
Ducksan (Pink)
Schematics
Telco (Blue)
Parts list
Schematic
Tatung (Gold)
Schematics
Monitor Adjustmerts (White)
Degaussing
Color adjustment
Section 6 - Technical Service Bulletins
Field Bulletin 9
(XL CD-ROM ribbon cable/Updated
software)
Field Bulletin 10
(XL NVRAM not clearing with new
software)
Tech Notes 7
(Over-torquing I/O board screws)

General Information- All Cabinet Styles
Dimensions/shipping weights
General Information - Countertop
Parts Illustrations
Parts List
General Information - 19” Upright
Parts Illustrations
Parts List
General Information - 19” Cabaret
Parts Illustrations
Parts List

Cabinet Information Section
General Information
The Megatouch XL video games are available in several different cabinet styles:
Countertop*
Dimensions: H - 15-1/4”; W - 20”; D - 18-1/4”
Shipping weight: approx 95 lbs.
Bill acceptor option*
19” Upright
Dimensions: H - 54-1/4”; W - 24”;D - 26-1/2”
Shipping weight: approx 250 lbs.
Bill acceptor option
19” Cabaret
Dimensions: H - 61”;W - 22-1/2”;D - 24”
Shipping weight: approx. 250 lbs.
Bill acceptor option
*An optional coin mech/bill acceptor (Mars 2000) combination unit is available for all countertop
models.

Countertop
Dimensions: H - 15-1/4”; W - 20”; D - 18-1/4”
CPU Board Information
DeAmertek
Telco
Touchscreen Type
Microtouch
ELO

13” COUNTERTOP

MEGATOUCH XL PARTS LISTS
Megatouch XL CTOP
Part List
CALLOUT # PART # DESCRIPTION
SA0100-01 ASSY, MEGATOUCH XL, CTOP
1 MW0009-01 CHASSIS, CTOP, XL
2 MW0015-01 BRACKET, LOCK, CTOP XL
3 HW8741 LOCK, CIRC, BNT, DIFF, 1/2”
4 SA4084-02 SPEAKER ASSY, 4”, W/6-PIN CONN
5 HW8993-02 LAZY SUSAN, 12” DIA, 15 DEG. STOPS
6 HW8018-01 ANTI-SKID PAD, 11.5”DIA, RA65 RBR
7 MW0038-01 CORD CLAMP, XL
8 HW9001 TUBING, PLASTIC
9 SA0108-01 HARNESS, MAIN, CTOP, XL
10 SA0111-01 HARNESS, DISPLAY, AC, CTOP, XL
11 SA5129-01 GASKET/BEZEL ASSY
11a HW8087 TAPE, NEOP, .18W X .38THK, PSA
11b HW8953 BEZEL, 13’ T/S
SA0102-01 HARNESS, COIN BOX, MGATCH XL, CTOP
12 CN7508 METRIMATE PLUG, 12 PIN
13 CN7501 METRIMATE PIN, FEMALE 20-24 AWG
14 EC9154 COUNTER, 12V FROG EYE MTG
15 SW3005 PB SWITCH, MOMENTARY (SETUP/CALIBRATE)
16 MW0012-01 BRACKET, CONN/COUNTER, CTOP XL
SA0104-01 DISPLAY/MOTHERBOARD ASSY, XL
17 MW0010-01 FRAME, DISPLAY, CTOP, XL
18 EC9840 TOUCHSCREEN CONTROLLER, SMT3
19 HW8171-01 PCB GUIDE, 8”, SNAP-ON, DEEP CHANNEL
20 EC0003-01 CD-ROM PLAYER, IDE, 4X
21 SA0103-01 TOUCHSCREEN/VGA DSPLY ASSY, 13”
21a EC9377 MONITOR, VGA, 13” (W/ CHASSIS BOARD & FRAME)
21b EC9824 TOUCHSCREEN OVERLAY, 13’
21c HW8078 TAPE, POLYESTER, 1”, W/ADH
21d HW8067 TAPE, FOAM, .5W X .03 THK, DBL
22 SA0112-01 ASSY, MOTHER BOARD & I/O, XL
22a SA10025-01 PCA, CRT-402, DE-AMER, RISER BOARD
22b SA10023-01 PCA, I/O BOARD, XL VID, CTOP
22c SA0101-01 ASSY, MOTHERBOARD
23 SA0118-01 CABLE, POWER EXTENSION, CD-ROM
SA0105-01 COVER ASSY, CTOP, XL
24 WD0001-01 SIDE PANEL, RIGHT, CTOP XL
25 WD0001-02 SIDE PANEL, LEFT, CTOP XL
26 MW0013-01 TOP, CTOP, XL
27 MW0016-01 DOOR, CTOP, XL
28 MW0014-01 PLATE, LATCH, CTOP, XL
29 HW8734-01 LOCK, W/O CAM, 564, 5/8”L (REAR DOOR)
30 MW0024-01 CAM, LOCK (REAR DOOR)

31 MW0023-01 BOLT, LOCK, CTOP, XL
32 HW8911-01 PIN, SPRING, STL, .094OD X .50L
33 MW5164-01 HINGE, REAR DOOR CTTS
34 EC9410 FAN, TUBAXIAL, 3”, 110V
35 SA0117-01 CABLE, POWER EXTENSION, FAN
SA0106-01 PWR ENTRY ASSY, CTOP, XL, 120V
36 EC7528 POWER SUPPLY, SW, PS/2-PC
37 MW0011-01 BARCKET, PWR SUPPLY, CTOP, XL
38 SW4024 ROCKER SW, DPST, 250V, PANEL MTG
39 TA10028-01 PCA, RS-485 COMMUNICATIONS BD, XL SYS
SA0119-01 DOOR ASSY, CD-ROM ACCESS, XL, CTOP
40 MW0039-01 DOOR, CD-ROM ACCESS, XL, CTOP
41 HW8727 LOCK, FLAT, STR, DIFF, 1-1/8 CAPKY (CD DOOR/COIN BOX)
42 MW0037-01 CAM, LOCK, .75 X 2.0
DECALS AND SIGNS
GL3100-01 DECAL, SIDE PANEL, XL, CTOP
GL3101-01 DECAL, FRONT, XL, CTOP
SA7297-06 SIGN HOLDER, MEGATOUCH XL (HOLDER & SIGN ASSEMBLY)
HW9461-03 SIGN HOLDER, PETG, 4 X 12, CTOP
PM8928-09 SIGN, MEGATOUCH XL, CTOP
COIN MECHS/BILL ACCEPTORS
25¢ USA
HW8249 FR/PLATE, SINGLE, M, .25, ROLL DOWN
$1 CANADIAN
HW8295 FR/PLATE, SINGLE, M, $1 CANADIAN
COIN BOX ASSY
SA5161-01 HARNESS, COIN BOX, MECHANICAL, CTOP, XL
MW0017-01 COIN BOX, CTOP, XL
MW5153-01 DOOR, COIN BOX, CTOP
COIN BOX/JCM B/A ASSY, $1-20, XL
EC9797 JCM B/A DBV-45 $1-20, W/ STACKER
SA0109-01 HARNESS, JCM B/A, CTOP, XL

19” Upright
Dimensions: H - 54-1/4”; W - 24”;D - 26-1/2”
CPU Board Information
DeAmertek
Telco
Touchscreen Type
Microtouch
ELO

19” UPRIGHT
(
FRONT ACCESS
)
19” UPRIGHT
(
FRONT ACCESS
)

19” UPRIGHT
(
REAR ACCESS
)
19” UPRIGHT
(
REAR ACCESS
)

19” Upright Parts List
CALLOUT # PART # DESCRIPTION
1 EC2001 POWER CORD, 120V
2 HW8711 ANCHOR PLATE FOR CAM LOCK
3 HW8716 LOCK, FLAT, STR, #564, 1-7/16” (REAR DOOR)
4 HW8960 LEG LEVELER, 2”, 3/8-16THD
5 MW5001-01 STAY LID, URTS, 19”
6 MW5003-01 BRACKET, CRT ADJUST, LEFT
7 MW5003-02 BRACKET, CRT ADJUST, RIGHT
8 MW5006-01 COVER, PERFORATED, SPEAKER, 4”
9 SB0010-01 COM, POWER CABLE
10 SA4084 SPEAKER ASSY, 4”
11 WD2017-01 CABINET, 19” URTS, XL/260, FA, BLK
12 SA0063-01 HARNESS, POWER, DUAL FANS, URTS
13 SA5117-05 FAN ASSY, 3”, 12V DC, 2 PIN, W/GUARD
14 HW8756 CAM, BENT, 1/8” OFFSET
15 SA0058-01 HARNESS, POWER SWITCH, URTB/URTS/CAB, XL
16 SW4024 ROCKER SWITCH, DPST, 250V, PNL MTG
17 TA10028-01 PCA, RS-485 COMM, XL SYS
18 EC2187-01 RIBBON CABLE, 9 COND, 31”L
19 HW6366 MOUNTING POST, KNURLED
20 EC9840 TOUCHSCREEN CONTROLLER BOARD, SMT-3
21 MW0057-01 COVER, FAN PROTECTOR
22 SA3209-01 BRACKET ASSY, METER/TEST SWITCH
23 MW0044-01 DOOR LOCK LATE, UR
24 SA3234-01 (-02) SHELF, PC POWER, URTS, XL (-02 “CE” APPROVED ASSY)
24a WD2018-01 SHELF, 19” VIDEO, UNIVERSAL
24b MW0063-01 PLATE, MTG, PC/PWR, XL
24c EC0007-01 TERMINAL BLOCK, 4 POSITION
24d EC7528 POWER SUPPLY, SWT, PS-2/PC
24e SA0077-01 HARNESS, MAIN, XL
24f EC0003-01 CD-ROM PLAYER, IDE, 4X
24g EC2191-06 RIBBON CABLE, 2X20 PIN, IDE, 7”L
24h SA0067-01 HARNESS, VOLUME POT, URTS/CAB, 260
25 SA0112-01 ASSY, MOTHERBOARD & I/O, XL
25a SA10025-01 PCA, CRT-402, DE-AMER, RISER BOARD
25b SA10023-01 PCA, I/O BOARD, XL VID, CTOP
25c SA0101-01 ASSY, MOTHERBOARD
26 SA3202-05 SHELF ASSY, TS/CRT (VGA)
26a SA3210-03 TS/CRT (VGA) ASSY, COLOR, 19”
26b EC9378 MONITOR, VGA, 19”
26c EC9823 T/S OVERLAY, 19”
26d HW8078 TAPE, POLYESTER, 1”, W/ADHESIVE
26e HW8067 TAPE, FOAM, .5W, .03THK,DBL
26f WD2013-01 SHELF, CRT MTG, 19” URTS
26g MW5008-01 BRACKET, CRT LEFT, 19” URTS
26h MW5008-02 BRACKET, CRT RIGHT, 19” URTS
27 SA3230-01 BEZEL ASSY, 19” URTS
27a MW5014-01 BEZEL/HINGE ASSY, 19” URTS
27b HW8951-02 BEZEL, MONITOR, 19” URTS
28 HW8713 LOCK, FLAT, STR, 564, 1-7/16 KYRM

19” Cabaret
Dimensions: H - 61”; W - 22-1/2”; D - 24”
CPU Board Information
DeAmertek
Telco
Touchscreen Type
Microtouch
ELO

19” CABARET
19” CABARET

19” Cabaret Parts List
CALLOUT # PART # DESCRIPTiON
1 EC2001 POWER CORD, 120V
2MW1672-01 CONTROL PANEL, 19” CABARET
3MW1671-01 BRKT, GLASS, UPPER, 19” CABARET
4MW1670-01 SPEAKER, MTG BRKT, 19” CAB
5 HW8951-01 BEZEL, MONITOR, 19” CABARET
6WD5060-01 WOOD CABINET, URTS, 19” CABARET
7 SA4084 SPEAKER ASSY, 4”
8 SA3209-01 BRACKET ASSY, METER/TEST SWITCH
9 HW8960 LEG LEVELER, 2”, 3/8-16THD
10 GL2411-03 PLEXI, CLEAR, 19” CABARET, SIGN
11 MW1674-01-0A MONITOR, SUPPORT LEFT, 19” CABARET
12 MW1674-02-0A MONITOR, SUPPORT RIGHT, 19” CABARET
13 HW8979 SLIDE LATCH
14 SA0058-01 HARN, PWR SWITCH, URTB/URTS/CAB, XL
14a SW4024 ROCKER SWITCH, DPST, 250V, PNL MTG
15 SB6058-01 FLUOR LAMP ASSY, 120V/60HZ, 15W
15a* LB2100 LAMP, FLUOR, 15W, F15T8CW
16 MW0028-01 PLATE, POWER ENTRY
17 HW6366 MOUNTING POST, KNURLED
18 TA10028-01 PCA, RS-485 COMM, XL SYS
19 EC2187-01 RIBBON CABLE, 9 COND, 31”L
20 EC9840 TOUCHSCREEN CONTROLLER BOARD, SMT-3
21 SA0014-01 HARN, E/M/CREJ, 19” CABARET
22 SA3266-03-0B CRT ASSY, 19” CABARET, XL
22a* EC9378 MONITOR, VGA, 19”
22b* EC9823 T/S OVERLAY, 19”
22c* HW8078 TAPE, POLYESTER, 1”, W/ADHESIVE
22d* HW8067 TAPE, FOAM, .5W, .03THK,DBL
22e WD5061-01-0A SHELF, MONITOR, 19” CABARET
23* SA3234-01 (-02) SHELF, PC POWER, URTS, XL (-02 “CE” APPROVED ASSY)
23a WD2018-01 SHELF, 19” VIDEO, UNIVERSAL
23b MW0063-01 PLATE, MTG, PC/PWR, XL
23c EC0007-01 TERMINAL BLOCK, 4 POSITION
23d EC7528 POWER SUPPLY, SWT, PS-2/PC
23e SA0077-01 HARNESS, MAIN, XL
23f EC0003-01 CD-ROM PLAYER, IDE, 4X
23g EC2191-06 RIBBON CABLE, 2X20 PIN, IDE, 7”L
23h SA0067-01 HARNESS, VOLUME POT, URTS/CAB, 260
24* SA0112-01 ASSY, MOTHERBOARD & I/O, XL
24a SA10025-01 PCA, CRT-402, DE-AMER, RISER BOARD
24b SA10023-01 PCA, I/O BOARD, XL VID, CTOP
24c SA0101-01 ASSY, MOTHERBOARD
*This part is not called out in the drawing. It is either part of an assembly that is shown, or it is an
assembly in which all of the parts are shown separately.

Touchscreens
Troubleshooting your Touchscreen
Advanced Touchscreen Calibration
Removal/Installation of Touchscreen Glass
Microtouch Touchscreen Information
Access/Removal of Major Assemblies
CD-ROM Player
Monitor
Circuit Boards
Troubleshooting Guide
Troubleshoooter™ Software Instructions
CMOS Setup
Mars 2000 Bill Acceptor
DIP Switch Settings
Coin-In Menu Instructions

Troubleshooting Your Touchscreen
Problem 1 The touchscreen appears to lose calibration if you touch the screen while
touching the metal on the cabinet (this particular problem is most likely to affect
upright and cabaret games, not countertops).
Solution Make sure the controller and/or the cabinet is properly grounded. NOTE: For the
19" upright, you may have to remove the paint from the hinge that the ground
braid is attached to in order to get a better connection.
Problem 2 The touchscreen won't calibrate correctly. This is a vague problem that requires
more information to determine the cause. To investigate further, go to the TEST
SCREEN mode and slowly pull your finger down the screen in a vertical line.
A) If the crosshair moves in a wavy line (sine wave) then there is a bad EEPROM in
the Microtouch touchscreen cable connector.
Solution Replace the touchscreen glass. NOTE: TO PRESERVE THE VALIDITY OF
YOUR WARRANTY, CONTACT MERIT TECHNICAL SERVICE (at 1-800-445-
9353) BEFORE ATTEMPTING ANY SERVICING.
B) If the cursor generally follows your finger, except for one particular area on the
screen, the EEPROM is not correcting for flaws in the touchscreen glass.
Solution Repair or replace the touchscreen glass (or you can try switching touchscreen
controllers, if you have another one. This can cause the EEROM to reinitialize
itself, leaving you with both controllers working).
C) If the crosshair moves continually towards one of the corners (the same corner
each time), every time you run your finger down the screen, the touchscreen
glass has a broken wire.
Solution Return the glass to Merit Technical Service to have it fixed.
D) If the controller works for a while, but stops working (the TTL LED does not
respond to a touch), the controller may not be properly grounded.
Solution Install the TTL Ground/Static kit (#SA1089-01) and the CRT-266 Electro-Static
Discharge Board kit (SA1088-01). On the upright model, you may want to check
the gray and green wires from the touchscreen controller cable. They should be
attached to the ground on the power supply.

Problem 3 If the glass is totally unresponsive, check the LED on the touchscreen controller
(board).
1. If the LED isn't flashing, touch the screen while keeping an eye on the LED. If the
LED reacts to your touch (i.e. gets brighter), the problem is with the CRT-260
board.
a) The U41, UART chip has been minorly affected by a static hit.
Solution Turn the game off, then power up. If that fixes the problem, call Merit Customer
Service for software that can prevent this problem from happening again.
b) The UART chip or the U39 Maxim chip (on the upright model) has been burnt
out by a static hit.
Solution Call Merit Technical Service at 1-800-445-9353. NOTE: Make sure to install, if
you haven’t already, the SA1089-01 Ground/Static kit to help prevent this from
happening again.
If the LED is flashing, refer to the following chart for interpretation of the error and contact
Merit Customer Service.
Flashes per 10 Second
Inerval Error Detected
1 RAM Error
2 ROM Error
3 A/D Error
4 EEROM Error
5 Analog Error

Advanced Touchscreen Calibration
The following directions will help you calibrate your touchscreen more accurately.
1. Enter calibrate mode. When the first dot appears, intentionally touch the screen about 1”
away from the dot, diagonally, towards the center of the screen (repeat this procedure
for the second calibration dot; see Figures 1a and 1b). You are now in TEST SCREEN
mode. As you test the screen, you should notice that the crosshair is considerably out of
calibration. By completing this step, you have shown that the machine is accepting
calibration input.
Figure 1a Figure 1b

2. Go back to calibrate mode, but this time touch exactly on the center of the calibration
dots, to more accurately calibrate the screen (see Figures 2a and 2b). You are now
back in TEST SCREEN mode. Touch the approximate location where the first dot
appeared. If the crosshair is not centered on your finger, note the direction and
approximate distance which it is off center. Repeat this procedure at the approximate
location of the second calibration dot (see Figures 2c and 2d). (If the crosshair is
centered on your finger, the screen is calibrated accurately.)
Figure 2a Figure 2b
Figure 2dFigure 2c
