Midian TVS-2-TAIT User manual

TVS-2-TAIT
High Level Rolling Code Scrambler for the Tait Orca & TM-8000 Radios
VPU-15-TAIT
Voice Inversion Scrambler for the Tait Orca & TM-8000 Radios
Manual Revision: 2008-05-01
Covers Software Revisions:
TVS-2-TAIT: 4.93 & Higher
VPU-15-TAIT: 4.93 & Higher
This manual & product supports the following radios:
Portables: Tait Orca 5010/5020/5040
Mobiles: TM-8115
1

SPECIFICATIONS
Operating Voltage 5 VDC
Operating Current 8 mA
Operating Temperature -30 - +60 C
Frequency Response 300-2400 Hz
Input Impedance >25 kΩ
Carrier Suppression 65 dB < Peak Voice
Audio Output Impedance <1K Ω
Security Specifications: TVS-2
Encryption Sequences +40 Trillion
Random Number Generator 64 bits
Sequence Length (est.) 84 billion years
Security Specifications: VPU-15
Inversion Frequencies 37
INSTALLATION OVERVIEW
1. Test the radio for functionality.
2. Program the radio per the Radio Programming Section of this manual.
3. Install the scrambler into the radio per the Hardware Installation Section of this manual.
4. Program the scrambler per the Product Programming Section of this manual.
*** Midian is not responsible for any damage/loss resulting from the use of Midian’s products.
GENERAL INFORMATION
TVS-2: The TVS-2 is a high-level rolling code scrambler that uses hopping type rolling code encryption for higher
security rather than the sweeping code type. The scrambler is capable of features such as ANI, ENI, Deadbeat
Disable, Spy, and more when using Midian’s Kryptic Signaling format with the CAD-300/DDU-300/TRC-300. For
more details, please see the TVS-2 Technical Reference Manual.
VPU-15: The VPU-15 is an entry level voice inversion scrambler. The scrambler is capable of features such as
ANI, ENI, Deadbeat Disable, Spy, and more when using Midian’s Kryptic Signaling format with the CAD-
300/DDU-300/TRC-300. For more details, please see the VPU-15 Technical Reference Manual.
2

RADIO PROGRAMMING
Tait Orca Portables:
In the “Specifications” screen, set the “Maximum Number of Encryption Codes” to the desired number of codes
(1-4 codes). This should correspond to the number of codes programmed into the scrambler. The 5010 can only
be single code.
In the “Key Settings” screen, set the Function 1, 2 or 3 key for mode select and code select. It is recommended to
program the Short Press key to “Encryption On/Off” for mode select and the Long Press key to “Encryption Code
Select” for code select. If only using 1 security code it is not necessary to program a key for code select.
3

Tait TM-8000 Mobiles:
Set the Programmable I/O on the Digital tab as follows:
1. Set Pin IOP_GP101 to Output > PTT > Reflect PTT Status > Active Low.
2. Set Pin IOP_GP102 to Input > PTTOUT > External PTT 1 > Active Low.
3. Set Pin IOP_GP103 to Output > MODE > F1 Key Status > Active Low >Latching. Note: This can also be set
to F2, F3 or F4. F2, F3 and F4 can also be set to momentary to allow for code selection in addition to mode.
4. Set Pin IOP_GP106 to Output > Busy Status > Active Low.
Set the Programmable I/O on the Audio tab as shown in the diagram below.
4

1. Set one key (Key 1 – Key 4) to Encryption. This will be the front panel key used to turn the scrambler on/off. If
the button is programmed for latched (see above) the button can only be used for mode selection. Key 2-4
can be programmed for momentary. In this case the button can be used for mode selection and code
selection. Pressing and releasing the key will change mode. Pressing and holding the key will change code.
5

HARDWARE INSTALLATION
Be certain to follow standard anti-static procedures when handling any of Midian’s products.
Tait Orca Portables:
Disassembling the Radio:
Reference the Tait Orca Service Manual for instructions on disassembly of the radio. Use extreme care when
disassembling the radio.
Installing the Scrambler:
Flex Installed: Make certain R5 and R6 are removed from the flex. The scrambler plugs onto the flex pads
labeled TS1. Lift the latch on the scrambler and plug the scrambler into the flex. Make certain the flex is inserted
evenly into the connector. Close the latch.
Remove R5 & R6
Program Out
Right Pad
Pro
g
ram In
Flex Not Installed: If the flex is not installed, please reference the Service Manual for Tait Encryption for
installation of the flex. Make certain R5 and R6 are removed from the flex. The scrambler plugs onto the flex
pads labeled TS1. Lift the latch on the scrambler and plug the scrambler into the flex. Make certain the flex is
inserted evenly into the connector. Close the latch.
Reassembling the Radio:
1. If programming the scrambler using the KL-3, proceed to the programming section. Reference the Tait Orca
Service Manual for instructions on assembly of the radio. Use extreme care when assembling the radio.
6

Tait TM-8000 Series Mobiles:
Tait Orca Portables:
Disassembling the Radio:
Reference the Tait Service Manual for instructions on disassembly of the radio. Use extreme care when
disassembling the radio.
Installing the Scrambler:
The scrambler plugs into the TM-8000 using the encryption interface module (EIM) from Tait. The Tait part
number for this is 228-24341-01. The 228-24341-01 should include the EIM, a gray ribbon cable, a white flex
cable, and mounting screws for the scrambler and EIM.
1. Set the links on the Tait EIM as follows and remove resistor R-27 from the interface:
Link Position
1 Open
2 Open
3 Open
4 Open
5 Open
6 Open
7 2-3
8 Open
9 1-2
10 Open
2. Plug the scrambler into the EIM using the white flex cable. See picture below:
3. Mount the scrambler onto the EIM as shown in the picture below:
7

4. Plug the gray ribbon cable from the SK102 connector on the main board to the SK102 connector on the EIM,
as shown in the picture below:
5. Mount the EIM into the metal lid of the radio using the mounting screws (torx type), as shown in the picture
below:
Reassembling the Radio:
If programming the scrambler using the KL-3, proceed to the programming section. Reference the Tait Service
Manual for instructions on assembly of the radio.
8

PRODUCT PROGRAMMING
Midian’s TVS-2-TAIT and VPU-15-TAIT are programmed via Midian’s KL-3 programming cable or using Tait’s
TOPA-EA-007G. Please reference the KL-3 manual for setup instructions of the KL-3 software and hardware.
From the product selection screen on the KL-3 software, select the appropriate product from the list and click OK.
Set the parameters of the scrambler software to fit the application. If any clarifications on a feature are required,
move the mouse cursor over the feature name until the question mark appears and right click, a definition of the
feature will be shown.
After entering the parameters, save the file by going to File - Save As. Enter the file name in the File Name block
and click Save. Saving the file will allow for quick and easy reprogramming of units.
Tait Orca Portable Programming:
KL-3 Programming: After plugging the board into the radio, but with the radio still open, connect the black lead of
the KL-3 to a common ground and the green clip lead to the Program In hole (P11). Turn power on to the radio
and click “Program Unit” in the KL-3 software.
KL-3 Reading: It will be necessary to connect the yellow clip lead to the Program Out pad (link 5 – right pad), in
addition to having the green clip lead connected to the Program In hole (P11). Follow the same procedure to read
the unit as for programming, but select “Read Unit” in the menu bar. It is necessary to cycle power after
programming or reading. Note: When the scrambler is read, the security codes will be read out as zeroes. If
another scrambler is then cloned with this information, the scramblers will be incompatible because they have
different security codes.
TOPA-EA-007G Programming: This enables the scrambler to be programmed and read through the radio’s
accessory connector. Plug the TOPA-EA-007G cable into the KL-3’s RJ-11 connector. Connect the TOPA-EA-
007G to the accessory connector of the radio. Turn power on to the radio and click “Program Unit” in the KL-3
software. Note: The read function is not available when using the TOPA-EA-007G, as well as programming
tones.
Tait TM-8000 Series Mobile Programming:
KL-3 Programming: After plugging the board into the radio, but with the radio still open, connect the black lead of
the KL-3 to a common ground and the green clip lead to the Program In hole (P11). Turn power on to the radio
and click “Program Unit” in the KL-3 software.
KL-3 Reading: It will be necessary to connect the yellow clip lead to the Program Out pad (link 5 – right pad), in
addition to having the green clip lead connected to the Program In hole (P11). Follow the same procedure to read
the unit as for programming, but select “Read Unit” in the menu bar. It is necessary to cycle power after
programming or reading. Note: When the scrambler is read, the security codes will be read out as zeroes. If
another scrambler is then cloned with this information, the scramblers will be incompatible because they have
different security codes.
219-03026-0X Programming: The scrambler may be programmed through the radio using the TM-8000
Encryption Direct Programming Cable (219-03026-0X) available from Tait. Plug the cable into the DB-9 connector
on the EIM. Turn power on to the radio and click “Program Unit” or “Read Unit” in the KL-3 software.
9

OPERATION
Tait Orca Portables:
Display Radios:
Mode Select: Press the Function Key (1, 2, or 3) that was assigned to this function (short or long press). When
the scrambler is on “SC” will be indicated on the screen as well as the Δsymbol.
Code Select: Press the Function Key (1, 2, or 3) that was assigned to this function (short or long press). Then
enter 1, 2, 3, or 4 on the keypad for the desired code followed by pressing the green Menu/Enter button. The
display will show “SC01” for instance when the scramble is on with code 1 selected. If the scrambler is off it
would show “01”.
Non-Display Radios:
Mode Select: Press the Function Key (1 or 2) that was assigned to this function (short or long press). The LED
indicates Encryption On/Off status.
Code Select: Code select is not available in this radio.
Tait TM-8000 Mobiles:
Mode Select: Press and release the key that was assigned to this function in the radio programming (F1, F2, F3
or F4). F1 is only available as a latched condition. F2, F3 and F4 can be momentary or latched.
Code Select: Pressing and holding the mode select key will step the scrambler through the multiple keys if
programmed. A number of beeps will be heard that correspond to the code (i.e. 2 beeps for code 2). Code select
is only available when using F2, F3, or F4 as momentary.
TECHNICAL NOTES
Radio Compatibility: Midian has taken the utmost care to ensure the option board integrates into the radio with
minimal impact to the features of the radio. However, some features may not be available in the radio when an
option board is used. If a feature is not available, please contact Midian to see if the feature can be added.
Known Issues:
Tones: Tones such as the Go-Ahead Beep, programming tones, etc. are not heard on this radio.
Multi-Code: If using multiple codes in the TVS-2-TAIT or VPU-15-TAIT and other Midian TVS-2 or VPU-15 Series
scramblers are being used in other types of radios, it should be noted that in the TVS-2-TAIT and VPU-15-TAIT
the binary is reversed. This means that code 4 in the TVS-2-TAIT or VPU-15-TAIT would equate to code 1 in a
regular TVS-2 or VPU-15 scrambler.
10

11
MIDIAN CONTACT INFORMATION
Midian’s sales and technical support departments are available by phone, fax and e-mail from 8 am to 5 pm
(Arizona Standard Time) Monday through Friday (except holidays).
Midian Electronics Inc.
2302 East 22nd Street
Tucson, Arizona 85713 USA
Orders:1-800-MIDIANS
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.midians.com
