METVISA SFMIL User manual

1

2
INDEX
1.
Safety Information ..................................................................................................... 3
1.1
General warnings................................................................................................................ 3
2.
Technical Characteristics ….................................................................................... 4
2.1
Main Components .............................................................................................................. 4
2.2
Technical Data ................................................................................................................... 5
3.
Installation .............................................................................................................. 6
3.1
Equipment Layout ............................................................................................................. 6
3.2
Safety Measures and User Instruction ............................................................................... 7
4.
Equipment Use ....................................................................................................... 8
4.1
Utility .................................................................................................................................. 8
4.2
Commands ......................................................................................................................... 8
4.3
Operating Procedures ........................................................................................................ 9
5.
Cleaning and Maintenance .................................................................................... 11
5.1
Cleaning Procedures and Products Used ........................................................................ 11
5.2
Maintenance and Procedures in Case of Breakdowns .................................................... 12
6.
Annexes .............................................................................................................. 17
Electrical schematic ......................................................................................................... 17
Exploded View …..……..................................................................................................... 18
Spare Parts List …………….............................................................................................. 20
ATTENTION!
The characteristics, pictures and figures presented in this manual should be considered for
information. IMG BRASIL reserves the right to make such modifications as may be deemed
necessary without prior notice.

3
1. Safety Information
1.1 General Warnings
•Cautions / precautions must be observed when installing, using, maintaining and discontinuing use
of this equipment;
•Before carrying out any operation (assembly, use, maintenance and reuse after prolonged use of the
equipment), read the manual carefully;
•The equipment must be used by trained people familiar with the use and safety regulations
described in this manual;
•This equipment is not intended for use by people (including children) with reduced physical, sensory
or mental capacities, or people with lack of experience and knowledge, unless they have received
instructions regarding the use of the equipment or are under the supervision of a person responsible
for their safety.
•It is recommended that children be supervised to ensure that they are not playing with the
equipment;
•In case of rotation of the people that will work with the equipment, the new operator must be
educated about the standards and the operation of the equipment;
•The operator must use the Adequate PPE (personal protective equipment). As for example: use
caps to the hair avoiding that they lock in the moving parts of the equipment;
•The operator must always be aware of situations that can cause a risk of accidents and avoid them.
For example: avoid working with sleeves of loose uniforms, where they can lock in moving parts,
causing accidents;

•After reading and clarifying all doubts, this manual should be carefully stored in an easily accessible
location, known to all people who will operate the equipment and make it available to those who will
carry out maintenance for any inquiries. Whenever any questions arise, be sure to check the manual.
Do not operate the equipment in any way with doubts;
•In the installation, it is essential to make this manual available to the professionals who will do the
work.
•Never open the door or place your hands, fingers or objects (such as spoons and knives) on the
blade and moving parts or near them with the equipment on, avoiding personal injury or damage to
the equipment;
•Never touch the blade while the equipment is running;
•Before starting cleaning and any maintenance, it is essential to disconnect the equipment from the
mains and must only be carried out by properly trained personnel;
•Periodically check the condition of the cables and electrical parts;
•Do not leave the equipment switched on unattended.
ATTENTION!
Do not perform repairs on your own. Go to a service center authorized by the manufacturer. Use
only original parts in your equipment.

4
2. Technical Characteristics
2.1 Main Components
For the equipment described in this manual, safety in use, cleaning, maintenance and
maximum hygiene are guaranteed by the design and special design of all parts and also by using
stainless steel and other materials suitable for contact with the food.
The equipment was built with the following features:
•In the SFMIL model, the structure and parts in sheets are made of stainless steel. In the SFMPL
model in carbon steel coated with epoxy electrostatic paint, an excellent corrosion protection. In both
models, the blade is made of 304 stainless steel that resists the attack of various corrosive agents,
such as most organic acids, organic substances in general, alkalis, oxy-salts, etc.
Note: Stainless steel 304 is attacked by sulfuric acid, and also does not withstand
hydrochloric acid, dilute sulfuric acid, chlorides and halides in general.
•The blade tensioner and upper and lower wheels are also produced in carbon steel with electrostatic
epoxy paint.
Following are the main components of the equipment:
Note: For exploded view
with spare parts list, see
the annexes.

5
2.2 Technical Data
Model
Net
weight
(aprox)
(kg)
Voltage
(V)
Rated
current
(A)
Electric
Cable
(Code IMG)
Standard Measures
for Operation
Length.xHt.xWidth
(mm)
Extended
Blade
(mm)
SFMIL110M604
53.0
110
8.3
CBE002
760x1530x725*
2180
SFMIL220M501
53.0
220
4.2
CBE023
SFMIL220M502
53.0
220
4.2
CBE029
SFMIL220M504
53.0
220
4.2
CBE030
SFMIL220M604
53.0
220
4.8
CBE030
SFMPL110M604
53.5
110
8.3
CBE002
760x1530x725*
2180
SFMPL220M501
53.5
220
4.2
CBE023
SFMPL220M502
53.5
220
4.2
CBE029
SFMPL220M504
53.5
220
4.2
CBE030
SFMPL220M604
53.5
220
4.8
CBE030
SFMILM110M604
53.4
110
9.5
CBE002
760x1530x725*
2180
SFMILM220M501
53.4
220
5.9
CBE023
SFMILM220M502
53.4
220
5.9
CBE029
SFMILM220M504
53.4
220
5.9
CBE030
SFMILM220M604
53.4
220
5.7
CBE030
SFMPLM110M604
53.9
110
9.5
CBE002
760x1530x725*
2180
SFMPLM220M501
53.9
220
5.9
CBE023
SFMPLM220M502
53.9
220
5.9
CBE029
SFMPLM220M504
53.9
220
5.9
CBE030
SFMPLM220M604
53.9
220
5.7
CBE030
SFMPLS240M506
53.9
240
5.3
CBE177
760x1530x725*
2180
* Background measurement considering the area that the movable table occupies during the cutting movement.
Sound Level: 80 dB.
ATTENTION!
Characteristics like: model, serial number and voltage of the equipment are provided on the
label (figure below). Before installation, check that the power supply voltage of the appliance
corresponds to that of the mains.

6
3. Installation
3.1 Equipment Layout
The connection to the mains and the arrangement for operation must be carried out by a
qualified professional. Check that the equipment voltage matches the mains voltage.
In the installation, it is essential to make this manual available to the professionals who will
do the work;
To facilitate transport, the equipment is packed with the feet disassembled. They accompany
the equipment with the screws, washers and nuts that will be used to fix the parts. Use the star
wrenches to tighten the screws.
Following is the parts list and mounting position:
Spare Parts List of the Feet
Position
ão
Description
Quantity
1
Front Traverse and Rear Feet
02
2
Side Traverse of the Feet
02
3
Side Structure of the Feet
04
4
Hexagonal Screw M6
28
5
Flat Washer 1/4"
52
6
Hexagon Nut M6
24
7
Rubber Foot
04
After fixing the equipment on the feet, the equipment must be positioned in a sufficiently wide
area, with a well-leveled, dry and stable floor, away from heat sources and water taps, and in a place
where there is no heavy traffic of people. Install your equipment leaving a free area at the front and a
distance of at least 50 cm on the sides and rear, so that it has enough space for inspection,
maintenance, cleaning and use.

7
ATTENTION!
The installation and the place where the equipment will be disposed must comply with the
norms of risk prevention and safety at work (regulatory norm in force in your country).
The manufacturer does not take responsability for any direct or indirect damages caused by
non-compliance with these rules and other instructions presented in this manual.
3.2 Safety Measures and User Instruction
The professional that makes the sale of the equipment should instruct the user about the
correct operation of the equipment and should give you this instruction manual.
The user must be informed of the necessary safety measures and must respect them as well
as all the measures described in this manual.
Your equipment has mechanical guards that prevents the worker to access the mobile parts
and electrical components. Removal or tampering with these safety components can cause serious
hazards to the operator.
ATTENTION!
Before operating your equipment, check that the blade teeth are pointing downward, and that the
direction of rotation of the wheels is counterclockwise. To do this, turn on the equipment by
pressing the power button in the "1" position (on). Position yourself in front of the equipment
and see if the blade moves up and down, as shown below.
In this image, just to illustrate the direction of rotation of the wheels, they are seen with the door
open, but for practical verification, do not open the door, because can cause accidents. Always
check the direction of rotation with the doors closed and locked with the screws.
If the blade is moving from the bottom to the top (clockwise rotation), check that the electrical
connection is reversed in relation to the wiring diagram (item 6 - Attachments) or contact your
nearest authorized service center.

8
4. Equipment Use
4.1 Utility
This equipment is exclusively intended for sawing, slicing meats, poultry, fish and food
products.
4.2 Commands
The equipment has only on / off switch, on the right side of the structure.

9
See description of each command below:
•on / off switch –used to activate and deactivate the electric power supply to the equipment. In
position "1" active, in position "0" disables power supply.
4.3 Operating Procedures
Before operating your equipment, make the perfect sanitation, especially of the components
that will come in contact with the food (blade, wheels, tables, pushers, etc.). Do the cleaning with the
equipment disconnected from the mains. Follow the cleaning instructions in item 5 of this manual
(below).
•Operation: The equipment can only be operated after checking that the voltage is in accordance
with the mains voltage, if the equipment is positioned in an ideal location (as per instructions in 3.1), if
the wheels are rotating counterclockwise ( instructions in item 3.2 Safety Measures) and that the door
is closed and locked with the screws.
•Cutting Adjustment: With the equipment switched off (power button in the "0" position), follow the
instructions for setting the equipment for cutting:
1. Facing to the equipment, pull the movable table toward you. Lift the side pusher. Place the
food to be processed on the movable table;

10
IMPORTANT
Never place a cutting food larger than the moving table.
4. Put down the pusher over the food locking against the movable table.
•Cutting Operation:
1. Turn the power switch to "1" (on). At that moment the blade begins to rotate;
3. With the right hand, take the slice behind the blade, avoiding contact with the cutting area. Stack
the slices on fixed table.
4. Pull the movable table towards you and repeat the procedure until the end of the process;
ATTENTION!
When moving the table back, be careful that the food does not touch the back (flat part) of
the blade. In this way there is no risk of the food moving or even releasing the blade from
the fly wheels, causing accidents.
5. After completing the cutting procedure, turn off the equipment by pressing the power button in
the "0" (off) position.
ATTENTION!
Always use the movable table and the pusher of the equipment to direct the food against the
blade. In no circumstances push with any other instrument or your own hands the food
against the blade.

11
IMPORTANT
Check the blade tension. When the tension is insufficient, cutting deviations and premature
wear of the blade occur. If it is necessary to adjust it, follow the instructions in item 5.2
(Maintenance and Procedures in Case of Breakdowns) of this manual.
ATTENTION!
Never place your hands, fingers or objects (such as spoons and knives) on the cutting blade
while the equipment is on as this may cause serious injury.
ATTENTION!
If you notice that the equipment can not slice the food or that it is not slicing, do not cut
foods too thick, so as not to impair the speed and performance of the motor and the life of
the equipment.
Failure to observe this guideline will be considered as unsafe act and abusive use of
equipment.
Any irregularities please contact the authorized service center nearest you.
5. Cleaning and Maintenance
5.1 Cleaning Procedures and Products Used
Your equipment was built with first-line materials, so use it properly and you will get great
satisfaction. Keep your equipment always clean and well-cared for, which will make it much more
durable.
A daily cleaning of the equipment must be carried out for good operation and durability.
ATTENTION!
Before performing maintenance or cleaning, make sure that the main switch (switch) is off
and that the plug is disconnected from the mains.
ATTENTION!
Do not use water jet to clean the equipment.

12
IMPORTANT
This equipment is not intended to be immersed in water for cleaning.
The equipment should be cleaned as many times as possible to prevent food residue from
drying out and sticking to parts. For cleaning, dilute soap or neutral detergent or ammonia-based
remover in warm water and apply with a soft cloth. With a cloth moistened with water, rinse and then
wipe the parts with a dry cloth.
Never use abrasive products or sponges and substances containing acids or chlorine to clean
the metal parts, as they may scratch or damage the surface of the parts causing corrosion. Do not
spill water on the engine and electrical parts for cleaning, otherwise, turning it on may cause electric
shock or even burn the equipment.
ATTENTION!
It is extremely important that products used in cleaning ensure maximum cleanliness and
are non-toxic.
Dry the blade thoroughly. Moisture compromises the life of the blade and yield of the
cutting process.
ATTENTION!
Take care when cleaning near the blade, it is extremely sharp. Handle with care because this
may cause accidents. The same attention is paid to any other cutting component of the
5.2 Maintenance and Procedures in Case of Breakdowns
The operator must be instructed to perform routine inspections, making minor adjustments,
cleaning and observing signs of breaches that may occur. Examples include: checking for strange
noise; loss of equipment power; the non-execution by the equipment of the service to which it is
proposed; among others. Actions like these are indispensable to ensure a longer equipment life.
ATTENTION!
When servicing (even minor adjustments), always disconnect the equipment from the mains.
It is recommended to carry out preventive maintenance every 6 months, checking and
adjusting clearances, cleaning internal parts, wear and tightening (tensioning) of the motor belt
(following guidelines), lubrication of the movable table, etc. When detecting broken or weakened
parts, replace with original parts.

13
By performing preventive maintenance, you eliminate the inconvenience of getting the
equipment stopped when you need it most, reducing the cost of maintenance and reducing the risk of
accidents.
ATTENTION!
Before adjusting or changing the blade, make sure the equipment is disconnected from the
mains, if the operator is using the appropriate PPE (personal protective equipment) and
suitable tools for disassembly and assembly of the following parts.
•Procedure for Adjusting and Changing the Blade (Band Saw):
Blade Adjustment:
1. Disconnect the equipment from the mains;
2. Remove the back cover of the equipment by unscrewing the screws;
3. To move the blade tensioner, loosen the nut. If your need is to stretch the blade, facing
the blade tensioner, turn the adjusting knob clockwise. And to loosen the blade, turn the
knob counterclockwise;
4. After proper tensioning of the blade, tighten the nut again, securing the blade tensioner;
5. Reassemble the tensioner protection with the screws.

14
Blade Exchange:
11. Before attaching the new blade to the wheels, note the direction of the blade teeth, where
they should be facing forward and pointing downwards;
12. The blade should be positioned centrally on the steering wheels;

15
13. After proper tensioning of the blade, as instructed a little (Blade Adjustment Procedure),
retighten the blade tensioner nut;
14. Insert the cover of the tensioner by fastening it with the screws;
15. Assemble the door again, fitting the left side in the supports and fixing the right side with
the screws.
ATTENTION!
Check the ideal tension of the blade before starting the cutting process, because when the
tension is insufficient, cutting deviations occur and premature wear of the blade. Excessive
tension, in turn, can cause the blade to break.
•Adjustment / Tensioning Belt Procedure:
1. Disconnect the equipment from the mains;
2. Remove the back cover of the equipment by unscrewing the 04 screws;
3. To move the engine, loosen or tighten the 04 screw located on the engine support;
4. Move the motor by adjusting the belt tension; To fix the motor in the ideal position tighten
tightly the screws.

16
5. Finally, secure the back cover with the 04 screws.
After completing all adjustments, make sure that all the disassembled parts are properly
assembled and secured, ensuring the safety of the operator while using the equipment.
ATTENTION!
Preventive maintenance requires a trained professional or authorized technical assistance.
Make sure that the equipment is disconnected from the mains.
Whenever any item regarding the safety of the equipment (such as cleaning or maintenance) is
removed, reset it and confirm that it is performing its function correctly.
When you experience any malfunction or non-compliance, refer your equipment to the
nearest service center. See technical assistance on our website: www.metvisa.com.br

17
6. ANNEXES
Electrical Schematic
NOTE: In the electric schematic above, the White wires are represented by the pink color.

18
Exploded View

19
Exploded View

20
Spare Parts
Position
Code
Description
Quant.
Model
1
RBT004
Rivet
14
SFMPL
RBT014
Stainless Steel Rivet
14
SFMIL
2
EPR017
Pendulum Pusher
01
*
2.1
MNL017
Pusher Handle
01
*
3
CJT713
Doors Set
01
SFMIL
CJT719
SFMPL
4
PRS332
Stainless Steel Hexagon Screw
08
*
5
CJT717
Fixed Protection Plate L Set
02
SFMIL
CJT720
SFMPL
6
PRA014
Stainless Steel Self-Drilling Hexagonal Screw
18
SFMIL
PRA008
SFMPL
7
PTC133
Protection Plate
01
*
8
VOL004
Lower Wheel
01
*
9
PRN001
Allen Screw
04
*
10
CJT376
Complete Higher Wheel
01
SFMIL
CJT154
SFMPL
11
SFL019
Blade
01
*
12
PTC059
Lower Blade Protection
01
*
13
MON025
Stainless Steel Monoblock
01
SFMIL
MON026
Painted Monoblock
SFMPL
14
POS021
Hexagon Nut
01
SFMIL
POS005
SFMPL
15
PRS021
Screw
05
SFMIL
PRS006
SFMPL
16
AMP081
Fixed Table Support
02
SFMIL
AMP082
SFMPL
17
CJT716
Plate Set of the Cutting Regulator
01
*
17.1
SBT354
Guide Support of the Cutting Regulator
02
*
17.2
GIA085
Cutting Regulator Guide
01
*
17.3
PRS045
Stainless Steel Hexagon Screw
02
*
17.4
CJT711
Welded Plate Set of the Cutting Regulator
01
*
17.5
TVS005
Round Pin
02
*
17.6
MNL030
Stainless Steel Handle
01
*
18
ARL011
Flat Washer
23
SFMIL
ARL003
SFMPL
19
POS013
Hexagon Nut
21
SFMIL
POS004
SFMPL
20
CRC409
Regulator Plate of the Movable Table
04
*
21
TRT016
Pin
04
SFMIL
TRT009
SFMPL
22
ROD035
Wheel
06
*
23
PRT004
Allen Screw with Head
04
*
24
TRS017
Double Rail
01
SFMIL
TRS018
SFMPL
25
CJT715
Side Pusher Set
01
*
25.1
SBT349
Side Pusher Support
01
*
25.2
GIA049
Side Pusher Guide
01
*
25.3
EPR013
Side Pusher
01
*
25.4
MNL013
Handle
01
*
25.5
APE017
Stainless Steel Ring Retention
02
*
25.6
ACA009
Plastic Handle
01
*
25.7
BGT039
Side Pusher Guide Bushing
02
*
25.8
TVS005
Round Spigot
02
*
25.9
MNL011
Internal Handle Screw Thread
01
*
25.10
PRR021
Machine Round Screw
01
*
25.11
ARL014
Flat Washer
02
*
25.12
PCC006
Stainless Steel Round Head Screw
02
*
25.13
PCC007
Stainless Steel Round Head Screw
03
*
25.14
POC008
Stainless Steel Hexagon Hat Nut
05
*
*Item applicable for all saw blade models described in this manual.
