Middle Atlantic Products L5-SD7 User manual

I-00817 Rev -
Instruction Sheet
L5-SD7
L5 Storage Drawer
Thank you for purchasing the L5-SD7 storage drawer.
Please read these instructions thoroughly before installing or assembling these products.
L5-SD7
• 7” Depth X 14” Width
• Left or right frame installation to align with wood kit.
• Weight capacity 25 lbs.
THANK YOU
PRODUCT FEATURES

Page 2
IMPORTANT SAFETY INSTRUCTIONS / INSTRUCTIONS IMPORTAANTES SUR LA SÉCURITÉ
SAVE ALL INSTRUCTIONS / CONSERVER CES INSTRUCTIONS
CAUTION/ATTENTION and the exclamation point within an
equilateral triangle is intended to alert the user to the possibility of
damaging or destroying the equipment if the instructions are not
followed.
Attention et le point d'exclamation dans un triangle équilatéral est
destiné à alerter l'utilisateur de la possibilité d'endommager ou de
détruire l'équipement si les instructions ne sont pas suivies.
WARNING/AVERTISSEMENT and the exclamation point within an
equilateral triangle is intended to alert the user to the possibility of
serious injury or death if the instructions are not followed.
Avertissement et le point d'exclamation dans un triangle équilatéral
est destiné à alerter l'utilisateur de la possibilité de blessures
graves ou la mort si les instructions ne sont pas suivies.
WARNING: Failure to read, understand and follow the following information can result in seri-
ous personal injury, damage to the equipment or voiding of the warranty.
AVERTISSEMENT: Ne pas lire, comprendre et suivre les informations suivantes peut entraîner
des blessures graves, des dommages à l'équipement ou de la nullité de la garantie.
WARNING: Exceeding the weight capacity may result in personal injury or equipment damage.
The combined weight of all components attached to the mount must not exceed weights listed
on page 3.
AVERTISSEMENT: Dépasser la capacité de poids peut entraîner des blessures ou des dom-
mages matériels. Le poids combiné de tous les composants reliés au support de montage ne
doit pas dépasser les grammages indiqués à la page 3.
WARNING: Be aware of pinch points and do not place fingers in between moving parts.
AVERTISSEMENT: Soyez conscient des points de pincement et de ne pas placer les doigts
entre les pièces mobiles.
WARNING: Use this product for its intended use and only use attachments recommended by
the manufacturer.
AVERTISSEMENT: Utilisez ce produit pour son utilisation prévue et utiliser uniquement les
accessoires recommandés par le fabricant.
WARNING: Do not use a damaged product. Return damaged products to a qualified service
center for repair.
AVERTISSEMENT: Ne pas utiliser un produit endommagé. Retour produits endommagés à un
centre de service qualifié pour la réparation.
WARNING: Not intended for outdoor use.
AVERTISSEMENT: Non destiné à une utilisation en extérieur.

Page 3
WEIGHT RATINGS
Model Weight Rating
L5-SD7 25 lbs. Maximum Total Rated Load
REQUIRED TOOLS
• #2 Phillips Screwdriver
• 3/8” Nut Driver and Handle (Supplied)
WARNING: Use tools with caution and follow all necessary safety protocols.
AVERTISSEMENT: Utiliser des outils avec prudence et suivre tous les protocoles de sécurité
nécessaires.
SUPPLIED COMPONENTS
Left & Right
Slide Set
(B)
Storage Drawer
(A)
3/8” Nut Driver & Handle
(C)
(4x)
10-32 Hex
Flange Nut
(D)

(2x) slide mounting holes for
installing storage drawer
on right side of frame.
(Typical front and rear)
(2x) slide mounting holes for
installing storage drawer
on left side of frame.
(Typical front and rear)
NOTE: For 23”, 33” and 43” frames, storage drawer can
be installed into left or right side of L5 frame to align with wood kit.
(FIGURE A)
DRAWER SLIDE INSTALLATION
Page 4
FIGURE A

DRAWER SLIDE INSTALLATION (CONTINUED)
DRAWER INSTALLATION
Page 5
1. Slides (B) are marked as (L) and (R). Install the slide assemblies into the mounting holes and secure
in place using (2x) hex nuts (D) each side. Tighten down using supplied nut driver and handle (C).
(FIGURE B)
NOTE: Slide stop bumpers must face inside
frame when installed.
1. To install storage drawer (A), align slides and using some force. Push drawer in completely to fully
lock in place.
2. Move the drawer in and out to ensure drawer slides freely. (FIGURE C)
B
D
C
D
A
Frame cut away
for clarity
FIGURE B
FIGURE C

DRAWER REMOVAL
Pull Lever Up To
Release Drawer
1. To remove storage drawer (A), fully extend drawer and pull up on lock lever on both slides at the
same time and pull drawer assembly off slides. (FIGURE D)
2. Refer to wood kit instructions (I-00815) for drawer face installation supplied with your wood kit or
purchased millworkers kit.
FIGURE D
For warranty information, refer to www.middleatlantic.com/terms.
