METROLOGIC INSTRUMENTS, INC.
MS2x20 Stratos®Series
Configuration Addendum
Mettler Toledo Diva Scale

Copyright
© 2008 by Metrologic Instruments, Inc. All rights reserved. No part of this
work may be reproduced, transmitted, or stored in any form or by any means
without prior written consent, except by reviewer, who may quote brief
passages in a review, or provided for in the Copyright Act of 1976.
Trademarks
Metrologic is a registered trademark of Metrologic Instruments, Inc.
Products identified in this document are hereby acknowledged as
trademarks, registered or otherwise, of Metrologic Instruments, Inc. or their
respective companies.

ii
TABLE OF CONTENTS
IMPORTANT NOTES -BEFORE YOU START ................................................................. 1
Important Bar Codes
Scale Save Data Bar Code .................................................................... 2
Scale Type Bar Code ............................................................................. 2
SCALE/LOAD CELL CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Unit Configuration (Pounds)................................................................... 3
Unit Configuration (Kilograms) ............................................................... 4
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Pole Display Configuration..................................................................... 5
Scale Settling Filter Configuration .......................................................... 7
Scale Internal Beeper............................................................................. 9
Zero Cursor.......................................................................................... 10
Quantitative Separator ......................................................................... 11
Dual Cable Scale Configuration Bar Codes
Scale Protocols .................................................................................... 12
Scale COM Port Settings (Baud Rate) ................................................. 18
Scale COM Port Settings (Data Bits & Parity)...................................... 20
Single Cable Scale Configuration Bar Codes
Set Scale for Single Cable Communication ......................................... 23
SCANNER CONFIGURATION BAR CODES
Dual Cable Scanner Configuration Bar Codes
Dual Cable Scanner Mode ................................................................... 24
Dual Cable Scanner OPOS Mode........................................................ 24
Various Dual Cable Scanner Mode ...................................................... 25
IBM 3rd Generation 46xx ...................................................................... 26
IBM OEM Full Speed USB ................................................................... 26

iii
TABLE OF CONTENTS
Single Cable Scanner Protocols for P.O.S. Compatibility
MSS Global.......................................................................................... 27
ISS45 ................................................................................................... 28
OPOS................................................................................................... 29
Retailix / NCR....................................................................................... 30
Retailix / OPOS .................................................................................... 31
IT Retail................................................................................................ 32
IBM Self Checkout System .................................................................. 33
Various RS232 Single Cable Codes .................................................... 34
IBM 3rd Generation 46xx ...................................................................... 35
IBM OEM Full Speed USB ................................................................... 36
Additional POS Data Formatting
Full Speed USB Table Top/Handheld .................................................. 37
Special Function ACK .......................................................................... 39
Prefix/Suffix.......................................................................................... 40
3x-30 Acknowledge Responses ........................................................... 41
Special Function Command Responses .............................................. 42
BCC in POS Communications ............................................................. 46
3 Scale Status Bytes ............................................................................ 47
Scale Options....................................................................................... 48
Remote Display.................................................................................... 49
StratosSTATS ...................................................................................... 50
Additional POS Related Functions
Scanner Beep on Weight Sent............................................................. 53
Restrict In-Store Codes........................................................................ 54
Scale Shadow Mode ............................................................................ 55
Scanner Razz on Not-On-File .............................................................. 56
Additional Scanner Configuration Bar Codes
Horizontal Depth of Field...................................................................... 57
Vertical Depth of Field.......................................................................... 59

iv
TABLE OF CONTENTS
Auxiliary Port
StratosSCHOOL™............................................................................... 61
Quick Start for a Secondary Metrologic Scanner ................................. 62
EAS Bar Codes
EAS Device Types ............................................................................... 64
EAS Timeout ........................................................................................ 67
EAS Connection................................................................................... 72
Continuous Mode ................................................................................. 75
EAS Deactivation ................................................................................. 76
Sensormatic ScanMax Pro................................................................... 79
SCANNER TEST BAR CODES
Supplemental Tests..................................................................................... 81
Display Software Numbers................................................................... 81
CONTACT INFORMATION AND OFFICE LOCATIONS ..................................................... 82

1
IMPORTANT NOTES -BEFORE YOU START
It is important to read carefully the notes marked with a symbol on the pages
contained in this manual. Not all configuration codes are designed to be used for
both a single and dual cable scanner/scale system. Many of the configuration
bar codes require additional steps before the unit can be configured and placed
into service. Most of the bar codes in this addendum were designed to be used
with a Stratos model that includes a scale. The text marked with a symbol will
provide important additional information about the restrictions and uses of the bar
codes shown.
All of the bar codes in this manual require:
•The scanner/scale to have a firmware number of 15367 or higher
•All configuration bar codes must be scanned with the vertical window
The Unit Configuration bar codes (located on pages 3 and 4 of this
addendum guide) require the scale security seal to be broken.
If the scale security seal is broken, it must be sealed and certified by local
Weights and Measures authorities after the scale calibration process has been
completed. The scanner/scale cannot be placed in service until it is sealed and
certified by the proper authorities.
For further details on calibration procedures for Weights and Measures
certification, refer to the Scale Operation: Calibration section of the Stratos
Installation and User’s Guide.
The certification of the weighing mechanism of the scale version of
this scanner is subject to federal, state and local Weights and
Measures statutes and regulations and can only be performed by
authorized government agencies and/or their duly registered
agents. Each time the scale or weighing mechanism is calibrated,
it should be properly sealed with a paper seal or a wire seal prior to
being placed into service in commerce.
It is the responsibility of the owner of the scale to confirm
compliance with the relevant Weights and Measures statutes and
regulations applicable in your area by checking with the appropriate
government agency before placing a newly calibrated unit into
service or removing any official seals.

2
IMPORTANT NOTES -BEFORE YOU START
Important Bar Codes
Scale Save Data Bar Code.
The Scale Save Data bar code must be scanned last to “save” the changes in the
scale’s memory. The scale will then reset and begin normal operation. This is
required only for scale configuration items – not for calibration.
Scale Save Data
³996045
Scale Type Bar Code.
The Stratos scanner should have been already programmed to recognize the
type K Diva scale. If, for any reason, the scanner’s non-volatile memory is lost,
the following bar code must be scanned to reprogram the scanner for the
type K Diva scale.
Type K Diva Scale
³446510

3
SCALE/LOAD CELL CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Unit Configuration (Pounds)
For Kilogram weight units see page 4.
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 must be in scale service mode to use these
bar codes.
Pounds Calibration
³996042
Set the scale measuring range from
0.00 to 30.00 pounds.

4
SCALE/LOAD CELL CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Unit Configuration (Kilograms)
For Pound weight units see page 3.
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 must be in scale service mode to use these
bar codes.
Kilograms Calibration
³996044
Set the scale measuring range from
0.000 to 15.000 kilograms.

5
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Pole Display Configuration
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale Display
Single-Line Weight Only
³996003
Set the scale to use a single-line weight only
display to show all scale activity.
The single-line display must be plugged into
the Scale to Display connector on the
MS2xx0 (see Figure 1).
Figure 1. Location of Scale to Display Connector
Scale Display
4-line Price Computing
³996009
Set the scale to use a 4-line price computing
display to show all scale activity.
The 4-line display must be plugged into the
Scale to Display connector on the MS2xx0
(see Figure 1).

6
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Pole Display Configuration
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale Has No Display
³996004
Set the scale to not require a remote
display. All weights are expected on a POS
terminal display.
A remote display can not be plugged into
the Scale to Display connector on the
MS2xx0 (see Figure 1).

7
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Scale Settling Filter Configuration
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
The scale’s filter setting allows the unit to withstand a certain amount of vibration
from the checkout counter. A stronger filter allows for more vibration to be
absorbed but the weight may take a little longer to settle. Scales are normally
shipped with a loose filter.
* Scale = Loose Filter
³996005
Loose filter setting for low vibration
environments.
* Factory Default Setting

8
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Scale Settling Filter Configuration
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale = Medium Filter
³996006
Medium filter setting for moderate vibration
environments.
Scale = Strong Filter
³996007
Strong filter setting for high vibration
environments.

9
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Scale Internal Beeper
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale Beep On
³996090
Enable the internal scale beeper to beep
when remote display keys are depressed.
*Scale Beep Off
³996091
Turn off the internal beeper inside the scale.
This is the desired default as the scanner
beeper is the main tone generator.
* Factory Default Setting

10
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Zero Cursor
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Zero Cursor Off
³996092
Turn off the zero cursor that appears on the
display when the scale is in the zero weight
area.
*Zero Cursor On
³996093
Enable the zero cursor to appear on the
display when the weight is within the zero
weight area.
* Factory Default Setting

11
SCALE CONFIGURATION BAR CODES
Single or Dual Cable Scale Configuration Bar Codes
Quantitative Separator
The following bar codes can be used to configure a Single or
Dual Cable MS2xx0.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Decimal Pt Separator
³996094
Use a decimal point to separate the units
from fraction values on the remote display.
Comma Separator
³996095
Use a comma to separate the units from
fraction values on the remote display.

12
SCALE CONFIGURATION BAR CODES
Dual Cable Scale Configuration Bar Codes
Scale Protocols
The following bar codes will change scale parameters intended for a
Dual Cable environment. To place the scanner in Dual Cable mode,
please refer to page 24.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale = EPOS Protocol
³996013
Set the scale RS232 protocol to
Serial EPOS.
Communication Port Settings:
•2400 Baud
•7 Data Bits
•1 Stop Bit
•Even Parity
Scale = EPOS2 Protocol
³996014
Set the scale RS232 protocol to
Modified Serial EPOS.
This Protocol does not require the POS
terminal to send the weight back to the scale
for validation.
Communication Port Settings:
•2400 Baud
•7 Data Bits
•1 Stop Bit
•Even Parity

13
SCALE CONFIGURATION BAR CODES
Dual Cable Scale Configuration Bar Codes
Scale Protocols
The following bar codes will change scale parameters intended for a
Dual Cable environment. To place the scanner in Dual Cable mode,
please refer to page 24.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale = 8217 Protocol
³996050
Set the scale RS232 protocol to 8217.
Communication Port Settings:
•9600 Baud
•7 Data Bits
•1 Stop Bit
•Even Parity
Scale = 8213 Protocol
³996051
Set the scale RS232 protocol to 8213.
Communication Port Settings:
•9600 Baud
•7 Data Bits
•1 Stop Bit
•Even Parity

14
SCALE CONFIGURATION BAR CODES
Dual Cable Scale Configuration Bar Codes
Scale Protocols
The following bar codes will change scale parameters intended for a
Dual Cable environment. To place the scanner in Dual Cable mode,
please refer to page 24.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale = ICL Protocol
³996049
Set the scale RS232 protocol to Serial ICL.
Communication Port Settings:
•2400 Baud
•7 Data Bits
•1 Stop Bit
•Even Parity
Scale = EMEA
Special Configuration
³996041
Set the scale to EPOS protocol, kilograms,
with a remote display, loose filter, no price
computing, and scroll weight.
Communication Port Settings:
•2400 Baud
•7 Data Bits
•1 Stop Bit
•Even Parity

15
SCALE CONFIGURATION BAR CODES
Dual Cable Scale Configuration Bar Codes
Scale Protocols
The following bar codes will change scale parameters intended for a
Dual Cable environment. To place the scanner in Dual Cable mode,
please refer to page 24.
If the MS2xx0 is currently in a Dual Cable configuration, temporarily
disconnect the Scale to Host cable prior to configuring the scale.
The MS2xx0 does not need to be in scale service mode.
The Scale Save Data bar code must be scanned last to save the
changed configuration (see page 2).
Scale = NCI Protocol
³996016
Reserved for Future NCI Protocol Variation
Scale = NCI-ECR Protocol
³996015
Set the scale RS232 protocol to NCI-ECR.
Communication Port Settings:
•9600 Baud
•8 Data Bits
•1 Stop Bit
•No Parity
