Microh FOG HORN 1200 User manual

1. INTRODUCTION AND UNPACKING
Thank you for purchasing the MICROH FOG HORN 1200 fogger. For your own safety and
knowledge, please read this manual before installing or operating the device. This manual covers
the important information on installation and applications. Please install and operate the fixture
according to instructions. Meanwhile, please keep this manual for future reference.
The MICROH FOG HORN 1200 fogger is manufactured following CSA standards, complying with
international standard DMX512 protocol. This fixture is applicable but not limited to large-scale
live performances, theater, studio, nightclubs and discos.
Please carefully unpack it when you receive the fogger and check if it was damaged during the
transportation. Please check whether the following items are included inside the box:
Fixture – One Power Cord – One User Manual – One
Wireless Remote – One Wired Remote - One
2. SAFTEY INSTRUCTIONS
Safety Notes Read all the following Safety Notes before working with this product. These notes
include important information about the installation, usage, and maintenance of this product.
This product contains no user-serviceable parts. Any reference to servicing in this User Manual
will only apply to properly trained MICROH certified technicians. Do not open the housing or
attempt any repairs.
All applicable local codes and regulations apply to proper installation of this product.
Personal Safety
· Always disconnect this product from its power source before servicing.
· Always connect this product to a grounded circuit to avoid the risk of electrocution.
· Do not touch this product’s housing during operation because it may be very hot.
· Do not drink or become in contact with the fog fluid. If you do, call your local emergency service
(911 in the CDA/US) for help.
· Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent
surfaces.
· Make sure there are no flammable materials close to this product while it is operating.
· When hanging this product, always secure to a fastening device using a safety cable
(not included).
Power and Wiring
· Make sure the power cord is not crimped or damaged.
· Always make sure you are connecting this product to the proper voltage in accordance with the
specifications in this manual or on the product’s specification label.
· Never connect this product to a dimmer pack or rheostat.
· Never disconnect this product by pulling or tugging on the power cable.
1

Operation
· Do not operate this product if you see damage to the housing, fluid tank, or cables. Have the
damaged parts replaced by an authorized technician at once.
· Be sure that no ventilation slots on the product’s housing are blocked.
· The fog exits the nozzle at a very high temperature. Keep a minimum distance of 6.5ft (2 m)
from the nozzle to the nearest object.
· The product’s nozzle is very hot during operation and it remains hot for a long time after
operation has stopped.
· The maximum ambient temperature is 104 °F (40 °C). Do not operate this product at a higher
temperature.
· In the event of a serious operating problem, stop using this product immediately!
· Do not add perfume, alcohol, gasoline, or any other flammables to the fog fluid.
· Operates best with MICROH’s ‘MAXIMUM’water-based High Density Fog Fluid (HDF).
3. MOUNTING AND INSTALLATION
Caution: For added protection, mount the fixtures in areas outside walking paths, seating areas,
or in areas were the fixture might be reached by unauthorized personnel. Before mounting the
fixture to any surface, make sure that the installation area can hold a minimum point load of 10
times the device’s weight. Fixture installation must always be secured with a secondary safety
attachment, such as an appropriate safety cable. Never stand directly below the device when
mounting, removing, or servicing the fixture.
Whether installing inverted on a truss / ceiling or set on a flat level surface (see illustration
below). Be sure this fixture is kept at least 0.5m (1.5 ft.) away from any flammable materials
(decoration etc.). Always use and install the supplied safety cable as a safety measure to prevent
accidental damage and/or injury in the event the clamp fails.
Mounting Points: Overhead mounting requires extensive experience, including calculating
working load limits. A knowledge of the installation material being used and periodic safety
inspection of all installation material and the fixture are all imperative and should only be
performed by a qualified technician. Improper installation can result in bodily injury and damage.
Be sure to complete all rigging and installation procedures before connecting the main power
cord to the appropriate wall outlet.
2

Clamp Mounting: The MICROH FOG HORN 1200 fogger provides a unique mounting bracket
assembly that integrates 2 brackets to be used to mount on a truss or the floor. When mounting
this fixture to truss, be sure to secure an appropriately rated clamp to the included bracket fitted
through the center hole. As an added safety measure, be sure to attach at least one properly
rated safety cable to the fixture.
Regardless of the rigging option you choose for your MICROH FOG HORN 1200 fogger, always
be sure to secure your fixture with a safety cable. The fixture provides a built-in rigging point for a
safety cable on the hanging bracket as illustrated above. Be sure to only use the designated
rigging point for the safety cable and never secure a safety cable to a carrying handle.
5. SETUP
Be sure the unit is unplugged from the power source, remove the cap from the tank, and add the
‘MAXIMUM’ fog fluid up to fluid fill line. Be sure to not over fill the tank. Replace the cap and plug
unit in.
Turn the power switch on; you will notice the tank lights up RED. Once the unit is ready for use,
the illuminated tank will change to BLUE. Heat-up will take 3-5 minutes.
3

REMOTE
The FOGHORN1200DMX can be operated manually, or with the included wireless remote
control.
MANUAL REMOTE
- When the GREEN LED lights up the unit is ready for operation. Press the RED button to
manually fog
WIRELESS REMOTE
- Plug the wired receiver into the fog machines 5-pin port labeled “Remote Control”
- Press the either of the fog buttons, and the fog machine will output fog for as long as you
hold down the button.
4

9. TECHNICAL SPECIFICATIONS
Heat up Time: 3-5 Mins
Tank Capacity: 2.5L
Spraying Distance: 15m
Output: 10000 cu.ff/min
Voltage: 110V AC 60Hz
Power: 1400W
Weight:12.3Lbs
10. MAINTENANCE AND CLEANING
The following points have to be considered during the inspection:
1) All screws for installing the device or parts of the device must be tightly connected, and must
not be corroded.
2) There must not be any deformations on the housing, colour lenses, fixations or installation
spots (ceiling, suspension, trussing).
3) Mechanically moved parts must not show any traces of wearing and must not rotate with
unbalances.
4）The electric power supply cables must not show any damage, material fatigue or sediments.
Further instructions depending on the installation spot and usage must be handled by a skilled
installer or technician. Any safety issues must be resolved.
In order to keep the fixture in good condition and extend the life, we suggest regular cleaning to
the fixture.
1) Clean the inside and outside lens each week to avoid the light output from darkening due to
accumulation of dust, dirt, etc.
2) Clean the fan each week.
3) A detailed electrical check by approved technician every three months is advised. Ensure the
circuit contacts are in good condition.
5

We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth. Never use
alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions under
“Installation instructions”.
Should you need any spare parts, please order genuine MICROH parts from your local dealer.
IF YOU SHOULD EXPERIENCE ANY PROBLEMS OR ISSUES PLEASE CONTACT MICROH
PROFESSIONAL PRODUCTS BY EMAIL AT [email protected]
In the event that your unit is defective in any way, please contact your local dealer to
obtain an RA number for service repair.
Disclaimer:
MICROH
believes that the information contained in this manual is
accurate in all respects. However,
MICROH
assumes no responsibility for any errors or
omissions in this document.
MICROH
reserves the right to revise and make changes to
the content of this document without obligation that
MICROH
notify any person or
company of such revision or changes. This does not in any way constitute a commitment
by
MICROH
to make such changes.
MICROH
may issue a revision of this manual or a
new edition to incorporate such changes.
6
