Swing Away Heat Press Machine Manual
Model NO.: SA-15/20/24
CONTENTS
I. Assembly Drawing -----------------------------------------------------------------------------------2
II. Technical Parameters ------------------------------------------------------------------------------2
III. Operation Process -------------------------------------------------------------------------------3-4
IV. Maintenance ------------------------------------------------------------------------------------------5
V. Trouble Shooting For Transfer Print Quality------------------------------------------------5
VI. Circuit Diagram -------------------------------------------------------------------------------------6
VII. Explosion View ----------------------------------------------------------------------------------7-8
MICROTEC
CONTENCON

-2-
I. Assembly Drawing
II. Technical Parameters
1. Model No.: SA-15/20/24
2. Machine Dimension: 630*325*390mm/ 630*325*520mm/630*325*620mm
3. Heat Platen Size: 15 x 20’’,16''x20'',20”x24”(38 x 38,40x50,40x60cm)
4. Printable Articles Max Size: 380*380*10mm
5. Voltage: 220V/1Phase; 110V/1Phase
6. Power: 220V/1.8KW; 110V/1.2KW
7. Recommend Setting: 30~280s; 180~200°C
Time Range: 0~480s
Maximum Temp: 225 C°
8. Packing Size: 73*48*48cm/ 75*60*50cm/ 74*69*49cm
9. Gross Weight: 40.95kg/ 50.3kg/ 52.55kg
ƻ
1Power Switch ƻ 2Temperature Controller ƻ 3Power Cord ƻ 4Time Controller
ƻ
5Swing Handle ƻ 6Fuse ƻ 7Pressure Adjuster
MICROTEC
II. Technical ParameTechnical Para
1. Model No.: SA-11. Model No.: S
2. Machine D2. Machine D
3. Heat3. H
4. P4
ƻƻ
ƻƻ
ƻ
Temperature ControllerTemperature Controller
ƻƻ
ƻ
Powe
dle
ƻƻ
ƻƻ
ƻ
FuseF
ƻƻ
ƻƻ
ƻ

-3-
III. Operation Process
1. Set temperature required
The meter on the left side is timer,
and the one on the right hand is the
temperature controller.
Power on, the display shows
Centigrade.
Then set the moderate temperatue
by pressing ‘’ˉ‘’ or “+” button.
2. Set time required
Then set the time by pressing ‘’ˉ‘’
or “+” button.
When rising to the set temperature,
close down the heat platen. Then
the time controller starts to
countdown.
Once the time is up, the buzzer will
send out sound. Then open and
swing away the heat platen.
Reduce Time
Time Temp
Increase Time
Reduce Tem
p
Increase Temp
MICROTEC
EC
EC
s
Then set the moderate tempeThen set the moderate temp
by pressing ‘’by press
ˉ
‘’ or “+” b‘’ or “+”
TEC
OT
OT
C
Then set the time by pThen set the time by
or “+” button.or “+”
ROT
MI
M
C
OT
e
crease Ti
me
M
ase Temp

-4-
3. Printing methods
Setp 1: Make sure the cord is connected well to the wall socket. Place the object (i.e. T-shirt) on press bed, and
tranfer paper with images facing down the object, adjust pressure to your requirement, and turn on the
power.
Setp 2: Set the temperature and time required, then temperature starts to rise.
Setp 3: When the temperature rises to the setting temperature, the buzzer sends out sounds; then close down
heat platen (meantime the sounds stop) and starts to transfer.
Setp 4: Then the time counter is on, once time is up, the buzzer will send out sounds again; then lift up the heat
platen and swing it away at the same time, meantime the sounds stop. Transfer work finished.
Setp 5: Consult the Transfer Paper instructions on whether to peel cold or hot, Here are suggested Pressing time
guidelines for different transfer paper.
Ink-Jet Transfer Paper (fabric) 14-18 seconds
Laser Copier/Printer Transfer Paper (fabric) 18-25 seconds
Sublimation Transfers (onto Fabrics) 25-30 seconds
Sublimation Transfers (onto FR-Plastic/Woods) 60-70 seconds
5. Recommendations:
1) Ceramic tile transfer:
Set temperature: 180ć.
Set time: 15 seconds
2) T-shirt transfer:
Set temperature: 180ć.
Set time: (chemical fiber use for sublimation transfer paper: 30-50 seconds; pure cotton use for T-shirt
transfer paper: 10-20 seconds)
3). Aluminum sheet transfer:
Set temperature: 180ć
NOTE:
1) Please switch off the machine and unplug the power cord when the machine is not in use.
2) The heat platen will cool down to the room temperature, if heat press stays unuse for more than 30 minutes.
3) The heat-releasing fan will automatically starts when the temeprature of heat platen reachs 80 degree C (176
degree F). It helps to reduce the temperature of electrical parts and prolong the service life of them.
4) For better maintenance of heat press, the maximum setting temperature is 210 degrees C (410 degrees F).
5) To avoid re-heating the first transfer when printing double sided T-Shirts, insert a sheet of cardboard in
between the shirt, adjust the height to less pressure, then press.
6) Heat platen may pivot slightly back and forth rotationally. This is due to movement allowance within the clamp
assembly, and is normal.
MICROTEC
ti
tion transfer paper: 30-50 seconds; pureon transfer paper: 30-50 seconds;
E:E:
1) Please switch off the machine and uease switch off the machine and
2) The heat platen will cool down2) The heat platen will cool dow
3) The heat-releasing fan wi3) The heat-releasing fan w
degree F). It helps to redegree F). It helps to
4) For better main4) For better main
5) To avoid r5) To av
twee
twee

-5-
IV. Maintenance
1. No action after turn on the machine
1). Check the plug whether it connects well or whether it is broken.
2). Check the power switch or digital controller whether it is broken.
3). Check the fuse whether it has been burnt out.
4). Indicating light is on, but no display on screen, check the 5 cable of Railway transformer. If it’s loosening,
showing the problem is poor connection. If they connects well, showing that the Transformer is faulty.
2. The display screen are working well, but no temperature increasing on the heat platen.
1). Check whether the thermocouple of the heat platen touches well. If the thermocouple is loose, the display will
show 255 and machie keeps beeping.
2). Check if the indicating light of solid-state relay is on, if not, check if the relay or digital controller is broken.
3). If you already changed the new solid-state relay but the heat platen still can’t heating up, check if the heat
platen is faulty or the heat platen’s power cable is loose, need to change by new heat platen.
3. The heat platen works well, but suddenly the display screen show 255к.
1). Check whether the thermocouple of the heat platen touches well.
2). If the thermocouple touches well but still show 255к, then it is faulty.
4. The machine is heating during 0~180
ć
, but display number jumps to above 200ćor 300ćsuddenly,
or the numbers on display jumps irregularly.
1). Check whether the thermocouple of the heat platen touches well.
2). If the thermocouple is good, It shows that the program of digital controller is broken, which namely IC or is
broken, need to change by new controller.
5. The temperature is out of control: Set 180ćˈbut the actual temperature is above 200
ćDŽ
1). It means the solid-state relay is broken, out of control, need to change the relay.
2). Or the digital controller is faulty and it keeps conveying electric to relay, need to change controller.
6. The setting temp and time becomes abnormal after exchange the heat platen
1). Please reset the temp and time according the operation process manual.
7. Other notice
1). In order to prolong the machine service life, please add the lubrication oil regularly on the joints.
2). In order to keep the heat platen's good transfer effect, you need to protect the heat platen carefully whenever
you are using it or not.
3). Please keep the machine in dry place.
4). If you are not able to solve the electrical parts problem, please kindly contact the supplier and get technical
support.
