Microsoft 9DR-00002 - Wireless Notebook Presenter 8000 Parts list manual

Rev. 1103A Microsoft®Wireless Notebook Presenter Mouse 8000 Page 1 of 2
Version Information
Product Name
Microsoft®Wireless Notebook Presenter Mouse 8000
Product Version
Microsoft Wireless Notebook Presenter Mouse 8000
Mouse Version
Microsoft Wireless Notebook Presenter Mouse 8000
Transceiver Version
Microsoft Transceiver v3.0 for Bluetooth
Product Dimensions
Mouse Length
3.68 inches (93.5 millimeters)
Mouse Width
2.22 inches (56.3 millimeters)
Mouse Depth/Height
1.47 inches (37.3 millimeters)
Mouse Weight
4.5 ounces (128 grams) includes 2 AAA alkaline batteries; battery weight may vary
Transceiver Length
2.10 inches (53.4 millimeters)
Transceiver Width
0.73 inches (18.6 millimeters)
Transceiver Depth/Height
0.34 inches (8.65 millimeters)
Transceiver Weight
0.24 ounces (6.80 grams)
Compatibility and Localization
Interface
USB Compatible
Operating Systems
Microsoft Windows®7, Windows Vista®, and Windows XP with Service Pack 2 (excluding Windows XP 64-bit)
Top-line System Requirements
Requires a PC that meets the requirements for and has Windows XP with Service Pack 2 (excluding Windows XP 64-bit) XP service pack 2
• 45 MB free (Install 100 MB)
• CD Drive
• USB Port
• Microsoft IntelliPoint software, version 7.0
Important: For best results and Bluetooth device compatibility, use the included Microsoft Mini Bluetooth Transceiver.
Compatibility Logos
• Certified for Microsoft Windows Vista
• Certified USB logo
• Bluetooth compatible product
Software Localization
Microsoft IntelliPoint software may be installed in Simplified Chinese, Traditional Chinese, English, French, German, Italian, Japanese, Korean, Brazilian
Portuguese, Iberian Portuguese, or Spanish. If available, standard setup will install the software in the default OS language. Otherwise, the English
language version will be installed.
Tracking Technology
Mouse Tracking System
Microsoft-proprietary high-definition laser technology
Imaging Rate
Dynamically adaptable to 6000 frames per second
X-Y Resolution
1000 points per inch (39.38 points per millimeter)
Tracking Speed
Up to 15 inches (381 millimeters) per second
Wireless Technology
Wireless Platform
Bluetooth 2.0
Wireless Frequency
2.4 GHz wireless
Wireless Range
30 feet (9.14 meters) typical. Note: RF range is affected by many factors, such as nearby metallic objects and relative positioning of the mouse and
receiver.
Bluetooth Profile Support
• Serial Port (SPP)
• Object Push (OPP)
• Personal Area Networking (PANU)
• Human Interface Device (HID)
• Hard Copy Cable Replacement (HCRP)
• Dial-Up Networking (DUN)
Power Requirements
Battery Type and Quantity
2 AAA alkaline batteries (included)
Battery Life
3 months typical with low battery LED feature
Product Feature Performance
Mouse Button Features
5 buttons including scroll wheel button, magnify, and Instant Viewer
Right & Left Button Life
3,000,000 actuations
Side Button Life
1,000,000 actuations
Wheel Button Life
350,000 actuations
Mouse Scrolling Features
Tilt wheel enables vertical and horizontal scrolling
Wheel Vertical Scrolling Life
• 100,000 revolutions (away from user) at no more than 60 rotations per minute
• 300,000 revolutions (toward user) at no more than 60 rotations per minute
Wheel Horizontal Scrolling Life
100,000 actuations per side
Mode Button Feature
Mode button enables user to switch between mouse and presenter/media controller functionality
Mode Switch Button
100,000 actuations
Power Switch Features
On/off power
Power Switch Life
4,000 actuations
Presenter/Media Controller Button Features
6 buttons including previous slide, next slide, volume up, volume down, laser pointer, and blank screen/play/pause
Presenter/Media Controller Button Life
500,000 actuations
Transceiver Features
Supports up to 7 Bluetooth compatible devices
Storage Temperature & Humidity
-40 °F (-40 °C) to 140 °F (60 °C) at <5% to 65% relative humidity (non-condensing)
Operating Temperature & Humidity
32 °F (0 °C) to 104°F (40 °C) at <5% to 80% relative humidity (non-condensing)
Certification Information
Country of Manufacture
People's Republic of China (PRC)
ISO 9001 Qualified Manufacturer
Yes
ISO 14001 Qualified Manufacturer
Yes
Laser Compliance
This device complies with International standard IEC 60825-1:2001-08 for both a Class 1 and Class 2 laser product. This device also complies with 21
CFR 1040.10and 1040.11, except for deviations pursuant to Laser Notice No. 50, dated July 26, 2001.
Restriction on Hazardous Substances
This device complies with all applicable worldwide regulations and restrictions including, but not limited to: EU directive 2002/95/EC on the Restriction of
the Use of Certain Hazardous Substances in Electrical and Electronic Equipment and EU Registration Evaluation and Authorization of Chemicals
(REACH) regulation regarding Substances of Very High Concern.
FCC/IC ID
This Class B digital apparatus complies with Part 15 of the U.S. Federal Communications Commission (FCC) rules, Canadian ICES-003, and RSS-210.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. The term "IC:" before the certification/registration number only signifies that the
Industry Canada technical specifications were met. Tested to comply with FCC (U.S. Federal Communications Commission) Standards.
For home or office use. Model numbers: 1065, Microsoft®Wireless Notebook Presenter Mouse 8000; 1063, Microsoft®Transceiver v3.0 for Bluetooth.
FCC IDs: C3K1065 and C3K1063, IC IDs: 3048A-1065 and 3048A-1063

Results stated herein are based on internal Microsoft testing. Individual results and performance may vary. Any device images shown are not actual size. This document is provided for informational purposes only and is subject to change
without notice. Microsoft makes no warranty, express or implied, with this document or the information contained herein. Review any public use or publications of any data herein with your local legal counsel.
©2011 Microsoft Corporation. The names of actual companies and products mentioned herein may be trademarks of their respective owners.
Rev. 1103A Microsoft®Wireless Notebook Presenter Mouse 8000 Page 2 of 2
Certification Information
Agency and Regulatory Marks
• CNC Certificate (Argentina)
• ACMA Declaration of Conformity (Australia and New Zealand)
• RSS-210 and IC ID, Certificate of Acceptance (Canada)
• SUBTEL Certificate (Chile)
• CMII Certificate (China)
• EIP Pollution Control Mark, EPUP (China)
• NTRA Certificate (Egypt)
• R&TTE Declaration of Conformity, Safety and EMC (European Union)
• WEEE (European Union)
• ETA Approval (India)
• MIC Certificate (Israel)
• MIC and KPS Certificates (Korea)
• SIRIM Certificate (Malaysia)
• COFETEL Certificate (Mexico)
• MTC Certificate (Peru)
• NTC Certificate (Philippines)
• GOST and FAC Certificates (Russia)
• CITC Letter (Kingdom of Saudi Arabia)
• IDA Certificate (Singapore)
• ICASA Certificate (South Africa)
• BSMI and DGT Certificates (Taiwan)
• FCC ID, Grant of Equipment Authorization (USA)
• UL and cUL Listed Accessory (USA and Canada)
• CONATEL Certificate (Venezuela)
• CB Scheme Certificate (International)
Windows Hardware Quality Labs (WHQL)
ID: 1451443 Microsoft Windows 7
