Messner eco-X2 4500 User manual

eco-X2 4500
eco-X2 7500
eco-X2 10000
eco-X2 13000
eco-X2 16000
eco-X2 20000
eco-X2 plus 10000
eco-X2 plus 15000
eco-X2 plus 20000
eco-X2 plus 25000

1
C
8
6
1 72
5
1
20
21
9
15 16
10
3
4
11
8
12
2
6
5
14
14
7
18
17 13
19 eco-X2 20000
eco-X2 plus 15000
eco-X2 plus 20000
eco-X2 plus 25000
43
min. 25 cm
max. 2 m
min. 2 m
min. 2 m
1.
2.
1.
9

2 3
eco-X2
4500
eco-X2
7500
eco-X2
10000
eco-X2
13000
eco-X2
16000
eco-X2
20000
82
4.900
l/min l/h
122
7.300
l/min l/h
183
11.000
l/min l/h
210
12.600
l/min l/h
257
15.400
l/min l/h
327
19.600
l/min l/h
3,1 m 4,0 m 5,4 m 5,5 m 5,8 m 5,5 m
48 W 75 W 110 W 140 W 190 W 205 W
230 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz
IP 68 IP 68 IP 68 IP 68 IP 68 IP 68 IP 68
Tmax. 35°C 35°C 35°C 35°C 35°C 35°C
max. 2 m 2 m 2 m 2 m 2 m 2 m
Art.-No. 156 / 005000 156 / 005001 156 / 005002 156 / 005003 156 / 005004 156 / 005005
eco-X2 plus
10000
eco-X2 plus
15000
eco-X2 plus
20000
eco-X2 plus
25000
165
9.900
l/min l/h
245
14.700
l/min l/h
300
18.000
l/min l/h
403
24.200
l/min l/h
2,4 m 3,2 m 3,6 m 3,8 m
60 W 105 W 155 W 190 W
230 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz
IP 68 IP 68 IP 68 IP 68 IP 68
Tmax. 35°C 35°C 35°C 35°C
max. 2 m 2 m 2 m 2 m
Art.-No. 156 / 005006 156 / 005007 156 / 005008 156 / 005009

4 5
Please read the instructions thoroughly before using the pump! Otherwise you may not use it!
This appliance is not suitable for use by persons (including children) with limited physical, sensory or mental
capabilities or lacking experience and/or knowledge, except if they are supervised by a person responsible
for their safety or have been instructed in the use of the appliance.
Children should be supervised in order to make sure that they do not play with the appliance.
Construction
These modern, powerful pumps are equipped with a single-phase alternating-current motor (canned motor
with capacitor). The motor is waterproof encapsulated in synthetic resin (IP68) and provided with an
overload protection.
Please refer to the type plate for technical specifications or the table on page 2 + 3.
Use
These pumps are designed for the transport of water, for the operation of filter systems,water displays,
waterfalls, etc., as well as for oxygenating and circulating the water.
Area of application: garden ponds, fishponds, outdoor and patio fountains!
- Attention! Use in garden ponds and their protected zone is permitted only if the installation is
performed in compliance with the applicable regulations. Please consult a licensed electrician.
- Before performing any work on the pump, the fountain, or the pond, disconnect the mains
plug. Do not operate the pump if people are in the water! (disconnect the pump from the power
source)
Area of application: swimming pond or swimming pool (if people are in the water)!
Pump suitable for installation and operation in systems and rooms according to DIN VDE 0100 Part 702 and
Part 737, if the erection requirements per DIN VDE 100 and the manufacturer’s specifications (assembly
and operating instructions) are followed.
Installation of these pumps at swimming ponds or swimming pools must comply with the following
standards: DIN EN 13451 Part 1 to Part 8, and DIN VDE 0100 Part 702 and Part 737.
Attention! Here operation of the pump is permitted only if the pump is permanently installed outside
of the water at least 2 m or more away from the pool.
The following measures must be undertaken: (see fig. 2)
- Build a shaft with pedestal for the pump, at least 2 m away from the edge of the water.
- Protect the shaft with a cover.
- To protect the pump from flooding build a drain for the shaft.
- Attach the pump to the pedestal with screws.
- Install a “M” metal socket in the suction line, toward the pump, to connect to the equipotential bonding
of the swimming pond/swimming pool system!
- Please consult a licensed electrician. Also refer to “Non submersible use” and “Safety Measures.”
Safety measures
- Before use: Check whether mains lead and plug are intact.
- Mains voltage and kind of current have to conform to the information on the type plate.
- The pump may only be connected to a proper earthing-contact type socket through a residual
current device (RCD, 30 mA).
- The connection box should be located in a water-protected area and at least 2 m away from the
edge of the water (see fig. 1).
- Always keep the plug dry.
- Important! If the mains lead or the motor housing are damaged, the pump cannot be used anymore. It
cannot be repaired since the lead is permanently encapsulated in the motor housing.
- Do never hang up or transport the pump by the mains lead.
Start-up (see fig. 1 - 3)
Important! Do not let the pump run „dry“. This could cause damages to the appliance.
- Immerse the pump completely in your pond. This causes the pump body to be filled with water.
- A minimum water depth of 25 cm is required for underwater operation to avoid the pump taking in air.
- The maximum depth for submerged operation of the
2 m pump is 2 m!
- The water temperature may not exceed 35°C.
- The pump must be protected from frost.
- The pump is switched on by putting the plug in the socket.
- To prevent the pump becoming unnecessarily dirty, place it above the sludge deposits in your pond, in a
firm and horizontal position (on a stone slab)!
- A range of accessories may be fitted onto the threaded connections of the pump.
- The supplied screen inserts are sufficient as protection from intake in clear water.
GB - Depending on the field of use, the outlet side can be mounted upwards or siedewards. Carry out step
1 - 3 Dismantling and step 6 - 8 Assembly!
- Suitable fountain jets can be found in our range of accessoires (catalog).
“Non submersible use” (see fig. 2 + 3)
The pump can be used in a nonsubmerged type application.
- Position the pump below the surface of the water, at the side of the pond so that the water can flow into
the pump (not self-priming).
- Remove strainer insert (8) (see fig. 5).
- Connect suction hose (S) and pressure hose (D) to the pump. Connection should be watertight.
- Suction hose and pump must be filled with water before switching-on.
- TIP! To prevent the pump becoming clogged, provide the suction hose with a pre filter
Art.-No. 168 / 009051 covered in our range of accessories.
Overload protection
In case the pump is becoming overheated the built-in thermal overload trip switches it off.
The pump must cool down.
The pump will not start automatically without the necessary controlling when it is cool.
Check the following operating conditions:
- Is there a sufficient water supply?
- Has the filter become clogged?
- Has dirt entered the pump housing (Follow the cleaning instructions below)?
- Have hoses or jets become clogged?
- Has the pump cooled down?
As soon as you have solved the problems, you can switch on the pump again by pulling the plug out of the
socket and putting it in again after a short time (1 min.)
Dismantling (see fig. 4 - 9)
1. Follow the safety measures. Disconnect pump from mains!
2. Grasp the two clips (20 + 21) on the front of the pump, on the lower end, and turn them upward and
forward.
3. Push the two flaps at the front side of the pump inwards. Lift and remove upper shell (1). Now the
screen inserts on the front (8), on the right side (7) and on the left side (5/6) work loose.
4. Remove the entire pump (10) with pump housing (12) from the lower shell (2).
5. Loosen the 4 screws (18).
6. Pull apart pump housing (12) and motor housing (10).
7. Remove rotor assembly (15) from motor housing (10). Take care of the O-ring (16) on the motor
housing (10).
8. Clean all parts with clear water and a soft sponge. Note! In case of massive calcination please use
Messner decalcifier for pumps art.-no. 168 / 009115.
Assembly (see fig. 4 - 9)
1. Push the O-ring (16) onto the starting point on the motor housing (10).
2. Carefully slide the rotor assembly (15) into the motor housing (10) and twist the bearing cover so that
the two holes fit onto the pins on the motor housing (10).
3. Check whether the rotor assembly can be rotated easily.
4. Check the position of the O-ring (16) on the motor housing (10).
5. Put the pump housing (12) on the motor housing (10) and attach it firmly and evenly with the 4
screws (18).
6. Put the pump (10) into the lower shell (2) in the desired position (the out let of the pump housing (12)
directed upwards or sidewards).
7. Attach the upper shell (1) to the rear hook of the lower shell (2) and lock it into the front flaps.
8. Grasp the two clips (20 + 21) on the lower end and turn them to the rear, this locks the upper shell (1)
and the lower shell (2).
9. Insert the respective screen inserts into the openings on top (3 or 4) and on the left (5 or 6) or on the
front (8) and on the right (7).
Maintenance
In order to prolong the service life of your pump significantly and to keep it in sound operating condition, it is
recommended to carry out maintenance and cleanup regularly.
This can be done by everyone, quickly and easily. See „Dismantling/Assembly“
Servicing intervals
- In the beginning check proper performance of your pump every day. If necessary, clean the filters.
- Since servicing intervals (complete cleaning) will vary depending on the level of pond pollution, repeat the
periodic service to your pump in accordance with the pollution of the pond water .
Should you determine that there are damaged or worn parts, replace them. See „Spare parts“
Important! When used in calcareous water, the rotor assembly (15) and the stainless steel can split
tube in the motor housing (10) should be cleaned at regular intervals.

6 7
Pump care in wintertime
Protect your pump from freezing-up!
Take the pump out of your pond in autumn. Clean the pump completely according to the instructions.
During the winter months store the pump in a tank filled with water to prevent the bearings from drying out.
Store the tank in a frostproof room.
Spare parts
To order spare parts, please indicate the pump type, the designation and the Art.-No. from the table below
(see also fig. 9).
ItemDesignation Pump Type Art.-No. Number
1 Upper shell eco-X2 4500 - 20000 104 / 004317 1
eco-X2 plus 10000 - 25000
2 Lower shell eco-X2 4500 - 20000 104 / 004318 1
eco-X2 plus 10000 - 25000
3 Top screen insert eco-X2 4500 - 20000 104 / 003441 1
eco-X2 plus 10000 - 25000
4 Top screen insert eco-X2 4500, eco-X2 7500 104 / 003451 1
1¼˝
Top screen insert eco-X2 10000, eco-X2 13000 104 / 003450 1
1½˝ eco-X2 16000, eco-X2 plus 10000
Top screen insert 2˝ eco-X2 20000, eco-X2 plus 15000 104 / 003449 1
eco-X2 plus 20000, eco-X2 plus 25000
5 Left screen insert eco-X2 4500 - 20000 104 / 003442 1
eco-X2 plus 10000 - 25000
6 Left screen insert eco-X2 4500, eco-X2 7500 104 / 003448 1
1¼˝
Left screen insert eco-X2 10000, eco-X2 13000 104 / 003447 1
1½˝ eco-X2 16000, eco-X2 plus 10000
Left screen insert 2˝ eco-X2 20000, eco-X2 plus 15000 104 / 003446 1
eco-X2 plus 20000, eco-X2 plus 25000
7 Right screen insert eco-X2 4500 - 20000 104 / 003443 1
eco-X2 plus 10000 - 25000
8 Front screen insert eco-X2 4500 - 20000 104 / 003440 1
eco-X2 plus 10000 - 25000
9 Handle eco-X2 4500 - 20000 104 / 003444 1
eco-X2 plus 10000 - 25000
12 Pump housing 1 ¼˝ eco-X2 4500, eco-X2 7500 104 / 003279 1
Pump housing 1½˝ eco-X2 10000, eco-X2 13000 104 / 003280 1
eco-X2 16000
Pump housing eco-X2 plus 10000 104 / 003570 1
1½˝ - Ø 35
Pump housing 2˝ eco-X2 20000, eco-X2 plus 15000 104 / 003409 1
Pump housing 2˝ - Ø 47 eco-X2 plus 20000 104 / 003508 1
Pump housing 2˝ - Ø 109 eco-X2 plus 25000 104 / 004627 1
13 Connection flange eco-X2 20000 104 / 003410 1
C3 2˝ eco-X2 plus 15000, eco-X2 plus 20000
Connection flange eco-X2 plus 25000 104 / 004612 1
C3 Ø 109
14 Rubber lagging C3 eco-X2 4500 - 20000 104 / 003452 3
eco-X2 plus 10000 - 25000
15 Rotor assembly eco-X2 4500 168 / 009156 1
Rotor assembly eco-X2 7500 168 / 009157 1
Rotor assembly eco-X2 10000 168 / 009158 1
Rotor assembly eco-X2 13000 168 / 009159 1
Rotor assembly eco-X2 16000 168 / 009160 1
Rotor assembly eco-X2 20000 168 / 009161 1
Rotor assembly eco-X2 plus 10000 168 / 009162 1
15 Rotor assembly eco-X2 plus 15000 168 / 009163 1
Rotor assembly eco-X2 plus 20000 168 / 009164 1
Rotor assembly eco-X2 plus 25000 168 / 009175 1
16 O-ring 96 x 3 eco-X2 4500 - 20000 112 / 000030 1
eco-X2 plus 10000 - 25000
17 O-ring 105 x 3 eco-X2 20000 112 / 000047 1
eco-X2 plus 15000, eco-X2 plus 20000
O-ring 105 x 2,5 eco-X2 plus 25000 112 / 000069 1
18 Screw M 6 x 16 eco-X2 4500 - 16000 114 / 000048 4
eco-X2 plus 10000
18 Screw M 6 x 20 eco-X2 20000, eco-X2 plus 15000 114 / 000079 4
eco-X2 plus 20000, eco-X2 plus 25000
ItemDesignation Pump Type Art.-No. Number
19 Screw Ø 3,5 x 13 eco-X2 20000 114 / 000078 2
eco-X2 plus 15000 -25000
20 Clip C3 right eco-X2 4500 - 20000 104 / 004270 1
eco-X2 plus 10000 - 25000
21 Clip C3 left eco-X2 4500 - 20000 104 / 004269 1
eco-X2 plus 10000 - 25000
Warranty conditions
This pump is covered for warranty claims for a period of 60 months, beginning on the day of supply. The
date in the proof of purchase document denotes the authoritative day of supply. In case of damage caused
by material or processing faults which arises during the warranty period, we shall repair or replace the item
free of charge. In each case we shall elect whether to repair or replace the item. Damage which is caused
by installation and operating errors, lime deposits, insufficient care, frost, normal wear or improper attempts
to perform repairs are not covered by this warranty.
Spare parts, such as rotors, impellers, lighting accessories etc. are subject to normal wear or have a certain
service life due to their design. They are therefore not covered by the warranty. The warranty will be ren-
dered null and void if any modifications are made to the pump, e.g. cutting off the mains connection cable or
the mains plug.
We shall not be liable for any consequential damages caused by failure of the pump or improper operation.
For all warranty claims please return the device to us together with proof of purchase, carriage paid and at
your own transportation risk.
Waste disposal
waste disposal of electronic devices by the user in private households of the EU
It is not allowed to dispose the product along with the regular waste disposal, instead it has to be collected
separately. It is your responsibility to dispose and recycle the device in a proper place and protect the
environment through this. More information, where to dispose your devices can be obtained at the local
departments.

130 / 004142 · 05/17
Stamp and Signature of Dealer / Date of purchase
_________________________________________________________________________
_________________________________________________________________________
© Meßner GmbH & Co. KG · Gewerbegebiet Echternhagen 7 · D - 32689 Kalletal
