Mi Dong Electronics Urive Green HD User manual

〉Customer Service: Product Inquiry: 1644-3880
A/S: 070-7425-0610
〉Product name: Car blackbox
〉Model name: MD-6900P
〉Sales/manufacture: Mi Dong Electronics & Telecommunication Co., Ltd.
User’s manual
This is an auxiliary product for safe driving.
The Manufacturer is not held responsible for liability arising from an accident. Use the product in
accordance with the intended use.

0. Before using the Urive Green HD 3
1. About the product 4
2. Cautions before using 5
3. Notice 6
4. Product features 7
5. Features 8
6. Part names and functions 10
7. Product information for screen saver icons 11
8. Upgrade 12
9. Components 15
10. Pin arrangement of each terminal 16
11. Installation precautions 17
12. Installation of Urive Green HD 18
13. Installation of external camera 19
14. Installation of the viewer 29
15. Execute and remove the viewer 30
16. Description of the viewer main screen 31
17. Viewer buttons 32
18. Black-box configuration 35
19. File open and play 39
20. Playlist creation and SD format 40
21. Tracking the driving record 43
22. Full-screen view 45
23. View recorded files information 46
24. Recorded data 47
25. Number of Saved Files & Storage capacity 48
26. Product Specifications 49
27. Warranty 50
28. Terms of Consumer damage compensation 51
29. Before requesting for A/S 52
30. Pre-fault diagnosis 53
Content
2

3
0. Before using the Urive Green HD…
URIVE Green HD is atrademark belonging to MI DONG ELECTRONICS &TELECOMMUNICATION CO.,
LTD.
All contents of this Manual and publications of the manufacturer are protected by intellectual property
rights.
All other trademarks quoted in this Manual are the properties of their respective owners.
All rights to the program are vested in the manufacturer and protected by the copyright laws.If this
program is unlawfully modified, created and distributed without prior written consent of the
manufacturer, the offender shall be punished with imprisonment for aperiod not exceeding five years
and liable on conviction to afine not exceeding $50million in accordance with the applicable software
copyright laws.
Some changes can be made to Urive Albatross for further improvement without any notice to users.
Some images used in this manual may look different depending on the printing state and the actual
color of the screen
Please use this product safely after reading this manual carefully.
Contents of this Manual may change without prior notice.

1. About the product
This product is a touch screen automotive black box with LCD. It is used to save the front and
rear video images of the vehicle with sounds together when there is an accident or severe
impact. It can help to provide evidences in the accident analysis.
Please follow the manual below for installing and using this product.
The manufacturer shall not be liable for product failures or damages due to misuse, incorrect
installation or unauthorized alteration.
The Urive Albatross PC viewer program can be run with Window XP/Vista/Windows 7.
The product and manual can be changed for further improvement without any notice to users.
All rights of the software and hardware related to this product are vested in the manufacturer.If they
are unlawfully reproduced, modified and distributed, aperson who did the actions shall be subject to
damages by civil action and criminal penalty in accordance with applicable intellectual property rights
laws.
Please do not operate this device and touch the LCD during the driving for safety.
This is an auxiliary product for safe driving.
The manufacturer is not held responsible for liability arising from an accident. Use the product in
accordance with the intended use. 4

2. Cautions before using
Warranty and Limited Liability
-This Product is asupplementary device for your safe driving.The manufacturer shall not be liable for any
loss or damage caused by product failure, data loss or use of the Product.
-The Product is used to record and save video images outside an automobile.Some functions may not be
available depending on the driving or vehicle’s environment.Performance of the Product may also vary as the
firmware will be updated from time to time for further improvement. In some cases, recording may be
disabled under certain user environment. Therefore the Product should only be used as reference.Recording
may also be disabled under certain SD card status.
-Although this product can save and record video images of the vehicle’s accident, the manufacturer does
not guarantee that all accidents are recorded by the product.Accidents caused by tiny impact can not
recorded as the event video image when the motion sensor does not work.
◆Caution in Use of SD Memory Card
-Data should be checked once aweek to ensure normal operation of the Product.
-The SD Memory Card should be formatted at least twice amonth to ensure reliability.
-Use of SD Cards exclusive for Urive is recommended. (contact us at the time of purchase)
-Please be careful to pop out the Micro SD card, when you install or remove it.
In general, memory cards are valid for a certain period of time (warranted for 6 months) and therefore
storage of new data may be disabled if the card had been in use for a long time. If this is the case, replace
with a new card as the manufacturer is not liable for data loss.
The latest data may be lost if the Memory Card is removed or power is turned off during recording. The
manufacturer is not liable for such data loss. Please save important data in a separate backup storage. 5

3. Notice
Warning. Ignoring this warning could cause serious injury or even death
This Section is for your safety and proper use of the Product to prevent safety accidents/risks. The
manufacturer shall not be responsible for troubles caused by use of the Product in violation of the
instructions.
If the Product is wet, do not place it in the heater or in
the microwave oven to dry.
It may cause explosion, deformation or product failure which is
not covered under the warranty.
Do not alter or impact on the Product.
Unauthorized alteration or product damage by impact shall not be
covered under the warranty..
Do not use chemicals (such as benzene, thinner,
alcohol) or detergent to clean the Product.
It may cause fire..
Do not install or operate the Product while driving.
Operation of the Product while driving can cause accidents. Pull
over to a safe spot to operate the Product..
Watch out for memory cards and removable.
Uncertified Micro SD card may not be recorded properly.
Please remove the power cable before inserting or
removing the SD Card
Please do not use sharp devices on the LCD.
The touch panel or LCD may be damaged by sharp devices
when the black box is set up with them on the LCD.
If the Product is directly connected to the car, do
not use the product for an extensive period of time.
It may discharge the battery.
Make sure that the double-side adhesive tape is
firmly affixed during installation.
The Product may show poor performance by over time
moving or motor vibration.
Install the Product in unaffected area by the
Navigation or HIPASS device.
Reflections of images of Navigation or HIPASS may cause
poor recording quality.
Keep the windshield clean.
Foreign materials may prevent normal recording of images..
Take extra care during installation of the
external camera.
Color of the coating on the rear windshield may impair
the recording quality.
Back up files periodically.
When the SD Card is full, the oldest file in the Card will be
overwritten by a new file. Please back up data periodically to
prevent unwanted data loss.
Caution. Ignoring this caution could cause injury or damage to property
6

Key features
-Constant Recording : Rear and front images are saved onto the Black Box folder as long as power is connected.
-Event Recording : Upon detection of predetermined degree of impact or press of the forced recording button, total 20
seconds long video file which are 10 seconds for the front and 10 seconds for the rear of the event is saved in the Event
Folder.
-Images in the Parking mode : When power stays on and upon detection of motion, a video file of 20 seconds long
(10 seconds for the front and 10 seconds for the rear of the event ) is saved in the Parking event Folder.
: A slight impact is also detected and saved.
: The Parking Mode is released upon detection of low voltage (to prevent battery discharge).
-Back-up Save :As an internal back-up function, the latest file is saved on occurrence of power interruption.
-Video Playback : Video files can be replayed on Navigation (if fitted with the video playback function) (Some Navigation
products may not be compatible.)
-Memory card auto format : Users can directly format SD card by a button.
-Exclusive PC Viewer: Through the exclusive Viewer, the degree of impact, speed or positioning at the time of accident
can be analyzed. (The positioning information is only available with the optional GPS module)
-Driving Info Recording : Driving date, time and mileage are recorded, and driving paths can be tracked via the Viewer.
(The Driving recording function is only available with the optional GPS module)
Product information
-HD 2chennals LCD black box : The Product enables the 2ch saving function (the front and rear images) when
connected to the external or rear camera.
-Constant, event, force, parking recording /image storage: it has not only the base faction of black box but also
images saving and parking recording.
4. Product features
7

8
Sharp Picture and wide field of view for recording of high definition images
Green HD can record any accidents in clear images and security images with extremely high resolution (front:
1280x720/ rear: 640x480) and wide angle(front: 120°/ rear: 120°) of camera in the parking lot day and night.
Constant Recording
All images during driving are continuously recorded in a series of one-minute video files.
Event (Impact) Recording
On occurrence of external impact during recording in the constant mode, accurate detection using the 3-axis
acceleration sensor is made based on the set impact value saving the real-time images in the Event Folder. A 30 second
long (10 seconds prior to the impact plus 20 seconds post the impact) video file saved in the Event Folder.
Manual recording
If users push the “image storage” button at the Screen Setting in the main menu, Urive Albatross save 30 second
long (10 seconds prior to the impact plus 20 seconds post the impact) video images as an event(impact) in the
Event folder.
CCTV for your own car protection, recording in the parking mode
Urive Albatross enables detection and recording of motions (that may be associated with damages and losses) while the
vehicle is in the parking mode.
images storage
Urive albatross can store the front and rear images by only one touch at the LCD during the Constant Recording mode.
Auto memory management
Even if the memory is full, the Product enables constant recording of images by auto-deleting of old files and overwriting
with new files in chronological order.
5. Features (1)

9
2ch Black Box for simultaneous Front and Rear monitoring
-Urive GreenHD facilitates the Black Box function; the Main Body of Urive Green is used to record the front side,
and at the same time the external camera fitted inside the car is used to record the rear side..
Recording data checking with exceptional PC viewer
when the users play the stored video images with PC viewer, it can show the front and rear video
images at the same time with lots of information for their driving conditions.
Real-time Video Monitoring during Recording
When the Black Box and the AV-in terminal on Navigation are connected by the video cable, real-time video
can be monitored on the Navigation screen. The Product enables easy and simple installation of the Black Box
at the most suitable position at the desired angle.
Power ON/OFF switch
Built-in Battery Discharge Protection and timer setting up
Urive GreenHD is fitted with a device that prevents battery discharge during constant power use.
When the voltage becomes low during recording in the parking mode to the set cut-off voltage, power on Black Box is
automatically cut off so as to prevent consequential battery discharge. Users can choose the one step among 4steps of
cut-off voltage and timers to set up them.
.
5. Features (2)

10
SD Card insertion part
3.0Mega Camera
Forced Recording /Rear
Video Output/ Mute Button Power ON/OFF switch
Connection of GPS
Module
Connection of Power Cable
Connection of
External Camera
Connection of Video
Output
Hole for Mount
RED/GREEN LED
(Recording/GPS)
Parking Monitoring LED
(Blue)
6. Part names and functions

7. Operation and Buttons on the Product _(1)
Control Conditions LED sign Sounds
Power on After the booting RED LED is turned on during it’s booting
then It is turned off after booting Beep~~~ 1 long sound
Update Update through SD Card
RED LED is turned off during update and
then GREEN LED turned on when the update
finished. And then rebooting by itself
2 short sound In the start
2 short sound in the end
Parking monitoring mode 20 seconds video recording by the front
and rear Motion / shock Detection
-Monitoring: Flashing BLUE LED 1-second
intervals
-Video recording by Motion/shock detection
: BLUE LED blinks rapidly
-
Power OFF from Cigarette
connection After saving the last video image by using a backup battery, Power off - -
Mode Conditions Main supply LED Siegen Sounds
Driving
mode (Vehicle) Turn ON Cigar cable
Or
Fuse cable
Regular recording(during driving) : RED
LED blinks with the interval of 1 second
Event recording: RED LED quickly blinks
(But, GREEN LED will blinks when GPS is
connected)
Beep~~~ 1 long sound
Parking
monitoring
mode (Vehicle) Turn OFF FUSE cable (3pole) only Monitoring : BLUE LED blinks with the
interval of 1 second
Recording : BLUE LED quickly blinks
Beep~~~ 1 long sound
when a mode is changed
Operation information
Note) No voice recording (=Mute) :LED blinks with the interval of 3 second
Functional Description
11

Button Operation Status LED display Alarm
Power switch ON Supply power - -
OFF Power OFF - -
-Apply power After booting, The RED and BLUE LEDsblink with the interval
of 1 second Beep~ long
GPS Operation Blink the GREEN and BLUE LEDs
REC button
Push for 1 second Start emergency (forced) recording The RED LED quickly blinks
Short 2 beep when it start a
recording
Short 1 beep when it finish a
recording
Push for 3 seconds Voice recording on/off
(Mute Off/On)
Regular recording mode: RED LED blinks with
the interval of 3second
(But, GREEN LED will blinks every 3 seconds
when GPS is connected)
Parking mode: BLUE LED blinks with the
interval of 3second
Short 2 beep
Press long
(Longer than 10
seconds) Format the micro SD card Blink the GREEN LED brinks
and operate again when the format is
completed
Start format: Beep~ long
End format: Beep~ long
-Update Update using the micro SD card The RED and GREEN LEDs alternatively blink and operate after rebooting when the update is
over
The beep sounds long in the
beginning and shortly beeps
in the end
-GPS input GPS Operation the GREEN blinks -
-Parking monitoring
mode
Recording 20sec. By Front/Rear motion and
check detection(before and after the
detection: 10sec. each)
Monitoring: BLUE LED blinks with the interval
of 1 second
Recording: BLUE LED quickly blinks
-Pulling off the power
terminal
Store the last video using the backup
battery
and turn off the set power. Turn off all the LEDs -
7. Operation and Buttons on the Product_(2)
12

[How to auto-upgrade]
1. Users can install the upgrade files from Albatross Viewer in user’s PC to a memory card.After connecting Micro SD card with
PC, Push the button at the top of the left in the Viewer
2. Check the firmware version at the Urive Albatross program information window. And then formatting the memory card in the
PC or Viewer.(But after formatting, users cannot check the firmware version.)
3. Check the driver’s location which is connected with memory card at the Urive Albatross program information window.
4. After pushing the update button, the upgrade files (MD6900P_app.bin, MD6900P_boot.bin, MD6900P_memInfo.bin)
5. save automatically at the memory card.(in case of showing the Windows safety warning window, Please check the NOTICE.)
8. Upgrade (1)
1 2 3
45
6
13

[How to auto-upgrade]
[NOTICE ]After Pushing the update button, if users can show the windows safety warning window as below, users should
push the ‘Unblock’ button.when users push the ‘Keep Blocking’button, auto-update would be failed cause of
windows safety issue.
5. After turning off the black box ,Install the Micro SD card to Albatross main body.
6. Black box power on and then the Upgrade will be progressing showed firmware upgrade image on the display with two
times buzzer sound. And also the work is finished with two times buzzer sound.After awhile, black box is restarted
automatically.
7. Some folders in the memory card can be created by themselves.
NOTICE) After progressing the formatting at the format menu in Albatross main body, The existing configuration value is kept.
8. Upgrade (2)
14

[How to Manual-Upgrade]
1. Copy the upgrade firmware files to Micro SD card.(www.urive.co.kr Urive download center )
Users should format Micro SD card in the Albatross viewer or the black box main body. And then copy the upgrade files
(MD6900P_app.bin, MD6900P_boot.bin, MD6900P_memInfo.bin)to it.
2. After turning off the Albatross, install the SD card to the main body.
3. Turn on the Black box
it shows firmware upgrade image as below and then upgrade is progressed and turning off automatically with two times
buzzer sound.After awhile, black box is restarted automatically.
4. After restarted it, Some folders in the memory card can be created by themselves.
NOTICE) After progressing the formatting at the format menu in Albatross main body, The existing configuration value is kept.
8. Upgrade (3)
15

Sixangle
wrench
3pole-
4pole
gender
VIDEO cable
(3pole)
Main
body
holder
Usual
power
cable
Second
camera and
cable(6m)
Urive Micro
SD(8GB) SD card reader
Double-side
tape Manual GPS
Module Cigarette
jack power
cable
This components can be changed based on the part supply without any notice
(The images for user’s understanding can be different from the real one)
Please check the all of the components in the box as the picture below.
if the components are damaged, please contact your retailer immediately.
9. Components
Basic components
Option
16

10. Pin arrangement of each terminal
Section Pin image Pin Assignment
Power supply terminal
(DC socket) ①GND ②ACC ③BAT(B+)
GPS terminal
(2.5 Pi)
①VCC(3.6~6V DC) ②Rx
③GND ④Tx(GPS Signal Output)
Second camera terminal
(2.5 Pi)
①Cam Output(NTSC) ②VCC (5V)
③GND
Second camera extension
cable terminal
(3.5 Pi)
①Cam Output(NTSC) ②VCC (5V)
③GND
1
2
3
12
34
12
3
12
3
17

11. Installation precautions
When it is installed, users should off the car engine and do on aflat surface.
Users should check it can record the front and rear as video images well before exact
installation.
Please install it without connecting external(second) camera to the main device.
All components required for installation are provided with the Product.Check the components and
read the instructions before installation.
Check if the SD Card is correctly inserted, and then connect power.
The Product should be located in such away that the driver’s view is unaffected.
Try to conceal cables for tidiness and safety.
Keep the windshield clean always.
Install the Product in asafe and bright area.
Please note that heavy glass tint or thermal wire in the glass may impair the recording quality.
Please remove the camera’s protective plastic after installation.
18

1
2
3
4
5
6
7
※Before finishing off, please check if the
front/rear video images are properly recorded.
Clean the spot on the
windshield where the
Product is installed.
Remove the paper
from the adhesive
tape on the Mount.
Affix the Mount on
the desired point.
Installation of the power
cables must be conducted by
the authorized workshop.
-Black : GND, (ex) Car body
- Yellow : ACC, (ex) Cigar jack fuse
-Red : BAT(B+), (ex) Emergency light
Connect the cables for
the external camera,
GPS Module and Video
Output (if applicable)
With LED and buzzer
sound, check if the
Product works properly.
It is more convenient to
install when you view
the screen.
Connect the power
cable to the DC port.
12. Product Installation _ Urive Green HD
4
19

1
2
3
4
5
6
Select an installation
point, and clean the
area.
※Please note that glass tint or thermal wire in the
glass may impair the picture quality when the
external camera is installed on the back windshield.
Remove the paper
from the adhesive
tape on the Mount.
Affix on the
desired point.
Connect the external
camera to an extension
cable.
Connect the extension
cable to the CAM port on
the Black Box.
Connect the power
cable to the DC port
on the Black Box.
13. Installation of External Camera
20
