MFC SPEED CREED Application guide

3334 North Booth Street, Milwaukee WI 53212 U.S.A. 414.964-4550 I
414-964-4503 EMAIL: [e-mail] I WEBSITE:
REV.03
ROLLER SCREED
OPERATION & PARTS MANUAL

REV.03_9/2021
1
OPERATION & PARTS MANUAL
The following products are covered in this manual:
Part Number
Description
780-204
END FRAME ASSEMBLY POWER SECTION, ROLLER SCREED
780-205
END FRAME ASSEMBLY, IDLER END, ROLLER SCREED
780-005
EXTENSION ASSEMBLY, 5’ ROLLER SCREED
780-006
EXTENSION ASSEMBLY, 6’ ROLLER SCREED
780-007
EXTENSION ASSEMBLY, 7’ ROLLER SCREED
780-008
EXTENSION ASSEMBLY, 8’ ROLLER SCREED
780-009
EXTENSION ASSEMBLY, 9’ ROLLER SCREED
780-010
EXTENSION ASSEMBLY, 10’ ROLLER SCREED
780-020
ROLLER ASSEMBLY, 10’-20’ (SET OF 3 ROLLERS & HARDWARE)
780-030
ROLLER ASSEMBLY, 21’-30’ (SET OF 3 ROLLERS & HARDWARE)
780-100
SPRAY SYSTEM, TANK/PUMP ASSEMBLY
780-10X
SPRAY SYSTEM, BOOM ASSEMBLIES (5’, 6’, 7’, 8’, 9’, 10’)
780-305
WALKWAY ASSEMBLY, 5’
780-310
WALWAY ASSEMBLY, 10’
This manual was first issued July 2020
Legal Notice
The information contained in this General Safety Guidelines Sheet was considered the best
available at the date of issue. However, no warranty is made or implied that the information is
accurate or complete. It is the user's obligation to evaluate and use this product safely and to
comply with all applicable laws and regulations.
All information, specifications, and illustrations in this manual are subject to change without notice
and are based on the latest information at the time of publication. No part of this manual may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose,
without the express written permission of Metal Forms Corporation (MFC). MFC assumes no
responsibility or liability for any errors or inaccuracies that may appear in this manual.

2
REV.03_9/2021
Table of Contents
Table of Contents.......................................................................................................................................................................................................................................2
Manual Information ....................................................................................................................................................................................................................................4
Serial Number Identification.......................................................................................................................................................................................................................5
Spare/Replacement Parts Ordering Information.......................................................................................................................................................................................6
Machine Specifications..............................................................................................................................................................................................................................7
MACHINE.............................................................................................................................................................................................................................................7
HYDRAULIC SYSTEM.........................................................................................................................................................................................................................7
ROLLER/SLINGER TUBES.................................................................................................................................................................................................................7
SUPPORT FRAMES............................................................................................................................................................................................................................7
SPRAY SYSTEM.................................................................................................................................................................................................................................7
Engine Specifications.................................................................................................................................................................................................................................8
Engine Wiring Diagram..............................................................................................................................................................................................................................9
26A CHARGING SYSTEM...................................................................................................................................................................................................................9
Machine Dimensions................................................................................................................................................................................................................................10
Safety Section..........................................................................................................................................................................................................................................11
State/Federal Regulations .................................................................................................................................................................................................................11
Safety Information..............................................................................................................................................................................................................................12
Safety Symbols ..................................................................................................................................................................................................................................13
General Safety Guidelines.................................................................................................................................................................................................................14
Machine Operation...................................................................................................................................................................................................................................18
Machine Basics..................................................................................................................................................................................................................................18
Loading/Unloading Your Machine......................................................................................................................................................................................................18
Startup Procedure..............................................................................................................................................................................................................................19
Controls/Features...............................................................................................................................................................................................................................20
Machine Operation.............................................................................................................................................................................................................................21
Starting Machine Operation.........................................................................................................................................................................................................21
Stopping the Machine..................................................................................................................................................................................................................21
Service & Adjustments.............................................................................................................................................................................................................................22
Height Adjustment on Slinger ............................................................................................................................................................................................................22
Changing Length & Tubes .................................................................................................................................................................................................................23
Maintenance.......................................................................................................................................................................................................................................24
Daily Maintenance.......................................................................................................................................................................................................................24
Weekly Maintenance...................................................................................................................................................................................................................24
Seasonal Maintenance................................................................................................................................................................................................................24
Parts.........................................................................................................................................................................................................................................................25
Full Assembly.....................................................................................................................................................................................................................................25
Full Assembly – BOM.........................................................................................................................................................................................................................25
End Frame – Power Assembly ..........................................................................................................................................................................................................25
End Frame – Power Assembly (Continued) ......................................................................................................................................................................................27
End Frame – Power Assembly BOM.................................................................................................................................................................................................28
Engine Assembly ...............................................................................................................................................................................................................................29
Engine Assembly BOM ......................................................................................................................................................................................................................30
Hydraulics Assembly..........................................................................................................................................................................................................................31
Hydraulics BOM .................................................................................................................................................................................................................................32
Hydraulic Assembly - Tank ................................................................................................................................................................................................................33

REV.03_9/2021
3
Hydraulics Assembly – Pump/Motors................................................................................................................................................................................................34
Hydraulics Assembly – Pump/Filter/Manifold/Cooler/Tank ...............................................................................................................................................................35
Hydraulics Assembly – Pump/Filter/KS Manifold/Kick Stand............................................................................................................................................................36
Hydraulics Assembly –Kick Stand .....................................................................................................................................................................................................37
Hydraulics Assembly – Tandem Pump..............................................................................................................................................................................................38
Hydraulics Assembly – Proportional Control Manifold.......................................................................................................................................................................39
Hydraulics Assembly – Motor ............................................................................................................................................................................................................40
Hydraulics Assembly – Hydraulic Cooler...........................................................................................................................................................................................41
Hydraulics Assembly – Kickstand Manifold.......................................................................................................................................................................................42
Hydraulics Assembly – Filter..............................................................................................................................................................................................................43
Fuel System Assembly.......................................................................................................................................................................................................................44
Fuel System BOM..............................................................................................................................................................................................................................45
Battery Assembly ...............................................................................................................................................................................................................................46
Battery BOM.......................................................................................................................................................................................................................................46
End Frame – Control Panel Assembly...............................................................................................................................................................................................47
End Frame – Control Panel BOM......................................................................................................................................................................................................48
Display Panel Assembly.....................................................................................................................................................................................................................49
Display Panel BOM............................................................................................................................................................................................................................49
Platform Assembly .............................................................................................................................................................................................................................50
Platform BOM.....................................................................................................................................................................................................................................50
End Frame – Lite (Idler) Assembly ....................................................................................................................................................................................................51
End Frame – Lite (Idler) BOM............................................................................................................................................................................................................52
Support Frame Assembly...................................................................................................................................................................................................................53
Support Frame BOM..........................................................................................................................................................................................................................53
Roller Assembly .................................................................................................................................................................................................................................54
Roller BOM.........................................................................................................................................................................................................................................54
Spray System, Tank/Pump Assembly (Option) .................................................................................................................................................................................55
Spray System, Tank/Pump Assembly BOM......................................................................................................................................................................................55
Spray System, Tank/Pump Components Assembly (Option)............................................................................................................................................................56
Spray System Tank/Pump Components BOM ..................................................................................................................................................................................57
Spray System, Boom Assembly (Option) ..........................................................................................................................................................................................58
Spray System, Boom Assembly BOM ...............................................................................................................................................................................................59
Spray System, Boom Assembly BOM (Continued) ...........................................................................................................................................................................60
Walkway Assembly, 5’ (Option) .........................................................................................................................................................................................................61
Walkway Assembly, 5’ BOM..............................................................................................................................................................................................................61
Walkway Assembly, 10’ (Option).......................................................................................................................................................................................................62
Walkway Assembly, 10’ BOM............................................................................................................................................................................................................62
Walkway, 5’ (Option)..........................................................................................................................................................................................................................63
Walkway, 5’ BOM...............................................................................................................................................................................................................................63
Walkway, 10’ (Option)........................................................................................................................................................................................................................64
Walkway, 10’ BOM.............................................................................................................................................................................................................................64
Walkway Ballast Assembly, 5’ (Option).............................................................................................................................................................................................65
Walkway Ballast Assembly, 5’ BOM..................................................................................................................................................................................................65
Walkway Bracket Assembly (Option).................................................................................................................................................................................................66
Walkway Bracket Assembly BOM......................................................................................................................................................................................................66

4
REV.03_9/2021
Manual Information
This manual is meant to provide safety, operation, and
maintenance procedures for your Speed Screed Roller
machine.
For your own safety and protection from personal injury,
carefully read, understand, and observe the safety
instructions described in the following sections. Keep this
manual with the machine at all times. Additional manuals
can be provided by contacting the dealer you purchased
the machine from, or Metal Forms Corporation directly.
You can find a list of contents and corresponding page
numbers for the following sections in this manual:
Your engine and battery are covered under their own manufacturer warranty and are not
covered or manufactured by Metal Forms Corporation. Complete any required warranty
information as specified by the manufacturer in their instructions, which you can find inside the
control panel of the machine.
Any parts, operation, or repair manuals should be obtained by contacting the manufacturer
directly.
PARTS
SERVICE
SAFETY
OPERATION

REV.03_9/2021
5
Serial Number Identification
If you need to order parts, you will be asked for your machine serial number. The serial
number found on the identification plate is a twelve-digit number and corresponds to the below
breakdown:
R-121381-03-19-1
Please note your machine serial number and information below:
R – Roller Screed
L – Speed Screed Light Duty
Blank – Speed Screed Heavy
Order
Number
Month
Order
Line
Year
Your Serial Tag can be found on the left side of the control panel.
Serial Number: ________________________________________
Date Purchased: ______________________________________
Purchased From: ______________________________________

6
REV.03_9/2021
Spare/Replacement Parts Ordering Information
The Parts section of this manual gives detailed assembly drawings and Bill of Materials
(BOMs) to aid in finding replacement parts for your machine.
Please note that all the information, specifications, and illustrations in this manual are subject
to change without notice and are based on the latest information available at the time of
printing.
To order your spare/replacement parts, please contact the dealer you purchased your machine
from, or you can contact Metal Forms Corporation directly at 414-964-4550. You can also
check for parts on our website at www.metalforms.com
FIND US ONLINE:
www.metalforms.com
@metalforms
@metalforms
www.youtube.com/MetalForms53212

REV.03_9/2021
7
Machine Specifications
MACHINE
Machine weight (15’):
3,537 lbs. [1604kg]
Approximate weight per foot for additions:
119 lbs. [54kg]
Hydraulic Oil Reservoir (ISO 46):
10 gallons [37.85L]
Available machine lengths (in 1’ increments):
10’-30’ [3m-9.1m]
Fuel Reservoir:
12 gal. [45.42L]
HYDRAULIC SYSTEM
Hydraulic motor attachment to each tube:
Direct drive via keyed bushing & bolt flange
Roller tube controls:
Independent electronic variable speed
control to drive rollers & slinger roller
Drive roller speed:
0’-125’ Per minute [0-.64mps]
Slinger roller speed:
150 rpm
Kickstand travel:
16” [406mm]
Kickstand extend speed:
1.2” per second [30.5 mm/s]
Kickstand retract speed:
1.8” per second [45.7 mm/s]
An electronically controlled tandem pump systemdrives the drive and slinger rollers
independently. The kickstand is standard on all machines and is controlled via two buttons at
the top of the drive roller joystick. It includes a monitoring light to indicate when the kickstand is
fully extended / retracted.
ROLLER/SLINGER TUBES
Diameter:
8” SCH.40 Pipe (Ø8.625”) [Ø219.1mm]
Wall thickness:
0.322” [8.18mm]
Weight per foot:
28.55 lbs. [12.95kg]
SUPPORT FRAMES
Frame Extension Size
Qty. Horizontal Support Tubes
Weight
5’ frame extension:
2
155 lbs. [70.3kg]
6’ frame extension:
3
198 lbs. [89.8kg]
7’ frame extension:
4
240 lbs. [108.8kg]
8’ frame extension:
4
260 lbs. [117.9kg]
9’ frame extension:
5
302 lbs. [137.0kg]
10’ frame extension:
5
321 lbs. [145.6kg]
All frame sections are made from 2”x6”x1/8” and 2”x2”x1/8” steel tubes with 3/8” bolt plates.
Operator work platform comes standard, and an Idler end platform and/or counterweight is
available as an optional accessory.
SPRAY SYSTEM
Tank capacity:
50 gal. [189.27L]
Nozzles per feet:
Approx. 0.5 (depending on machine length)
Hose attachment:
Included w/ hand spray nozzle & hose reel

8
REV.03_9/2021
Engine Specifications
HONDA GX690 22hp V-TWIN
Engine Type
Air-cooled 4-stroke OHV
Bore x Stroke
78 mm X 72 mm
Displacement
42 in3[688 cm3]
Net Power Output*
22.1 bhp [16.5 kW] @ 3,600 rpm
Net Torque
35.6 lb-ft [48.3 Nm] @ 2,500 rpm
PTO Shaft Rotation
Counterclockwise [from PTO shaft side]
Compression Ratio
9.3:1
Lamp/Charge coil options
26A
Carburetor
N/A
Ignition System
Full transistorized ignition
Starting System
Shift Type
Lubrication System
Full Pressure
Governor System
Electronic (STR Governor)
Air cleaner
Paper
Oil Capacity
2.1 US qt [2.0L]
Fuel
Unleaded 86 octane or higher
Dry Weight
104.7 lbs. [47.5 kg]
Length
13.1" [333 mm]
Width
19.0" [483 mm]
Height
17.2" [438 mm]
*The power rating of the engine indicated in this document is the net power output tested on a production engine for the engine model and
measured in accordance with SAE J1349 at 3,600 rpm (net power) and at 2,500 rpm (max net torque). Mass production engines may vary
from this value. Actual power output for the engine installed in the final machine will vary depending on numerous factors, including the
operating speed of the engine in application, environmental conditions, maintenance, and other variables.
Specifications are subject to change without notice.

REV.03_9/2021
9
Engine Wiring Diagram
26A CHARGING SYSTEM

10
REV.03_9/2021
Machine Dimensions

SAFETY
REV.03_9/2021
11
Safety Section
State/Federal Regulations

SAFETY
12
REV.03_9/2021
Safety Information
Make sure to read this manual in its entirety BEFORE operation or servicing of this machine.
Safety precautions must be followed at all times when operating this equipment. Failure to
read and understand the safety messages and operating instructions could result in injury to
yourself and others.
Safety Warnings
All occupants and personnel should be alerted to the potential hazards indicated by the
product safety labeling on this unit.
The following conventions are used to indicate and classify precautions and on product safety
labeling. Failure to observe precautions could result in injury to people or damage to property.
Safety Warnings
This is the safety alert symbol. It is used to alert you to potential personal
injury hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
“Danger” indicates an imminently hazardous situation,
which, if not avoided, will result in death or serious injury.
“Warning” indicates a potentially hazardous situation,
which, if not avoided, could result in death or serious
injury.
“Caution” indicates a potentially hazardous situation,
which, if not avoided, may result in minor or moderate
injury.
“Notice” indicates an important topic/practices that are
not directly related to personal injury or accidents.
DANGER
WARNING
CAUTION
NOTICE

SAFETY
REV.03_9/2021
13
Safety Symbols
Potential hazards associated with the operation of this equipment will be referenced with
hazard symbols which may appear throughout this manual in conjunction with safety notes.
SYMBOL
SAFETY HAZARD
Lethal exhaust gas hazards
Explosive fuel hazards
Burn hazards
Rotating parts hazards
Crush hazards
Hydraulic fluid hazards
Safety harness warning

SAFETY
14
REV.03_9/2021
General Safety Guidelines
•Operator concentration is always an important factor when using mechanical equipment
and anything that distracts the operator during operation is a clear and present danger.
•Familiarity and proper training are required for the safe operation of all Metal Forms
Corporation™ equipment. Equipment operated improperly or by untrained personnel
can be dangerous. All operators MUST read both the General Safety Guidelines Sheet
and the Speed Screed manual prior to operation.
•NEVER allow anyone to operate this equipment without proper training. People
operating this equipment must be familiar with all the risks and hazards associated with
it.
•DO NOT operate any equipment while under the influences of drugs, alcohol, or
medications
•Check machine EACH DAY before use to ensure it is proper running condition.
•If any parts are worn or damaged, fix or replace IMMEDIATELY.
•ALWAYS use OEM replacement parts.
•When equipment is not in use, remove the key and be sure to store it in a clean and dry
environment, out of reach of unauthorized personnel and children.
•ALWAYS keep doors, covers, and heat shields attached/closed when the engine is
running.
•DO NOT place hands or fingers inside the engine compartment when
engine is running.
•Keep fingers, hands, hair, and clothing away from all moving parts to
prevent injury.
•DO NOT remove the engine oil drain plug while the engine is hot. Hot oil can rapidly
flow out of the oil tank and severely scald or burn any persons in the general area of the
machine.
NOTICE
WARNING

SAFETY
REV.03_9/2021
15
•NEVER touch the hot exhaust manifold,
muffler, or cylinder.
Allow these parts to cool before servicing equipment.
•NEVER run engine without an air filter or with a dirty air filter. Severe engine damage
may occur. Service air filter frequently to prevent engine malfunction.
•NEVER tamper with the factory settings of the engine, engine governor, or control
levers. Damage to the engine or equipment can result if operating in speed ranges
above the maximum allowable.
•DO NOT start the engine near spilled fuel or combustible fluids. Fuel is
extremely flammable, and its vapors can cause an explosion if ignited.
•ALWAYS refuel in a well-ventilated area, away from sparks and open flames.
•ALWAYS use extreme caution when working with flammable liquids.
•DO NOT fill the fuel tank while the engine is running or hot.
•DO NOT overfill tank. Spilled fuel could ignite if it comes in contact with hot engine parts
or sparks from the ignition system.
•Store fuel in appropriate containers, in well-ventilated areas and away
from sparks and flames.
•NEVER use fuel as a cleaning agent.
•DO NOT smoke around or near the equipment. Fire or explosion could
result from fuel vapors or if fuel is spilled on a hot engine.
CAUTION
NOTICE
DANGER

SAFETY
16
REV.03_9/2021
•DO NOT drop the battery. There is a possibility that the battery will explode.
•DO NOT expose the battery to open flames or sparks. The battery contains
combustible gases and liquids. If these gases and liquids come in contact
with a flame or spark, an explosion could occur.
•ALWAYS wear safety glasses when handling the battery to
avoid eye irritation. The battery contains acids that can cause
injury to the eyes and skin.
•Use well-insulated gloves when picking up the battery.
•ALWAYS keep the battery charged. If the battery is not charged, combustible gas will build
up.
•DO NOT charge battery if frozen. Battery can explode. When frozen, warm the battery to at
least 61°F (16°C).
•ALWAYS recharge the battery in a well-ventilated environment to avoid the risk of a
dangerous concentration of combustible gases.
•If the battery liquid (dilute sulfuric acid) comes in contact with clothing or skin,
rinse skin or clothing immediately with plenty of water.
•If the battery liquid (dilute sulfuric acid) comes in contact with eyes, rinse
eyes immediately with plenty of water and contact the nearest doctor or
hospital to seek medical attention.
•When using the optional walkway, always use a safety harness to
prevent falling into moving rollers
DANGER
WARNING

SAFETY
REV.03_9/2021
17
•ALWAYS disconnect the negative battery terminal before performing service on the
equipment.
•ALWAYS keep battery cables in good working condition. Repair or replace all worn cables.
•Walk around the machine before starting it to see if any items are worn, damaged, leaking,
etc. that may make the machine dangerous to operate.
•Stop and inspect the equipment if you strike an object. If necessary, make repairs before
restarting.
•ALWAYS check that all controls are functioning properly immediately after start-up.
•DO NOT operate machine unless all controls operate correctly.
CAUTION

OPERATION
18
REV.03_9/2021
Lifting Eyes
Machine Operation
Machine Basics
The Speed Screed™ Roller (SSR) is a variable length triple tube roller system that allows
users to easily swap rollers and extension frames between jobs that require different pour
widths. With rollers and extensions available from 10’ to 30’ in single foot increments, almost
any job can be easily handled with this machine.
This machine comes with standard safety features such as the kickstand (steering leg) and
drive lever hydro-back, which returns the drive lever to neutral when the operator steps away
from the machine. It also available with an optional idler end weight pack to offset the engine
end weight differential, or a spray system to keep your roller tubes clean during operation.
Metal Forms Corporation™ manufactures these machines with state-of-the-art equipment and
processes, and only sources the highest quality materials and components to ensure a long
life out of your investment.
Our one-of-a-kind design utilizes a variable volume, closed loop dual piston pump and a
remote-mounted muffler to allow for a fully enclosed power side end frame. This design
simplifies the system, reduces the number of components, and allows for easier maintenance
and clean-up every time you use the machine.
Loading/Unloading Your Machine
When loading and unloading your machines from a flat-bed or trailer, always use either the (4)
provided lifting-eyes with shackles and chains rated above the maximum weight of your
machine or the provided adjustable fork pocket assemblies.
The lifting eyes are attached to the extension frame and can be moved to adjust the picking
points for different length machines. The fork pockets can be adjusted by loosening the square
U-bolts. Always place the picking support bars or fork pockets at an equal distance from the
center of gravity of the machine.
Fork
Pockets
