MFC International Bravo 2000 User manual

Product Manual
Bravo 2000 Electric Inator

2© MFC International
Technical Data
Safety Instructions
Instructions for Use
Repairs
3
4
5
6
WARNING: Carefully read this manual before operating the
Bravo 2000 Electric Inator.
NOTICE: The manufacturer takes no responsibility for the
consequences of actions not complying with the instructions
given in this manual.
Index

3
© MFC International
Technical Data
Technical Data Bravo 2000 Electric Inator
Product Code 180026
Voltage Supply 230V (Main Motor) 230V (Booster)
Max. Power 1000W / 2000W
Max. Pressure 140 mbar (2 psi) / 400 mbar (5.8 psi)
Max. Flow Rate 1200 l/min / 2000 l/min
Dimensions 32 x 17 x 26 cm
Weight 4.1 kg
The Bravo 2000 electric inator consists of a main motor and a supplementary (booster)
motor, which increases the capacity and pressure. The two motors can run simultaneously
to obtain maximum capacity and pressure.
On the Bravo 2000, you can press the orange button to just run the main motor, or you can
press the red button to switch on the booster to help obtain maximum performance. Both
motors are protected by thermal-amperic fuses.
Bravo 2000 Electric Inator Features:
• Inates and deates
• Has a robust outer steel casing for additional protection
• Fitted with main motor and a booster motor to increase capacity and pressure
• 3m integral mains power lead comes with 2 pin plug (supplied with UK 3 pin plug
adapter if needed)
• Comes with an ination hose, 7 dierent adapters and a shoulder carry strap

4© MFC International
Safety Instructions
WARNINGS
1. Before inserting the plug into the mains socket, check that the voltage corresponds
with that written on the plate.
2. It is forbidden to use the device in humid environments and/or close to water.
3. Never touch the power cable with wet hands (risk of electric shock).
4. The electrical power cable cannot be replaced, if the cable is damaged the product
cannot be used.
5. Keep the product out of the reach of children.
6. Do not leave the inator running unattended.
7. Do not use the inator with adapters other than those supplied with the product as
they could damage the device.
8. Take care not to allow foreign bodies (sand or small stones) to get into the inator.
9. Repairs should only be performed by the technical assistance service (see page 6).
10. The manufacturer is not responsible for damage caused as a result of improper use
or failure to observe the envisaged usage.
11. Long periods of use can cause overheating and damage to the product. Do not use
for more than 20 minutes continuously.

5
© MFC International
Instructions for Use
INFLATION OPERATION
1. From the white universal adaptor, select the reducer that engages and opens the
valve of the inatable structure.
2. Insert the selected adaptor on the braided joint on the end of the tube.
3. Tighten the black adaptor on to the ination side of the inator (OUT).
4. Check that both start switches are set to ( 0 ).
5. Insert the plug and set the orange switch to position ( | ). If necessary, also use the
red switch to obtain maximum performance to start the ination.
6. The inator is limited to a maximum pressure of 140 mbar (orange switch) and 350
mbar (orange+red switches).
7. When the maximum pressure is reached, switch o the inator immediately to avoid
overheating the motor.
DEFLATING OPERATION
1. From the white universal adaptor, select the reducer that engages and opens the
valve of the inatable structure.
2. Insert the selected adaptor on the braided joint on the end of the tube.
3. Fit the black adaptor on to the deation side of the inator (IN).
4. Check that both ON switches are set to ( 0 ).
5. Insert the plug and set the orange switch to position ( | ). If necessary, also use the
red switch to obtain maximum performance to start the deating.
6. When the inatable is completely deated, switch o the inator immediately to avoid
overheating the motor.
NOTE: It is advisable to check the pressure with a pressure gauge.

6© MFC International
Repairs
REPAIRS
As a general rule, repairs/damaged products will need to be assessed in two categories:
a) that which is repairable at the base, or b) serious damage that will need to be
repaired by MFC International.
If in doubt as to the extent of the damage and the level of repairs necessary,
please contact the MFC service department on [phone].
WARNING: Repairs may only be carried out by the manufacturer, or people
certied by MFC International Ltd.
.

7
© MFC International

MFC International
Naval Yard
Tonypandy
Rhondda Cynon Ta
CF40 1JS
T. [phone]
[email protected]
www.mfc-international.com
A Respirex International Limited Group Company SA-MA118-01
