INTRODUCTION
4/ 22
Y500-1500_usermanual_engl_updated_202001.docx
1. Introduction
ONLINE USV-Systeme AG (ONLINE) is one of the leading manufac-
turers of uninterruptible power supplies (UPS). Since 1988, the Ger-
man company has focussed on the development, production, sale and
support of UPS systems. Based on unit numbers sold, ONLINE prod-
ucts are the German number one in the UPS market and internation-
ally recognised because of their top quality and excellent support.
The power supply often fails when you least expect it. There can also
be significant fluctuation in the quality of the power supply. Network
problems can lead to the destruction of critical data, data which is not
backed up can be lost and hardware damaged. This means expensive
repairs and downtime.
With models from the YUNTO series from ONLINE, you are perfectly
prepared for such eventualities. YUNTO protects sensitive applica-
tions from data loss and operating downtime, whether they are price-
sensitive entry servers or high-end PCs, telephone systems, network
peripherals or NAS boxes.
YUNTO offers the following advantages:
•Compact design
•Silent operation
•Cold start function, starts the UPS system without network volt-
age
•Intelligent battery management, self test and fast charge func-
tion
•Surge protection for data and telephone wires
•Alarm function
•USB interface
•Built-in wall mount
•Inc. shutdown, management and monitoring software, Da-
taWatch to download for all operating systems
•2 years warranty incl. battery and 24h advance replacement

INTRODUCTION
5/ 22
Y500-1500_usermanual_engl_updated_202001.docx
Figure1: YUNTO 500 - 800
Figure 2: YUNTO 1200 - 1500

SAFETY WARNINGS
6/ 22
Y500-1500_usermanual_engl_updated_202001.docx
2. Safety warnings
This manual contains important instructions that you must follow dur-
ing the installation and maintenance of the UPS system and the bat-
teries. Please read all the instructions in the manual before working
with the device. Keep the manual in a safe place.
CAUTION
•The UPS system carries life-threatening voltages. All repair
and maintenance work must be carried out by customer ser-
vice personnel.
•The UPS system has its own energy source (batteries). The
output of the UPS system can be live even when the UPS sys-
tem is not connected to a wall outlet.
•In order to reduce the risk of fire or electric shock, the UPS
system may only be installed in buildings with controlled tem-
perature and air humidity in which there are no conductive
contaminants. The ambient temperature must not exceed
40°C. The UPS system must not be operated near water or in
extremely high air humidity (>90%).
•Before transporting the UPS system, make sure that it is dis-
connected from the power supply and switched off.
•Batteries can pose a risk of electric shock or catch fire as a
result of high short circuit current. Please take the necessary
precautionary measures. Maintenance must be carried out by
qualified personnel who are trained in handling batteries and
have good knowledge of the necessary precautionary
measures, see Chapter 6 Maintenance. Keep unauthorised
personnel away from batteries
•Batteries must be disposed of properly. Local regulations must
be taken into consideration.
•Batteries must not be burnt. There is risk of explosion.

INSTALLATION
7/ 22
Y500-1500_usermanual_engl_updated_202001.docx
3. Installation
3.1 Checking the delivery
Keep the transport box and the packaging material for the carrier or
sales point. If parts of the system have been damaged in transit, sub-
mit a transport damage complaint to your supplier within 24 hours. If
you only discover damage after accepting the device, please submit a
complain for concealed damage.
3.2 Unpacking the UPS system
CAUTION
Unpacking the UPS system at a low ambient temperature can
lead to the formation of condensation inside and outside the
casing. Only install the UPS system if the inside and outside
are completely dry (risk of electric shock).
PLEASE NOTE
Move and open the packaged UPS system carefully. Leave
the components in their packaging until they are installed.
To unpack the UPS system and accessories:
1. Open the external box and take the accessories packed with
the UPS system out.
2. Carefully lift the UPS system out of the external box.
3. Place the UPS system in a protected, adequately ventilated po-
sition which is free of humidity, flammable gasses and corro-
sion.
4. In order to avoid interference with other devices, make sure to
maintain a clearance of at least 20 cm.

INSTALLATION
8/ 22
Y500-1500_usermanual_engl_updated_202001.docx
3.3 Checking the accessories
Description
YUNTO 500
YUNTO 800
YUNTO 1200
YUNTO 1500
USB interface cable
1
1
1
1
10A power extension cable
2
2
2
2
Quick start guide
1
1
1
1
DataWatch software*
Manual*
*Download from www.online-ups.com
Table 1: Package contents
3.4 Installation and setup
The UPS system is delivered fully assembled.
CAUTION
Make sure that the overall rated performance of the load
connected does not exceed the capacity of the UPS system.
The power consumption of inductive loads or laser printers
can be very high, please take this into consideration when
specifying your UPS system.
1. Connect the load with the UPS system without switching them
on.
2. Connect the mains connection cable for the UPS system into a
socket.
3. Press the button on the UPS system until a short beep
sounds and the status LED lights up.
4. The UPS system is now operating in normal mode and supply-
ing the load with reliable power.
5. Switch the loads on one by one.

INSTALLATION
9/ 22
Y500-1500_usermanual_engl_updated_202001.docx
PLEASE NOTE
The internal batteries charge up to 90% of their full capacity in
less than eight hours. ONLINE recommends charging the bat-
teries for 48 hours after installation or extended periods of
non-use.
The battery charging starts as soon as the UPS system is con-
nected to the supply network and switched on.
Starting in battery mode
1. Press the button on the UPS system until a short beep
sounds and the status LED lights up.
2. The UPS system is starting, the display then shows the battery
statues (see Chapter 4 Battery statuses) and supplies the loads
connected with reliable power.
3. If the display is lit, fix all warnings (see Chapter 7 Trouble-
shooting) and restart the UPS system.
Switching off
1. Press the off switch on the UPS system. The UPS system
switches off.
2. Disconnect the mains connection cable of the UPS system from
the socket.

FUNCTIONS AND CONTROLS
10 / 22
Y500-1500_usermanual_engl_updated_202001.docx
4. Functions and controls
Together with the beeps, the LEDs on the front of the device indicate
the operating status of the UPS.
Figure 3: Control panel and display
Switch / LED
Function
Alarm
Switch on/off
Normal operating mode:
Green LED permanently lit
Battery mode:
Green LED flashes every 10 sec-
onds
Every 10 seconds
Battery voltage low:
Green LED flashes every second,
red LED permanently lit
Every second
Error:
Red LED permanently lit
Continuous tone
Temperature too high:
Red LED flashes every 0.5 seconds
Table 2: Descriptions of display

COMMUNICATION AND INTERFACES
11 / 22
Y500-1500_usermanual_engl_updated_202001.docx
5. Communication and interfaces
5.1 USB interface
In order to establish communication between the UPS system and a
computer, connect the computer using a suitable data cable (cable
provided) to the USB interface on the UPS system (see Chapter 9.2
Rear view).
The UPS system can then exchange data via the DataWatch software
(see Chapter DataWatch software).
5.2 Surge voltage protection for data and telephone
lines (DSL / telephone / fax / network)
The surge protection filters surge voltage from the data and telephone
cables. This involves connecting the incoming cable to the IN connec-
tion on the reverse of the UPS system. Connect the OUT connection
to the end device. The data connection protection cable protects net-
works with a transfer rate of 10 to 1000 Mbit/s.
5.3 DataWatch software
The YUNTO series is supplied as standard with DataWatch, the com-
prehensive software solution for shutdown and management of the PC
or server system and for monitoring the YUNTO and the power supply
network. To ensure you are always working with the latest version of
DataWatch, please download it from the download area of
www.online-usv.de.
DataWatch works in the background and is in constant communication
with the YUNTO via the USB protocol. The most famous of all func-
tions: Automatic data backup including the shutdown of running appli-
cations and the proper shutdown of the whole system by means of a
freely configurable shutdown routine. At the same time, DataWatch
has a comprehensive messaging system, time-controlled test routines
and event logging.
DataWatch supports all current operating systems.

COMMUNICATION AND INTERFACES
12 / 22
Y500-1500_usermanual_engl_updated_202001.docx
As a client/server application, DataWatch works in networks and on
local workstations. Based on optional RCCMD agent (Remote Con-
sole Command), multiple servers connected to a UPS system can be
addressed and controlled across the network without additional hard-
ware.

MAINTENANCE
13 / 22
Y500-1500_usermanual_engl_updated_202001.docx
6. Maintenance
6.1 Care and maintenance
To ensure a long service life of the system, the area around the UPS
system should be kept clean and free of dust. If the area around the
system is very dusty, clean the external surfaces of the system with a
vacuum cleaner.
To ensure a long service life for the batteries, the ambient temperature
should not exceed 25°C.
PLEASE NOTE
•Before transporting the UPS system, make sure that it is dis-
connected from the supply network and switched off.
•The service life of a battery varies as a function of how often it
is used, intensity of use and ambient temperature. Batteries
which are used beyond their expected service life often have
reduced autonomy times. Replace the batteries in good time
to ensure the system always runs at optimum performance.
6.2 Storage
If you intend to store the UPS system for an extended period, charge
the battery every three months by connecting the UPS system to the
supply network for five hours. The system should be stored in a cool,
dry place.
6.3 Replacing the batteries
PLEASE NOTE
Do not replace the batteries while the UPS system is in battery
mode.
To replace the batteries, the UPS system bust be switched off, discon-
nected from the power supply and opened. Batteries cannot be hot-
swapped.

MAINTENANCE
14 / 22
Y500-1500_usermanual_engl_updated_202001.docx
CAUTION
•Maintenance work must be carried out by a qualified techni-
cian who is familiar with batteries and the necessary safety
measures. Do not allow unauthorised personnel to handle the
batteries.
•Batteries pose the risk of an electric shock or injury due to high
short circuit current. Take the following safety measures:
oremove watches, jewellery and other metal items
oonly use tools with insulated handles
odo not place tools or metal components on the batteries
•The batteries must only be replaced with the same number of
batteries of the same type.
•Batteries must be properly disposed of. When disposing of
batteries, comply with the statutory regulations applicable in
your location.
•Batteries must not be burnt. There is risk of explosion.
•Do not open or damage the battery or batteries. Battery acid
can damage the eyes and skin and cause poisoning.

MAINTENANCE
15 / 22
Y500-1500_usermanual_engl_updated_202001.docx
CAUTION
•DANGER OF ELECTRIC SHOCK. Never make changes to
the battery cabling or connections. Attempting to change the
battery cabling yourself could lead to serious injury.
•The batteries of the UPS system are very heavy. Be careful
when handling heavy batteries.
6.4 Disposing of the old batteries or UPS system
Find out from a local recycling centre how the old batteries or the UPS
system should properly be disposed of. Old batteries can also be re-
turned to ONLINE for disposal free of charge. Please contact Support
(see Chapter 8 Support).
CAUTION
•Batteries must not be burnt. There is risk of explosion.
•Batteries must be disposed of properly. Find out about the lo-
cal disposal regulations.
•Do not open or damage the battery or batteries. Battery acid
can damage the eyes and skin and cause poisoning.

TROUBLESHOOTING
16 / 22
Y500-1500_usermanual_engl_updated_202001.docx
7. Troubleshooting
The YUNTO is designed for autonomous operation and automatically
reports any problems in the display.
Operating status
Possible cause
Measure
No LED display on the
front panel.
The battery capacity is
too low.
Charge the battery for at
least 8 hours.
The battery is worn
through age or faulty.
Replace the battery (see
Chap. 6.3).
The UPS system is not
switched on.
Press the ON button.
Permanent alarm beep
and red LED while
mains voltage is availa-
ble.
The UPS system is over-
loaded.
Check whether the total
load exceeds the capac-
ity of the UPS system.
Reduce the load as re-
quired.
Error
Contact ONLINE support
(see Chapter 8).
Alarm sounds every 2
seconds while network
voltage available.
The battery is worn
through age or faulty.
Replace the battery (see
Chap. 6.3).
Charger faulty.
Contact ONLINE support
(see Chapter 8).
Autonomy time is shorter
than expected.
The UPS system is over-
loaded.
Check whether the total
load exceeds the capac-
ity of the UPS system.
Reduce the load as re-
quired.
The battery capacity is
too low.
Charge the battery for at
least 8 hours.
The battery is worn
through age or faulty.
Replace the battery (see
Chap. 6.3).
LED flashing with normal
network voltage.
Mains cable not con-
nected properly.
Check the mains cable
and connect it properly.
Table 3: Troubleshooting

SUPPORT
17 / 22
Y500-1500_usermanual_engl_updated_202001.docx
8. Support
ONLINE USV-Systeme AG (ONLINE) is one of the leading manufac-
turers of uninterruptible power supplies (UPS). Since 1988, the Ger-
man company has focussed on the development, production, sale and
support of UPS systems. Based on unit numbers sold, ONLINE prod-
ucts are the German number one in the UPS market and internation-
ally recognised because of their top quality and excellent support.
As a German provider, ONLINE guarantees direct approachability,
simple processing and short response times. Comprehensive support
is a matter of course - before and after purchase.
ONLINE sets great store by reliable support and service.
•Free direct advice and support on:
Software hotline: [phone] - 13
Hardware hotline: [phone] - 18
•Free 24 h advance exchange
•Interactive UPS configurator online or as app
•2 years full warranty, optional renewal
•Unbureaucratic 14 day money-back guarantee
•Excellent product availability and wide network of distributors.
Further information: www.online-usv.de

TECHNICAL DATA
18 / 22
Y500-1500_usermanual_engl_updated_202001.docx
9. Technical data
9.1 Specification
Model
YUNTO
500
YUNTO
800
YUNTO
1200
YUNTO
1500
Order no.
Y500
Y800
Y1200
Y1500
Electrical characteristics
Rated power (VA / W)
500 / 300
800 / 480
1200 / 720
1500 / 900
Input voltage and toler-
ance in normal mode
230V (180 –270V)
Frequency
50 / 60Hz (automatic detection) +/-5Hz
Max. input current
3.3A
5.2A
7.8A
9.7A
Cold-start function
Yes
Output voltage
230V +/-10%
Output frequency
Battery operation
50 / 60Hz +/-1Hz
Wave form
Simulated sine
Efficiency,
Normal operation
>95%
Battery mode
70%
Power loss, max.
15W
24W
36W
45W
Connections
Input
1x IEC320 C14 (10A)
Outputs, 10A
3x IEC320
C13 (10A)
3x IEC320
C13 (10A)
5x IEC320
C13 (10A)
5x IEC320
C13 (10A)
Batteries
Typ. Autonomy times at
50 and 100% load and
pf=0.6
6 / 3
6 / 2.5
6 / 3
6 / 2.5
Battery type
1x 12V /
7Ah
1x 12V /
9h
2x 12V /
7Ah
2x 12V /
9Ah
Design
Sealed, maintenance-free, valve-controlled,
lead/acid, life expectancy 3 to 5 years in accordance
with EUROBAT
Charge current
0.5A
Charging time
< 8 hours to 90%
Communication
USB
Yes
Modem / Network
Over-voltage protection
Yes

TECHNICAL DATA
19 / 22
Y500-1500_usermanual_engl_updated_202001.docx
Operating conditions, standards and approvals
Operating temperature
0 - 40°C
Storage temperature
-15 - 50°C
Rel. air humidity
0 –90%
Noise level
silent
Safety
EN62040-1: 2008 +A1: 2013
EMC, Performance
EN62040-2: 2006
Approval
CE
Protection class
IP20
Dimensions / Weight
Dimensions (W x H x D)
80.1 x 177.5 x 232
90.9 x 238.7 x 282
Weight
3kg
3.5kg
5.4kg
6.3kg
Table 4: Specification

TECHNICAL DATA
20 / 22
Y500-1500_usermanual_engl_updated_202001.docx
9.2 Rear view
Figure 4: Rear view of YUNTO 500 - 800
Figure 5: Rear view of YUNTO 1200 - 1500
