MGE UPS Systems Galaxy 3000 User manual

Galaxy 3000
10-30kVA
Uninterruptible Power Systems
Installation and User Manual
www.mgeups.com

Galaxy 3000
10-30kVA
Installation and User Manual
Revision History
Galaxy 3000 10-3-kVA UPS Installation and User Manual
Revision: A00 Initial Release 05/01
A01 ECN 002152 08/01
A02 ECN 002271 10/01
B00 ECN 002473 03/02
C01 ECN 002565 02/03
C02 ECN 003280 05/03
C03 ECN 003507 08/03
C04 ECN 003723 01/04
C05 ECN 004064 10/04
Copyright © 2004 MGE UPS SYSTEMS, INC.
All rights reserved. Printed in U.S.A.
MGE UPS SYSTEMS, INC.
1660 Scenic Avenue
Costa Mesa, CA 92626
[phone]
Technical Support:
1-800- 523-0142 (during business hours)
Customer Care Center:
1-800-438-7373 (Hours: 24/7)
Galaxy 3000 10-30kVA
ii 86-172010-00 C05

Contents
Contents
i
86-172010-00 C05
section description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . .v
Safety of Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii
CAUTION: Record All Serial Numbers! . . . . . . . . . . . . . . . . . . . . . . .viii
Typographical and Symbol Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Section Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Quick Start
Getting Started with Galaxy 3000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—1
First steps by an on-site qualified Technical Engineer . . . . . . . . . . . . . . . . . . .QS—1
Final steps by MGE Field Service Engineer . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—1
Required Equipment and Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—1
STEP 1 Unpacking and Positioning . . . . . . . . . . . . . . . . . . . . . . . . . .QS—2
STEP 2 Connect the Main Utility Power . . . . . . . . . . . . . . . . . . . . . .QS—3
STEP 3 Connect the Output to the Distribution Panel (Load) . . . . . .QS—4
STEP 4 Call MGE UPS Systems for Field Engineer Service . . . . . .QS—4
STEP 5 Arrival of MGE Field Engineer . . . . . . . . . . . . . . . . . . . . . . .QS—4
Operator Interface Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—5
Quick Start Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—6
Section 1 Introduction
1.0 Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 1
1.1 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 1
1.1.1 Major Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 2
1.1.2 Galaxy 3000 Micro and Standard Cabinets . . . . . . . . . . . . . . . . .1 — 2
1.1.3 Preparation for Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 2
1.1.4 Cabinet Descriptions and Placement . . . . . . . . . . . . . . . . . . . . . .1 — 3
1.1.5 Cabinet Clearance and Environmental Requirements . . . . . . . . .1 — 3
1.1.5.1 Air Flow / Heat Rejection . . . . . . . . . . . . . . . . . . . . . . . .1 — 3
1.1.5.2 Recommended Operating Environments . . . . . . . . . . . .1 — 3
1.2 Cabinet Footprints and Electrical Entries . . . . . . . . . . . . . . . . . . .1 — 5
1.2.1 Conduit Plate Locations (top entry) . . . . . . . . . . . . . . . . . . . . . . .1 — 5
1.2.2 Conduit Plate Locations (bottom entry) . . . . . . . . . . . . . . . . . . . .1 — 5
1.2.3 Single Line Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 6
1.3 Preparation for Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 6

Galaxy 3000 10-30kVA
Contentsii 86-172010-00 C05
Section 2 Setup and Installation
2.0 Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 — 1
2.1 Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 — 1
Environmental Recommendations . . . . . . . . . . . . . . . . . . . . . . . .2 — 1
2.2 Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 — 2
2.2.1 Electrical Connections (UPS Module) . . . . . . . . . . . . . . . . . . . . .2 — 2
2.2.1.1 Main AC Input Connections . . . . . . . . . . . . . . . . . . . . .2 — 3
2.2.1.2 Bypass AC Input Connections (optional) . . . . . . . . . . .2 — 3
2.2.1.3 AC Output Connections . . . . . . . . . . . . . . . . . . . . . . . .2 — 3
2.3 Connecting Remote Emergency Power Off Cables . . . . . . . . . . .2 — 4
2.3.1 Connection of Relay Communication Card . . . . . . . . . . . . . . . . .2 — 4
2.4 Removing the Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 — 5
2.4.2 Characteristics of the Output Contacts . . . . . . . . . . . . . . . . . . . .2 — 6
2.4.3 Characteristics of the Input Contacts . . . . . . . . . . . . . . . . . . . . . .2 — 6
2.5 Check Points Before and After Start Up . . . . . . . . . . . . . . . . . . . .2 — 6
Section 3 Operation
3.0 Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —1
3.1 Preparing for Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —1
3.1.1 Pre-Start Up Safety Check List . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —1
3.1.2 Normal Start Up Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —2
3.1.3 Post Start Up Safety Check List . . . . . . . . . . . . . . . . . . . . . . . . . .3 —3
3.1.4 Normal Shutdown Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —3
3.2 Operator Interface Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —4
3.2.1 Screen Saver Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —5
3.2.2 Operational Summary Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —5
3.2.3 Main Menu Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —6
3.2.4 Battery Measurements Display . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —6
3.2.5 Power Measurements Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —7
3.2.7 Voltage Measurements Display . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —8
3.2.8 Frequency Measurements Display . . . . . . . . . . . . . . . . . . . . . . . .3 —8
3.2.9 Ratios Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —9
3.2.10 Mimic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —9
3.2.11 Status Displays Menu . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —10
3.2.12 Commands Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —10

Installation and User Manual
Section 4 Maintenance
4.0 Scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 —1
4.1 Servicing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 —1
MGE Warranty & Proprietary Rights for Single Phase Products
MGE Warranty
Proprietary Rights Statement
Warranty and Product Registration
User Information
Product information
Warranty Extension (Warranty+) not available on products
MGE Customer Care Center
Technical Support and Product Services
Who To Contact
Scheduling Field Service Engineer Support
Return Policy for Repair (RMA)
Glossary
Index
Reorder Form
Contents iii
86-172010-00 C05

Figures
figure description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page
QS-1: Pallet Mounting Configuration for the Galaxy 3000. . . . . . . . . . . . . . . . .QS—2
QS-2: Utility Power Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—3
QS-3: Terminal Blocks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—4
QS-4: Operator Input Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—5
QS-5: Bypass Switch Set to Bypass Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . .QS—6
1-1: Galaxy 3000 UPS Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 1
1-2: UPS Cabinet Showing the Airflow and Recommended Clearance. . . . . . .1 — 4
1-3: A Typical Configuration for Bottom Entry Knockouts and
Footprints for Galaxy 3000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 5
1-4: Galaxy 3000 UPS System - Single Line Diagram. . . . . . . . . . . . . . . . . . .1 — 6
2-1: Typical Power Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 — 3
2-2: Remove Cover Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 — 5
3-1: Bypass Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —2
3-2: Operator Input Panel Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —4
3-3: Screen Saver Movement within the
display indicates the unit is active. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —5
3-4: Operational Summary Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —5
3-5: Main Menu. 3 —6
3-6: Battery Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —6
3-7: Power Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —7
3-8: Current Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —7
3-9: Voltage Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —8
3-10: Frequency Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —8
3-11: Ratios. 3 —9
3-12: Mimic Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —9
3-13: Status Displays Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —10
3-14: Commands Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —10
3-15: Settings Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 —11
Tables
table description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page
1-1: Heat Rejection Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 — 3
2-1: Electrical Specifications for the Galaxy 3000. . . . . . . . . . . . . . . . . . . . . . . .2 — 1
2-2: Relay Contacts (communications card). . . . . . . . . . . . . . . . . . . . . . . . . . .2 — 4
Galaxy 3000 10-30kVA
Contentsiv 86-172010-00 C05

Installation and User Manual
v
86-172010-00 C05
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS – This manual contains important instructions for Galaxy
4000 that must be followed during operation and maintenance of the equipment.
WARNING Opening enclosures expose hazardous voltages. Always refer service to
qualified personnel only.
ATTENTION L'ouverture des cabinets expose des tensions dangereuses. Assurez-vous
toujours que le service ne soit fait que par des personnes qualifiees.
WARNUNG! Das öffnen der Gehäuse legen gefährliche Spannungen bloss.
Service sollte immer nur von qualifizierten Personal durchgeführt
werden.
WARNING As standards, specifications, and designs are subject to change, please ask for
confirmation of the information given in this publication.
ATTENTION Comme les normes, spécifications et produits peuvent changer, veuillez
demander confirmation des informations contenues dans cette publication.
WARNUNG! Normen, Spezifizierungen und Pläne unterliegen Anderungen. Bitte verlangen
Sie eine Bestätigung über alle Informationen, die in dieser Ausgabe gemacht
wurden.
NOTE This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at user's own expense.
WARNING To reduce the risk of fire or electric shock, install in a controlled indoor
environment free of conductive contaminants.
This equipment is intended only for installations in a RESTRICTED
ACCESS LOCATION.
ATTENTION Pour réduire le riske d'inccendie ou d'électrocution, installer dans une
enciente intérieure contrôlée en température et humidité et sans contaminants
conducteurs.
Ce matériel est destiné seulement pour des installations dans un
EMPLACEMENT RESTREINT D'ACCES.
WARNUNG! Um die Gefahr von Feuer und elektrischem Schock zu reduzieren, muss das
Gerät in einem temperatur - und feuchtigkeitskontrollierten Raum, frei von
leitungsfähigen Verunreinigungen, installiert werden. Dieses Gerät ist nur für
die Installation an einem Ort mit qeingeschränkter Zugangserlaubnis vorge-
sehen.
Diese Ausrüstung ist nur für Anlagen in einem
EINGESCHRäNKTEN ZUGRIFF STANDORT bestimmti.
Important Safety Instructions

Galaxy 3000 10-30kVA
vi 86-172010-00 C05
WARNING HIGH LEAKAGE CURRENT. Earth connection essential before
connecting supply.
ATTENTION COURANT DE FUITE ELEVE. Raccordement a la terre indispensable
avant le raccordement au reseau.
WARNUNG! Hoher Ableitstrom Vor Inbetriebnahme Schutzleiterverbindung
herstellen.
Certification Standards - Three Phase UPS
◗IEEE 587-1980/ANSI C62.41 1980 Standards for Surge Withstand Ability
◗FCC rules and regulations of Part 15, Subpart J, Class A
◗UL listed under 1778, Standards for Uninterruptible Power Supply Equipment
◗NEMA PE 1 (National Electrical Manufacturers Association) - Uninterruptible Power Systems
◗NEMA 250 (National Electrical Manufacturers Association)
– Enclosures for Electrical Equipment (1000 Volts Maximum)
◗NFPA 70 – National Electrical Code
◗ISO 9001
◗Occupational Safety & Health Administration (OSHA)
Certification Standards

Safety of Persons
◗The UPS has its own internal power source (the battery). Consequently, the power terminals may be energized
even if the UPS is disconnected from the AC power source.
◗The UPS must be properly grounded.
◗The battery supplied with the UPS contains small amounts of toxic materials. To avoid accidents, the directives
listed below must be observed:
- Never burn the battery (risk of explosion).
- Do not attempt to open the battery (the electrolyte is dangerous for the eyes and skin).
- Comply with all applicable regulations for the disposal of the battery.
- Batteries constitute a danger (electrical shock, burns). The short-circuit current may be very high.
Precautions must be taken for all handling: remove watches, rings, bracelets and any other metal
objects, use tools with insulated handles.
- Do not lay tools or metal parts on top of batteries.
Product Safety
◗Upstream protectioin must be installed and be easily accessible.
◗The UPS can be disconnected from the AC power source by opening the input protective devices.
◗UPS must be connected to a nearby power source that is easily accessible.
◗Never block the ventilation openings of the UPS.
◗The UPS must be installed in a controlled environment.
Special Precautions
◗The UPS connection instructions and operation described in the manual must be followed in the indicated order.
◗Check that the indications on the rating nameplate correspond to your AC powered system and to the actual
electrical consumption of all the equipment to be connected to the UPS.
◗Before and after the installation, if the UPS remains de-energized for a long period, the UPS must be energized
for a period of 24 hours, at least once every 3 months (for a normal storage temperature less than 25°C). This
charges the battery, thus avoiding possible irreversible damage.
Safety of Persons
Installation and User Manual
vii
86-172010-00 C05

viii 86-172010-00 C05
CAUTION: Record All Serial Numbers
CAUTION: Record All Serial Numbers!
RECORD ALL SERIAL NUMBERS FOR THE GALAXY 3000 AND ACCESSORIES.
THESE SERIAL NUMBERS WILL BE REQUIRED IF YOUR SYSTEM NEEDS SERVICE.
KEEP THIS MANUAL IN A PLACE WHERE YOU CAN REFERENCE THE SERIAL
NUMBERS IF SERVICE IS REQUIRED!
UPS SERIAL NUMBER: _______________________________________________________
BATTERY SERIAL NUMBER: ____________________________________________________
AUXILIARY SERIAL NUMBER: ___________________________________________________
ADDITIONAL SERIAL NUMBERS:
____________________________ ______________________________
____________________________ ______________________________
____________________________ ______________________________
____________________________ ______________________________
____________________________ ______________________________
____________________________ ______________________________
NOTES:
Galaxy 3000 10-30kVA

Typographical and Symbol Usage
Typographical conventions are designed for ease of use and location of information in procedures.
“< >” angle brackets and bolded text in procedures denote a prompt for User action:
For example: 1. After the selections are complete, click on the <Save> button.
Bold text indicates important names and titles related to the subject of the procedure.
For example: 1. Enter a new document name into the Name of File text field.
This manual uses four icon symbols with text to convey important information and tips.
WARNING Indicates information provided to protect the user and service
personnel against safety hazards and/or possible equipment damage.
CAUTION Indicates information provided to protect the user and service
personnel against possible equipment damage.
IMPORTANT Indicates information provided as an operating instruction, or as an
operating tip.
NOTE Indicates information provided as an operating tip or an equipment
feature.
Section Descriptions
Quick Start
This section is a quick start guide to unpack, setup, and make necessary connections before installation of the
Galaxy 3000 UPS.
1 Introduction
Provides a general description of the Galaxy 4000 systems intended use, major components, and environmental
and mechanical specifications.
2 Setup and Installation
Guides the user through tools and equipment required for unpacking and performing connections required for initial
installation. Included are the electrical specifications, environmental recommendations and connection details.
3 Operation
Provides startup, shutdown, and normal operation of the Galaxy 3000 UPS. Included are pre and post startup safety
checklists.
4 Maintenance
Describes maintenance and safety information on servicing batteries for the Galaxy 3000.
A Glossary provides definitions of abbreviations and terms used in this manual.
Typographical and Symbol Usage
Installation and User Manual
ix
86-172010-00 C05

(This page left blank intentionally)
Galaxy 3000 10-30kVA
x 86-172010-00 C05

Quick Start
Getting Started with Galaxy 3000
System Setup describes receiving and handling of the Galaxy 3000, a description of major components, the battery
cabinet, and definition of the control panel indicators, which includes electrical, mechanical and environmental
specifications.
MGE also recommends obtaining an MGE field service engineer for final installation and basic startup for single and
parallel units.
CAUTION Scheduling of the MGE Field Service Engineers typically should be
done 7 to 10 days before they are required on-site. If the startup
of the UPS is critical to maintaining your schedule, please call the
MGE toll free telephone number at
1-800-438-7373 for assistance.
The MGE Field Service Engineers will insure a quick installation
for the initial safe startup and configuration of your Galaxy 3000.
Final installation and start-up should be completed by a qualified MGE Field Service Engineer.
First steps by an on-site qualified Technical Engineer
Step 1. Unpack and position the unit.
Step 2. Connect the main (utility) power.
Step 3. Connect the output to the power distribution panel.
Final steps by MGE Field Service Engineer
Step 4. Call MGE and wait for the MGE Field Service Engineer to complete the installation.
Step 5. The MGE Field Service Engineer finalizes installation and the startup process.
Optional: Procedure for temporary power prior to the final startup.
Required Equipment and Tools
The following equipment and tools are recommended for on-site installation:
◗Digital volt meter (DVM)
◗1/8 inch slotted screwdriver
◗Pallet jack/forklift
◗Conduit installation tools
◗Nut driver set
Quick Start QS—1
86-172010-00 C05

STEP 1 Unpacking and Positioning
This section describes installation of the Galaxy 3000 10-30 kVA UPS, including receiving, handling, and storage
procedures; prerequisites to the installation; installation procedures; and start-up procedures.
Once the Galaxy 3000 UPS System has been inspected and received from the shipping courier, the unit should be
moved with the
use of a fork lift or pallet jack to a position as close to the final installation location as possible.
Figure QS-1: Pallet Mounting Configuration for the Galaxy 3000.
Installation should be performed by a qualified electrician and should conform to local and national
electrical codes.
Prior to any installation, the following items should be observed upon receipt of the Galaxy 3000 10-30 kVA UPS.
The casters on the unit will allow it to be positioned into the final installation location. At this point, the leveling legs
can be adjusted to provide a level and stable footing for the Galaxy 3000 UPS system. See Figure QS-1.
1) Inspect shipment for any damage prior to receipt. Damage claims should be filed directly with the courier.
Replacements for damaged components should be ordered through MGE Customer Support Services at 1-800-
438-7373.
2) Move equipment as close to the final location as possible using a pallet jack or forklift.
3) Once equipment is close to the installation location, and If configuration is optional pallet mount, remove the
Galaxy 3000 UPS from the shipping pallet using extreme caution when rolling the cabinet off the pallet as its
weight may exceed 500 lbs. See Figure QS-1.
4) All cabinets are equipped with casters allowing the equipment to be placed into final position. Push cabinets
very slowly into position to avoid any tipping hazard.
5) Once in position, adjust the leveling legs to provide a fixed and stable footing for the Galaxy 3000 UPS system.
6) At this point, the UPS system can either be prepared for operation, or for storage until such time as it may be
required for service.
Galaxy 3000 10-30kVA
Quick StartQS—2 86-172010-00 C05

Installation and User Manual
STEP 2 Connect the Main Utility Power
All Galaxy 3000 UPS systems provide the option for dual (redundant) utility power inputs. Whether the single or
dual inputs are selected, the connection of the utility feed is made to the same terminal block strip in the Galaxy
3000 UPS system.
From the diagram Figure QS-2 below, it can be seen that the main power feed to the Galaxy 3000 system should
be connected to the terminal blocks TB1 on the
right hand side of the strip. If a bypass AC source is available (and
the unit was specified to include a second AC source), this power should be connected
to the middle set of terminal
blocks TB3.
If the Galaxy 3000 system was specified for a second (bypass) AC source, but a separate power source is not
available, then jumpers should be installed from the primary AC source to the terminal blocks for the bypass AC
source.
NOTE The three phase power should be supplied as a Wye with a separate
neutral that will be connected to the input neutral busbar.
If the second (bypass) AC source if provided from a source other than
that of the main input, it is recommended to use isolation transformers
so that the neutral of both AC sources can be grounded to the same
potential.
Figure QS-2: Utility Power Connection.
Quick Start QS—3
86-172010-00 C05
UPS OUTPUT
(TB2)
(UTILITY2)
BYPASS INPUT
(TB3)
(OPTIONAL)
MAIN INPUT
CONNECTIONS
(TB1)
TERMINAL BLOCK
INPUT NEUTRAL
TERMINAL POST
1/4-20 X 3/4" DIA.
OUTPUT NEUTRAL
TERMINAL POST
1/4-20 X 3/4" DIA.
GROUND TERMINAL POSTS
(INPUT & OUTPUT)
1/4-20 X 3/4" DIA.
FRONT VIEW
BOTTOM ENTRY
CONDUIT PLATE

STEP 3 Connect the Output to the Distribution Panel (Load)
The Galaxy 3000 UPS system offers a standard 208 VAC output voltage. Optionally, a transformer can be provided
in an auxiliary cabinet that will provide 240 VAC, 480 VAC or 600 VAC for the output.
Figure QS-3: Terminal Blocks.
The output from either the Galaxy 3000 cabinet or from the external auxiliary transformer cabinet should be wired
to the existing power distribution panel, or to an appropriate power management panel.
The output from the Galaxy 3000 UPS system should be connected to the left most set of terminal blocks (see
Figure QS-3.).
STEP 4 Call MGE UPS Systems for Field Engineer Service
Call MGE Field Engineer Service support at 800 438-7373 to finalize the installation of the unit.
STEP 5 Arrival of MGE Field Engineer
The MGE Field Engineer will finalize the initial Galaxy 3000 UPS start-up. To insure a successful installation and
reliable UPS service, the MGE Field Engineer will verify all of the installation connections, fusing, and then will
examine the extensive set of Galaxy 3000 UPS personalization parameters to insure that the operation of the UPS
exactly matches your installation requirements.
Galaxy 3000 10-30kVA
Quick StartQS—4 86-172010-00 C05
UPS OUTPUT
(TB2)
MAIN INPUT
CONNECTIONS
(TB1)
INPUT NEUTRAL
TERMINAL POST
1/4-20 X 3/4" DIA.
OUTPUT NEUTRAL
TERMINAL POST
1/4-20 X 3/4" DIA.
FRONT VIEW
B
Y
P
A
S
S
N
O
R
M
A
L
TRANSFER
J3 J4
TB2 OUTPUT TB1 INPUT
KNOCKOUTS
(OPTIONAL)

Installation and User Manual
Operator Interface Panel
The Galaxy 3000 system is simple to operate and yet provides a wealth of continuous monitoring and diagnostic
features to insure the proper operation of the unit.
Operators gain access to information in the Galaxy 3000 system through the operator interface. This display panel
and keyboard is conveniently located on the front of the UPS cabinet see Figure QS-4.
Operator Interface - The Galaxy 3000 Operator Interface provides an easy to use method to access and control the
Galaxy features. Through the use of four (4) "soft" keys and four (4) dedicated purpose keys, the operators can
quickly move through the available displays, and control the performance of the unit.
Figure QS-4: Operator Input Panel.
Quick Start QS—5
86-172010-00 C05
OPERATOR
INPUT PANEL
GALAXY 3000
FRONT VIEW
?
!
!
Galaxy 3000
COLOR DISPLAY
(Screen Saver shown)
MAIN MENU KEY
LED INDICATORS
SOFT KEYS
1 = Scroll up
2 = Scroll down
3 = View Alarm messages
4 = Detail of Alarm message
ONLINE HELP KEY
INVERTER OFF/STOP KEY
INVERTER ON/START KEY
23 4
1
(
(
NOTE:SEE DETAILS OF OPERATOR PANEL IN SEXTION 3.3

Quick Start Notes
If AC power is required on site prior to the arrival of the MGE Field Engineer, the following procedure will provide
the AC power without powering the UPS. Any questions about this procedure contact the MGE Field Service
support line at 800 438-7373.
A. Insure that the Bypass Switch is in the BYPASS position.
B. Insure that the battery breaker, QF1, is open.
C. Close the input power breaker to energize the AC power.
D.
At this point, power will be available for site usage until the UPS is properly commissioned.
E. Upon arrival of the MGE Field Service Engineer, the main power must be disconnected so that a safe and
proper commissioning of the unit may be accomplished.
WARNING Do not, under any circumstance, rotate the switch to the TRANSFER or
NORMAL position, or close the battery breaker, QF1, until the unit has
been commissioned by an MGE Field Engineer.
Figure QS-5: Bypass Switch Set to Bypass Mode.
Galaxy 3000 10-30kVA
Quick StartQS—6 86-172010-00 C05
BYPASS
SWITCH
FRONT VIEW
N
O
R
M
A
L
B
Y
P
A
S
S
TRANSFER
J3 J4
TB2 OUTPUT TB1 INPUT

Introduction
1.0 Scope
Provides a general description of the Galaxy 3000 systems intended use, major components, and environmental
and mechanical specifications.
1.1 General Description
The Galaxy 3000 is the world’s first data center grade Uninterruptible Power Supply system designed specifically for
mid-range enterprise level applications. The Galaxy 3000 family consists of units available in power ratings from 10 -
30
kVA, and are optimized for compatibility with nonlinear computer-type loads.
By incorporating the Ultra High Availability Topology (UHAT), the Galaxy 3000 family of UPS systems are designed
to provide the optimal level of reliability and to react to any power disturbance in an inherently safe way to protect
the critical load. The Galaxy 3000 all-in-one design incorporates every feature into one compact cabinet, including
a graphical user interface, power factor corrected input, batteries, and communication cards that support network
based power management.
The Galaxy 3000 UPS and its auxiliary equipment are designed for installation in a room where humidity and temper-
ature can be controlled. The recommended and maximum environmental parameters are listed in Appendix A,
Specifications, of this document.
The Galaxy 3000 UPS and auxiliary equipment is listed for safety by Underwriters Laboratories, Inc. (UL) under UL
Standard 1778 - Uninterruptible Power Systems; and also listed by Underwriters Laboratories (CUL) under
Canadian Standards Association (CSA) standard C22.107.
Figure 1-1: Galaxy 3000 UPS Systems.
1 — 1
86-172010-00 C05 Introduction

1.1.1 Major Components
Rectifier Converts AC input voltage to DC voltage. The rectifier uses IGBT (Insulated
Gate Bipolar Transistor) power transistors and a Pulse Width Modulated (PWM)
technique to provide input power factor correction and to minimize any harmonic
reflected onto the input power lines.
Inverter Converts DC voltage from the rectifier or from the batteries into AC output voltage
to maintain the attached load. This module uses the IGBT technology to provide
digital power quality.
Static Switch Automatically supplies the attached load from the bypass source when the inverter
is off.
Battery System Stores energy for utilization by the inverter and attached load in the event that utility
AC power is lost or is of unacceptable quality.
1.1.2 Galaxy 3000 Micro and Standard Cabinets
The Galaxy 3000 UPS system is available in two different cabinet sizes, the Micro cabinet and the Standard cabinet.
Dimensions for the cabinets
are:
◗Micro cabinet: 48.6in (1234.4) H x 23.0in (584.2) W x 38.1in (967.7) D
◗Standard cabinet: 62.5in (1587.5) H x 32.8in (833.12) W x 40.1in (1018.5) D
Both cabinets are designed to provide for top and bottom entry of the utility power feed. The Micro cabinet is
typically supplied assuming bottom entry only.
Operating internally on 208 VAC, the Galaxy 3000 UPS system can be purchased to accept 208 VAC, 220 VAC,
480 VAC, or 600 VAC utility feed with the use of an internal input transformer contained in a Standard cabinet. The
Micro cabinet was designed to provide all of the features of the Galaxy 3000 system in the smallest possible
enclosure. Without an auxiliary cabinet, the Galaxy 3000 system in a Micro cabinet provides only 208 VAC input
and 208 VAC output.
An output voltage of 208 VAC is standard with the Galaxy 3000 and does not require any additional cabinetry. If
output voltages of 240 VAC, 408 VAC or 600 VAC are required, an auxiliary cabinet is required for the output
transformer.
The complete list of additional cabinets that could be included with your Galaxy 3000 system are: External
Maintenance Bypass cabinet, extended battery cabinet, and distribution cabinets.
1.1.3 Preparation for Operation
Several items must be considered when preparing the Galaxy 3000 UPS system for operation.
First – The UPS cabinet and its auxiliary cabinets must be arranged in the required configuration to insure that the
interconnection cables are located in the correct adjacent cabinets.
Second – The cabinets must be in a location that provides for proper air flow and heat rejection.
Third – The room in which the Galaxy 3000 UPS system is located must maintain environmental conditions within
recommended tolerances
Forth – All electrical connections must utilize the top or bottom conduit entries provided.
The following sections discuss in more detail these items.
Galaxy 3000 10-30kVA
Introduction1 — 2 86-172010-00 C05
