Metasys META Air Installation instructions

META SYS
GB Compressors
META Air
Equipment Logbook
Assembly, operation and maintenance
GB

Gerätedokument / equipment LoGbook / Livret d'appareiL / verbaLe d'instaLLazione
Gerätedokument / equipment LoGbook / Livret d'appareiL / verbaLe d'instaLLazione
i
Vom Techniker auszufüllen:
To be filled in by the technician
A remplir par le technicien:
Da compilare dal tecnico:
Dieses Gerätedokument ist ausgestellt für / This equipment logbook has been issued for:
Ce livret d'appareil est emis pour / Questo documento apparecchiatura è rilasciato per:
Zahnarztpraxis - Dental surgery
Cabinet dentaire - Studio odontoiatrico
Praxisinhaber - Practice Owner
Titulaire du cabinet - Titolare dello studio
Adresse - Address
Adresse - Indirizzo
Adresse - Address
Adresse - Indirizzo
Firma - Company
Société - Società
Seriennummer - Serial number
N°série - Nr. di matricola
Datum Montage - Date of installation
Date de l'installation - Data dell'installazione
Datum Inbetriebnahme - Date of first operation
Date de la mise en service - Data della messa in servizio
Die Installation wurde durchgeführt von / The installation has been performed by:
L'installation a été faite par / L'installazione è stata effettuata da:
Seriennummer des METASYS-Geräts / Serial number of the METASYS device:
N° série de l'appareil METASYS / Nr. di matricola dell'apparecchiatura METASYS:
Name / Name / Nom / Nome
Name / Name / Nom / Nome
Name / Name / Nom / Nome
Strasse / Street / Rue / Via
PLZ / Postal Code /Code Postal /CAP Stadt / City / Cité / Città
Strasse / Street / Rue / Via
PLZ / Postal Code /Code Postal /CAP Stadt / City / Cité / Città
Seite / Page / Page / Pagina

Gerätedokument / equipment LoGbook / Livret d'appareiL / verbaLe d'instaLLazione
ii
Seite / Page / Page / Pagina
Vom Techniker auszufüllen:
To be filled in by the technician
A remplir par le technicien:
Da compilare dal tecnico:
Druckbedarfsberechnung dentaler Kompressoren/ Compressed air consumption calculation for dental compressors/
Calcul du besoin en air comprimé pour compresseurs dentaires / Calcolo del fabbisogno di aria compressa dei compressori dentali
Anzahl Dentaleinheiten/Number of dental units/
Nombre d‘units dentaires/ Numero di unità dentali Labor/Laboratory/
Laboratoire/Laboratorio
ja/yes/oui/sì
nein/no/non/no
Luftverbrauch der eingesetzen Geräte und Verbraucher/Compressed air consumption of operated equipment/ Consommation en air de l‘appareillage utilisé/ Consumo d‘aria degli apparecchi utilizzati e delle utenze
Geräte, Verbraucher (zB. Turbine)/
Devices, consumers (e.g. turbine) /
Appareil, consommateur (pex turbine) /
Apparecchi / utenze (ad esempio turbina)
Luftverbrauch/
air consumption/
consommation en air/
Consumo aria
Anzahl geräte/
No. of devices/
Nombre d‘appareils/
Numero apparecchi
Auslastung/min /
capacity utilisation/min /
utilisation /min /
Massimo utilizzo / min
Gleichzeitigkeitsfaktor %
/Simultaneity factor %/
Facteur de simultanéité % /
Fattore di simultaneità %
Luftverbrauch/
air consumption/
consommation en air/
Consumo aria
l/min
x x
%
x
%
=
l/min
l/min
x x
%
x
%
=
l/min
l/min
x x
%
x
%
=
l/min
l/min
x x
%
x
%
=
l/min
l/min
x x
%
x
%
=
l/min
=
Luftverbrauch aller Geräte und Verbraucher/Compressed air consumption of required compressed air/
Consommation en air comprimé pour l‘ensemble des appareils consommateurs/ Consumo d‘aria di tutti gli apparecchi ed utenze
=
V
Verbraucher/consumer
V
consommateur/utenze
l/min
+
Zusätzliche sonstige Verbraucher/Additional consumers/
Consommateurs supplémentaires/ Ulteriori utenze vaire
=
V
sonstige/others
V
d‘autres cons./ Altre utenze
l/min
+
Reserven, Sicherheit/Reserves, Safety/Réserves, sécurité/ Riserve, sicurezza
=
V
Sicherheit/safety
V
sécurité/sicurezza
l/min
=
Min. erforderliche Liefermenge der Kompressoren/min. quantity of required compressed air/
Minimum du débit d‘air nécessaire/ Minima erogazione necessaria dei compressori
=
V
gesamt/total
V
total/totali
l/min
Aufstellungsbedingungen Kompressorenraum/Installation conditions compressor room/
Conditions d‘installation dans la salle des compresseurs/ Condizioni di installazione della sala compressori
Staubgehalt/Dust content/
Teneur en poussières/ Contenuto polveri
Sauberkeit/Cleanliness/
Proprété/Pulizia
Luftfeuchtigkeit/Air humidity/
Humidité de l‘air/ Umidità atmosferica
Temperatur/Temperature/
Température/Temperatura
gering/low/basse/bassa
gering/low/basse/bassa
gering/low/basse/bassa t raum/room C°
t piece/sala
hoch/high/haute/alta
hoch/high/haute/alta
hoch/high/haute/alta
Öffnung Ventilationssystem/Inlet, outlet ventilation system/ Système de ventilation/ Apertura sistema di ventilazione
Zuluft/Supply Air/Arrivée d‘air/Mandata aria Abluft/Exhaust Air/Air vicié/ Aria ripresa
Öffnung/Inlet/Ouverture/Apertura: Ventilation/Ventilazione Öffnung/Inlet/Ouverture/Apertura: Ventilation/Ventilazione
vorhanden/existent/existante /esistente m
2
ja/yes/oui/sì
vorhanden/existent/existante /esistente m
2
ja/yes/oui/sì
nicht vorhanden/nonexistent/inexistante/inesistente
nicht vorhanden/nonexistent/inexistante/inesistente
Optional / optional / optionnel / opzionale:
Sind bereits Kompressoren vorhandem/Are compressors already present?/ Y a-t-il déjà un compresseur?
Esistono già dei compressori?
ja/yes/oui/sì
nein/no/non/no
Bezeichnung/Description/Lequel/Denominazione Hersteller/Manufacturer/
Fabricant/Produttore Typ/Type/Type/Tipo Druck /pressure/
pression/pressione
Liefermenge /Quant. of compr. air/
Débit d‘air / Erogazione
bar l/min
Weiterer Einsatz des best. Kompressors geplant?/ Continued use ofexistent compressor planned?/
Le compresseur existant continuera t-il à être utilisé?/ È in progetto un altro impiego del compressore?
ja/yes/oui/sì
nein/no/non/no
Welche Druckluftqualität ist notwendig? (ISO/DIN 8573) / What quality of compressed air is required? (ISO/DIN 8573)/
Quelle est la qualité d‘air requise? (ISO/DIN 8573) / Quale qualità d‘aria compressa è necessaria? (ISO/DIN 8573)
Luftverbrauch/air consumption/
consommation en air/ Consumo aria
Klasse Druckluftqualität/Classof compressed air purity/ Classe de la qualité d‘air/ Classe di qualità dell‘aria compressa
V
gesamt
/
total/total/totale
Partikel/Particles/Particules/Particella Drucktaupunkt/pressure dew point/Pointde ro
-
sée sous pression/ punto di rugiada in pressione
Restölgehalt/content of residual oil/
Teneur résiduelle en huile/Olio residuo
l/min
≤
o,1 µm
>
≤
+ 7 °C
>
ja/yes/oui/sì
nein/no/non/no
Druckverluste / Loss of pressure / Pertes de dépression / Perdite di pressione
Min. notwendiger Arbeitsdruck/min. required pressure/Pression de travail minimum requise/ Pressione di esercizio
necessaria minima
P
Wmin
bar
Material der Rohrleitung/Material of pipework/ Matière des conduits/
Materiale delle tubazioni
Durchmesser des Rohrleitungsnetzes/Diameter of pipework/ Diamètre des conduits/
Diametro della rete di tubazione
Ø
mm +
Länge des Rohrleitungsnetzes/Length of pipework/ Longueur des conduits/
Lunghezza della rete di tubazioni
L
m
SonstigeVerluste (z.B. Kondensatabscheider)/Other loss of pressure (e.g. condensate separator) /
Pertes diverses (pex. condensateur) / Altre perdite (p.e. separatore di condensa)
P
FV
bar
Erforderlicher Druckder Kompressoren/Required pressure on the compressor/
Pression requise des compresseurs/ Pressione necessaria dei compressori
P
req
bar

Gerätedokument / equipment LoGbook / Livret d'appareiL / verbaLe d'instaLLazione
iii Seite / Page / Page / Pagina
Service und Wartungsarbeiten
Service and maintenance
Service et maintenance
Assistenza e manutenzione
Service- und Wartungsarbeiten sind gemäss der Einbau-, Betriebs- und Wartungsanleitung durchzuführen.
Service and maintenace must be carried out as per the instructions for the installation, operation and maintenance.
Les programmes de service et de maintenance sont à effectuer selon le manuel technique de l‘appareil.
Interventi d‘assistenza e manutenzione devono essere eseguiti secondo il manuale di montaggio, funzionamento e manutenzione.
Zusätzliche Wartungsarbeiten - Other maintenance activities
Travaux de maintenance supplémentaires - Manutenzione aggiuntiva
Datum Service - Date of service
Date de la maintenance - Data dell‘assistenza tecnica
Art. Nr. (z.B. Ersatzteil/Servicekit) - Order no. (e.g. spare part/service kit)
Réf. (p. ex. pièces détachées/kit d‘inspection) - Codice (p.e. ricambio/kit ispezione)
Firma - Company
Société - Società
TT/MM/JJJ
dd/mm/yyyy
JJ/MM/AAAA
gg/mm/aaaa
Zusätzliche Wartungsarbeiten - Other maintenance activities
Travaux de maintenance supplémentaires - Manutenzione aggiuntiva
Datum Service - Date of service
Date de la maintenance - Data dell‘assistenza tecnica
Art. Nr. (z.B. Ersatzteil/Servicekit) - Order no. (e.g. spare part/service kit)
Réf. (p. ex. pièces détachées/kit d‘inspection) - Codice (p.e. ricambio/kit ispezione)
Firma - Company
Société - Società
TT/MM/JJJ
dd/mm/yyyy
JJ/MM/AAAA
gg/mm/aaaa
Zusätzliche Wartungsarbeiten - Other maintenance activities
Travaux de maintenance supplémentaires - Manutenzione aggiuntiva
Datum Service - Date of service
Date de la maintenance - Data dell‘assistenza tecnica
Art. Nr. (z.B. Ersatzteil/Servicekit) - Order no. (e.g. spare part/service kit)
Réf. (p. ex. pièces détachées/kit d‘inspection) - Codice (p.e. ricambio/kit ispezione)
Firma - Company
Société - Società
TT/MM/JJJ
dd/mm/yyyy
JJ/MM/AAAA
gg/mm/aaaa
Zusätzliche Wartungsarbeiten - Other maintenance activities
Travaux de maintenance supplémentaires - Manutenzione aggiuntiva
Datum Service - Date of service
Date de la maintenance - Data dell‘assistenza tecnica
Art. Nr. (z.B. Ersatzteil/Servicekit) - Order no. (e.g. spare part/service kit)
Réf. (p. ex. pièces détachées/kit d‘inspection) - Codice (p.e. ricambio/kit ispezione)
Firma - Company
Société - Società
TT/MM/JJJ
dd/mm/yyyy
JJ/MM/AAAA
gg/mm/aaaa
Zusätzliche Wartungsarbeiten - Other maintenance activities
Travaux de maintenance supplémentaires - Manutenzione aggiuntiva
Datum Service - Date of service
Date de la maintenance - Data dell‘assistenza tecnica
Art. Nr. (z.B. Ersatzteil/Servicekit) - Order no. (e.g. spare part/service kit)
Réf. (p. ex. pièces détachées/kit d‘inspection) - Codice (p.e. ricambio/kit ispezione)
Firma - Company
Société - Società
TT/MM/JJJ
dd/mm/yyyy
JJ/MM/AAAA
gg/mm/aaaa

Gerätedokument / equipment LoGbook / Livret d'appareiL / verbaLe d'instaLLazione
Gerätedokument / equipment LoGbook / Livret d'appareiL / verbaLe d'instaLLazione
iv
Allgemeine Geschäftsbedingungen
Es gelten die allgemeinen Geschäftsbedingungen. Die Garantie umfasst
sämtliche Materialfehler, welche die Funktion des Geräts mehr als nur
geringfügig beeinträchtigen. Von der Garantiepflicht ausgenommen
sind Schäden, die durch falsche oder unsachgemäße Handhabung
sowie normalen Verschleiß entstehen. Defekte Teile werden repariert
oder bei Notwendigkeit durch Neuteile ersetzt. Die Garantie bezieht sich
zudem nicht auf den Austausch des Amalgam-Sammelbehälters sowie
nichtauf leicht zerbrechliche Teile wie Glas, Kunststoff oder Glühlampen.
Vorgeschriebene Wartungsintervalle sind verbindlich einzuhalten.
Der Hersteller behält sich das Recht vor, das Gerätedokument zur
Überprüfung von Wartungsintervallen anzufordern.
Um die Gültigkeit der Garantie festzusetzen, ist nach ordnungsgemäßer
Montage die dem Gerät beigefügte Montagemeldung unverzüglich
an METASYS zu retournieren. In diesem Fall beginnt die Garantiefrist
mit Inbetriebnahme. Bei Einbau ohne Montagemeldung an METASYS
erlischt jeglicher Garantieanspruch. Einbau und Einsendung der
Montagemeldung müssen innerhalb von 24 Monaten erfolgen, und zwar
ab Datum des Verkaufs durch METASYS.
Es sei darauf hingewiesen, dass Garantieansprüche bei Amalgam-
abscheidern und zentralen Saugsystemen nur bei vorgeschriebener
Verwendung des METASYS Absaugdesinfektions- und -reinigungsmit-
tels GREEN&CLEAN M2, sowie beim Wasserentkeimungsgerät WEK bei
ausnahmsloser Verwendung des METASYS Entkeimungspräparates
GREEN&CLEAN WK geltend gemacht werden können. Dasselbe gilt für
das Hygienesystem H1, für welches nur das METASYS GREEN&CLEAN H1
verwendet werden darf. Gesetzliche Gewährleistungsansprüche bleiben
davon unberührt.
Garantieansprüche bei Kompressoren können nur bei Nachweis der
Durchführung des jährlichen Austausch der Filterpatronen sowie, falls
zutreffend, der Durchführung des 3.000 Stunden-Services geltend
gemacht werden.
Terms and conditions
METASYS delivers exclusively on the basis of the present terms and
conditions. The guarantee comprises all material faults that more
than negligibly influence the function of the device. Excluded from
the guarantee are damages that arise through incorrect or improper
handling as well as normal wear. Faulty parts will be repaired or as
necessary replaced by new parts. Furthermore, the guarantee does
not apply to the replacement of the amalgam collection container or to
fragile parts such as glass, plastic or light bulbs. Prescribed maintenance
intervals are obligatory. The manufacturer reserves the right to request
the equipment logbook to validate the maintanence intervals.
In order to determine the validity of the guarantee, the notification
of assembly accompanying the device must be sent to METASYS
immediately after proper assembly has taken place. In this case the
guarantee period begins with commissioning. In case of installation
without notification of assembly to METASYS, any warranty claim is
forfeited. Installation and return of installation proof must be completed
within 24 months after date of sale from METASYS.
We point out that guarantee claims for amalgam separators and central
suction systems can only be asserted if the device has been treated with
the suction system disinfectant METASYS’ GREEN&CLEAN M2 according
to the directions of use. In case of water decontamination system
WEK, the unexceptional use of the water decontamination preparation
METASYS’ GREEN&CLEAN WK is essential for the validity of a guarantee
claim. This regulation does also apply to the hygiene system H1, which
must exclusively be operated with GREEN&CLEAN H1. Implied warranty
remains unaffected of this.
Warranty claims for compressors can only be granted upon presentation
of proof that the yearly exchange of filter cartridges and, if applicable,
the service after 3.000 hours have been performed.
Conditions générales de vente
La garantie s’étend sur toutes les demandes résultant d’un défaut
de fabrication affectant la fonctionnalité de l’appareil. La garantie ne
s’applique pas à des défauts résultant d’une utilisation inappropriée,
aux pièces d’usure, ni aux pièces fragiles(verre, plastique ou ampoules)
ou à l’échange du récipient de collecte. La pièce défectueuse sera
réparée ou remplacée par une neuve. L’intervalle des maintenances
programmées doit être obligatoirement respectée. En cas d’une
demande de garantie, le fabricant se réserve le droit de demander le
livret de l’appareil avec les dates des maintenances effectuées.
La garantie débute à la date d‘installation. Afin d’arrêter la validité de
celle-ci le coupon de garantie dûment complété doit nous être retourné.
La garantie expire si le coupon de garantie n‘a pas été renvoyé chez
METASYS. L‘installation et le retour du coupon de garantie doivent se
faire dans un délai maximum de 24 mois, la date de facture faisant foi.
METASYS ne donnera suite aux demandes de garantie que si le produit
de nettoyage et de désinfection pour l’aspiration GREEN&CLEAN M2
est utilisé comme préconisé pour les récupérateurs d’amalgame et
les aspirations centralisées, le produit GREEN&CLEAN WK pour le
système de décontamination d’eau WEK et le GREEN&CLEAN H1 pour le
système d’hygiène H1. Les obligations légales de garantie ne sont pas
concernées par cette clause.
Toute revendication éventuelle à la garantie est subordonnée au strict
respect de l‘échange annuel des filtres ainsi que, le cas échéant, à la
réalisation de la révision des 3000 heures .
Condizioni generali di vendita
Sono validi le condizioni generali di vendita. La garanzia copre tutti
i difetti materiali che pregiudicano notevolmente il funzionamento
dell‘apparecchio. Sono esclusi dall‘obbligo di garanzia i danni dovuti
ad un uso errato od incorretto e all‘usura normale. Pezzi rotti vengono
riparati o sostituiti con pezzi nuovi se c‘è necessità. Inoltre la garanzia
non copre la sostituzione del barattolo d’amalgama né di pezzi fragili
quali vetro, plastica o lampadine. È necessario osservare i termini di
manutenzione prescritti. Il produttore si riserva il diritto di esigere il
documento accompagnatorio d‘apparecchiatura, per la verifica degli
intervalli di manutenzione.
Perché la validità della garanzia possa essere accertata, dopo il
montaggio conforme è necessario rendere immediatamente a METASYS
l‘avviso l‘installazione consegnato con l‘apparecchio. In questo caso,
la durata di validità della garanzia ha inizio con la messa in servizio. Il
mancato invio dell‘avviso d‘installazione a METASYS dopo l‘installazione
comporta l‘estinzione del diritto di garanzia. Montaggio ed invio
dell‘aviso del montagio eseguito devono avvenire entro 24 mesi dalla
data di vendita da
Dental eCO ServiCe Srl.
SI fa presente che potranno essere fatti valere i diritti alla garanzia
sole se con i separatori d‘amalgama e i sistemi d‘aspirazione viene
utilizzato il prodotto METASYS di disinfezione e pulizia per l‘aspirazione
GREEN&CLEAN M2, così come se, con il sistema di decontaminzione
dell’acqua WEK, verrà utilizzato esclusivamente il preparato METASYS
per la decontaminazione GREEN&CLEAN WK. Lo stesso vale per ilsistema
d’igiene H1, per il quale è permesso l’utilizzo del solo GREEN&CLEAN H1.
Di questo rimangono intangibili i legali diritti di garanzia di assenza di
vizi del prodotto consegnato.
Si possono far valere diritti di garanzia solo in caso di dimostrazione di
manutenzioni annuali avvenute per il ricambio dei filtri e, se applicabile,
l‘effettuazione della manutenzione delle „3000 ore“.
D GB
IF
Seite / Page / Page / Pagina

GB
2Page GB Practice personnel / technicians
Index
Key to symbols
2. Key to symbols
Warning that to ignore the following instructions
could lead to personal injury, disrupt operation or
damage the apparatus!
means that particular attention is drawn to an
important situation for the operating personnel or the
technician.
Page
1. Index 2
2. Key to symbols 2
3. General Information 3
4. Use 4
5. Scope of delivery 4
6. Explanation of the type plate 4
7. Technical data 5
8. Description of function of the compressor 8
9. Description of function of the membrane dryer 8
10. Storage and transportation conditions 9
11. Installation guidelines 9
12. Instrument unit 10
13. Electrical connections 10
14. Preparations before first use 11
15. Commissioning and usage 12
16. Wiring diagrams 14
17. Service and maintenance 17
18. Decommissioning and disposal 19
19. Troubleshooting 20
1. Index
The footnote found on each page defines the user group
particular information is aimed at.

GB
3
GB
Practice staff / technicians Page
GB
Practice personnel / Technicians
General information
3. General information
The safety, reliability and performance of the
equipment is only guaranteed by METASYS if the
following instructions are observed:
qAssembly, alterations or repairs may exclusively be carried
out by authorized service personnel in compliance with
EN Standard 60601-1 (International Standard for Medical
Electrical Apparatus, in particular Part 1: General Rules for
Safety).
qThe electrical installation must comply with the regulations
of the IEC (International Commission for Electrical
Engineering).
qThe appliance must exclusively be used in conformity with
the instructions for installation, operation and maintenance.
qOnly original parts may be used for repairs or replacements.
Following the commissioning of the apparatus, the
Installation Proof must be completed and returned to
METASYS in order to establish the guarantee period.
qEvery service and inspection must be recorded in the
Equipment Logbook.
qWhen requested by an authorized engineer, METASYS
agrees to make all documents available for the use of
technically qualified service personnel.
qMETASYS accepts no responsibility for damages caused due
to external factors, such as wrong installation, improper use
of the apparatus or unauthorized technical intervention.
qWhen the whole compressor is dismantled at the end of its
service life, it must be disposed of properly.

1
2
Un = 230V, 50 Hz
P = 2,2 kW
V tank = 50 l
5120
DL-
METASYS Medizintechnik GmbH
00000
A-6063 Rum bei Innsbruck, Florianistr. 3
META Air 250 mit Abdeckung
Made in EU
P max = 7 bar
3
3.1
3.2
3.3
3.4
3.5
3.6
GB
4Page GB Practice personnel / technicians
Use, scope of delivery
Explanation of the type plate
4. Use:
METASYS META Air compressors produce oil-free, dry, filtered
compressed air required for the operation of dental units or similar
applications.
The compressors are designed for operation in dry
ventilated rooms and may therefore not be operated in a
damp or wet environment.
Use of the compressors in the vicinity of gases or
inflammable liquids is also prohibited.
5. Scope of delivery:
All METASYS META Air compressors are shipped in a single
package consisting of a pallet plus carton. A booklet containing
the installation proof, equipment logbook and manual for
installation, operation and maintenance is included in each
shipment.
6. Explanation of the type plate:
3see illustration
The type plate is located on the fitting panel.
3.1 Equipment type
3.2 Mains supply data
3.3 Serial number
3.4 Address of the manufacturer
3.5 CE marking
3.6 Protection Class I

1
1
1
1
GB
5
GB
Practice staff / technicians Page
GB
Practice personnel / technicians
Technical data
META Air 70 / 150 /250 / 450
7. Technical data
META Air 70
Tank capacity 30 l
Electric motor power 0,75 kW
Delivery rate 78 l/min
Dimensions (H x W x D) 40 x 64 x 72 cm
Power supply 230 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 69 dB(A)
META Air 150
Tank capacity 30 l
Electric motor power 1,5 kW
Delivery rate 152 l/min
Dimensions (H x W x D) 40 x 64 x 72 cm
Power supply 230 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 69 dB(A)
META Air 250
Tank capacity 50 l
Electric motor power 2,2 kW
Delivery rate 225 l/min
Dimensions (H x W x D) 52 x 68 x 96 cm
Power supply 230 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 69 dB(A)
META Air 450
Tank capacity 100 l
Electric motor power 4,4 kW
Delivery rate 450 l/min
Dimensions (H x W x D) 65 x 102 x 79 cm
Power supply 400 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 73 dB(A)

1
2
3
4
GB
Technical data
META Air 70 Light / 150 Light /
250 Light / 450 Light
META Air 70 Light
Tank capacity 30 l
Electric motor power 0,75 kW
Delivery rate 85 l/min
Dimensions (H x W x D) 39 x 57 x 72 cm
Power supply 230 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 69 dB(A)
META Air 150 Light
Tank capacity 30 l
Electric motor power 1,5 kW
Delivery rate 170 l/min
Dimensions (H x W x D) 39 x 57 x 66 cm
Power supply 230 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 69 dB(A)
META Air 250 Light
Tank capacity 50 l
Electric motor power 2,2 kW
Delivery rate 250 l/min
Dimensions (H x W x D) 52 x 52 x 96 cm
Power supply 230 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 69 dB(A)
META Air 450 Light
Tank capacity 100 l
Electric motor power 4,4 kW
Delivery rate 500 l/min
Dimensions (H x W x D) 55 x 102 x 72 cm
Power supply 400 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 73 dB(A)
6Page GB Practice personnel / technicians

1
1
GB
Technical data
META Air 650 / 650 Light
META Air 650
Tank capacity 200 l
Electric motor power 6,6 kW
Delivery rate 660 l/min
Dimensions (H x W x D) 85 x 140 x 92 cm
Power supply 400 V
Frequency 50 Hz
Pressure range 5-7 bar
Sound level 73 dB(A)
META Air 650 Light
Tank capacity 200 l
Electric motor power 6,6 kW
Delivery rate 750 l/min
Dimensions (H x W x D) 60 x 140 x 92 cm
Power supply 400 V
Frequency 50 hz
Pressure range 5 -7 bar
Sound level 73 dB(A)
100% operating time:
An operating time of 100% is possible at the specified delivery
rate.
7
GB
Practice staff / technicians Page
GB
Practice personnel / technicians

1
2
GB
8Page GB Practice personnel / technicians
Description of function
8. Description of function of the compressor 1
Compressors without a membrane dryer (Light models):
The compressor power unit sucks in air from the outside through
the air intake filter (1). The air is compressed in an oil-free
compression chamber (2), then passes through a delivery hose (3)
and is forced through the non-return valve (4) into the pressure
tank (5). The air flow is regulated by a valve plate that allows air
flow in one direction only.
Compressors with a membrane dryer:
The compressor power unit sucks in air through the air intake
filter (1). The air is compressed in an oil-free compression chamber
(2), then is forced through the cooler (6) which cools down the
compressed air and thus forms condensate water.
The condensate is trapped by a 5 mµ filter (7) located below the
cooler. A second 0,01 mµ filter (8) blocks further water droplets
to ensure high quality, clean air. This double filtration system
has a semi-automatic drain system that empties the small filters
receivers everytime pressure is discharged.
The clean compressed air then passes through the membrane
dryer (9) where residual humidity is removed and the compressed
air reaches an average dew point value of -35°C (at 7 bar). Dry,
compressed air is delivered to the air receiver through a hose that
connects the dryer to the non-return valve (5).
The entire system is controlled by the pressure switch (10)
that regulates the ON/OFF mode of the unit. Every time the
compressors reaches the cut out pressure, it switches off and
residual compressed air in the delivery pipe system is vented out
by a solenoid valve (for compressors without air dryer) or by the
membrane dryer (9) - for compressors with air dryer.
9. Description of the function of the membrane dryer 2
Filtered air enters the membrane dryer and water droplets are
collected on the membrane fibres. While the dried air is delivered
to the receiver, a small amount of this dried air is purged back
through the membrane to sweep away the water droplets around
the fibers. The moisture is then delivered to the outside through
the rinsing nozzles of the membrane dryer. Since this purge
cycle is continuous, the membrane dryer can operate without
interruptions or efficiency reduction.
Membrane dryers do not require any maintenance because there is
no water adsorption or adsorbing material.
Periodical maintenance needs to be performed on the double
filtration system (0,5 µm, 0,01 µm) before the membrane dryer.
Filters cartridges must be replaced once a year. Maintenance kits
are available at METASYS.

1
2
GB
9
GB
Practice staff / technicians Page
GB
Practice personnel / technicians
Storage and transportation conditions
Installation guidelines
10. Storage and transportation conditions:
The compressor is dispatched by the manufacturer in a carton
on a non-returnable pallet to protect the appliance from damage
during transportation. Wherever possible, the original packaging
should always be used for transportation. Therefore it is advised
to keep the original packaging.
During transportation the compressor must be protected
from moisture, dirt and extreme temperatures. The packaged
compressors must be stored in a dry place to protect it from
humidity (max. relative air humidity: 70%). Storage temperature
must be between -10°C and +40°C.
The compressor may only be transported unpressurised.
Before it is transported, it is essential that the com-
pressed air from the pressure tank and pressure hoses
is released and any condensate water is drained off.
11. Installation guidelines:
Unpack the compressor and check carefully to ensure that it is in
perfect condition. Assemble the support legs as supplied (see
illustration 1).
The compressor may only be installed and operated in a dry,
well-ventilated and low-dust location. If there is insufficient air
flow, a suction device or ventilator of the correct dimensions
must be installed. The ambient temperature must be between
+5°C and +40°C.
The motor fan ensures that the power unit is force-cooled
effectively. However, for this to happen, the air must be able to
flow in and out without obstructions. If this is not the case, a
separate ventilation system must be installed (see illustration
2).
The compressor must be installed in such a way that it is easily
accessible for operation and maintenance. The compressor must
be placed on a level floor which is sufficiently robust.
The compressor must not touch any other objects due to heat
development.
It is not necessary to provide a special foundation or base.
The compressor may simply be placed on a level floor. If the
compressor is fitted in a mounting bracket, then the mounting
bracket should not be secured to the ground. It is recommended
to attach four vibration dampers.

1
2
3
3.1
2.1
2.2
2.3
2.5
2.4
2.6
GB
10 Page GB Practice personnel / technicians
Instrument unit
Electrical connections
12. Instrument unit:
2See picture
The compressor is fitted with an instrument unit as standard:
This consists of:
qpressure switch 2.1
qpressure reducer / pressure reducer with condensate separator
(Light models only) 2.2
qsafety valve 2.3
qcompressed air supply 2.4
qmanometer 2.5
qcondensate separator (Light models only) 2.6
The flexible delivery hose must be pushed onto a pipe connection
and secured against slippage using hose clips.
The flexible delivery hose connecting the permanently
installed compressed air pipe and the compressor
prevents the transfer of vibrations and noise.
13. Electrical connections
Connections to the mains supply may only be made by a qualified
electrician. It must be ensured that the electrical wiring and the
mains voltage conform with the data indicated on the type plate. A
tolerance of +/- 5% is permissible.
Earthing must always be used for safety purposes.
3See picture
The compressors must be connected to a socket which is protected
by a suitable magnetothermal switch. The socket must be easily
accessible so that the appliance can be unplugged easily from the
mains supply in the event of danger. When a compressor which is
operated by three-phase alternating current is switched on for the
first time, it is necessary to ensure that the direction of rotation of
the ventilation rotor is correct (see arrow on housing 3.1 ).
If any electrical wires or air hoses are damaged, they
must be immediately replaced! The electrical wiring may
not touch the surfaces of the apparatus since the outer
surfaces of the compressor become hot during operation
and may thereby damage the cable insulation!

3
4
GB
11
GB
Practice staff / technicians Page
GB
Practice personnel / technicians
Preparations before first use
14. Preparations before first use
Before using the compressor for the first time, it must be ensured
that all the fastenings securing the compressor for transportation
have been removed. Ensure that the compressed air lines are
connected correctly. The compressor must be connected to the
mains supply in the proper manner. Switch on the compressor at
the pressure switch by rotating the switch to position “1”.
Safety valve
The safety valve is set at 10 bar, checked and stamped
before leaving the factory. When the compressor is
operated for the first time, the safety valve must be
checked.
The safety valve may not be used to vent the pressure
tank, as this may impair the function of the safety valve.
Adjusting the pressure switch
3See picture
The pressure switch is factory-set. The power unit switches itself
on when the tank pressure reaches 5 bar and switches itself off
when it reaches 7 bar. If necessary, the working pressure of the
compressor may be altered at the pressure switch.
These tasks may only be carried out by authorised
technicians. During this work the protective cover of the
pressure switch must be removed.
The adjustment can only be carried out while the unit is
live.
If problems develop with the cut-in and cut-out pressure, refer to
the following:
Screws A: Minimum pressure adjustment (cut-in) – both of them
have to be regulated at the same level. Note that to regulate
Max pressure, it is enough to regulate screws A (min. pressure)
because the differential pressure is fixed.
Screw B: Differential min-max pressure adjustment (cut-out) –
actually regulated at 2 bar.
The cut-in pressure is set by even adjustment of the two screws A.
Turn clockwise to increase the switch-on and anticlockwise to
reduce it.
The cut-out pressure is set by means of differential screw B (cut-
in pressure+differential=cut-out pressure). Turn clockwise to
increase the differential.

1
GB
12 Page GB Practice personnel / technicians
Preparations before first use
Commissioning and usage
14. Preparations before first use
Draining off condensate water
During transportation, condensate may form inside the air tank
because of temperature fluctuation. Each time a compressor is
installed, the condensation water must first be drained off – even
in compressors with a membrane dryer.
Procedure:
qCheck for condensate in the air receiver.
qSwitch off the compressor and reduce pressure to 1 bar
qPlace a collection container under the air receiver
qOpen the drain valve until there is no more condensate inside
the air receiver.
qClose the drain valve again.
Installation of the manometer
The manometers must be installed as shown in picture 1and
2on page 10 and checked for leakage.
15. Commissioning and usage:
Automatic start-up: If the pressure in the air receiver
drops, the compressor will switch on automatically until
the maximum operational pressure of 7 bar is reached
again.
If the maximum operational pressure of 7 bar is
exceeded, the compressor power unit must be switched
off and disconnected from the mains (remove the power
plug.) Inform an authorised technician.
In the event of danger, disconnect the compressor from
the mains (remove the power plug).
The compressor has hot surfaces and may cause burns
upon contact.

2
GB
13
GB
Practice staff / technicians Page
GB
Practice personnel / technicians
Commissioning and usage
15. Commissioning and usage:
See illustration 2
Plug in the power cable and connect the air hose (1). Turn the
pressure switch (2) to position “1”. The compressor operates fully
automatic and is controlled by the pressure switch which stops
when pressure in the tank (3) reaches the cut out pressure (7 bar),
allowing compressor to start again when it reaches the cut in
pressure (5 bar).
When air receiver is under pressure, the operating pressure can be
adjusted through the pressure regulator (2): Rotate the regulating
screw in a clockwise direction to increase pressure, and in a
counterclockwise direction to reduce it. The current pressure can
be read on the pressure gauge (4). When air pressure required is
reached, push the regulating screw downwards in order to block it.
3
META Air Light models
META Air
models
2
1
4

1 2
3 4
META Air
META Air
Light META Air
Light
META Air
META Air
META Air
META Air
Light META Air
Light
GB
14 Page GB Practice personnel / technicians
Wiring diagrams
16. Wiring diagrams
*
*
*
*
* META Air Light versions only

5 6
7
META Air
Light META Air META Air
META Air
Light
META Air
Light META Air
GB
15
GB
Practice staff / technicians Page
GB
Practice personnel / technicians
Wiring diagrams
Legend:
F fuse
P pressure switch
M1 - M2 compressor motor 1-3
W1 - W3 ventilator 1-3
EV pressure relief valve
H hour meter
KS1 - KS3 motor contactor 1
t1 - t2 timing relay 1-2
1META Air 70 / 70 Light
2META Air 70 / 70 Light with cover
3META Air 150 / 150 Light / META Air 250 / 250 Light
4META Air 150 / 150 Light / META Air 250 / 250 Light
with cover
5META Air 150 / 150 Light / META Air 250 / 250 Light
3-phase
6META Air 150 / 150 Light / META Air 250 / 250 Light
3-phase with cover
7META Air 450 / 450 Light 3-phase
16. Wiring diagrams
*
*
*
* META Air Light versions only

9
8
META Air
META Air
META Air Light
Version with
cover
GB
16 Page GB Practice personnel / technicians
Wiring diagrams
8META Air 450 / 450 Light with cover
9META Air 650 / 650 Light
16. Wiring diagrams
*
*
* META Air Light versions only
