Lincoln SKF A Series Instruction Manual

User and maintenance instructions
Models 85736, 5 US gallons, 85737, 60 lbs, 85738, 120 lbs, 85739, 400 lbs, 85740, 40 lbs
FlowMaster II rotary driven
24 V electric pump, series “A”
Date of issue August 2019
Form number 404517
Version 2

Contents Safety
Read and carefully observe installation
instructions before installing, operating or
troubleshooting assembly. Assembly must
be installed, maintained and repaired
exclusively by persons familiar with
instructions.
Install assembly only after safety
instructions have been read and are
completely understood.
• Adequate personal protection must be
used to prevent splashing of material on
skin or in eyes.
• Always disconnect power source
(electricity, air or hydraulic) from pump
when not in use.
• Equipment generates very high grease
pressure. Extreme caution should be used
when operating equipment as material
leaks from loose or ruptured components
can inject fluid through skin and into body.
If fluid appears to penetrate skin, seek
attention from doctor immediately.
• Do not treat injury as simple cut.Tell
attending doctor exactly what type of
fluid was injected.
• Any other use not in accordance with
instructions will result in loss of claim for
warranty or liability.
• Do not misuse, over-pressurize, modify
parts, use incompatible chemicals, fluids,
or use worn and/or damaged parts.
• Do not exceed stated maximum working
pressure of pump or of lowest rated
component in system.
• Always read and follow fluid
manufacturer’s recommendations
regarding fluid compatibility, and use of
protective clothing and equipment.
• Failure to comply may result in personal
injury and/or damage to equipment.
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Explanation of signal words
for safety . . . . . . . . . . . . . . . . . . . . . . . . . 2
Overview . . . . . . . . . . . . . . . . . . . . . . . . 3
Appropriate use. . . . . . . . . . . . . . . . . . . 3
Pump specifications . . . . . . . . . . . . . . . . 3
Description. . . . . . . . . . . . . . . . . . . . . . . 3
Electric pump performance
specifications. . . . . . . . . . . . . . . . . . . . . . 3
Inspection . . . . . . . . . . . . . . . . . . . . . . . . 3
Damaged pumps . . . . . . . . . . . . . . . . . . 3
Control wiring diagram using
lubrication system controller . . . . . . . . . 4
Pump without controller. . . . . . . . . . . . . 4
Pump dimensions. . . . . . . . . . . . . . . . . . 5
Install pump. . . . . . . . . . . . . . . . . . . . . . 6
Electric FlowMaster II pump. . . . . . . . . . 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . 7
Prime pump . . . . . . . . . . . . . . . . . . . . . . 7
Set pump speed . . . . . . . . . . . . . . . . . . . 7
Crankcase oil service interval . . . . . . . . . 7
Disassembly. . . . . . . . . . . . . . . . . . . . . . 8
Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Crank rod and eccentric . . . . . . . . . . . . . 9
Reciprocating tube . . . . . . . . . . . . . . . . . 10
Crank rod. . . . . . . . . . . . . . . . . . . . . . . . . 10
Assembly . . . . . . . . . . . . . . . . . . . . . . . . 11
Crank rod and eccentric
assembly . . . . . . . . . . . . . . . . . . . . . . . . . 11
Pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Illustrated parts breakdown . . . . . . . . 14
Parts list. . . . . . . . . . . . . . . . . . . . . . . . . 17
Non-common repair parts . . . . . . . . . . . 17
Troubleshooting . . . . . . . . . . . . . . . . . . 18
EC Declaration of Conformity* . . . . . . 19
Warranty . . . . . . . . . . . . . . . . . . . . . . . . 20
NOTE
Emphasizes useful hints and
recommendations as well as
information for efficient and
trouble-free operation.
CAUTION
Indicates a dangerous situation that can
lead to light personal injury or property
damage if precautionary measures are
ignored.
WARNING
Indicates a dangerous situation that
could lead to death or serious injury if
precautionary measures are ignored.
DANGER
Indicates a dangerous situation that will
lead to death or serious injury if
precautionary measures are ignored.
Explanation of signal
words for safety
*Indicates change.
2

Description
Lincoln Industrial rotary 24 V
electric pump uses a 24 V motor and
either a single or two stage planetary gear
drive. Grease output is proportional to pump
revolutions per minute. Pump is primarily
designed for centralized lubrication systems
such as single line parallel, single line
progressive and two line systems.
Pump is driven by rotary motion of
electric motor. Rotary motion is converted to
reciprocating motion through eccentric crank
mechanism. Reciprocating action causes
pump cylinder to move up and down. Unit is
a positive displacement double-acting pump
as grease output occurs during both up and
down stroke. Pump motor employs an
integral speed control capable of reducing
pump speed to 10% maximum value.
During down stroke, pump cylinder is
extended into grease.Through combination
of shovel action and vacuum generated in
pump cylinder chamber, grease is forced into
pump cylinder. Simultaneously, grease is
discharged through outlet of pump. Volume
of grease during intake is twice amount of
grease output during one cycle.
During upstroke, inlet check closes, and
one half of grease taken in during previous
stroke is transferred through outlet check
and discharged to outlet port.Typical output
of pump is shown in Table 2.
All five models 85736 5 U.S. gallons
(18 liter), 85737 60 lb (27 liter) 85738 120 lb
(181 kg), 85739 400 lb (181 kg) and 85740
40 lb (18 kg) are similar, with main
difference being length of housing tube.
Fig. 1, page 4, is an electrical wiring
schematic for pump with controller and
Fig. 2 , page 4, is an electrical wiring
schematic for pump without controller.
Inspection
If overpressurizing of equipment is believed
to have occurred, contact factory authorized
warranty and nearest service center for
inspection of pump.
Specialized equipment and knowledge is
required for repair of pump.
Annual inspection by factory authorized
warranty and nearest service center is
recommended.
Damaged Pumps
Do not use any pump that appears to be
damaged, badly worn or operating
abnormally. Remove pump from service and
contact factory authorized warranty and
nearest service center for repairs.
Listing of authorized warranty and service
centers is available upon request.
Overview
This manual details the procedure that must
be followed while installing, operating,
troubleshooting and repairing FlowMaster II
rotary driven 24 V electric pump.
All required parts, tools, and equipment
needed to complete operation of
FlowMaster II rotary driven 24 V electric
pump are defined and listed within manual.
Review of parts list and nomenclature is
recommended before starting disassembly
or operation.
Appropriate use
All pump models are exclusively designed to
pump and dispense lubricants using electric
power. Specifications for pump are shown in
Table 1. Maximum specification ratings
should not be exceeded.
Any other use not in accordance with
instructions will result in loss of claims for
warranty and liability.
1) Motor controller will shut motor off when outside of voltage limits. Test conducted with Alvania NLGI 2 grade grease at 1 000 psi (68 bar) backpressure.
Table 1
Pump specifications
Operating temperature –40 to 150 °F (–40 to 65 °C)
Operating voltage 1) 24 V (minimum 18, maximum 32 V )
Motor, power 1/3HP (0,25 kW)
Current draw † Table 3
Output/pump cycle 0.07 in3(1,15 cm3)
Pump performance † Table 2
Pump outlets 1/4NPTF internal
Table 2
Electric pump performance specifications
Temperature 50 r/min. 100 r/min.
80 °F (27 °C) 3.5 in3/min. (57 cm3/min.) 7 in3/min. (114 cm3/min.)
40 °F (4 °C) 3.5 in3/min. (57 cm3/min.) 7 in3/min. (114 cm3/min.)
20 °F (–7 °C) 3 in3/min. (49 cm3/min.) 6 in3/min. (98 cm3/min.)
0 °F (–18 °C) 3 in3/min. (49 cm3/min.) 6 in3/min. (98 cm3/min.)
–10 °F (–23 °C) 2.5 in3/min. (40 cm3/min.) 5 in3/min. (81 cm3/min.)
3

A
B
C
D
F
Fig. 2
Pump without controller
Item Description
A24 V
B Fuse
CManual switch
DRed wire
E Motor
FBlack wire
Connect red motor lead to the positive side of the circuit. Motor is polarity sensitive and will not run if improperly wired.
4

5.84 in
(148 mm)
1.25 in
(32 mm)
A
B
6.97 in
(177 mm)
9.13 in
(232 mm)
2.72 in
(69 mm)
3.90 in
(99 mm)
2.25 in
(57 mm)
(4X)
0.28 (
7)
2.25 in
(57 mm)
/ NPTF
(4X) / -20
14
14
Fig. 3
Pump dimensions
Dimensions
Model Dimension “A” Dimension “B”
85736 13.74 in (349 mm) 22.67 in (576 mm)
85737 19.05 in (484 mm) 27.98 in (711 mm)
85738 27.56 in (700 mm) 36.49 in (927 mm)
85739 34.06 in (865 mm) 42.99 in (1 092 mm)
85740 15.76 in (400 mm) 24.69 in (627 mm)
5

Install pump
Pump was tested in lightweight oil left to
protect pump from corrosion. Flush pump
before connecting to system to prevent
contamination of grease with residual oil.
1 Mount pump securely on drum cover so
that it cannot move or vibrate during
operation. Refer to Fig. 4.
2 Connect material supply line to pump
outlet (55).
3 Install safety unloader (77) in open
outlet port.
77
37
55
4 Install high pressure shut-off valve in
material supply line (required).
5 Refer to Fig. 1 and Fig. 2, page 4, to wire
pump motor and vent valve (if used).
6 Fuse motor as recommended in Table 3.
7 Connect power to motor leads.
DANGER
Prior to connecting electrical wiring, perform
lock out/tag out of system.
Failure to comply will result in death or
serious personal injury.
NOTE
If it is necessary to drill mounting holes into
reservoir cover, refer to fig. 3, page 6,
for hole pattern and dimensions.
NOTE
Connect the red motor lead to the positive
side of the circuit. Motor is polarity sensitive
and will not run if not properly connected.
NOTE
Refer to fig. 1, page 4, if system has a
controller. Refer to fig. 2, page 4, if system
does not have a controller.
Fig. 4
Table 3
Electric FlowMaster II pump
24 V 19:1 gear ratio, 2 stage
Backpressure Current 1)
0 psi (0 bar) at 105 r/min. 1.28 A
1 000 psi (68 bar) at 103 r/min. 2.03 A
2 000 psi (137 bar) at 101 r/min. 2.96 A
3 000 psi (206 bar) at 99 r/min. 3.68 A
4 000 psi (275 bar) at 98 r/min. 4.83 A
5 000 psi (344 bar) at 96 r/min. 6.47 A
1) Fuse for 10 A.
6

Operation Crankcase oil service interval
• Check oil level after every 750 hours of
machine operation, or monthly.
• Change oil after every 2 000 hours of
machine operation, or every year.
• Use SAE 10W30 motor oil in all units used
in an ambient temperature of
–40 to 150 °F (–40 to 65 °C).
For ambient temperatures of
–70 to 50 °F (–56 to 10 °C) , use Mobil
Aero HFA low temperature oil.
• Oil level should be at indicating dot on
dipstick (middle of crankshaft).
• Use 10W30 motor oil 15 oz (0,44 l).
Prime pump
1 Remove pump outlet line from
outlet port (55).
2 With pump in full container of
lubricant, energize pump.
3 Purge air from pump.
4 Verify lubricant is flowing evenly
from pump.
5 Stop pump.
6 Attach pump outlet line to outlet
port (55).
Set pump speed
1 Refer to Fig. 5 and remove speed
adjustment hex socket head (3 mm)
cover screw.
2 Adjust screw counter-clockwise to reduce
pump speed.
3 Install speed adjustment hex socket head
(3 mm) cover screw.
DANGER
Do not exceed maximum rated outlet
pressure. Pumps are not equipped with high
pressure shut off valve.
Failure to comply will result in death or
serious personal injury.
NOTE
Never allow pump to run dry of lubricant.
Dry pump quickly speeds up, creating
friction heat that can damage seals.
Monitor supply lubricant level and refill
when necessary.
Failure to comply may result in damage to
equipment.
NOTE
Motor used in 24 V FlowMaster II pump
is equipped with a built in speed control.
Pump speed is factory set to maximum
setting, but easily changed in field.
Speed adjustment screw is located
under cover screw, 120° away from
power cord.
NOTE
Do not reduce pump speed below 20 r/min.
Speed adjustment screw has no stop and has
total of 30 turns.
Refer to Table 2, page 3, for speed
recommendations.
NOTE
Do not change pump settings until after start
up procedure. All pumps are set to run at full
speed.
Failure to comply may result in damage
to pump.
WARNING
Always install relief valve in pump outlet to
ensure pump pressure remains below
5 000 psi (345 bar). Use only high pressure
components.
Failure to comply may result in serious
personal injury.
Fig. 5
7

Disassembly
Pump
1 Place pump into vise.
2 Remove dipstick (31).
3 Drain crankcase oil from crankcase.
4 Remove housing cover screws (33)
(† Fig. 6).
5 Remove housing cover (35) and
gasket (36).
6 Loosen and remove three jam
nuts (74) from electric motor (66)
(† Fig. 6).
7 Remove electric motor (66) mounting
screws (64) with lock washers (65).
8 Remove electric motor (66).
9 Remove motor o-ring (73).
10 Refer to Fig. 7 and remove gear box
mounting screws (71), washers (72) and
gear box (76).
11 Loosen and remove screws (67) holding
first stage gear set (68), spacer (69) and
final stage gear set (70) in place.
12 Remove first stage gear set (68),
spacer (69) and final stage gear set (70)
from gear box.
13 Remove shaft adapter (75).
14 Remove gear box o-ring (38).
15 Loosen screws (44) holding shaft
cover (46) on pump housing (37)
(† Fig. 8).
16 Remove retaining ring (48) from pump
shaft (40).
17 Remove pump shaft (40) by pushing
pump shaft on retaining ring (48) side.
67
68 69 70
73 71
72
76 38
37
75
744
45
46
48
40
52
53
54
55
60
61
63
62
59
58
57
56
24 Remove shovel plug (62) from housing
tube (60).
25 Remove spiral retaining ring (61).
26 Loosen and remove tube housing (60)
(† Fig. 9).
27 Remove bronze bearing (56) from tube
housing (60).
28 Remove o-ring (57) from
tube housing (60).
29 Remove back up washer (58) from tube
housing (60).
30 Remove o-ring (59) from
tube housing (60).
31 Tap on crank rod (7) inside housing (37).
32 Pull eccentric (5) and crank rod (7)out of
top of pump housing (37).
18 Remove outlet pin nut (55) from pump
housing (37).
19 Remove o-ring (54) from groove in out-
let pin nut (55).
20 Remove back up washer (52) from outlet
pin nut (55).
21 Remove o-ring (53) from outlet
pin nut (55).
22 Repeat steps 18 - 21 for remaining
outlet pin nut (55) on opposite side
of pump.
23 Remove retaining ring (63) from housing
tube (60). Refer to Fig. 9.
Fig. 6 Fig. 7
Fig. 8
Fig. 9
NOTE
Slight force may be necessary to remove
eccentric (5) and crank rod (7) from
housing (37).
31
33
34
35
36
37
74
64, 65
66
72
71
8

Crank rod and eccentric
1 Remove pivot screws (11) from
crank rod (7) († Fig. 10).
14 With crank rod in vise and using special
tool (T1) provided in tool kit, remove
plunger link rod (20) († Fig. 12).
15 Place end of plunger link rod (20) into
hole of special tool (T1).
16 Align outlet hole of plunger link rod (20)
with hole in special tool (T1) († Fig. 12).
7
12
11
60
2 Using 5/16–24 bolt, press out wrist pin
bushing (12).
3 Remove crank rod (7).
4 Refer to Fig. 11 and remove wrist pin
anchor (13) from reciprocating tube (25).
5 Pull cup seal (16) out of wrist pin
anchor (13).
6 Remove steel backup ring (17).
7 Place plunger link rod (20) in vise.
8 Loosen plunger link rod (20) and remove
from outlet pin (8).
9 Remove plunger link rod (20).
10 Remove retainer clip (19) from plunger
link rod (20).
11 Remove o-ring (18) from plunger
link rod (20).
12 Remove back up washer (15) from
plunger link rod (20).
13 Remove o-ring (14) from plunger
tube (10).
T1
10
9
8
13
14
15
16
17
18
19
20
21
22
23
24 25
26
27 28
29
30
17 Insert pin included in tool kit (275996)
through tool and into plunger link
rod (20) outlet hole.
18 Turn tool counter clockwise to remove
lower bushing and plunger (24) from
plunger link rod (20).
19 Remove plunger (24).
20 Remove check rod from (22) lower
bushing and plunger (24).
21 Remove ball (23) from lower bushing
and plunger (24).
22 Remove spring (21) from link rod (20).
Fig. 10
Fig. 11
Fig. 12
NOTE
Wrist pin bushings (12) often stick in wrist pin
anchor (13). It may be necessary to use
5/16–24 bolt from kit (276275) to remove
wrist pin bushings (12).
9

Reciprocating tube
1 Loosen check seat housing (30) with
3/8in hex head wrench († Fig. 13).
2 Remove check seat housing (30) from
reciprocating tube (25).
3 Remove ball cage (28), check ball
(29) and o-ring seals (27) from check seat
housing (30).
4 Remove lower bushing (24) from
reciprocating tube (25).
5 Remove lower cup seal (26) from
reciprocating tube (25).
Crank rod
1 Loosen and remove flat head screws (1)
from eccentric (5) († Fig. 14).
2 Remove counterbalance weights (2).
3 Remove outer (3) and inner (4) retaining
ring from both sides of crank rod (7).
4 Place crank rod (7) on supplied
2 1/2in (63,5 mm) diameter steel pipe.
5 Drive crank eccentric (5) out of ball
bearing (6).
6 Drive ball bearing (6) out of crank rod (7).
1
1
2
2
3
3
4
4
5
6
7
10
10
9
8
13
14
15
16
17
18
19
20
21
22
23
24 25
26
27 28
29
30
Fig. 14
Fig. 13
10

Assembly
Crank rod and eccentric
assembly
1 Place crank rod (7) on 2 1/2in (63,5 mm)
diameter steel pipe from kit.
2 Refer to Fig. 15 and install ball bearing
assembly (6) into crank rod (7).
3 Place eccentric (5) in ball bearing (6).
4 Place one end of inner retaining
ring (4) on top of eccentric (5).
5 Squeeze other end of retaining ring (4)
toward center and slide retaining ring (4)
into place.
6 Place one end of outer retaining ring (3)
on top of inner retaining ring (4).
7 Squeeze other end of retaining ring (4)
toward center and slide retaining ring (4)
into place.
8 Align holes of counter-balance
weights (2) with threaded holes of
eccentric (5) and place on eccentric (5).
Pump
1 Install ball (23) into lower bushing and
plunger (24) († Fig. 16).
2 Insert check rod (22) into pump
plunger (23).
3 Place spring (21) onto check rod (22).
4 Thread plunger link rod (20) into pump
plunger (24).
5 Insert lower bushing pump plunger (24)
into tool (T1).
6 Refer to Fig. 17 and align hole in lower
bushing pump plunger (24) with hole in
supplied tool (T1).
7 Insert pin into hole of tool (T1) and into
lower bushing pump plunger (24).
8 Torque lower bushing pump plunger (24)
to torque of 110–125 in.lbf
(12,4–14,1 Nm).
9 Install steel back up ring (17) onto
threads of upper bushing and plunger
end (10).
10 Slide o-ring (18) onto upper
bushing and plunger end (10).
11 Install retaining clip (19) on
upper bushing and plunger end (10).
12 Install o-ring (9) on upper
bushing and plunger end (10).
13 Place outlet pin (8) into vise.
14 Apply Loctite 242 to threads of upper
bushing and plunger end (10).
15 Thread upper bushing and plunger
end (10) into outlet pin (8).
16 Torque to 110–125 in.lbf (12,4–14,1 Nm).
T1
17 Install back-up washer (15) in wrist pin
anchor (13).
18 Place new cup seal (16) inside wrist pin
anchor (13).
19 Clean threads of wrist pin anchor (13).
20 Install o-ring (14) on he wrist pin anchor
(13) (†Fig 16).
21 Insert upper bushing and plunger
end (10) into wrist pin anchor (13)
and tighten.
22 Place wrist pin anchor (13) in vise.
23 Tighten wrist pin anchor (13) to torque of
20–25 ft.lbf (27–34 Nm).
24 With wrist pin anchor (13) still in vise,
align crank rod/eccentric assembly (7)
holes with wrist pin anchor (13) holes
(† Fig. 18).
1
1
2
2
3
3
4
4
5
6
7
10
9
8
13
14
15
16
17
18
19
20
21
22
23
24 25
26
27 28
29
30
Fig. 15
Fig. 17
Fig. 16
11

25 Install wrist pin bushings (12) through
crank rod (7) and into wrist pin
anchor (13) († Fig. 15).
26 Apply Loctite 242 to threads of wrist pin
bushing screws (11).
27 Insert and thread wrist pin bushing
screws (11) into crank rod (7).
28 Torque bushing screws (7) to torque of
110–125 in.lbf (12,4–14,1 Nm).
29 Install cup seal (26) with slotted side
toward center of reciprocating tube (25)
(† Fig. 19).
30 Place new o-ring (27) on lower bushing
and plunger (24).
31 Slide lower bushing and plunger (24)
into reciprocating tube (25) with
o-ring (27) near bottom of reciprocating
tube (25) († Fig. 19).
32 Install steel check cage (28) into
reciprocating tube (25).
33 Install ball (29) into steel check cage (28).
34 Apply Loctite 242 or equivalent to
threads of check seat housing (30).
42 Position crank rod assembly (7) over top
of pump housing (37) and lower into
pump housing (37).
43 Align crank rod (7) with shaft (40)
mounting hole (†Fig. 21).
7
12
11
56
57
58
59
60
35 Thread check seat housing (30) into
reciprocating tube (25) and tighten using
3/8in hex key.
36 Torque to 20–25 ft.lbf (27–33 Nm).
37 Remove crank rod (7) from vise.
38 Refer to Fig. 20 and insert o-ring (59)
into housing tube (60).
39 Place back up washer (58) into housing
tube (60).
40 Insert o-ring (57) into housing tube (60).
41 Insert bronze bearing (56) into
housing tube (60).
25
24
27
26
28
29
30
44 While aligning key (39) on shaft (40) with
eccentric key way (5), slide shaft (40) into
eccentric (5) († Fig. 22).
45 Install retaining ring (48) on shaft. (40).
46 Install shaft cover (46) on pump (37)
(† Fig. 21).
47 Insert and thread screws (44) with
lock washers (45) into shaft cover (46)
and pump housing (37).
39
40
37
7
44
45
46
47
48
5
NOTE
Failure to align key on shaft and key way in
eccentric will result in damage to equipment.
NOTE
For ease of installation of lower cup, use
small piece of tubing to slide lower up into
reciprocating tube and over pump plunger.
Fig. 18
Fig. 19
Fig. 20
Fig. 21
Fig. 22
12

67
68 69 70
38
76
75
37
72
73 71
75 Fill the crankcase with oil up to indicator
dot on dipstick.
31
33
34
35
36
37
74
64
66
60
48 Install shaft adapter (75) inside
pump housing (37).
49 Install gear box o-ring (38) in pump
housing (37) groove († Fig. 23).
50 Position final stage gear set (70)
in gear box (76).
51 Place spacer (69) on top of final stage
gear set (70).
52 Insert final stage gear set (68) into
gear box (76).
53 Install screws (67) through gear
sets (68 and 70) and spacer (69) into
gear box (76).
54 Torque screws (67) to 20–25 in.lbf
(2,3–2,8 Nm).
55 Place the gear box (76) on pump
housing (37).
56 Install four gear box mounting
screws (71) and washers (72) in gear
box (76) and into pump housing (37).
57 Torque gear box mounting screws to
torque of 20–25 ft.lbf (27–33 Nm).
58 Install electric motor o-ring (73) in
groove of gear box (76).
59 Place electric motor (66) on pump
housing (37).
60 Insert electric motor mounting
screws (64) with lock washers (65) into
electric motor (66) and gear box (76).
61 Thread electric motor jam nuts (74) onto
mounting screws (64).
62 While holding mounting screws (64) with
hex head wrench, torque jam nuts (74) to
torque of 100–110 in.lbf (1,3–12,4 Nm)
(†Fig. 25).
63 Refer to Fig. 25 and insert retaining
ring (61) into second groove of
housing tube (60).
64 Install shovel plug (62) into housing
tube (60).
65 Install spiral retaining ring (63).
66 Install new cover gasket (36) on pump
housing (37) († Fig. 24).
67 Install pump cover (35).
68 Install screws (33) with o-rings (34) into
pump cover (35).
69 Torque screws (33) to torque of
10–15 in.lbf (1,1–1,6 Nm).
70 Install o-ring (54) in outlet pin mounting
hole groove of pump housing (37)
(† Fig. 25).
71 Install back up washer (52) inside outlet
pin nut (55).
72 Install the o-ring (53) inside the outlet
pin nut (55).
73 Line up the outlet pin and thread the
outlet pin nuts (55) into the pump
housing (37).
74 Torque to 30–35 ft.lbf (40,7–47,5 Nm).
52
54
37
52
53
55
60
62
61
63
76 Install crank case oil dip stick and torque
to 10–15 in.lbf (1,1–1,7 Nm) († Fig. 24).
NOTE
Refer to Crankcase oil service interval,
page 7 for oil recommendations.
Fig. 23 Fig. 24 Fig. 25
13

1
1
2
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24 25
26
27
28
29
30
Fig. IPB 1
14

31 32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52 53 54
55
56
57
58
59
60
61
62
63
Fig. IPB 2
15

64
65
66
67
68
69
70
71
72
73
74
75
76
Fig. IPB 3
16

Parts list
Item no. Description Part no. Qty, Item no. Description Part no. Qty,
1 Flat head screw (1/4-28 x 1 3/4) 270635 2 40 Pump shaft 277397 1
2 Counter weight 272197 2 41 Retaining ring 272561 1
3 Retaining ring 270609 2 42 Ball bearing 272556 1
4 Retaining ring 270608 2 43 Shaft seal 272554 2) 1
5 Crank eccentric 270666 1 44 Screws 272557 4
6 Ball bearing 270607 1 45 Lock washer 66051 4
7 Crank rod 270665 1 46 Bearing cover 272549 1
8 Outlet pin 270670 1 47 O-ring 272559 2) 1
9 O-ring (nitrile) 34255 1) 2) 1 48 Retaining ring 272563 1
10 Upper bushing and plunger 275000 1) 1 49 Ball bearing 272555 1
11 Pivot screw 275006 2 50 Retaining ring 272562 1
12 Wrist pin bushing 275005 2 51 Drain plug 244752 1
13 Wrist pin anchor 274992 1 52 Backup washer 249837 2) 2
14 O-ring 275015 2) 1 53 O-ring 249838 2) 2
15 Backup washer 274998 1) 2) 1 54 O-ring 270719 2) 2
16 Cup seal (polyurethane) 274999 1) 2) 1 55 Outlet pin nut 270619 2
17 Steel back-up ring 274997 1) 2) 1 56 Bronze bearing 270674 1
18 O-ring 272791 1) 2) 1 57 O-ring (polyurethane) 249839 2) 1
19 Retainer clip 274996 1) 2) 1 58 Backup washer 270652 2) 1
20 Plunger link rod See chart 1 59 O-ring 34431 2) 1
21 Spring 277168 2) 1 60 Housing tube See chart 1
22 Check rod 277167 1 61 Retaining ring 277398 1
23 Ball (3/16 in) 66010 2) 1 62 Shovel plug 270707 1
24 Lower bushing and plunger 275002 1 63 Retaining ring 270705 1
25 Reciprocating tube See chart 1 64 Screw 50051 3
26 Cup Seal (polyurethane) 270625 2) 1 65 Lock washer 272569 3
27 O-ring (nitrile) 275011 2) 2 66 Motor 278661 1
28 Ball cage 272179 1 67 Screw 272552 4
29 Ball (3/16 in) 66001 2) 1 68 First stage gear set 272543 1
30 Check seat 270664 1 69 Spacer 272547 1
31 Dipstick with o-ring 275369 1 70 Final stage gear set 272663 1
32 O-ring 275015 2) 1 71 Screw 272564 4
33 Self-threading screw (#8 x 1/2) 270633 6 72 Lock washer 272566 4
34 Gasket (screw) 252986 2) 6 73 O-ring seal 272544 1
35 Housing cover 275009 1 74 Nut (1/4–20) 51304 3
36 Cover gasket (nitrile) 270630 2) 1 75 Shaft, adapter 272546 1
37 Pump housing 278230 1 76 Gear box housing 272541 1
38 O-ring 272567 2) 1 77 Safety unloader 272722 1
39 Woodruff key 272560 1
1) Included in 275186 upper bushing and plunger kit.
2) Included in 277723 repair kit.
Non-common repair parts
Model 85736 Model 85737 Model 85738 Model 85739 Model 89740
20 Plunger link rod 277381 277382 277383 277384 277975
25 Reciprocating tube 277732 277733 277734 277735 277979
60 Housing tube 277736 277737 277738 277739 277981
17

Troubleshooting
Condition Possible cause Corrective action
Pump does not run. Pump is seized or damaged. Disassemble pump and repair any parts that are
damaged or worn.
Incorrectly wired. Connect red motor lead to positive battery
terminal and black motor lead to negative
terminal.
Pump speeds up or runs erratically. Low level of grease or reservoir is empty. Fill reservoir.
Follower plate is stuck and separated
from grease. Check follower plate and container for damage.
Pump piston or checks are worn. Disassemble pump and repair.
Pump runs, but output is low. Motor speed set to low. Increase motor speed setting.
Faulty inlet check (29, 30), faulty discharge
check (23, 24) or damaged o-ring (27). Replace faulty components.
Seepage from housing cover (35). Cup seal (16) or o-ring (14) worn out. Check seals and replace if necessary.
Pump is noisy. Crankcase needs oil. Fill with oil.
Pump does not build pressure.
Worn wrist pin bushing (12). Check bushings and replace if necessary
Foreign material holding lower check open.
Dismantle and clear check.
Consider adding grease filter to system.
Motor runs, but no pump output. Gear set or adapter shaft stripped or broken. Dismantle and replace damaged part.
18

Product: 24 V Electric FlowMaster pump
Model(s): 85736, 85737, 85738, 85739, 85740
24 V Electric FlowMaster Pump models 85736, 85737, 85738,
85739, 85740
*Indicates change.
EC Declaration of Incorporation*
Manufacturer: SKF
5148 N. Hanley Road
St louis, MO U.S.A.
URL: SKF.com
Phone: [phone]
EU Contact:SKF
Heinrich-Hertz-Straße 2-8
69190 Walldorf
Phone: [phone]
Description: Metering valve
Year of construction: see type identification plate complies with all
basic requirements of the following directives at the time when first
being launched in the market.
Report No.’s: NA
The equipment indicated on this declaration complies with the
following directives:
Machinery Directive 2006/42/EC
And was evaluated using the following harmonized EN standards:
EN ISO 12100:2010, EN ISO 4413:2010, EN809,EN ISO 13732-
1:2008, EN 60204-1:2018, EN 12162, EN 349,
International Standard ISO 20361,
European ROHS directive 2011/65/EU
SKF declares under its sole responsibility that the
are in in conformity with the Machinery Directive 2006/42/EC.
In the case of modifications or alterations of the above mentioned
machine not authorized by the manufacturer, validity of this
ECdeclaration of conformity will cease.The person empowered to
assemble the technical documentation on behalf of the
manufacturer is the head of standardization; see EC-representative‘s
address.
Bob Hoefler
Manager Product Development
Product Engineering LPD North America
Innovation and Product Management
19

skf.com | lincolnindustrial.com
® SKF, Lincoln and FlowMaster are registered trademarks of the SKF Group.
© SKF Group 2019
The contents of this publication are the copyright of the publisher and may not be reproduced (even
extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy
of the information contained in this publication but no liability can be accepted for any loss or damage
whether direct, indirect or consequential arising out of the use of the information contained herein.
August 2019 · Form 404517 Version 2
Warranty
The instructions do not contain any information on the warranty.
This can be found in the General Conditions of Sales, available at:
www.lincolnindustrial.com/technicalservice or
www.skf.com/lubrication.
