MS7580
Genesis™

Product Overview
Metrologic’s MS7580 Genesis™, the world’s first presentation area imager
engineered to decode all standard 1D, 2D barcodes and OCR text,
supports advanced applications with revolutionary imaging technology in
an elegant, yet durable design.

Unique Value of Genesis
Innovative
Reliable
Design
Multiple Interfaces
Total Freedom
Image Capture
CodeSelect
200 cm/sec motion
4.0 mil 1D bar codes
9.8 mil Datamatrix
Reads mobile phones
All 1D, PDF & 2D
OCR (optional)
Value-Added
Solutions
Min LED Flashing
Single Board Design
No Moving Parts
1.5 Meter Drop Test
Warranty
Breakthrough
Scanning
Performance

Damaged Bar Code Reading
Ripped Scratched
Wrinkled
Faded
All popular symbologies supported
With Swiftdecoder software and patented revolutionary image capture technology,
MS7580 sets the bar for reading ALL kinds of standard 1-D, 2-D and PDF bar codes,
which dramatically improves efficiencies of any application.
2-D Bar Codes
PDF417
MicroPDF417
Data Matrix
MaxiCode
Aztec Code
QR Code
MicroQR Code
1-D Bar Codes
UPC/EAN/JAN Interleaved 2 of 5
Codabar Straight/NEC 2 of 5
Codablock Matrix 2 of 5
Code 11 Telepen
Code 128 MSI Plessey
Code 3 of 9 Pharmacode
Code 93 Trioptic Code
RSS-14 Family
Postal Bar Codes
POSTNET and PLANET
USPS 4CB
Australia Post
Japan Post
Royal Mail (Great Britain)
KIX Code (Denmark)
UPU
OCR
OCR-A
OCR-B
MICR-E13B

Specialty Bar Code Reading
MS7580’s decodes the most challenging 1-D bar codes, which increases operator
productivity by reducing the number of manual key-ins and enabling high-
throughput scanning
Low Contrast Bar Codes
Truncated Bar Codes
Under-printed Bar Codes
Low Contrast Bar Codes
High Density Bar Codes
Over-printed Bar Codes
Specular Reflection Bar Codes
MS7580 reads even very truncated bar codes

OCR識別能力
OCR A
OCR B （護照）
MICR （支票）

Depth of Field
Minimum Element Width
5.0 mil
0 -5 cm
7.5 mil
0 - 10 cm 10.4 mil UPC/PDF
15 mil QR
0 - 13 cm 13 mil
0 - 15 cm
4.0 mil
PDF
5.0 mil
2D
9.8 mil
1D

Innovative & Reliable Design
¾Reduce the strain on operator’s
eyes common to many imaging
products on the market.
¾Avoid potential headaches, eye
blurriness and other side effects of
bright flashes.
¾Single board design with no moving
parts ensures the most reliable design
possible with points of failure drastically
minimized.
Single row LED illumination
Industrial design to shield LEDs
Patented auto-illumination control
21# Camera Sensors
70# Internal Cables
21# of Buttons
21# of Lens Assemblies
YesNoEmissions Shield
150# Internal Connectors
71# of Boards
CompetitorGenesis

Markets and Applications
RETAIL HEALTHCARE MANUFACTURING GOVERNMENT
T & L, OFFICE
Automated Form Entry
POS –Age Verification
POS –Item Transaction
Security/Access Control
Automated Form Entry
Document Management
Asset Management
Pick & Place
Lab Sample Tracking
Security/Access Control
Document Management
Asset Management
Pick & Place
WIP Tracking
Security/Access Control
Automated Form Entry
Document Management
Asset Management
Security/Access Control
Pick & Place (T & L)

Mobile Couponing/Marketing
¾Save cost
No printed paper
No shipping fees
No advertising fee
¾Increase Hit Rate
Targeted audience
Time sensitive and customized
No more “cutting” coupons

Accessories – Mountable Stand
Mountable Stand
Mount the MS7580 to a counter-top or wall
