Microview MVINVR-08POE4MP-E User manual

E18v1MVIN04UM
Network Video Recorder
User Manual
MVINVR-08POE4MP-E

Network Video Recorder User Manual
1
User Manual
About this Manual
This Manual is applicable to Network Video Recorder (NVR).
The Manual includes instructions for using and managing the product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version in the company website.
Please use this user manual under the guidance of professionals.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND OUR COMPANY MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE,
AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL OUR COMPANY, ITS DIRECTORS,
OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN
CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF OUR COMPANY HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY
AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER
ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY
WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS
THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS
USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS
THE APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS
USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.

Network Video Recorder User Manual
2
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and
comply therefore with the applicable harmonized European standards listed under the
EMC Directive 2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of
as unsorted municipal waste in the European Union. For proper recycling, return this
product to your local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more information see: www.recyclethis.info
2006/66/EC (battery directive): This product contains a battery that cannot be disposed
of as unsorted municipal waste in the European Union. See the product documentation
for specific battery information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

Network Video Recorder User Manual
3
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Provides additional information to emphasize or supplement
important points of the main text.
Indicates a potentially hazardous situation, which if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Indicates a hazard with a high level of risk, which if not avoided, will
result in death or serious injury.

Network Video Recorder User Manual
4
Safety Instructions
Proper configuration of all passwords and other security settings is the responsibility of the
installer and/or end-use r.
In the use of the product, you must be in strict compliance with the electrical safety
regulations of the nation and region. Please refer to technical specifications for detailed
information.
Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power
Source with 100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to
technical specifications for detailed information.
Do not connect several devices to one power adapter as adapter overload may cause over-
heating or a fire hazard.
Please make sure that the plug is firmly connected to the power socket.
If smoke, odor or noise rise from the device, turn off the power at once and unplug the power
cable, and then please contact the service center.
Preventive and Cautionary Tips
Before connecting and operating your device, please be advised of the following tips:
Ensure unit is installed in a well-ventilated, dust-free environment.
Unit is designed for indoor use only.
Keep all liquids away from the device.
Ensure environmental conditions meet factory specifications.
Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of
dropping it may cause damage to the sensitive electronics within the unit.
Use the device in conjunction with an UPS if possible.
Power down the unit before connecting and disconnecting accessories and peripherals.
A factory recommended HDD should be used for this device.
Improper use or replacement of the battery may result in hazard of explosion. Replace with
the same or equivalent type only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.

Network Video Recorder User Manual
5
Product Key Features
General
Connectable to network cameras, network dome and encoders.
Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom,
Canon, PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that
adopt ONVIF or PSIA protocol.
Connectable to the smart IP cameras.
H.265+/H.265/ H.264+/H.264/MPEG4 video formats
PAL/NTSC adaptive video inputs.
Each channel supports dual-stream.
Up to 8/16/32/64 network cameras can be added according to different models.
Independent configuration for each channel, including resolution, frame rate, bit rate, image
quality, etc.
The quality of the input and output record is configurable.
Local Monitoring
HDMI/VGA1 and HDMI2/VGA2 outputs provided.
HDMI Video output at up to 4K resolution.
Multi-screen display in live view is supported, and the display sequence of channels is
adjustable.
Live view screen can be switched in group. Manual switch and auto-switch are provided and
the auto-switch interval is configurable.
3D positioning supported by I series device in live view.
Configurable main stream and sub-stream for the live view.
Quick setting menu is provided for live view.
POS information overlay on live view.
Motion detection, video tampering, video exception alert and video loss alert functions.
Privacy mask.
Multiple PTZ protocols supported; PTZ preset, patrol and pattern.
Zooming in by clicking the mouse and PTZ tracing by dragging mouse.
HDD Management
Up to 16 SATA hard disks and 1 eSATA disk can be connected for I16 models, and up to 8 SATA
hard disks and 1 eSATA disk can be connected for I8 and K8 models.
Up to 8TB storage capacity for each disk supported.
8 network disks (NAS/IP SAN disk).
S.M.A.R.T. and bad sector detection.

Network Video Recorder User Manual
6
HDD group management.
Supports HDD standby function.
HDD property: redundancy, read-only, read/write (R/W).
HDD quota management; different capacity can be assigned to different channel.
RAID0, RAID1, RAID5, RAID6 and RAID 10 are supported.
Hot-swappable RAID storage scheme, and can be enabled and disabled on your demand. And
16 arrays can be configured.
Disk clone to the eSATA disk.
HDD health monitoring.
Recording, Capture and Playback
Holiday recording schedule configuration.
Continuous and event video recording parameters.
Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm
VCA, and POS.
8 recording time periods with separated recording types.
POS information overlay on image by I series device.
Pre-record and post-record for alarm, motion detection for recording, and pre-record time for
schedule and manual recording.
Searching record files and captured pictures by events (alarm input/motion detection).
Tag adding for record files, searching and playing back by tags.
Locking and unlocking record files.
Local redundant recording and capture.
Normal/Smart/custom video playback mode.
Searching and playing back record files by channel number, recording type, start time, end
time, etc.
Supports the playback by main stream or sub stream.
Smart search for the selected area in the video.
Zooming in when playback.
Reverse playback of multi-channel.
Supports pause, play reverse, speed up, speed down, skip forward, and skip backward when
playback, and locating by dragging the mouse.
Supports thumbnails view and fast view during playback.
Up to 16-ch synchronous playback at 1080p real time.
Supports playback by transcoded stream.
Manual capture, continuous capture of video images and playback of captured pictures.
Supports enabling H.264+ to ensure high video quality with lowered bitrate.

Network Video Recorder User Manual
7
Files Management
Vehicle detection files and human files search and export.
Export video data by USB, SATA or eSATA device.
Export video clips when playback.
Either Normal or Hot Spare working mode is configurable to constitute an N+1 hot spare
system.
Alarm and Exception
Configurable arming time of alarm input/output.
Alarm for video loss, motion detection, tampering, abnormal signal, video input/output
standard mismatch, illegal login, network disconnected, IP confliction, abnormal
record/capture, HDD error, and HDD full, etc.
POS triggered alarm supported by I series device.
VCA detection alarm is supported.
Smart analysis for people counting and heat map.
Connectable to the thermal network camera.
Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email
and alarm output.
Automatic restore when system is abnormal.
Other Local Functions
Operable by front panel, mouse, remote control, or control keyboard.
Three-level user management; admin user is allowed to create many operating accounts and
define their operating permission, which includes the limit to access any channel.
Admin password resetting by exporting/importing the GUID file.
Operation, alarm, exceptions and log recording and searching.
Manually triggering and clearing alarms.
Import and export of device configuration information.
Network Functions
Two self-adaptive 10M/100M/1000Mbps network interfaces.
IPv6 is supported.
TCP/IP protocol, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, and iSCSI are supported.
TCP, UDP and RTP for unicast.
Auto/Manual port mapping by UPnPTM.
Support access by Guarding Vision.
Remote web browser access by HTTPS ensures high security.

Network Video Recorder User Manual
8
ANR (Automatic Network Replenishment) function is supported, which enables the IP camera
save the recording files in the local storage when the network is disconnected, and
synchronizes the files to the device when the network is resumed.
Remote reverse playback via R T S P.
Supports accessing by the platform via ONVIF.
Remote search, playback, download, locking and unlocking of the record files, and support
downloading files broken transfer resume.
Remote parameters setup; remote import/export of device parameters.
Remote viewing of the device status, system logs and alarm status.
Remote keyboard operation.
Remote HDD formatting and program upgrading.
Remote system restart and shutdown.
RS-232, RS-485 transparent channel transmission.
Alarm and exception information can be sent to the remote host.
Remotely start/stop recording.
Remotely start/stop alarm output.
Remote PTZ control.
Remote JPEG capture.
Virtual host function is provided to get access and manage the IP camera directly.
Two-way audio and voice broadcasting.
Embedded WEB server.
Development Scalability
SDK for Windows system.
Source code of application software for demo.
Development support and training for application system.

Network Video Recorder User Manual
9
TABLE OF CONTENTS
Chapter 1 Introduction...................................................................................................................16
Front Panel .......................................................................................................................16
MVINVR-08POE04MP-E ..........................................................................................16
IR Remote Control Operations .........................................................................................16
USB Mouse Operation......................................................................................................23
Rear Panel ........................................................................................................................24
MVINVR-08POE04MP-E ..........................................................................................24
Chapter 2 Getting Started ..............................................................................................................25
Start up the Device...........................................................................................................25
Activate the Device ..........................................................................................................25
Configure Unlock Pattern for Login..................................................................................26
Login to the Device...........................................................................................................28
Log in via Unlock Pattern.........................................................................................28
Log in via Password .................................................................................................29
Enter Wizard to Configure Quick Basic Settings...............................................................29
Enter Main Menu .............................................................................................................33
System Operation.............................................................................................................34
Log out ....................................................................................................................34
Shut Down the Device.............................................................................................34
Reboot the Device...................................................................................................34
Chapter 3 Camera Management ...................................................................................................35
Add the IP Cameras..........................................................................................................35
Add the IP Camera Manually ..................................................................................35
Add the Automatically Searched Online IP Cameras ..............................................36
Manage Cameras for PoE Device .....................................................................................36
Add PoE Cameras ....................................................................................................37
Add Non-PoE IP Cameras ........................................................................................37
Configure PoE Interface ..........................................................................................37
Enable the H.265 Stream Access......................................................................................39
Upgrade the IP Camera ....................................................................................................39
Configure the Customized Protocols................................................................................39
Chapter 4 Camera Settings ............................................................................................................41

Network Video Recorder User Manual
10
Configure OSD Settings ....................................................................................................41
Configure Privacy Mask....................................................................................................42
Configure the Video Parameters......................................................................................43
Configure the Day/Night Switch.......................................................................................43
Configure Other Camera Parameters...............................................................................43
Chapter 5 Live View .......................................................................................................................45
Start Live View..................................................................................................................45
Digital Zoom ............................................................................................................45
Fisheye View............................................................................................................45
3D Positioning .........................................................................................................46
Live View Strategy ...................................................................................................47
Target Detection...............................................................................................................47
Configure Live View Settings............................................................................................48
Configure Live View Layout..............................................................................................48
Configure Auto-Switch of Cameras ..................................................................................50
Configure Channel-zero Encoding....................................................................................50
Chapter 6 PTZ Control ...................................................................................................................52
PTZ Control Wizard...........................................................................................................52
ConfigurePTZ Parameters.................................................................................................52
Set PTZ Presets, Patrols & Patterns..................................................................................53
Set a Preset .............................................................................................................53
Call a Preset.............................................................................................................54
Set a Patrol ..............................................................................................................55
Call a Patrol .............................................................................................................56
Set a Pattern............................................................................................................57
Call a Pattern ...........................................................................................................58
Set Linear Scan Limits..............................................................................................58
Call Linear Scan .......................................................................................................59
One-touch Park .......................................................................................................59
Auxiliary Functions...........................................................................................................60
Chapter 7 Storage............................................................................................................................62
Storage Device Management...........................................................................................62
Install the HDD ........................................................................................................62
Add the Network Disk .............................................................................................62
Configure eSATA for Data Storage ...........................................................................64

Network Video Recorder User Manual
11
Storage Mode...................................................................................................................65
Configure HDD Group .............................................................................................65
Configure HDD Quota..............................................................................................67
Recording Parameters ......................................................................................................68
Main Stream............................................................................................................68
Sub-Stream..............................................................................................................69
Picture .....................................................................................................................69
ANR..........................................................................................................................69
Configure Advanced Recording Settings .................................................................69
Configure Recording Schedule .........................................................................................70
Configure Continuous Recording .....................................................................................73
Configure Motion Detection Triggered Recording ...........................................................73
Configure Event Triggered Recording...............................................................................73
Configure Alarm Triggered Recording ..............................................................................74
Configure POS Event Triggered Recording .......................................................................74
Configure Picture Capture..............................................................................................75
Configure Holiday Recording and Capture.....................................................................76
Configure Redundant Recording and Capture ...............................................................77
Chapter 8 Disk Array......................................................................................................................79
Create Disk Array..............................................................................................................79
Enable RAID.............................................................................................................79
One-Touch Creation ................................................................................................80
Manual Creation......................................................................................................80
Rebuild Array....................................................................................................................82
Configure Hot Spare Disk ........................................................................................82
Automatically Rebuild Array....................................................................................82
Manually Rebuild Array...........................................................................................83
Delete Array .....................................................................................................................84
Check and Edit Firmware .................................................................................................85
Chapter 9 File Management ..........................................................................................................86
Search and Export All Files ...............................................................................................86
Search Files..............................................................................................................86
Export Files..............................................................................................................86
Search and Export Human Files .......................................................................................87
Search Human Files.................................................................................................87

Network Video Recorder User Manual
12
Export Human Files .................................................................................................87
Search and Export Vehicle Files .......................................................................................88
Search Vehicle Files .................................................................................................88
Export Vehicle Files .................................................................................................88
Search History Operation .................................................................................................89
Save Search Condition.............................................................................................89
Call Search History ..................................................................................................89
Chapter 10 Playback .......................................................................................................................90
Play Video Files...............................................................................................................90
Instant Playback ....................................................................................................90
Play Normal Video.................................................................................................90
Play Smart Searched Video ...................................................................................91
Play Custom Searched Files...................................................................................92
Play Tag Files .........................................................................................................93
Play Event Files......................................................................................................95
Play by Sub-periods...............................................................................................97
Play Log Files .........................................................................................................97
Play External File ...................................................................................................98
Playback Operations.......................................................................................................98
Set Play Strategy in Smart/Custom Mode.............................................................98
Edit Video Clips......................................................................................................99
Switch between Main Stream and Sub-Stream ....................................................99
Thumbnails View.................................................................................................100
Fisheye View........................................................................................................100
Fast View .............................................................................................................101
Digital Zoom ........................................................................................................101
POS Information Overlay.....................................................................................101
Chapter 11 Event and Alarm Settings........................................................................................102
Configure Arming Schedule .........................................................................................102
Configure Alarm Linkage Actions .................................................................................102
Configure Motion Detection Alarm..............................................................................104
Configure Video Loss Alarm .........................................................................................106
Configure Video Tampering Alarm...............................................................................107
Configure Sensor Alarms..............................................................................................108
Configure Alarm Input.........................................................................................108

Network Video Recorder User Manual
13
Configure One-Key Disarming.............................................................................108
Configure Alarm Output......................................................................................109
Configure Exceptions Alarm.........................................................................................111
Configure Auto-switch Full Screen Monitoring...................................................113
Configure Audio Warning....................................................................................113
Notify Surveillance Center ..................................................................................113
Configure Email Linkage......................................................................................114
Trigger Alarm Output ..........................................................................................114
Configure PTZ Linkage.........................................................................................114
Trigger or Clear Alarm Output Manually......................................................................115
Chapter 12 VCA Event Alarm.....................................................................................................117
Face Detection..............................................................................................................117
Vehicle Detection .........................................................................................................118
Line Crossing Detection................................................................................................119
Intrusion Detection ......................................................................................................120
Region Entrance Detection ..........................................................................................122
Region Exiting Detection ..............................................................................................123
Unattended Baggage Detection...................................................................................124
Object Removal Detection ...........................................................................................125
Audio Exception Detection...........................................................................................126
Sudden Scene Change Detection ...............................................................................127
Defocus Detection......................................................................................................128
PIR Alarm....................................................................................................................129
Chapter 13 Smart Analysis ..........................................................................................................131
People Counting ...........................................................................................................131
Heat Map......................................................................................................................131
Chapter 14 POS Configuration....................................................................................................133
Configure POS Settings.................................................................................................133
Configure POS Connection..................................................................................133
Configure POS Tex Overlay..................................................................................137
Configure POS Alarm....................................................................................................138
Chapter 15 Network Settings ......................................................................................................140
Configure TCP/IP Settings.............................................................................................140
Device with Dual Network Interface...................................................................140
Device with a Single Network Interface..............................................................141

Network Video Recorder User Manual
14
Configure Guarding Vision ...........................................................................................142
Configure DDNS............................................................................................................142
Configure PPPoE...........................................................................................................143
Configure NTP ..............................................................................................................144
Configure SNMP ...........................................................................................................144
Configure Email ............................................................................................................145
Configure Ports.............................................................................................................147
Chapter 16 Hot Spare Device Backup ........................................................................................149
Set Hot Spare Device....................................................................................................149
Set Working Device ......................................................................................................150
Manage Hot Spare System...........................................................................................150
Chapter 17 System Maintenance.................................................................................................152
Storage Device Maintenance .......................................................................................152
Configure Disk Clone ...........................................................................................152
S.M.A.R.T Detection ............................................................................................153
Bad Sector Detection ..........................................................................................154
HDD Health Detection.........................................................................................155
Search & Export Log Files.............................................................................................156
Search the Log Files.............................................................................................156
Export the Log Files.............................................................................................157
Import/Export IP Camera Configuration Files..............................................................158
Import/Export Device Configuration Files ...................................................................160
Upgrade System ...........................................................................................................161
Upgrade by Local Backup Device ........................................................................161
Upgrade by FTP ...................................................................................................161
Restore Default Settings...............................................................................................163
Chapter 18 General System Settings ..........................................................................................164
Configure General Settings ..........................................................................................164
Configure Date & Time.................................................................................................165
Configure DST Settings.................................................................................................166
Manage User Accounts ................................................................................................166
Add a User...........................................................................................................166
Set the Permission for a User..............................................................................168
Set Local Live View Permission for Non-Admin Users ........................................170
Edit the Admin User ............................................................................................171

Network Video Recorder User Manual
15
Edit the Operator/Guest User.............................................................................173
Delete a User.......................................................................................................174
Chapter 19 Appendix ...................................................................................................................175
Specifications ...............................................................................................................175
DS-9600NI-I8 .......................................................................................................175
DS-9600NI-I16 .....................................................................................................178
MVINVR-08POE04MP-E ......................................................................................181
MVINVR-08POE04MP-E/P...................................................................................184
DS-7700NI-I4 .......................................................................................................187
DS-7700NI-I4/P....................................................................................................190
DS-7700NI-K4 ......................................................................................................193
DS-7700NI-K4/P ..................................................................................................196
DS-7600NI-K2 ......................................................................................................199
DS-7600NI-K2/P ................................................................................................202
Glossary........................................................................................................................205
Troubleshooting ...........................................................................................................206
Summary of Changes ...................................................................................................214
Version 4.1.10 ................................................................................................................214
Version 4.1.0...................................................................................................................214
Version 3.4.92 ................................................................................................................214
Version 3.4.91 ................................................................................................................214
Version 3.4.90 ................................................................................................................214
Version 3.4.80 ................................................................................................................214
Version 3.4.70 ................................................................................................................215
Version 3.4.6...................................................................................................................215
Version 3.4.2...................................................................................................................215
Version 3.3.9...................................................................................................................216
Version 3.3.7...................................................................................................................216
Version 3.3.6...................................................................................................................216
Version 3.3.4...................................................................................................................216
List of Compatible IP Cameras .....................................................................................217
List of IP Cameras Connected to PoE by Long Network Cable (100 - 300 m) ..............231

Network Video Recorder User Manual
16
Chapter 1 Introduction
Front Panel
MVINVR-08POE04MP-E
MVINVR-08POE04MP-E
Panel Description
IR Remote Control Operations
The device may also be controlled with the included IR remote control, shown in Figure 1-5.
Batteries (2×AAA) must be installed before operation.
The IR remote is set at the factory to control the device (using default Device ID# 255) without any
additional steps. Device ID# 255 is the default universal device identification number shared by the
devices. You may also pair an IR Remote to a specific device by changing the Device ID#, as follows:
Pairing (Enabling) the IR Remote to a Specific Device (optional)
You can pair an IR Remote to a specific device by creating a user-defined Device ID#. This feature is
useful when using multiple IR Remotes and devices.
On the device:
No. Name Connections
1 POWER Turns green when device is powered up.
2 HDD Flickers red when data is being read from or written to HDD.
3 Tx/Rx Flicker
s blue when network connection is functioning
properly.
4 USB Interface Universal Serial Bus (USB) port for additional devices such as
USB mouse and USB Hard Disk Drive (HDD).

Network Video Recorder User Manual
17
Go to System > General.
Type a number (255 digits maximum) into the Device No. field.
On the IR Remote:
Press the DEV button.
Use the Number buttons to enter the Device ID# that was entered into the device.
Press Enter button to accept the new Device ID#.
Remote Control
Unpairing (Disabling) an IR Remote from a Device
To unpair an IR Remote from a device so that the unit cannot control any device functions, proceed
as follows:
Press the DEV key on the IR Remote. Any existing Device ID# will be erased from the unit’s memory
and it will no longer function with the device.
(Re)-enabling the IR Remote requires pairing to a device. See “Pairing the IR Remote to a Specific
device (optional),” above.

Network Video Recorder User Manual
18
Rem
ote
Func
tions
.
N
ame
Function
Description

Network Video Recorder User Manual
19
1
POWER
ON/OFF
•
To Turn Power On:
-
If User Has Not Changed the Default device Device ID# (255):
1.
Press Power On/Off button (1).
-
If User Has Changed the device Device ID#:
1.
Press DEV button.
2.
Press Number buttons to enter user-defined Device ID#.
3.
Press Enter button.
4.
Press Power button to start device.
•
To Turn device Off:
-
If User Is Logged On:
1
.Hold Power
On/Off button (1) down for five seconds to display the
“Yes/No” verification prompt.
2.
Use Up/Down Arrow buttons (12) to highlight desired selection.
3.
Press Enter button (12) to accept selection.
-
If User Is Not Logged On:
1.
Hold Power
On/Off button (1) down for five seconds to display the
user name/password prompt.
2.
Press the Enter button (12) to display the on-screen keyboard.
3.
Input the user name.
4.
Press the Enter button (12) to accept input and dismiss the on
-
screen keyboard.
5.Use the Down Arrow button (12) to move to the “Password” field.
6.
Input password (use on-
screen keyboard or numeric buttons (3)
for numbers).
7.
Press the Enter button (12) to accept input and dismiss the on
-
screen keyboard.
8.Press the OK button on the screen to accept input and display the
Yes/No” verification prompt (use Up/Down Arrow buttons (12) to
move between fields)
9.
Press Enter button (12) to accept selection.
User name/password prompt
depends on device
is configuration.
See “System Configuration” section.
2
DEV
Enable IR Remote: Press DEV button, enter
device
Device ID# with
number keys, press Enter to pair unit with the
device
