Midea MLH52N5AWW Manual

MLH52N5AWW

WASHER SAFETY ............................................................................3
Proper Installation .................................................................................5
When Not in Use ....................................................................................5
OPERATION REQUIREMENTS ....................................................... 6
Location of Your Washer ....................................................................6
Electrical Requirements ......................................................................6
Water Supply Requirements ..............................................................7
Drain Requirements ..............................................................................7
INSTALLATION INSTRUCTIONS ....................................................8
Before You Begin ...................................................................................8
Tools Required ........................................................................................8
Parts Required (Obtain Locally) ......................................................9
Parts Supplied .........................................................................................9
Rough-In Dimensions ...........................................................................9
Unpacking the Washer ......................................................................10
Installing the Washer ........................................................................... 11
WASHER USE .................................................................................14
Control Panel ......................................................................................... 14
Features ................................................................................................... 19
Loading and Using the Washer ..................................................... 22
Dear user
THANK YOU and CONGRATULATIONS on your purchase of
this high-quality Midea product. Your Midea washer is designed
for reliable, trouble-free performance. Please take a moment to
register your new washer.
Register your new washer at
https://www.midea.com/ca/support/Product-registration
For future reference, record your product model and serial
numbers located on the inside frame of the washer.
Model Number________________________________________
Serial Number_________________________________________

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
WARNING
To reduce the risk of death, fire, explosion, electric shock, or injury
to persons when using your vfd appliance, follow basic precautions,
including the following:
• Read the instruction manual before using the appliance.
• DO NOT wash or dry articles that have been previously cleaned in,
washed in, soaked in or spotted with gasoline, dry-cleaning solvents,
or other flammable or explosive substances, as they give off vapors
that could ignite or explode.
• DO NOT add gasoline, dry-cleaning solvents, or other flammable or
explosive substances to the wash water. These substances give off
vapors that could ignite or explode.
• Under certain conditions, hydrogen gas may be produced in a
hot-water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a washing machine, turn
on all hot-water faucets and let the water flow from each for several
minutes. This will release any accumulated hydrogen gas. As the gas
is flammable, DO NOT smoke or use an open flame during this time.
• DO NOT allow children to play on or in this appliance. Close
supervision of children is necessary when this appliance is used near
children. Before the washer is removed from service or discarded,
remove the door or lid. Failure to follow these instructions may
result in death or injury to persons.
• DO NOT reach into the appliance if the drum or other components
are moving to prevent accidental entanglement.
• DO NOT install or store this appliance where it will be exposed to the
weather.
• DO NOT tamper with controls, repair or replace any part of this
appliance or attempt any servicing unless specifically recommended
in the user maintenance instructions or in published user repair
instructions that you understand and have the skills to carry out.
• Keep the area around your appliance clean and dry to reduce the
possibility of slipping.
• DO NOT operate this appliance if it is damaged, malfunctioning,
partially disassembled, or has missing or broken parts including a
damaged cord or plug.
• Unplug the appliance or turn off the circuit breaker before servicing.
Pressing the Power button DOES NOT disconnect power.
• See “Electrical Requirements” located in the Installation Instructions
for grounding instructions. This appliance is not intended for use
by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with appliance.
4
IMPORTANT SAFETY INSTRUCTIONS

• This washer must be properly installed and located in accordance
with the Installation Instructions before it is used. Ensure the cold
water hose is connected to the “C” valve.
• Install or store where it will not be exposed to temperatures below
freezing or exposed to the weather, which could cause permanent
damage and invalidate the warranty.
Properly ground washer to conform with all governing codes and
ordinances. Follow details in installation instructions.
WARNING
Electrical Shock Hazard
• Plug into a grounded 3 prong outlet.
• Do not remove the ground prong.
• Do not use an adapter.
• Do not use an extension cord.
• Failure to do so can result in death, fire or electrical
shock.
WARNING: Cancer and Reproductive Harm
-www.P65Warnings.ca.gov.
PROPER INSTALLATION
WHEN NOT IN USE
Turn off water faucets to minimize leakage if a break or rupture should
occur. Check the condition of the fill hoses; We recommend changing the
hoses every 5 years.
State of California Proposition 65 Warnings:
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
5
• If the supply cord is damaged, it must be replaced by the
manufacture, its service agent or similarly qualified persons in order
to avoid a hazard.
• The new hose-sets bought from the retailer where the product was
purchased are to be used and that old hose-sets should not be
reused.
• This appliance is for indoor use only.
SAVE THESE INSTUCTIONS
Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK AND PERSONAL
INJURY:
• DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG
WITH THIS APPLIANCE. Washer must be electrically grounded in
accordance with local codes and ordinances.
6
OPERATION REQUIREMENTS
LOCATION OF YOUR WASHER
DO NOT INSTALL THE WASHER:
1. In an area exposed to dripping water or outside weather conditions.
The ambient temperature should never be below 60°F (15.6°C) for
proper washer operation.
2. In an area where it will come in contact with curtains or drapes.
3. On carpet. The floor MUST be a hard surface with a maximum slope of
1/2" per foot (1.27 cm per 30 cm). To make sure the washer does not
vibrate or move, you may have to reinforce the floor.
NOTE: If floor is in poor condition, use 3/4" impregnated plywood sheet
solidly attached to the existing floor covering.
IMPORTANT: MINIMUM INSTALLATION CLEARANCES
• When installed in alcove: Top and Sides = 0" (0 cm), Back = 3" (7.6 cm)
• When installed in closet: Top and Sides = 0" (0 cm), Front = 2" (5 cm),
Back = 3" (7.6 cm)
• Closet door ventilation openings required: 2 louvers each 60 square in.
(387 cm), located 3" (7.6 cm) from top and bottom of door
ELECTRICAL REQUIREMENTS
Read these instructions completely and carefully.
CIRCUIT - Individual, properly polarized and grounded 16-amp branch
circuit fused with 16-amp time -delay fuse or circuit breaker.
POWER SUPPLY - 2-wire with ground, 120V~, single-phase, 60Hz,
alternating current.
OUTLET RECEPTACLE - Properly grounded receptacle located so the
power supply cord is accessible when the washer is in an installed
position.

BACK
47.24"
(120 cm)
Max.
GROUNDING REQUIREMENTS
Improper connection of the equipment grounding conductor can result in a
risk of electrical shock. Check with a licensed electrician if you are in doubt
as to whether the appliance is properly grounded.
1. The washer MUST be grounded. In the event of malfunction or breakdown,
grounding will reduce the risk of electrical shock by providing a path of
least resistance for electrical current.
2. Since your washer is equipped with a power supply cord having an
equipment-grounding conductor and a grounding plug, the plug MUST
be plugged into an appropriate, copper-wired receptacle that is properly
installed and grounded in accordance with all local codes. If in doubt, call
a licensed electrician. DO NOT cut off or alter the grounding prong on the
power supply cord. In situations where a two-slot receptacle is present, it
is the owner’s responsibility to have a licensed electrician replace it with
a properly grounded grounding-type receptacle.
WATER SUPPLY REQUIREMENTS
Hot and cold water faucet MUST be installed within 42" (107 cm) of your
washer’s water inlet. The faucet MUST be 3/4" (1.9 cm) garden hose-type
so inlet hoses can be connected. Water pressure MUST be between 10 and
120psi. Your water department can advise you of your water pressure.
DRAIN REQUIREMENTS
1. Drain capable of eliminating 64.3 L per minute.
2. A standpipe diameter of 1-1/4" (3.18 cm) minimum.
3. The standpipe height above the floor should be:
Minimum height: 24" (61 cm)
Maximum height: 47.24" (120 cm)
7
24"
(61 cm)
Min.
Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
• IMPORTANT - Save these instructions for local
inspector’s use.
• IMPORTANT - Observe all governing codes and ordinances.
• Note to Installer - Be sure to leave these instructions with the
Consumer.
• Note to Consumer - Keep these instructions for future reference.
• Skill level - Installation of this appliance requires basic mechanical
and electrical skills.
• Completion time - 1-3 hours.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under the
Warranty.
WARNING
• This appliance must be properly grounded and installed as described
in these Installation Instructions.
• Do not install or store the appliance in an area where it will be
exposed to water/weather. See the Location of Your Washer section.
• NOTE: This appliance must be properly grounded, and electrical
service to the washer.
• Certain internal parts are intentionally not grounded and may present
a risk of electric shock only during servicing. Service Personnel - Do
not contact the following parts while the appliance is energized:
Electrical Valve, Drain Pump, Heater and Motor.
8
INSTALLATION INSTRUCTIONS
BEFORE YOU BEGIN
Read these instructions completely and carefully.
FOR YOUR SAFETY:
TOOLS REQUIRED
•Adjustable wrench or 1/2" (13mm) socket with ratchet
•Adjustable wrench or 9/16" (14mm) open-end wrench
•Channel-lock adjustable pliers
•Carpenter’s level

27.0"
(68.6 cm)
39.8"
(101.09 cm)
SIDE
34.2"
(86.9cm)
PARTS REQUIRED (OBTAIN LOCALLY)
Water Hose (2)
PARTS SUPPLIED
Inlet Hose Screen Washers(2)
ROUGH-IN DIMENSIONS
*NOTE: With pedestal, 52.6"
Stacked, 84"
9
Cable Tie Drain Hose Guide
Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use
39.8"
(101.09 cm)

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
WARNING:
• Recycle or destroy the carton and plastic bags after the washer is
unpacked. Make materials inaccessible to children. Children might use
them for play. Cartons covered with rugs, bedspreads or plastic sheets
can become airtight chambers causing suffocation.
1. Cut and remove the top and bottom packaging straps.
2. While it is in the carton, carefully lay the washer on its side. DO NOT lay
the washer on its front of back.
3. Turn down the bottom flaps-remove all base packaging, including the
cardboard, styrofoam base and styrofoam tub support (inserted in
center of base).
NOTE: If you are installing a pedestal, proceed to the installation instructions
that come with the pedestal.
4. Carefully return the washer to an upright position and remove the carton.
5. Carefully move the washer to within 4 feet (122 cm) of the final location.
6. Remove the following from the back side of the washer:
4 bolts
4 plastic spacers (including rubber grommets)
4 power cord retainers
10
UNPACKING THE WASHER
IMPORTANT: Failure to remove the shipping bolts* can cause the washer to
become severely unbalanced.
Save all bolts for future use.
* Any damages from failure to remove the shipping bolts are not covered by the
warranty.

Inlet
Hose
Screen
Washers
NOTE: If you must transport the washer at a later date, you must reinstall
the shipping support hardware to prevent shipping damage. Keep the
hardware in the plastic bag provided.
INSTALLING THE WASHER
1. Run some water from the cold faucet to flush the water lines and
remove particles that might clog up the inlet hose.
2. Ensure there is a rubber washer in the hoses. Reinstall the rubber
washer into the hose fitting if it has fallen out during shipment.
Carefully connect the inlet hose marked HOT to the rear “H” inlet of the
water valve. Tighten by hand;then tighten another 2/3 turn with pliers.
And COLD to the rear “C” inlet of the water valve. Tighten by hand;
then tighten another 2/3 turn with pliers.
Do not crossthread or over-tighten these connections.
3. Install the screen washers by inserting them into the free ends of the
inlet hoses with protruded side facing the faucet.
4. Connect the inlet hose ends to the HOT and COLD water faucets
tightly by hand, then tighten another 2/3 turn with pliers. Turn the
water on and check for leaks.
5. Carefully move the washer to its final location. Gently rock the washer
into position ensuring inlet hoses do not become kinked. It is important
not to damage the rubber leveling legs when moving your washer to its
final location. Damaged legs can increase washer vibration. It may be
helpful to spray window cleaner on the floor to help move your washer
into its final position.
NOTE: To reduce vibration, ensure that all four rubber leveling legs are
firmly touching the floor. Push and pull on the back right and then back
left of your washer.
11
H
C
Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
Cable
Tie Cable
Tie
Cable
12
NOTE: Do not use the dispenser drawer or door to lift the washer.
NOTE: If you are installing into a drain pan, you can use a 24-inch long 2x4
to lever the washer into place.
6. With the washer in its final position, place a level on top of the washer
(if the washer is installed under a counter, the washer should not be able
to rock). Adjust the front leveling legs up or down to ensure the washer
is resting solid. Turn the locknuts on each leg up towards the base of the
washer and snug with a wrench.
NOTE: Keep the leg extension at a minimum to prevent excessive
vibration. The farther out the legs are extended, the more the washer
will vibrate.
If the floor is not level or is damaged, you may have to extend the rear
leveling legs.
7. Attach the U-shaped hose guide to the end of the drain hose. Place
the hose in a laundry tub or standpipe and secure it with the cable tie
provided in the enclosure package.
NOTE: Placing the drain hose too far down the drain pipe can cause a
siphoning action. No more than 7 inch (17.78 cm) of hose should be in the
drain pipe. There must be an air gap around the drain hose. A snug fit can
also cause a siphoning action.
8. Plug the power cord into a grounded outlet.
NOTE: Check to be sure the power is off at the circuit breaker/fuse box
before plugging the power cord into an outlet.
9. Turn on the power at the circuit breaker/fuse box.
10. Read the rest of this Owner’s Manual. It contains valuable and helpful
information that will save you time and money.

11. Before starting the washer, check to make sure:
• Main power is turned on.
• The washer is plugged in.
• The water faucets are turned on.
• The unit is level and all four leveling legs are firmly in the floor.
• The shipping support hardware is removed and saved.
• The drain hose is properly tied up.
12. Run the washer through a complete cycle.
13. If your washer does not operate, please review the Before You Call
For Service section before calling for service.
14. Place these instructions in a location near the washer for future
reference.
13
Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
QUICK START
Press the Power button.
If the screen is dark, a press of the Power
button will “wake up” the display.
Select a wash cycle. (Defaults are set for
each cycle. These default settings can be
changed. See Control setting for more
information).
Press the START/PAUSE.
14
WASHER USE
CONTROL PANEL
CONTROL SETTING
Power
Press to “wake up” the display. If the display is active, press to put
the washer into standby mode.
NOTE: Pressing Power does not disconnect the appliance from the
power supply.
6
Normal/Colors
Bulk/Sheets
Heavy Duty
Whites
Towels Rinse & Spin
Tub Clean
Sportswear
Delicates
Quick Wash
Extra Heavy
Heavy
Medium
Light
Extra Light
Hot
Warm
Eco Warm
Cold
Tap Cold
Extra High
High
Medium
Low
No Spin
POWER
START/PAUSE
Spin Speed
Soil Level Wash Temp
PRE
SOAK DELAY EXTRA
RINSE
Water Plus/Hold 3 sec Control Lock/Hold 3 sec
Normal/Colors
Bulk/Sheets
Heavy Duty
Whites
Towels Rinse & Spin
Tub Clean
Sportswear
Delicates
Quick Wash

Wash Cycles
The wash cycles are optimized for specific types of wash loads. The
chart below will help you match the setting with the loads.
15
Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use
Normal/
Colors
For heavily to lightly soiled colorfast cottons, household
linens, work and play clothes.
NOTE: This is the most common cycle.
Bulky/
Sheets
For large items such as comforters, blankets, small rugs
and similar bulky items.
Heavy
Duty
Washing the large and heavy clothing, such as overcoats
or towels.
Whites For heavily to lightly soiled white laundry, work and play
clothes
Towels For items such as towels, sheets, pillowcases and dish
rags.
Quick Wash For lightly soiled items needed in a hurry. Cycle time
is approximately 40 minutes, depending on selected
options.
Delicates For delicate, washable textiles, e.g. made of silk, satin,
synthetic fibers or blended fabrics.
Sportswear Washing the activewear.
Tub Clean Use for cleaning the basket of residue and odor.
Recommended use of at least once per month.
NOTE: Never load laundry white using Tub Clean.
The laundry may become damaged See the Care and
Cleaning section.
Rinse &
Spin
To quickly rinse and spin out any items at any time.

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
16
SOIL LEVEL Change the Soil level
to increase or decrease
the wash time to
remove different
amounts of soil.
To change the Soil level,
press the Soil level button
until you have reached the
desired setting. You can
choose between Extra Light,
Light, Medium, Heavy or
Extra Heavy soil levels.
WASH TEMP Adjust to select the
proper main water
temperature for
the wash cycle. The
PreWash rinse water
is always cold to help
reduce energy usage
and reduce setting of
stains and wrinkles.
Follow the fabric
manufacturer’s care
label when selecting
the wash temperature.
To change the wash
temperature, press the
wash Temp button until you
have reached the desired
setting.
Tap Cold, Cold,Eco Warm,
You can choose between
Warm or Hot.
By design, to protect
fabrics, not all wash
temperatures are available
for certain wash cycles.
SPIN SPEED Changing the Spin
speed changes the
final spin speed of
the cycles. Always
follow the garment
manufacturer’s care
label when changing
the Spin speed.
To change the Spin speed,
press the Spin speed button
until you have reached the
desired setting. You can
choose between No Spin,
Low, Medium, High or Extra
High. Higher spin speeds
are not available on certain
cycles, such as Delicates.
Higher spin speeds remove
more water from the clothes
and will help reduce dry
time, but may also increase
the possibility of setting
wrinkles on some fabrics.

Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use
17
PRE SOAK For soaking your
garments prior to
the wash cycle. This
option begins with a
brief tumble and then
proceeds to soak the
clothes with water
and detergent for a
specified period of
time. Once complete,
the cycle will begin
automatically. Pre Soak
must be selected prior
to pressing button.
The Pre Soak time will
add an additional 10-20
minutes to the overall
wash time. High-eciency
detergent from the main
wash compartment in the
dispenser is used for the Pre
Soak period and main wash
cycle.
WATER
PLUS
Hold 3 sec
Increases the water
level of the main wash.
Option is available on
Normal/Colors,Bulky/
Sheets,Heavy
Duty,Whites, Towels,
Delicates, Sportswear
To use:
1. Turn power ON and select
a wash cycle.
2. Select the Add Water Plus
button to activate water
plus.
3. Press the button.
DELAY You can delay the
start of a wash cycle
for up to 24 hours.
Press the Delay Wash
button to choose the
amount of time you
want to delay the start
of the wash cycle.
Once the desired time
is reached, press the
button. The machine
will count down and
start automatically at
the correct time.
NOTE: If you forget to close
the door, a double beep will
sound when pressing pause/
add garment button.
NOTE: If you open the door
when the delay is count-
ing down, the machine will
enter the pause state. You
must close the door and
press again in order to
restart the countdown.
EXTRA
RINSE
This option allows for
an extra rinse during a
cycle to remove excess
dirt and detergent
from soiled loads.

DELAY and
EXTRA
RINSE
Control Lock/Hold 3 sec
You can lock the
controls to prevent any
selections from being
made. Or you can lock
or unlock the controls
after you have started
a cycle.
Children cannot
accidentally start the
washer by touching
buttons with this
option selected.
To lock the washer, press
and hold the Delay and
Extra Rinse buttons for
3 seconds.
To unlock the washer
controls, press and hold
Delay and Extra Rinse
buttons for 3 seconds.
NOTE: The Power button
can still be used when the
machine is locked.
STAR T/PAUSE
Press to start a wash
cycle. If the washer
is running,pressing it
once will pause the
washer. Press again to
restart the wash cycle.
If you want add a
garment, please press
the button.
The washer will unlock
the door. Press again
to restart the cycle.
NOTE: In some cycles the
washer will drain first,then
unlock the door when it is
paused.
NOTE: The washer performs
automatic system checks
after pressing the button
You may hear the door lock
and unlock before water
flows, this is normal.
Display Displays the
approximate time
remaining until the end
of the cycle.
NOTE: The cycle time
is affected by the
water pressure in your
home and the balance
of the load in the
washer. You may see
the time remaining on
the display increase to
accommodate a slower
spin speed to handle
unbalanced loads.
%$
&'
Wash
Rinse
Spin
Cycle status is also
displayed and certain
features such as Delay
Wash or Steam are shown
indicating they have been
selected.
ADisplay
Wash Time Delay Time
END Error
BRemain-Delay
CChild Lock
DDoor Lock
Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
18

FEATURES
THE DISPENSER DRAWER
Slowly open the dispenser drawer by pulling it out until it stops.
After adding laundry products, slowly close the dispenser drawer. Closing
the drawer too quickly could result in early dispensing of the bleach,
fabric softener or detergent.
You may see water in the dispenser drawer at the end of the cycle. This
is a result of the flushing/siphoning action and is part of the normal
operation of the washer.
NOTE: Liquid detergent will drain into the washer drum as it is added.
• Detergent usage may need to be adjusted for water temperature,
water hardness, size and soil level of the load. Avoid using too
much detergent in your washer as it can lead to over sudsing and
detergent residue being left on the clothes.
19
Washer
Safety Operation
Requirements Installation
Instructions Troubleshooting
Washer Care
Washer Use

Washer
Safety Operation
Requirements Installation
Instructions TroubleshootingWasher CareWasher Use
Remove for powder detergent
Normal
HE Liquid
Detergent
Setting
2X HE Liquid
Detergent
Setting (most
common
setting)
3X HE
Liquid
Detergent
Setting
2X
DETERGENT
The Detergent Compartment
• High-ecient detergent is required for this washer.
Use the detergent manufacturer’s recommended amount.
• Add measured detergent to the front left detergent compartment of
the dispenser drawer.
• Detergent is flushed from the dispenser at the beginning of the wash
cycle. Either powdered or liquid detergent can be used.
• Powder Detergent-Remove the Detergent selection insert and place
it in a safe location outside of the washer. Follow the detergent
manufacturer’s instructions when measuring the amount of powder to
use.
• Detergent usage may need to be adjusted for water temperature,
water hardness, size and soil level of the load. Avoid using too much
detergent in your washer as it can lead to oversudsing and detergent
residue being left on the clothes.
• Using more detergent than the recommended quantity can cause
residue buildup on your washer.
• Liquid Detergent - Locate the concentration of your detergent on
the bottle. Place the Detergent selection insert in the corresponding
location depending on the concentration.
remove for powder
SO
LIQUID 1X3X
20
