Midea MMC07COAST User manual

Microwave Oven
INSTRUCTION MANUAL
EN
MMC07COAST
Read these instructions
carefullybefore using your
microwave oven, and keep
it carefully.
If you follow the instructions,
your oven will provide you
with many years of good
service.
Oven Capacity: 20 Liter
120V~ 60Hz, 0W
www.midea.com/global
105

PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
01
(a) Do not attempt to operate this oven with the door open since open
door operation can result in harmful exposure to microwave energy.
It is important not to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door
or allows soil or cleaner residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important
that the oven door close properly and that there is no damage to
the:
(1) DOOR (bent)
(2) HINGES AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACES
(d) The oven should not be adjusted or repaired by anyone except
properly qualified service personnel.
SPECIFICATIONS
Model:
Rated Voltage:
Rated Input Power (Microwave):
Rated Output Power (Microwave):
MMC07COAST
120V~60Hz
1050W
700W
EN-2

1. Read all instructions before using the appliance.
2. Read and follow the specific: "PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" found on page 2.
3. This appliance must be grounded. Connect only to properly grounded
outlet. See "GROUNDING INSTRUCTIONS" found on page 6.
4. Install or locate this appliance only in accordance with the provided
installation instructions.
5. Some products such as whole eggs and sealed containers - for
example, closed glass jars - are able to explode and should not be
heated in this oven.
6. Use this appliance only for its intended use as described in the manual.
Do not use corrosive chemicals or vapors in this appliance. This type
of oven is specifically designed to heat, cook or dry food. It is not
designed for industrial or laboratory use.
7. As with any appliance, close supervision is necessary when used by
children.
8. Do not operate this appliance if it has a damaged cord or plug, if it is
not working properly, or if it has been damaged or dropped.
9. This appliance should be serviced only by qualified service personnel.
Contact nearest authorized service facility for examination, repair, or
adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this product near
water - for example, near a kitchen sink, in a wet basement, near a
swimming pool, or similar location.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surface.
14. Do not let cord hang over edge of table or counter.
IMPORTANT SAFETY
INSTRUCTIONS
02
When using electrical appliances basic safety precautions should be
followed, including the following:
WARNING- To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy:
EN-3

15. When cleaning surfaces of door and oven that comes together on
closing the door, use only mild, nonabrasive soaps, or detergent
applied with a sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
- Do not overcook food. Carefully attend appliance when paper, plastic,
or other combustible materials are placed inside the oven to facilitate
cooking.
- Remove wire twist-ties from paper or plastic bag before placing bag
in oven.
- If material inside of the oven ignite, keep oven door closed, turn oven
off, and disconnect the power cord, or shut off power at the fuse or
circuit breaker panel.
- Do not use the cavity for storage purposes. Do not leave paper
products, cooking utensils, or food in the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be overheated
beyond the boiling point without appearing to be boiling. Visible
bubbling or boiling when the container is removed from the
microwave oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE
CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO
THE LIQUID. To reduce the risk of injury to persons:
- Do not overheat the liquid.
- Stir the liquid both before and halfway through heating it.
- Do not use straight-sided containers with narrow necks.
- After heating, allow the container to stand in the microwave oven
for a short time before removing the container.
- Use extreme care when inserting a spoon or other utensil into the
container.
SAVE THESE INSTRUCTIONS
EN-4

This appliance must be grounded. In the event of an electrical short
circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. This appliance is equipped with
a cord having a grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and grounded.
Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions
are not completely understood, or if doubt exists as to whether the
appliance is properly grounded. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade grounded plug,
and 3-slot receptacle that will accept the plug on the appliance. The
marked rating of the extension cord shall be equal to or greater than
the electrical rating of the appliance.
WARNING
Electric Shock Hazard
Touching some of the internal components can cause serious personal
injury or death. Do not disassemble this appliance.
DANGER
Electric Shock Hazard
Improper use of the grounding can result in electric shock. Do not plug
into an outlet until appliance is properly installed and grounded.
1. A short power-supply cord is provided to reduce the risks resulting
from becoming entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used
if care is exercised in their use.
3. If a long cord or extension cord is used:
(1) The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the appliance.
(2) The extension cord must be a grounding-type 3-wire cord.
(3) The longer cord should be arranged so that it will not drape over
the counter top or tabletop where it can be pulled on by children
or tripped over unintentionally.
WARNING
GROUNDING INSTRUCTIONS
03
EN-5

04
1. Operation of the microwave oven may cause interference to your radio,
TV or similar equipment.
2. When there is interference, it may be reduced or eliminated by taking
the following measures:
(1) Clean door and sealing surface of the oven.
(2) Reorient the receiving antenna of radio or television.
(3) Relocate the microwave oven with respect to the receiver.
(4) Move the microwave oven away from the receiver.
(5) Plug the microwave oven into a different outlet so that microwave
oven and receiver are on different branch circuits.
RADIO INTERFERENCE
EN-6

UTENSILS
05
Personal Injury Hazard
Tightly-closed utensils could explode. Closed containers should be
opened and plastic pouches should be pierced before cooking.
See the instructions on "Materials you can use in microwave oven
or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not safe to use
for microwaving. If in doubt, you can test the utensil in question
following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml)
along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it
for microwave cooking.
4. Do not exceed 1 minute cooking time.
UTENSILS
CAUTION
EN-7

MATERIALS YOU CAN USE IN MICROWAVE OVEN
REMARKS
Follow manufacturer’s instructions. The bottom of browning
dish must be at least 3/16 inch (5mm) above the turntable.
Incorrect usage may cause the turntable to break.
Dinnerware
Glass jars
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic wrap
Thermometers
Plastic
Glassware
UTENSILS
Browning dish
Microwave-safe only. Follow manufacturer's instructions.
Do not use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no
metallic trim.
Do not use cracked or chipped dishes.
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as
directed by package.
Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Use as a cover to prevent splattering or a wrap for steaming.
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
EN-8

MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
REMARKS
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
Wood will dry out when used in the microwave oven and
may split or crack.
May cause a fire in the oven.
May cause arcing and could cause a fire in the oven.
Metal shields the food from microwave energy. Metal trim
maycause arcing.
Aluminum tray
Metal or metal
trimmed utensils
Metal twist ties
Wood
Plastic foam
Paper bags
Food carton with
metal handle
UTENSILS
EN-9

06
SETTING UP YOUR OVEN
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray
Turntable ring assembly
Instruction Manual
1
1
1
F
G
A
C B
ED
Turntable Installation
Countertop Installation
Glass
tray
Turntable
shaft
Turntable ring assembly
Hub (underside)
Remove all packing material and accessories.
Examine the oven for any damage such as dents or broken door. Do not install if oven is
damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect
the magnetron.
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
EN-10

07
INSTALLATION
Installation
1. Select a level surface that provide enough open space for the intake
and/or outlet vents.
A minimum clearance of 3.0 inches (7.5cm) is required between the
oven and any adjacent walls. One side must be open.
The minimum installation height is 3.0ft(91.6cm).
(1) Leave a minimum clearance of 12 inches (30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio
or TV reception.
2. Plug your oven into a standard household outlet.
Be sure the voltage and the frequency is the same as the voltage and
the frequency on the rating label.
3.0 inch(7.5cm)
>3.0ft(91.6cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
WARNING: Do not install oven over a range cooktop or other heat-
producing appliance. If installed near or over a heat source, the oven
could be damaged and the warranty would be void.
The accessible surface
may be hot during
operation.
EN-11

08
OPERATION INSTRUCTION
Power Level
11 power levels are available.
Clock Setting
(1) Press " CLOCK "once, "00:00" will display.
(2) Press the number keys and enter the current time. For example,
time is 12:10 now, please press "1, 2, 1, 0" in turn.
(3) Press " CLOCK " to finish clock setting. ":" will flash and the clock
will be lighted.
(4) If the numbers input are not within the range of 1:00--12:59, the
setting will be invalid until valid numbers are input.
Note:
(1) In the process of clock setting, if the " STOP/CANCEL " button is
pressed or if there is no operation within 1 minute, the oven will
go back to the former setting automatically.
(2) If the clock need to be reset, please repeat step 1 to step 3.
Note:
(1) The kitchen time is different from 12-hour system. Kitchen Timer
is a timer.
(2) During kitchen timer, any program cannot be set.
Kitchen Timer
(1) Press " TIMER " once, the screen will display 00:00, the first hour
figure flash.
(2) Press the number keys and enter the timer time. (The maximum
cooking time is 99 minutes and 99 seconds.)
(3) Press " START/+30SEC. " to confirm setting.
(4) When the timer time arrives, the buzzer will ring 5 times.
If the clock has been set (12-hour system), the screen will display
the current time.
Level
Power
Display
10
100%
PL10
9
90%
PL9
8
80%
PL8
7
70%
PL7
6
60%
PL6
5
50%
PL5
4
40%
PL4
3
30%
PL3
2
20%
PL2
1
10%
PL1
0
0%
PL0
EN-12

Microwave cook
(1) Press " COOK TIME " once, the screen will display "00:00".
(2) Press number keys to input the cooking time; the maximum
cooking time is 99 minutes and 99 seconds.
(3) Press " POWER LEVEL " once, the screen will display "PL10".
The default power is 100% power. Now you can press number
keys to adjust the power level.
(4) Press " START/+30SEC. " to start cooking.
Example: to cook the food with 50% microwave power for 15 minutes.
a. Press " COOK TIME " once. "00:00" displays.
b. Press "1", "5", "0", "0" in order.
c. Press " POWER LEVEL " once, then press "5" to select 50%
microwave power.
d. Press " START/+30SEC. " to start cooking.
Speedy Cooking
(1) In waiting state, instant cooking at 100% power level can be
started by select a cooking time from 1 to 6 minutes by pressing
number pads1 to 6. Press " START/+30SEC. " to increase the
cooking time; the maximum cooking time is 99 minutes and 99
seconds.
(2) In waiting state, instant cooking at 100% power level with 30
seconds' cooking time can be started by pressing " START/
+30SEC ". Each press on the same button will increase cooking
time by 30 seconds. the maximum cooking time is 99 minutes
and 99 seconds.
Note:
(1) In the process of setting , if the " STOP/CANCEL " button is
pressed or if there is no operation within 1 minute, the oven will
go back to the former setting automatically.
(2) If "PL 0" selected, the oven will work with fan for no power.
You can use this level to remove the odour of the oven.
(3) During microwave cooking, " POWER LEVEL " can be pressed to
change the power you need.
After pressing " POWER LEVEL ",the current power flash for 3
seconds, now you can press number button to change the power.
The oven will work with the selected power for the rest time.
Note:
during microwave cooking and time defrost, time can be added by
pressing " START/+30SEC. " button.
EN-13

Weight Defrost Function
(1) Press " WEIGHT DEFROST "once, the screen will display "dEF1".
(2) Press numerical buttons to input weight to be defrosted.
Input the weight ranged between 4~100 Oz.
(3) Press " START/+30SEC. " to start defrosting and the cooking
time remained will be displayed.
Time Defrost Function
(1) Press " TIME DEFROST " once, the screen will display "dEF2".
(2) Press number pads to input defrosting time. The effective time
range is 0:01~99:99
(3) The default microwave power is power level 3. If you want to
change the power level, press " POWER LEVEL " once, and the
screen will display "PL 3", then press the number pad of the
power level you wanted.
(4) Press " START/+30SEC. " to start defrosting. The remained
cooking time will be displayed.
Multi-stage cooking
At most 2 stages can be set for cooking. In multi-stage cooking, if
one stage is defrosting, then defrosting shall be placed at the first
stage automatically.
PIZZA
(1) Press " PIZZA " repeatedly until the number you wish appears
in the display, "4.0-", "8.0-", "14.0-"will display in order.
For example, press " PIZZA" once, "4.0-" appears.
(2) Press " START/ +30SEC. " to cook, buzzer sounds once. When
cooking finishes, buzzer sounds five times and then turn back to
waiting state.
Note:
Auto cooking cannot work in the multi-stage cooking.
Note: the default power is P70.
Example: if you set the defrost for 10 Oz and cook with 80% power
level for 7 minutes.
The cooking steps are as following:
(1) Press " WEIGHT DEFORST " once, then "DEF1" will display.
(2) Press "1","0" to input the weight of food.
(3) Press " COOK TIME " once, then press "7", "0", "0" to set the
cooking time;
(4) Press " POWER LEVEL "once, then press "8" to select 80%
microwave power.
(5) Press " START/ +30SEC. " to start cooking.
EN-14

POPCORN
(1) Press " POPCORN "repeatedly until the number you wish
appears in the display, "1.75", "3.0-" ,"3.5-" will display in order.
For example, press " POPCORN " once, "1.75" appears.
(2) Press " START/+30SEC. " to cook, buzzer sounds once. When
cooking finishes, buzzer will sound fiven times and then turn back
to waiting state.
Note: the default power is P100.
Auto menu
(1) In waiting state,press " MENU " and then “A1” will display.
(2) Press " MENU " to choose the desired menu,A1~A4 are available.
(3) Press " Start/+30Sec./Confirm " to confirm.
(4) Press " MENU " again to choose the weight.
(5) Press " Start/+30Sec./Confirm " to start cooking.
Auto Menu Chart
Menu Weight(g) Display Power
A-1
Potato
1
2
3
1
2
3
P100
A-2
Frozen
Vegetable
4 Oz
8 Oz
16 Oz
4.0
8.0
16.0
P100
A-3
Pizza
1 cup
2 cups
3 cups
1
2
3
P100
A-4
Dinner Plate
9 Oz
12 Oz
18 Oz
2 cups
3 cups
9.0
12.0
18.0
2
3
P70
EN-15

LOCK FUNCTION FOR CHILDREN
Lock: In waiting state, press " STOP/CANCEL " for 3 seconds, there
will be a long "beep" denoting the entering into the children-lock
state; meanwhile, screen will display locked icon.
Lock quitting: In locked state, press " STOP/CANCEL " for 3 seconds,
there will be a long "beep" denoting that lock is released.
INQUIRING FUNCTION
In cooking state, press " CLOCK ", the oven will display clock for
three seconds.
SLIDE MODE
To activate the silent mode:
In waiting state, press and hold “8” for 3 seconds.
A long beep will sound.
When you press the keys, it does not make a sound.
To deactivate the silent mode:
In silent mode, press and hold “8” for 3 seconds.
A long beep will sound.
ECO FUNCTION
To enter ECO mode:
In waiting state, press " 0/ECO " twice within one second.
The screen will turn off.
To cancel ECO mode:
In ECO mode, press any keys or open or close the door.
EN-16

09
MAINTENANCE
Troubleshooting
Check your problem by using the chart below and try the solutions
for each problem. If the microwave oven still does not work properly,
contact the nearest authorized service center.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Oven will not start
a. Electrical cord for oven is
not plugged in.
b. Door is open.
c. Wrong operation is set.
a. Plug into the outlet.
b. Close the door and try
again.
c. Check instructions.
Unevenly cooked
foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Cooking time, power level
is not suit ble.
d. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Use correct cooking time,
power level.
d. Turn or stir food.
Overcooked foods Cooking time, power level is
not suitable. Use correct cooking time, power level.
Arcing or sparking
a. Materials to be avoided in
microwave oven were used.
b. The oven is operated when
empty.
c. Spilled food remains in the
cavity.
a. Use microwave-safe
cookware only.
b. Do not operate with
oven empty.
c. Clean cavity with wet
towel.
Undercooked foods
a. Materials to be avoided in
microwave oven were used.
b. Food is not defrosted
completely.
c. Oven ventilation ports are
restricted.
d. Cooking time, power level is
not suitable.
a. Use microwave-safe
cookware only.
b. Completely defrost food.
c. Check to see that oven
ventilation ports are not
restricted.
d. Use correct cooking
time, power level.
Improper defrosting
a. Materials to be avoided in
microwave oven were used.
b. Cooking time, power level is
not suitable.
c. Food is not turned or stirred.
a. Use microwave-safe
cookware only.
b. Use correct cooking
time, power level.
c. Turn or stir food.
EN-17

EN
MMC07COAST
www.midea.com/global
MANUEL D ’ INSTRUCTIONS
Capacité du four: 20 litres
120 V~ 6 0 Hz, 1050 W
Lisez ces instructions
attentivement avant
d’utiliser votre four micro-
ondes et assurez-vous de
les conserver.
Si vous suivez ces instructions,
votre four vous fournira de
nombreuses anné es de bons
services.
FOUR MICRO-ONDES
