INSTRUCTION MANUAL
Microwave Oven
SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
MODEL:MM720CXM

PRECAUTIONS TO AVAID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
a) Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
c) WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its surface could
be degraded and affect the lifespan of the apparatus and lead to a dangerous
situation.
SPECIFICATIONS
Model:
MM720CXM
Rated Voltage: 220-240V~
50Hz
Rated Input Power(Microwave):
1050 W
Rated Output Power(Microwave):
700 W
Oven Capacity:
20 L
Turntable Diameter: Ø255
mm
External Dimensions(LxWxH): 439.5mmX328mmX258.2mm
Net Weight: Approx
10.5kg
2

in
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive
microwave oven energy when using your appliance, follow basic precautions, including the
following:
1. Warning: Liquids and other foods must not be heated in sealed containers since
they are liable to explode.
2. Warning: It is hazardous for anyone other than a competent person to carry out
any service or repair operation that involves the removal of a cover which gives
protection against exposure to microwave energy.
3. Warning: Only allow children to use the oven without supervision when
adequate instructions have been given so that the child is able to use the oven
in a safe way and understand the hazards of improper use.
4. Warning: When the appliance is operated in the combination mode, children
should only use the oven under adult supervision due to the temperatures
generated. (only for grill series)
5. Only use utensils suitable for use in microwave ovens.
6. The oven should be cleaned regularly and any food deposits should be removed.
7. Read and follow the specific:"PRE-CAU
TIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
8. When heating food in plastic or paper containers, keep an eye on the oven due
to the possibility of ignition.
9. If smoke is observed, switch off or unplug the appliance and keep the door
closed in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes. Do not store items, such as
bread, cookies, etc. inside the oven.
12. Remove wire twist-ties and metal handles from paper or plastic containers/bags
before placing them in the oven.
13. Install or locate this oven only
in accordance with the installation instructions
provided
.
14. Eggs in the shell and whole hard-boiled eggs should not be heated in
microwave ovens since they may explode, even after microwave heating has
ended.
15. Use this appliance only for its
intended uses as described in manual. Do not
use corrosive chemicals or vapors in this appliance. This oven is especially
designed to heat. It is not designed for industrial or laboratory use .
3

16. If the supply cord is damaged, it
must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement or near a swimming pool.
19. The temperature of accessible surfaces may be high when the appliance is
operating. The surfaces are liable to get hot during use. Keep cord away from
heated surface, and do not cover any vents on the oven.
20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a
clean condition could lead to deterioration
of the surface that could
adversely affect the life of the appliance and
possibly result in a hazardous situation.
22. The contents of feeding bottles
and baby food jars shall be stirred or shaken
and the temperature checked before consumption, in order to avoid burns.
23. Microwave heating of beverages can result in delayed eruptive boiling; therefore
care must be taken when handling the container.
24. The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
25. Children should be supervised to ensure that they do not play with the
appliance.
26. The microwave oven shall not be placed in a cabinet unless it has been tested
in a cabinet.
27. Appliances are not intended to be operated by means of an external timer or
separate remote-control system.
28. The door or the outer surface may get hot when the appliance is operating.
29. The rear surface of appliance shall be placed against a wall.
4

SAFETY GROUNDING INSTALLATION
DANGER
Electric Shock Hazard
- Touching some of the internal components can cause serious personal injury or
death. Do not disassemble this appliance.
WARNING
Electric Shock Hazard
- Improper use of the grounding can result in electric shock. Do not plug into an
outlet until appliance is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood or if doubt exists as to whether the appliance is properly
grounded. If it is necessary to use an extension cord, use only a 3-wire extension
cord.
1. A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:
i. The marked electrical rating of the cord set or extension cord should be
at least as great as the electrical rating of the appliance.
ii. The extension cord must be a grounding- type 3-wire cord.
iii. The long cord should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or tripped over
unintentionally.
CAUTION
Personal Injury Hazard
It is hazardous for anyone other than a competent person to carry out any service or
repair operation that involves the removal of a cover which gives protection against
exposure to microwave energy.
5

APPLICABLE COOKING UTENSILS
See the instructions on "Materials you can use in microwave oven or to be avoided in
microwave oven." There may be certain non-metallic utensils that are not safe to use
for microwaving. If in doubt, you can test the utensil in question following the
procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the
utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave
cooking.
4. Do not exceed 1 minute cooking time
Materials You Can Use in Microwave Oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover
thin parts of meat or poultry to prevent overcooking.
Arcing can occur if foil is too close to oven walls. The foil
should be at least 2.5cm away from oven walls.
Browning dish Follow manufacturer’s instructions. The bottom of
browning dish must be at least 5mm above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer's instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking
bags
Follow manufacturer’s instructions. Do not close with
metal tie. Make slits to allow steam to escape.
Paper plates
and cups
Use for short–term cooking/warming only. Do not leave
oven unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use
with supervision for a short-term cooking only.
6

Parchment
paper
Use as a cover to prevent splattering or a wrap for
steaming.
Plastic Microwave-safe only. Follow the manufacturer’s
instructions. Should be labeled "Microwave Safe". Some
plastic containers soften, as the food inside gets hot.
"Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Aluminum tray May cause arcing. Transfer food into microwave-safe
dish.
Food carton with
metal handle
May cause arcing. Transfer food into microwave-safe
dish.
Metal or metal -
trimmed utensils
Metal shields the food from microwave energy. Metal trim
may cause arcing.
Metal twistties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside
when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and
may split or crack.
7

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
CB
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
Turntable shaft
a. Never place the glass tray upside down.
The glass tray should never be
restricted.
b. Both glass tray and turntable ring
assembly must always be used during
cooking.
c. All food and containers of food are
always placed on the glass tray for
cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Turntable Installation
8

20cm
30cm
20cm
min85cm
0cm
INSTALLATION
1. Select level surfaces that provide enough open space for the intake and/or outlet
vents.
The rear surface of appliance shall be placed against a wall.
A minimum clearance of 7.9inches (20cm) is required between the oven
and any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12 inches (30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio or TV
reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the
frequency is the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing
appliance. If installed near or over a heat source, the oven could be damaged
and the warranty would be void.
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the inside of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighboring parts must be cleaned carefully with a damp
cloth when they are dirty.
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such
as dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to
protect the magnetron.
9



Timer
Power 1 To set cooking power by
turning the power knob to
desired level.
2 To set the time of cooking by
turning the timer knob to
desired time per your food
cooking guide.
3
The microwave oven will
automatically start cooking after
power level and time are set.
4
After the cooking time is up, the
unit will "Dong" to stop.
5 If the unit is not in use,
always set time to "0".
OPERATION
CONTROL PANEL AND FEATURES
Operation Instructions
Function/Powe Out
p
ut
App
licati
Low 17% Soften ice cream
Med. Low 33% Soup stew, soften butter or defrost
Med. 55% Stew, fish
Med. High 77% Rice, fish, chicken, ground meat
High 100% Reheat, milk, boil water, vegetables,
Notice: When removing food from the oven, please ensure that the oven
power is switched off by turning the timer switch to 0 (zero).
Failure to do so, and operating the microwave oven without food in
it, can result in overheating and damage to the magnetron.
10
