SANYO:PLC-XU305/305A/355/355AIR CommandList
  □Transmissionformatof LCD projectoroperation key
    :NECFormat (singlecommand/command pipelining mode)
  □Transmissionformatof PCmouseoperationbutton(mousecursorbutton)/ L/ Rkey
    :InterlinkMouseCodeFormat(Includes3bitof ID)
  □Formatforthe transmissionof OSDLaseroperation button(mouse cursorbutton)
    :InterlinkOSD Mouse CodeFormat(Includes3bitof ID)
  □CustomCode+Custom Code
:8patternsasbelow
    33h+00h(Default;code1), 33h+11h(code2), 33h+22h(code3),33h+33h(code4),
    33h+44h(code5),33h+55h(code6),33h+66h(code7),33h+77h(code8)
Key
No. Data Code (HEX) Function
1 *1 L-CLICK ※Back-side ClickTriggerKey
2 00 ON-OFF
3 38 COMPUTER
4 05 VIDEO
5 08 NETWORK
6 16 INFORMATION
7 5B KEYSTONE
8 17 AUTOSET/ CANCEL
9 8C CURSORUP
10 1E CURSORLEFT/VOLUME-
11 1D CURSOR RIGHT/VOLUME +
12 8D CURSORDOWN
13 1C MENU
14 0F SELECT
15 *1 R-CLICK
16 43 FREEZE
17 84/85*2 LASER
18 8B NOSHOW
19 59 PAGE +
20 01 D.ZOOM+
21 8A P-TIMER
22 5A PAGE-
23 02 D.ZOOM-
24 0B MUTE
25 18 LAMPCONTROL
26 82 SCREEN
27 0C IMAGE
OB1 *1 MOUSE CURSORBUTTON
*1･･･ Transmit code for Mouse *2･･･ Transmit code to set Laser Pointer / OSD Laser to
ON/OFF
