Microaces Percee Militair Twin Engine Kit User manual

LED Installation Guide

2
S
Leading Edge Housing
Wingtip Housing LED Housing Pack 1
Fuselage Mounting Plate
SP P
LED HOUSING PARTS
LENSE PARTS
CLEAR PARTS
LOOSE PARTS
1 x 5mm Ø x 140mm
plastic tube (Clear)
Bulb Cover
Wing Tip Cover

3
STAGE 1 ANTI COLLISION LIGHT
T11
T11B
T11B
T12
T12
See Important Information on gluing
Tyvek before proceeding
Do NOT attact T11 until Stage 8
in this guide.
Drawn to scale
LED position
From page 31 of main
Assembly Guide
From page 32 of main
Assembly Guide

4
Return to page 33 of main
Assembly Guide
STAGE 1 ANTI COLLISION LIGHT

5
From page 33 of main
Assembly Guide
Return to page 34 of main
Assembly Guide
STAGE 2 CABLE INSTALLATION
2 x 5mm Ø x 70mm
plastic tube (Clear)
Run motor extension cables
OUTSIDE of the plastic tube.
Run servo ‘Y’ cable INSIDE
plastic tubes.
** *

6
Repeat Leading Edge housing assembly for PORT SIDE. (Use plastic housing part labelled ‘P’)
Starboard side illustrated
Starboard side illustrated
Repeat for Port Side
STAGE 3 NAVIGATION LIGHTS
STAGE 4 LANDING LIGHTS
Wingtip Housing
Leading Edge Housing S
x2
Metal LED Pins can be bent if careful.
From page 43 of main
Assembly Guide

7
Starboard side illustrated
Repeat wing build for PORT SIDE.
STAGE 5 WINGS + LEDS
Return to page 44 of main
Assembly Guide

8
STAGE 6 WINGS
Return to page 45 of main
Assembly Guide
Route both LED connectors through
plastic tube into fuselage interior
during installation of wing
Servo connector
Servo connector
From page 44 of main
Assembly Guide

9
STAGE 7 LED LIGHT COVERS
Wing Tip Cover
Wing Tip Cover
LED Landing Light
Cover (P)
LED Landing Light
Cover (S)
From page 51 of main
Assembly Guide

10
LED Port 1 LED Port 3
LED Port 4
LED Port 2
Landing Lights
(White)
Landing Lights
(White)
LED Y Cable
Anti-Collision
(Red)
Nav. Lights
(Green)
Nav. Lights
(Red)
STAGE 7 LED CONNECTIONS

11
RECEIVER SETUP
For assistance and enquiries contact: [email protected]
Receiver Setup for LED operation from Transmitter Switch.
Using the Crossover RX Conguration Tool for PC and the USB Programming Interface Module (UPIM), connect the
Percee Twin ESC Receiver to your computer and connect. (Refer to the Receiver Guide for detailed instructions)
From the menu in the Crossover RX app, select the ‘Ports’ tab. Using the drop-down menu, change Port3 from its
default (THR) to AUX1. See image below.
Click save within the Crossover RX app and disconnect before physically unplugging the receiver from the PC.
Connecting LCU to Twin ESC Receiver
Plug the 3 pin JST-SH connector on the LED Control Unit to the THR port on the Twin ESC Receiver.
The LCU can then be placed in the fuselage, behind the bulkhead. It should not need to be secured in place.
Setting up your transmitter to operate the LEDs.
Within your transmitter setting, allocate AUX1 to a 3-way switch on your transmitter. Refer to your transmitter guide
for assistance.
To switch between LED modes, change the position of the switch accordingly.

STAGE 8 HATCH INSTALLATION
Return to page 51 of main
Assembly Guide
