Ganz DIGIMASTER DR-16M55-RA-4TB User manual

8CH/16CH
2U 5M HYBRID DVR
User Manual
ganzsecurity.com

SYSTEM
SETTING
34
SEARCH
85
OVERVIEW
4
INSTALLATION
10
MONITORING
22
Copyright
This manual without the manufacturer's approved copy and reprinted partially or in full, or translated into another language is
prohibited.
Limitation of Liability
This product is designed to prevent fire and theft is not the main means. We shall not be liable for accidents or damage by
using this product can result in liability for accidents or damage
In order to improve the performance of the product without prior notice to the product may be a firmware upgrade.

SYSTEM
SETTING
34
34 To move to the System Setup
menu
35 Camera Setting
41 Display Setting
49 Audio Setup
50 User Setting
52 Network Setup
58 System Setting
65 Storage
69 Event Setup
78 To start the Record Setup
menu
79 Record Setup
SEARCH
85
85 To move to the Search menu
while in monitoring
85 To move to the Search menu
while in playback mode
86 Search Settings
PLAY
90
90 If you want to play
ARCHIVING
93
93 To start the Archive menu
WEB VIEWER
96
96 What is the Web Viewer?
98 Live
102 Search
105 Setup
MOBILE
VIEWER
126
126 nViewer
ARCHIVE
VIEWER
141
141 Getting started with the
Backup Player
143 Backup Player At a Glance
Content
OVERVIEW
4
4 Safety Instruction
5 Key Features
6 What's included
7 Rear Panel
9 Remote Control At a Glance
INSTALLATION
10
10 Replacing HDD
15 Basic Layout
16 Connecting to an external
device
MONITORING
22
24 Live Screen At a Glance
APPENDIX
146
146 Compatible HDD
Specifications
147 Troubleshooting (FAQ)

4 |Overview
Overview
Safety Instruction
This product was tested with a UPS to satisfy EN 61000-4-11 test conditions (voltage dips and short interruptions test)
under the EN 50130-4: 2011 standard.
The Company shall not have any responsibility for any accident or damage that may incur during the use of the product. For
your safety, we provide a few instructions about installation, manipulation, cleaning, assembly/disassembly of the product as
below. So please read carefully and comply with the instructions.
Before installation
Comply with the following instructions to prevent a fire, explosion, system failure or electric
shock.
~
Remove the power supply module before proceeding.
~
Check the input voltage (AC100V–AC240V) to the power supply module before connecting it.
~
Keep the product away from humidity.
~
Ensure that all devices connected to the product should be properly earth-grounded.
In operation mode
Comply with the following instructions to prevent a fire, explosion, system failure or electric
shock.
~
If you need to open the cover, consult with a service person who could help you do what you
want to do.
~
Do not connect multiple devices to a single power socket.
~
Keep the product away from dust or too much combustible substances (ex: propane gas).
~
Do not touch it with wet hand.
~
Do not insert a conductor in the vent of the ventilation system.
~
Do not apply excessive force to unplug the power cord.
Disassembly & Cleaning
~
When cleaning on the surface, use a dry cloth.
~
Do not wipe the product using water, paint thinner or organic solvents.
~
Do never dismantle, repair or modify the product by your own.
During installation
To prevent an accident or physical injury and to operate DVR properly, please comply with
the followings:
~
Secure at least 18 centimeter of distance between cooling fan and wall for a proper ventilation.
~
Install the product on a flat surface.
~
Keep it away from direct sunlight or excessive temperature.
While in use
~
Do not apply force to or shake it while using it.
~
Do not move, throw away or put excessive force to it.
~
Using any unrecommended HDD may cause a system failure. Check the compatibility list and
use only compatible HDDs.
{A system failure or data loss caused by an incompatible HDD will void your warranty.}

English |5
Overview
 CAUTION
Replaceable batteries
Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions.
Warning to service personnel
Double pole/neutral fusing
Ethernet Instruction
This equipment is indoor use and all the communication wiring are limited to inside of the building or similar word.
Key Features
This product is capable of receiving inputs from up to 16 channels of 5MP camera inputs of video and audio and recording
onto a hard disk drive in real-time, as well as providing monitoring, playback and backup footages in excellent quality of 5MP
resolution.
It also provides transferring video and audio data to the networked external devices, which allows remote monitoring
environment for computers and mobile devices including cell phones.
~
Up to 16 channels of 5MP camera video can be displayed at 480 fps in real time.
~
Up to 16 channels of 5MP camera videos can be saved at maximum 160 fps.
~
Simultaneous recording and playback of maximum 16 channels (at 480fps @ CIF)
~
Supports H.264 HP (High Profile) CODEC
~
Auto alarm feature with self-diagnostics on the system (HDD S.M.A.R.T, system temperature, network error, FAN
error, etc.)
~
Supports dual streaming for remote access service
~
Supports HDD extension (eSATA)
~
Various search methods (time, event, bookmark, thumbnail and text-in)
~
Mass storage backup via USB port or FTP server
~
Supports remote access and search using web browser
~
Dedicated smart phone applications that can be used with iPhone and iPad or on Android OS
~
1080p Full HD GUI

Overview
6 |Overview
What's included
Mouse x1 Remote Control x1 & Batteries (AAA x2) Power Cable x1
DC 12V Adaptor x1 (90W) Adapter cable retainer clip x1 Screws (For fixing HDD / ODD)
Terminal Block (7P/for 8CH) x2 Terminal Block (9P for 16CH) x2 Terminal Block 10P (for 16CH x4 / for 8CH x2)
Quick Guide

English |7
Overview
Rear Panel
 8 channels
 16 channels
No. Name Description
a
VIDEO IN Video input terminal for cameras.
b
AUDIO IN Port for audio input.
c
AUDIO OUT Port for speaker connection.
d
ALARM IN Alarm input signal port.
ALARM OUT Alarm out signal port. O.C. (Pulled up to 5V via 10KOhm)
RELAY Relay Terminal output port.
RS485 Ports for communication with external devices such as PTZ camera and system keyboard.
RS232 Connection ports for signal cables to external devices such as PTZ camera, POS and ATM
devices.
e
SPOT OUT Exclusive port for SPOT output only. (Connect to a TV monitor.)
f
VGA VGA monitor video output port.
HD
MONITOR
VGA
1357
2468
VIDEO IN
AUDIO
OUT
DC12V
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO3 AO1
AO4 AO2
GND GND
RS-232
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
PANIC
ARI
ALARM IN
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
AUDIO IN
1 3 5 7
2 4 6 8
b c de
f g hi ka j
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3 AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND
ARI
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
VIDEO IN
AUDIO IN
9 11 13 157531
10 12 14 168642
b c de
a f g h i kj

Overview
8 |Overview
No. Name Description
g
HD-MONITOR HD monitor video output port.
h
e-SATA Connection port for external eSATA storage.
i
USB Used for connecting USB storage or mouse.
j
WAN(UPLINK) Network port for connection to the Internet, router or hub.
LAN(DOWN LINK) Port for connecting the dedicated network device.

Do not share it with other device.
k
DC12V Power input port.

English |9
Overview
Remote Control At a Glance
POWER
Turn on or off the power.
ARCHIVE
Display the backup window.
PANIC
Start the emergency recording.
SEARCH
Display the search window.
SEQ
Switch to sequence mode.
$, %, _, +
Use to move through the menus.
EXIT
SETUP
Display the system setup menu.
ENTER
Select a menu item or apply your settings.
DISPALY
Switch the split mode.
NEXT
PREV
MENU
Display the tool bar on the live screen.
&, _, p, *
Used to change the direction or adjust the
play speed in playback mode.
Channel
Function as channel selection button
in live or playback mode. Or used for
entering the password.

10 |Installation
Installation
Replacing HDD
When an HDD is full or problematic, you can replace it with a new one by yourself.
 8 / 16Ch Model

Below illustrations are based on the 8/16-channel model.
1.
Remove 2 screws on both ends of DVR.
2.
Pull the front side of the unit forward to separate it.
3.
Hold the middle of HDD bracket's handle with index
finger and pull it forward while sustaining the bracket
handle with your thumb and middle finger as shown
in the illustration.
a
b

English |11
Installation
4.
Once the HDD bracket is separated from the main
unit, remove 4 screws on both ends of HDD bracket
to separate the HDD from the bracket.
5.
Install a new HDD and fasten 4 screws back to both
ends of the bracket to fix it.

When installing HDD, make sure to install in the correct
direction.
6.
Push the bracket installed with new HDD back into
the main unit until it is completely inserted.
7.
Hold center of the ODD bracket’s holder by your
index finger and pull it.
DVR Assembly
Direction

Installation
12 |Installation
8.
Install the ODD on the ODD bracket and fix it by
fastening 4 screws on the bottom of it.
9.
Insert the bracket with ODD into the main unit, push
it until it’s fully inserted.
10.
Assemble the front panel back to the unit.
J
When assembling the front panel to the main unit, make
sure the marked part is tightly attached.
11.
Fasten 2 screws on both ends of the main unit.
M3 X 6

English |13
Installation
 If installed 5 HDD drives

Below illustrations are based on the 8/16-channel model.
1.
Remove 2 screws on both ends of DVR.
2.
Pull the front side of the unit forward to separate it.
3.
Hold the middle of HDD bracket's handle with index
finger and pull it forward while sustaining the bracket
handle with your thumb and middle finger as shown
in the illustration.
a
b

Installation
14 |Installation
4.
Once the HDD bracket is separated from the main
unit, remove 4 screws on both ends of HDD bracket
to separate the HDD from the bracket.
5.
Install a new HDD and fasten 4 screws back to both
ends of the bracket to fix it.

When installing HDD, make sure to install in the correct
direction.
6.
Push the bracket installed with new HDD back into
the main unit until it is completely inserted.
7.
Assemble the front panel back to the unit.
J
When assembling the front panel to the main unit, make
sure the marked part is tightly attached.
8.
Fasten 2 screws on both ends of the main unit.
DVR Assembly
Direction

English |15
Installation
Basic Layout
J
Since the cable quality may affect directly to the video quality depending on the distance between the camera
and DVR, it is recommended to consult an authorized installer when installing the DVR.
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND
ARI
VIDEO IN
1 3 5 7 9 11 13 15
14 16
AUDIO IN
9 11 13 157531
10 12 14 168642
Mouse POS Control
Devices
Alarm
Sensor
e-SATA
Storage
VGA
MONITOR
HD
MONITOR
Speaker
MIC
Camera
IP Router
or HUB
ATM
Access
Controller
SPOT
Monitor

Installation
16 |Installation
Connecting to an external device
 Connecting to the monitor
This product supports 1080p 60 Hz HDMI monitors and regular monitors that support DVI and VGA inputs. Use the
switch on the product’s rear side to set it for HDMI or VGA monitor. Connect an HDMI cable to the port on the product’
s rear bottom, or connect an HDMI-DVI converter cable to connect a DVI monitor. Or, use VGA cable to connect the
product with a VGA monitor.
~
Once the product is set for NTSC or PAL output, connect cameras of the corresponding video standard for
proper operations.
J
Make sure to connect the product to a monitor that supports 1920x1080 at 60Hz.
(HDMI, DVI, VGA)
 Power Connection
Connect the power cable supplied with the product into the power socket on the main unit’s rear side.
J
For stable operation of the product, it is recommended to use the adapter provided. (12V, 10A)
J
Make connection when the power is not applied yet.
J
Arrange up the cables and be careful not to peel off the cable coating.
J
Do not place the power cord under the carpet or rug. The power cord is usually earth-grounded. However, even if
it's not earth-grounded, do never modify it on your own for earth-grounding.
J
Do not insert multiple devices in a single power socket. Otherwise, it may cause a power overload.
J
For stable power supply, this product provides two separate adaptors and two corresponding AC cords by factory
default. Make sure all cables are connected properly.
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1 AO6 AO2
GND GND
AO7 AO3 AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND
ARI
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
VIDEO IN
AUDIO IN
9 11 13 157531
10 12 14 168642
DC12V
Power adaptor

English |17
Installation
 Alarm I/O Connection
To connect the alarm input signal
Connect the signal line of an alarm input device such as sensor to the rear [ALARM IN] port.
1.
Loosen the screws on both the alarm input port and [GND] port of the provided terminal block plug.
2.
Insert one end of alarm signal cable through the [AO1] or [AO8] terminal hole below the screw hole, and then fasten
the screw.
3.
Insert the ground signal wire into the hole of the [GND] port (shown also below the screw), and tighten the screw.
4.
To check proper insertion of cable, stop pushing and gently pull the cable and test whether it disconnects.
To disconnect a cable, push the bottom side of the terminal and pull out the cable.
To connect the alarm output signal
Connect the signal line of an alarm output device to the rear [REL AY] port.
1.
Loosen the screws on the [NO] and [NC] ports and the [COM] port of the provided terminal block plug.
2.
Insert the alarm signal wire into the hole of the [NO] or [NC] input port (shown below the screw), and tighten the
screw.
Check the relay output type of Normal Open or Normal Close before selecting a proper type (NO or NC).

NO(Normal Open) : Normally Open but switching to Close if an alarm out occurs.

COM : Insert the grounding wire.

NC(Normal Close) : Normally Close but switching to Open if an alarm out occurs.
3.
Insert the ground signal wire into the hole of the [COM] port (shown also below the screw), and tighten the screw.
Or, you can connect the signal cable of the alarm output device to the [ALARM OUT] port on the rear side.
1.
Loosen the screws on the [AO1] and [AO8] ports and the [GND] port of the provided terminal block plug.
2.
Insert the alarm signal wire into the hole of the [AO1] or [AO8] input port (shown below the screw), and tighten the
screw.
Check the relay output type of Normal Open or Normal Close before selecting a proper type (NO or NC).
3.
Insert the ground signal wire into the hole of the [GND] port (shown also below the screw), and tighten the screw.
4.
To check proper insertion of cable, stop pushing and gently pull the cable and test whether it disconnects.
To disconnect a cable, push the bottom side of the terminal and pull out the cable.
5.
Install the wire-connected terminal block in the rear port.
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND
ARI
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
VIDEO IN
AUDIO IN
9 11 13 157531
10 12 14 168642
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND ARI
ALARM IN
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND ARI
ALARM IN
RS-485_1
ALARM OUT
RS-485_2
D+ D+
D- D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232

Installation
18 |Installation
 Communication Port
RS-485 Connection
Connect a PTZ Camera or Keyboard Controller.
After connecting the control device, be sure to match the connection settings between DVR and device.
Make communication settings in <Control Device>. (page 62)
1.
Use a signal cable to connect the [D+] port of the terminal block plug and the [D+] port of the keyboard controller.
2.
Connect the [D+] port of the terminal block plug and the [D+] port of the keyboard controller.
3.
Connect the [GND] port of the terminal block plug and the [GND] port of the keyboard controller.

For RS-485 communication configuration, refer to the user’s manual of the applicable PTZ camera or keyboard
controller.
RS-232 Connection
You can connect PTZ cameras, POS or ATM devices.
For connection of the text-in device, refer to the user manual of the text-in device.
 Audio Device Connection
You can connect an audio output device such as speaker amplifier.
Connect the audio input device such as microphone to the rear Audio In port, connect the audio output device such as
speaker amplifier to the Audio Out port.
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND
ARI
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
VIDEO IN
AUDIO IN
9 11 13 157531
10 12 14 168642
RS-485_1
ALARM OUT
RS-485_2
D+ D+
D- D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232

English |19
Installation
 Storage and Mouse Connection
eSATA Storage
If the internal storage space is insufficient, you can extend your storage capacity by adding an eSATA storage device to
the rear eSATA port.
J
Using devices other than recommended eSATA products may cause serious problem.
USB Device
You can connect and use USB storage devices for backup of recorded video, saving snapshots, firmware updating,
importing/exporting user configurations. Also, USB mouse can be connected for DVR manipulations.
J
If you need to connect a USB HDD with a high power consumption, it is recommended to use a separate power
source for that HDD.
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND ARI
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
VIDEO IN
AUDIO IN
9 11 13 157531
10 12 14 168642
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND ARI
ALARM IN
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN3 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
ALARM IN
RS-485_1
ALARM OUT
RS-485_2
D+ D+
D- D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
LAN
(DOWNLINK)
WAN
(UPLINK)
e-SATA USB HD MONITOR AUX VGA
NTSC
PAL
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 / 2
1 / 2 5 / 6 9 / 10
3 / 4 7 / 8 11 / 12
AUDIO OUT
VIDEO IN
LOOP OUT
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND ARI
ALARM IN
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN3 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
ALARM IN
RS-485_1
ALARM OUT
RS-485_2
D+ D+
D- D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
LAN
(DOWNLINK)
WAN
(UPLINK)
HD MONITOR AUX VGA
NTSC
PAL
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1 / 2
1 / 2 5 / 6 9 / 10
3 / 4 7 / 8 11 / 12
AUDIO OUT
VIDEO IN
LOOP OUT
USB MouseUSB storage
(backup,
firmware
updating)
USB HDD
(for backup only)
External HDD
(for video recording)

Installation
20 |Installation
 Network Connection
PC connection in the local network
You can connect DVR to a PC in the same network and control or manipulate it on the PC monitor.
1.
Connect the [ETHERNET] port in the rear panel to the router or hub.
2.
Connect the local PC to the router or hub.
3.
Enter the address in the Web browser of your PC in the format of: “http://IP address:Web service port”
(Ex : http://192.168.0.23:8080) The web service port is set to 8080 by default. From the Network Setup screen, you
can change the port number.

If using the dedicated PC S/W, refer to the user manual of the program.
4.
Provide the ID and password before logging in. Then, you can view the monitoring screen.
The initial administrator ID is “ADMIN”and the password should be set when logging in for the first time.
J
For security purpose, change the password before you use the product for the first time after purchasing it.
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND
ARI
VIDEO IN
1 3 5 7 9 11 13 15
14 16
AUDIO IN
9 11 13 157531
10 12 14 168642
Local PC
Local PC
Broadband
router or hub
Camera
HD
MONITOR
VGA
AUDIO
OUT
DC12V
WAN(UPLINK)
LAN(DOWNLINK)e-SATA USB
SPOT
OUT
RS-485_1
ALARM OUT
RS-485_2
D+
D+
D-
D-
GND GND
RX TX
AO5 AO1
AO6 AO2
GND GND
AO7 AO3
AO8 AO4
RS-232
RELAY
NO7 NO5
COM7 COM5
COM8 COM6
NC8 NC6
IN13 IN9
IN14 IN10
GND GND
IN15 IN11
IN16 IN12
GND
PANIC
RELAY
NO3 NO1
COM3 COM1
COM4 COM2
NC4 NC2
IN5 IN1
IN6 IN2
GND GND
IN7 IN3
IN8 IN4
GND
ARI
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
VIDEO IN
AUDIO IN
9 11 13 157531
10 12 14 168642
WAN(UPLINK)
LAN(DOWNLINK)
4WANRESETPWR 3 2 1
Local PC Local PC
Broadband router
or hub
